SIIG Serial ATA PCI Manuel utilisateur

Serial ATA PCI

Quick Installation Guide

04-0265F

Introducing the Serial ATA PCI

The Serial ATA PCI is an ultra high-speed dual channel

Serial ATA controller board for use in Pentium-class

computers. It achieves burst data transfer rates up to

150MB/s (1.5Gb/s) and supports various brand of hard

disk drives with capacities greater that 137GB.

FeaturesandBenefits

•Add up to two high-speed SATA hard drives

•New Serial ATA cable - easier to install & provides

better air circulation

•Compliant with Serial ATA 1.0 specification

•Compliant with PCI 2.3 specification

•Supports data transfer rate up to 1.5Gb/s

(150MB/s)

•Two independent bus master DMA channels with

256-byteFIFOsperchannelforhostreadsandwrites

•Breaksthe137GBbarrier!Works withvariousbrands

of large capacity Serial ATA hard disk drives

SystemRequirements

• Pentium®or equivalent PC with an available PCI

slot

• Windows®98SE / ME / NT4.0 / 2000 / XP (32-/64-

bit) / Server 2003 & 2008 (32-/64-bit) / Vista (32-/

64-bit)

PackageContents

•Serial ATA PCI adapter

•Driver CD

•Serial ATA cable

•Serial ATA power cable

•Quick installation guide

BoardLayout

Figure 1. Serial ATA PCI Board Layout

Hardware Installation

General instructions for installing the card are provided

below. Since the design of computer cases and

motherboards vary, refer to your computer’s reference

manual for further information, if needed.

Static Electricity Discharge may permanently damage

your system. Discharge any static electricity build up in

your body by touching your computer case for a few

seconds. Avoid any contact with internal parts and

handle cards only by their external edges.

CN1

CN2

Serial ATA

connector

1. Turn OFF the power to your computer and any

other connected peripheral devices.

2. Unplug the power cord from the back of the

computer.

3. Remove the computer cover.

4. Remove the slot bracket from an available PCI slot.

5. To install the card, carefully align the card bus

connector to the selected PCI slot on the

motherboard. Push the board down firmly, but

gently, until it is well seated.

6. Replace the slot bracket holding screw to secure the

card.

DeviceConnection

TheSerialATA PCI is a dual channel Serial ATA controller

that supports up to two Serial ATA hard disk drives. If

you plan to use the second Serial ATA channel, you will

need to purchase another Serial ATA cable.

1. Install hard disk drive(s) in chassis.

2. ConnecttheSerialATA hard disk drive tothesystem

power supply using the Serial ATA power cable.

3. Connect one end of the Serial ATA cable to the hard

disk drive.

Figure 2: Hard disk drive connecrions

4. Attach the other end of the Serial ATA cable to the

Serial ATA connector on the Serial ATA PCI.

Serial ATA cable

Serial ATA power

cable

Figure 3. Connecting the Serial ATA cable

5. Follow the same instructions when connecting a

second hard drive. Device connection is now

complete.

6. Replacethecomputercover andreconnectthe power

cord.

Driver Installation

This section provides information on how to install the

Serial ATA PCI drivers.

Windows98SE

For New Windows 98SE Installation

1. Install the board and follow Microsoft procedures

to install Windows 98SE accordingly.

2. Once Windows has been installed, right click My

Computer and click Properties. Select Device

Manager tab.

3. Double click PCI Mass Storage Controller listed

under Other Devices.

4. Select Driver tab, then click Update Driver button.

5. Insert the driver CD and click Next.

Serial ATA

cable

6. Select Search for a better driver..., then click Next.

7. Check Specify a location, uncheck the other boxes,

then click Next.

8. Click Next,then click Finish.

9. Remove the driver CD and restart Windows to

complete the installation.

For Existing Windows 98SE Installation

1. Install the board and boot up Windows.

2. At the Add New Hardware Wizard, click Next.

3. Select Search for the best driver for your device and

click Next.

4. Insert the driver CD, check Specify a location,

uncheck the other boxes, type D:\98SE, then click

Next. (Change D: to match the drive letter of your

CD-ROM)

5. Click Next,then Finish.

6. Remove the driver CD and restart Windows to

complete the installation.

WindowsME

For New Windows ME Installation

1. Install the board and follow Microsoft procedures

to install Windows ME accordingly.

2. Once Windows has been installed, right click My

Computer, then click Properties. Select Device

Manager tab.

3. Double click PCI Mass Storage Controller listed

under Other Devices.

4. Select Driver tab, then click Update Driver button.

5. Insert the driver CD, select Specify the location of

the driver (Advanced), then click Next.

6. Check Specify a location, uncheck the other box,

type D:\ME, click Next. (Change D: to match the

drive letter of your CD-ROM)

7. Click Next, then click Finish. Remove the driver CD

and restart Windows to complete the installation.

For Existing Windows ME Installation

1. Install the board and boot up Windows ME.

2. AttheAddNewHardwareWizard,insertthedriver

CD.

3. Select Specify thelocationof the driver(Advanced),

then click Next.

4. Check Specify a location, uncheck the other box,

type D:\ME, click Next. (Change D: to match the

drive letter of your CD-ROM)

5. Click Next, then click Finish.

6. Remove the driver CD and restart Windows to

complete the installation.

