SMART KAPP IQ Manuel utilisateur

smarttech.com/docfeedback/171037

Quick reference guide

This quick reference guide explains how to use your SMARTBoard® 6000 series interactive flat

panel and SMARTkapp iQ features.

Turning the board on

1. Turn on the room computer.

2. Flick the power switch beside the AC power inlet to the ON (I) position.

3. Press the Standby button on the front control panel.

Front control panel

The front control panel contains the Standby, Input

Select, Mute and volume control buttons.

Basic gestures

The SMARTkapp iQ board supports a variety of gestures within apps, including panning, scaling,

rotating and zooming in and out.

QUICK REFERENCE GUIDE

SMART KAPP IQ BOARD

Zoom in Pan

Erase (with hand)

Zoom out Erase (with pen)

Cleaning

To clean the screen

1. Turn off any connected computers.

2. Press the Standby button on the front control panel twice.

3. Turn off the interactiveflatpanel by flicking the power switch beside the AC power inlet.

4. Wipe the screen with a lint-free, non-abrasive cloth.

Cleaning tips

lIf dry-erase markers are used on the screen, remove the ink as soon as possible with a lint-

free, non-abrasive cloth.

lDo not use cleaning solution or glass cleaner on the interactiveflatpanel screen, because

they can deteriorate or discolor the screen.

QUICK REFERENCE GUIDE

SMART KAPP IQ BOARD

Using SMARTInk

If the computer is connected to a SMARTinteractive product, SMARTInk starts automatically when

you start your computer.

Pick up a pen and the dynamic toolbar appears (minimized) on the

display.

If the dynamic toolbar doesn’t appear, start SMARTInk manually using

one of the following processes:

lWindows 7: Select Start > All Programs > SMARTTechnologies >

SMART Ink

lWindows 8: Go to the Apps screen and select SMARTTechnologies > SMARTInk

lWindows 10: Select Start > All apps, and select SMARTTechnologies SMARTInk

Using the dynamic toolbar in minimized mode

Interaction Action Interaction Behavior

Press to switch between

minimized and full mode

Pan

Drag to edge of display to dock

the dynamic toolbar

Erase (with pen)

If there are two users at the interactive flat panel, two dynamic toolbars appear and can be used

independently.

QUICK REFERENCE GUIDE

SMART KAPP IQ BOARD

Using the dynamic toolbar in full mode

SMARTTouch Inking Tool

If the computer is connected to a SMARTinteractive product that supports touch recognition, you

can use the SMARTTouch Inking Tool to write or draw with your finger or an accessibility aid, such

as a tennis ball. Follow these steps to switch from the dynamic toolbar to the SMARTTouch Inking

Tool:

1. Press the SMARTBoard icon in the notification area (Windows operating system).

Press the Mac menu bar (Mac OSXoperating system software).

2. Select Show SMARTTouch Inking Tool.

Switching modes

To present information, you can use board in computer mode and pick up the pen and start writing

without connecting your mobile device. If you want to save or share your notes, switch to

SMARTkapp iQ mode and connect your mobile device.

You can switch between your the computer and SMARTkapp iQ mode by pressing the Input

Select button on the front control panel and selecting HDMI (computer) or OPS/HDMI2

(SMARTkapp iQ).

Using SMARTkapp iQ

SMARTkapp iQ is a whiteboard and a suite of apps that runs from an embedded appliance.

Designed specifically to complement individual, small group and whole-room collaboration,

SMARTkapp iQ fully integrates with mobile devices, including tablets, smartphones, laptops and

Chromebooks.

QUICK REFERENCE GUIDE

SMART KAPP IQ BOARD

Using the launcher

The launcher contains all your apps and settings.

To open the launcher

Press the Home button on the screen.

The launcher appears.

To close the launcher

Select an app, press the Home button or tap anywhere on the screen.

The launcher closes.

Using the Whiteboard

You can draw on the Whiteboard with the pen and use basic gestures to manipulate

content. SMART Ink is available only while using the Input app and when SMARTProduct

Drivers is installed on the connected computer.

To use the Whiteboard with your mobile device

Task Solution

Before you connect

to a session

Ensure you’ve downloaded the SMARTkapp app from the App Store or

Google Play™

Connect and start a

session

1. Start the SMARTkapp app on your mobile device.

2. Hold the mobile device’s rear facing camera to the board’s QR code

until the QRcode appears in the center of the app.

TIPS

oConnect your mobile device to the board as soon as you

enter the classroom, as only one mobile device can be

connected to the board at a time.

oTo disconnect a student’s device from the board, press

Disconnect on the board.

Save a snapshot of a

session

Connect to the board and press Capture on the board or in the

SMARTkapp app.

