SMART 8055i Manuel utilisateur

SMARTBoard® 8055i and

8055i-SMP

Interactive flat panel

Installation guide

Product registration

If you register your SMART product, we’ll notify you of new features and software upgrades.

Keep the following information available in case you need to contact SMARTSupport.

Serial number:

Date of purchase:

1013787 Rev 03

FCC warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instructions, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the

interference at his own expense.

Trademark notice

SMARTBoard, SMARTNotebook, SMARTMeetingPro, SMARTGoWire, smarttech, the SMART logo and all SMART taglines are trademarks or registered

trademarks of SMARTTechnologiesULC in the U.S. and/or other countries. All third-party product and company names may be trademarks of their respective

owners.

translated into any language in any form by any means without the prior written consent of SMARTTechnologiesULC. Information in this manual is subject to

change without notice and does not represent a commitment on the part of SMART.

One or more of the following patents: US6320597; US6326954; US6563491; US6741267; US6803906; US6829372; US6947032; US6954197; US6972401;

US7151533; US7236162; US7411575; US7619617; US7643006; US7692625; US7755613; US7757001; US7880720; USD612396; USD616462; USD617332; and

USD636784. Other patents pending.

08/2012

Contents
Chapter 1: Installing your interactive flat panel 1
What’s included 2
Components of your interactive flat panel 3
Wall-mounting your interactive flat panel 4
Chapter 2: Connecting computers and peripheral devices 7
Installing the speakers 8
Connecting a room control system 11
Connecting computers to your interactive flat panel 12
Connecting peripheral devices to your interactive flat panel 17
Chapter 3: Installing SMART software 19
Installing SMARTMeetingPro software 20
Using a SMARTGoWire cable 20
Installing SMARTNotebook software 21
Updating SMART Product Drivers 22
Appendix A: Hardware environmental compliance 23
Waste Electrical and Electronic Equipment regulations (WEEE directive) 23
Restriction of Certain Hazardous Substances (RoHS directive) 23
Batteries 23
Packaging 23
iii|1013787 Rev 03

Chapter 1: Installing your interactive flat

panel

What’s included 2

Installation hardware 2

Accessories 2

Documentation 2

Components of your interactive flat panel 3

Front view 3

Back view 3

Side view 4

Wall-mounting your interactive flat panel 4

Important mounting considerations for trained installers 5

Choosing a mounting location 6

Choosing a mounting height 6

You need a team of professional installers to install your SMARTBoard 8055i interactive flat

panel.

This chapter provides additional considerations and details for installing your interactive flat

panel.

I M P O R T A N T

Because the receptacles might not be accessible after wall-installation, consider connecting

cables for speakers, computers and peripheral devices while the interactive flat panel is still in

its packaging or is suspended from a lifting device. For more information, see Connecting

computers and peripheral devices on page 7.

Chapter 1

1|1013787 Rev 03

What’s included

The following items are included with your interactive flat panel.

Installation hardware

lFive large clamps (for cable management)

lTen small clamps (for cable management)

lPower cable

lUSB cable

lVGA cable

Accessories

lTwo speakers with mounting screws

lInfrared remote control with two batteries

lTwo pens with four replacement pen nibs

lEraser

lSMARTGoWire™ auto-launch cable (SMARTBoard 8055i-SMP and 8055ie-SMP

interactive flat panels only)

lCAT 5 USB extender (SMARTBoard 8055i-SMP and 8055ie-SMP interactive flat panels

only)

lSMARTNotebook™ collaborative learning software DVD (SMARTBoard 8055i interactive

flat panels only)

Documentation

lInstallation guide

lImportant information document

lWarranty card

lRegistration card

lSMARTGoWire cable installation guide (SMARTBoard 8055i-SMP and 8055ie-SMP

interactive flat panels only)

lCAT 5 USB extender installation guide (SMARTBoard 8055i-SMP and 8055ie-SMP

interactive flat panels only)

lSMARTBoard 8055i interactive flat panel cabling guide (SMARTBoard 8055i-SMP and

8055ie-SMP interactive flat panels only)

C H A P T E R 1

Installing your interactive flat panel

2|1013787 Rev 03

Components of your interactive flat panel

The following images identify the components of your interactive flat panel.

Front view

Back view

C H A P T E R 1

Installing your interactive flat panel

3|1013787 Rev 03

Side view

N O T E S

lThe computer connected to VGA1 and USB1 accesses the USBdrive that's connected

to the USBA receptacle.

lTo disable the USBA receptacle, see SMARTBoard 8055i interactive flat panel user’s

guide (smarttech.com/kb/170177).

Wall-mounting your interactive flat panel

Use a team of trained, professional installers to install your interactive flat panel.

WARNING

lImproper installation can result in personal injury or product damage.

lYour interactive flat panel weighs 98 lb. (44.5 kg). Refer to local building codes to ensure

your installation area can support this weight.

C A U T I ON

Do not allow the weight of the interactive flat panel to rest on the color select module because it

is not designed to support product weight. Attach other components while the interactive flat

panel is either still in its packaging or suspended from a lifting device to prevent the weight of

the interactive flat panel from damaging the color select module.

I M P O R T A N T

lSave all product packaging so that it is available if you need to transport your interactive

flat panel. If your original packaging is not available, you can purchase new product

C H A P T E R 1

Installing your interactive flat panel

4|1013787 Rev 03

packaging from your authorized SMART reseller (smarttech.com/where).

lAttach the speakers and connect the speaker wires to the interactive flat panel before

you wall-mount it. For more information, see Installing the speakers on page 8.

Important mounting considerations for trained installers

Consider the following when mounting the interactive flat panel on a wall:

ll Plan your workflow to include cabling because some cable connection points might not be

accessible after installation.

lCarry and lift the interactive flat panel by gripping the handles and sides.

lTo mount the interactive flat panel on a wall, you require a standard VESA 600 mm × 400

mm compatible wall mount bracket (not included). The wall mount bracket must have

minimum depth of 14 mm to ensure sufficient space for the speakers.

lUse M8 screws to fasten the wall bracket. The screws must be 14–15 mm long plus the

thickness of the bracket and the washer.

lThe recommended fasten force is 99.57–121.70 in-lb. (11.25–13.75 N·m).

lRefer to the instructions included with the mounting equipment for more detailed

information.

C H A P T E R 1

Installing your interactive flat panel

5|1013787 Rev 03

Choosing a mounting location

Consider the following when you select a location for the interactive flat panel:

lThe wall must be strong enough to support the interactive flat panel and the mounting

equipment. The interactive flat panel weighs 98 lb. (44.5 kg).

lDo not install the interactive flat panel in a location where a door or gate could hit it.

lDo not install the interactive flat panel in an area where it will be subjected to strong

vibrations or dust.

lDo not install the interactive flat panel near where the main power supply enters the

building.

lEnsure adequate ventilation or provide air conditioning around the interactive flat panel so

that heat can flow away from the unit and the mounting equipment.

lIf you mount the interactive flat panel in a recessed area, leave at least 4" (10 cm) of space

between the interactive flat panel and the recess walls to enable ventilation and cooling.

Choosing a mounting height

Consider the general height of your user community when your choose the mounting height for

the interactive flat panel.

C H A P T E R 1

Installing your interactive flat panel

6|1013787 Rev 03