View a snapshot To view a saved snapshot on your mobile device, tap Sessions and tap

the thumbnail to view it.

QUICK REFERENCE GUIDE

SMART KAPP IQ BOARD

Task Solution

Sharing a snapshot 1. View a snapshot on your mobile device.

iOS device: Tap Export and then select Save to Camera Roll or

Share as PDF.

Android device: Tap Menu and then select Share as Image or

Share as PDF.

Invite others to a

session (up to 250

people)

1. Connect your mobile device to the board.

2. From the SMARTkapp app, tap Invite and then select Send Link.

3. Select the app you want to use to send the invitation.

When others connect, remote participants can use their own device or

SMARTkapp iQ board to add content to the session.

To erase all notes on the Whiteboard

1. Press the Erase All icon.

2. Press Yes, Save it to save the Whiteboard session to the Library and erase the Whiteboard.

Press No, discard it to erase the Whiteboard. The session isn’t saved to the Library.

Press Cancel to return to the Whiteboard. Your notes are not erased.

Using the Whiteboard Library

The Whiteboard Library stores Whiteboard sessions on the AM30 appliance. You can open the

Library and continue a saved session on the board.

Using Workspaces

Workspaces app allows you to access SMARTamp collaborative learning software on

your SMARTkapp iQ board. SMARTamp is an easy-to-use cloud-based app that

enables teachers and students to collaborate in real time. SMARTamp integrates with

Google Drive and Google Apps for Education, which simplifies deployment and account

management for your school.

Using the Browser

You can use a web browser on the SMARTkapp iQ board.

QUICK REFERENCE GUIDE

SMART KAPP IQ BOARD

Using Input

You can display content from your computer on the board when you connect a

computer to the AM30 appliance. To take full advantage of the board’s touch and ink

features, download and install SMARTsoftware:

smarttech.com/en/Home+Page/Support/Browse+Support/Download+Software.

To display content on the board

NOTE

Make sure the OPS/HDMI input source is selected.

1. Connect a computer to the AM30 appliance’s HDMI in and USB receptacles.

2. Open the launcher.

The launcher appears.

3. Press Input .

The board detects the connection.

4. The computer’s desktop appears on the screen.

Using Screen Share

You can share content wirelessly on the SMARTkapp iQ board from your computer or

mobile device. Make sure the board and your mobile device or computer are on the

same network.

IMPORTANT

For more information about screen sharing, see the SMARTkapp iQ user’s guide

(smarttech.com/en/kb/170812) or visit the support page

support.smarttech.com/en/hardware/kapp.

To share content using the Chrome browser

1. On the board, open the launcher.

The launcher appears.

2. Press Screen Share .

3. On your computer, open the Chrome browser.

4. Open the tab you want to share on the board.

QUICK REFERENCE GUIDE

SMART KAPP IQ BOARD

5. In the top right corner of your browser, click the Cast icon .

6. Select the board’s name.

When you’re sharing content, the Cast icon turns blue.

NOTE

For troubleshooting tips for the Chrome browser, see

support.smarttech.com/docs/hardware/kapp/kapp-iq/en/troubleshooting/screenshare-

troubleshooting/more-screensharing-troubleshooting_Chrome.cshtml.

To share content from a Windows computer

You can use the Chrome browser to share content from your Windows computer. See To share

content using the Chrome browser on the previous page.

You can purchase AirParrot, an application that allows you to share your display, a single

application or a media file. See airsquirrels.com/airparrot/features/win.

NOTE

For troubleshooting tips for Screen Share on a Windows computer, see

support.smarttech.com/docs/hardware/kapp/kapp-iq/en/troubleshooting/screenshare-

troubleshooting/more-screensharing-troubleshooting_Windows.cshtml.

To share content from an Apple device

NOTE

For troubleshooting tips for an Apple product, see

support.smarttech.com/docs/hardware/kapp/kapp-iq/en/troubleshooting/screenshare-

troubleshooting/more-screensharing-troubleshooting_Apple.cshtml.

1. On the SMARTkapp iQ board, open the launcher.

The launcher appears.

2. Press Screen Share .

3. On your Mac computer, click the Airplay icon in the menu bar.

4. Select the board’s name.

The Airplay icon turns blue when your Mac computer is sharing content with AirPlay.

QUICK REFERENCE GUIDE

SMART KAPP IQ BOARD

To share content from an Android mobile device

1. Download the Google Cast app from Google Play.

2. On the board, open the launcher.

The launcher appears.

3. Press Screen Share .

4. On your Android mobile device, open the Google Cast app.

5. In the top left corner, press the navigation drawer .

6. Press Cast Screen.

7. Select the board’s name.

If you don’t see the board you want, press MORESETTINGS to show more boards.

NOTE

For troubleshooting tips for an Android mobile device, see

support.smarttech.com/docs/hardware/kapp/kapp-iq/en/troubleshooting/screenshare-

troubleshooting/more-screensharing-troubleshooting_Android.cshtml.

To stop sharing content to the board

TIP

You can disconnect your mobile device or computer to stop sharing content to the board.

1. Tap the board.

The overlay appears.

2. In the top right corner of the screen, press .

3. The message “Want to disconnect?” appears. Press Yes.

QUICK REFERENCE GUIDE

SMART KAPP IQ BOARD

Connecting computers to the SMARTkapp iQ

Some models of the AM30 appliance include computer connectors. To

the board’s touch features and use a pen to draw and write, follow

these steps:

By connecting a computer to the AM30 appliance instead of the board,

you can quickly switch between the computer and other SMARTkapp

iQ features.

NOTE

If the computer you’re connecting has SMARTInk and SMART Product Drivers installed, you can

write and draw on the board.

1. Connect a computer to the AM30 appliance using USB and HDMI cables.

2. Download and install SMARTProduct Drivers and SMARTInk on your computer. See

smarttech.com/us/Support/Browse+Support/Download+Software.

3. Use the Input app.

NOTE

When you connect a computer to the AM30 appliance, make sure the input source is OPS/HDMI.

Resolving touch and video issues

If you’re having touch or video issues, ensure the USB and HDMI cables connecting the room

computer to the interactive flat panel are secure. The USB cable controls touch, and the HDMI

cable controls the video.

Resources

Resource URL

Support page support.smarttech.com/en/hardware/kapp

User’s guides and online help lSMARTkapp iQ user’s guide (smarttech.com/en/kb/170812)

lSMARTInk 4 (smarttech.com/en/kb/171027)

Autres manuels pour KAPP IQ

Table des matières

Autres manuels SMART Tableau blanc interactif

SMART

SMART Inforce 67X1 Manuel utilisateur

SMART

SMART Smart Board M600 series Manuel utilisateur

SMART

SMART SBID8055i-G5-SMP Manuel de service

SMART

SMART 600i Manuel utilisateur

SMART

SMART SMART Board Manuel utilisateur

SMART

SMART Podium ID350 Manuel utilisateur

SMART

SMART Board MX Manuel utilisateur

SMART

SMART SC12A Guide de l'utilisateur

SMART

SMART Board 6000 Series Manuel utilisateur

SMART

SMART Sympodium ID250 TM Manuel utilisateur

SMART

SMART Podium ID422w Manuel utilisateur

SMART

SMART 885ix Manuel utilisateur

SMART

SMART SB880i5 Manuel utilisateur

SMART

SMART Board 7000 Manuel utilisateur

SMART

SMART UF55 Manuel d'instructions

SMART

SMART 2000i-DVS Manuel utilisateur

SMART

SMART Board E70 Manuel d'utilisation

SMART

SMART KAPP42 Manuel utilisateur

SMART

SMART KAPP iQ PRO 55 Manuel de service

SMART

SMART SmartBoard 600 Series Manuel utilisateur

SMART

SMART Podium 500 Series Manuel utilisateur

SMART

SMART SmartBoard 600i2 Manuel utilisateur

SMART

SMART RTM-ATCA-F125 Guide de démarrage rapide

SMART

SMART Table 230i Manuel d'installation

Manuels Tableau blanc interactif populaires d'autres marques

HitachiSoft

HitachiSoft StarBoard FX-TRIO-88W Manuel utilisateur

Buhl

Buhl LyteBoard Manuel utilisateur

SMART Board

SMART Board 680 Manuel utilisateur

Legamaster

Legamaster e-SCREEN ETX Manuel utilisateur

SMART Board

SMART Board SBM685ix2 Manuel utilisateur

Seneca

Seneca eno Manuel utilisateur

BenQ

BenQ RP840G Manuel utilisateur

Olivetti

Olivetti OLIBOARD Manuel utilisateur

Turning Technologies

Turning Technologies MOBIVIEW Manuel utilisateur

Panasonic

Panasonic UB-5335 Manuel utilisateur

Dukane

Dukane ITP84 Manuel utilisateur

Bretford

Bretford EDUIMS Guide de configuration

Panasonic

Panasonic Panaboard UB-5315 Manuel utilisateur

Plus

Plus M-11S Manuel utilisateur

TRIUMPH BOARD

TRIUMPH BOARD ULTRA SLIM Manuel utilisateur

Returnstar Interactive Tech

Returnstar Interactive Tech IQBoard DVT V7.0 Manuel utilisateur

AVer

AVer CP series Manuel utilisateur

Genee

Genee 56" Manuel utilisateur