ToVerifyWindows98SE/MEInstallation

1. Right-click My Computer, then click Properties.

Select Device Manager tab.

2. Double click SCSI controllers, Silicon Image SiI...

Controller should be listed.

3. Double click Silicon Image SiI... Controller and

click Properties. A message This device is working

properly is displayed in the dialog box when the

driver is correctly installed.

WindowsNT4.0

For New Windows NT4.0 Installation

A new installation of Windows NT4.0 requires a floppy

disk for the driver installation. To make this floppy disk,

copy the contents of the NT4 folder, found on the driver

CD, onto a blank floppy disk then follow the directions

below.

1. Install the board and follow Microsoft procedures

to install Windows NT4.0 accordingly.

2. At the Windows NT Setup screen, press F6 to

specify and add the driver.

3. Press S, select Other, then press Enter.

4. Insert the driver diskette then press Enter.

5. Select Silicon Image... for Windows NT 4.0 and

2000 and press Enter.

6. Press Enter to continue, then follow the on-screen

instructions to complete Windows NT4.0

installation.

For Existing Windows NT4.0 Installation

1. Install the board and boot up Windows NT4.0.

2. Double click My Computer/Control Panel/SCSI

Adapters, then click the Drivers tab.

3. Click Add..., then click Have Disk....

4. Insert the driver CD, type D:\NT4, then click OK.

(Change D: to match the drive letter of your

CD-ROM)

5. Highlight Silicon Image in the left column, then

select Silicon Image SiI... SATALink Controller,

and click OK.

6. ClickOK,removethedriver CD and restart NT4.0 to

complete the installation.

ToVerifyWindowsNT4.0Installation

1. Double click My Computer/Control Panel/SCSI

Adapters.

2. Highlight Silicon Image... Controller from SCSI

Adapters listing and click Properties. A message

This device is working properly is displayed in the

dialog box when the driver is correctly installed.

Windows2000

For New Windows 2000 Installation

A new installation of Windows 2000 requires a floppy

disk for the driver installation. To make this floppy disk,

copy the contents of the Floppy folder, found on the

driver CD, onto a blank floppy disk then follow the

directions below.

1. Install the board and follow Microsoft procedures

to install Windows 2000 accordingly.

2. Restart your system when prompted during

Windows' installation.

3. At the Windows 2000 Setup screen, press F6 to

install the driver.

4. Insert the driver diskette. Press S, then press Enter.

5. Select Silicon Image SiI... Controller and press

Enter.

6. Press Enter to continue and follow on-screen

instructions to complete the installation.

For Existing Windows 2000 Installation

1. Install the board and boot up Windows 2000.

2. At the Found New Hardware Wizard, click Next.

3. Select Search for a suitable driver for my device

(recommended) and click Next.

4. InsertthedriverCD,checkCD-ROMdrives,uncheck

the other boxes, and click Next. Click Next again to

continue.

5. Click Finish, remove the driver CD and restart

Windows to complete the installation.

WindowsXP/Server2003(32-bit)

For New Windows XP/Server 2003 Installation

A new installation of Windows XP/Server 2003 requires

a floppy disk for the driver installation. To make this

floppy disk, copy the contents of the Floppy folder,

found on the driver CD, onto a blank floppy disk then

follow the directions below.

1. Install the board and follow Microsoft procedures

to install Windows accordingly.

2. Restart your system if prompted by Windows

installation.

3. At the Windows Setup screen, press F6 to install the

driver.

4. Insert the driver diskette. Press Sthen press Enter.

5. Select Silicon Image SiI... Controller and press

Enter.

6. Press Enter to continue and follow the on-screen

instructions to complete the installation.

For Existing Windows XP/Server 2003 Installation

1. Install the board and boot up Windows.

2. At the Found New Hardware Wizard:

XP (w/SP1 or earlier)/Server 2003: continue to step #3

XP (w/SP2 or later)/Server 2003 (w/ SP1 or later): select

No, not at this time, then click Next.

3. Insert the driver CD, select Install the software

automatically (Recommended),and click Next.

4. Click Finish and restart Windows to complete the

installation.

WindowsXP/Server2003(64-bit)

For New Windows XP/2003 Installation

A new installation of Windows XP 64-bit/Server 2003

64-bit requires a floppy disk for the driver installation.

To make this floppy disk, copy the contents of the 64bit

folder, found on the driver CD, onto a blank floppy disk

then follow the directions below.

1. Install the board and follow Microsoft procedures

to install Windows accordingly.

2. Restart your system when prompted by Windows

installation.

3. At the Windows Setup screen, press F6 to install the

driver.

4. Insert the floppy disk you made above. Press Sthen

press Enter.

5. Select Silicon Image SiI 3512... that matches your

system processor, then press Enter.

6. Press Enter to continue and follow the on-screen

instructions to complete the installation.

For Existing Windows XP/2003 Installation

1. Install the board and boot up Windows.

2. AttheFound New Hardware Wizard, select No, not

at this time, then click Next.

3. Insert the driver CD, select Install the software

automatically (Recommended),and click Next.

4. Click Finish and restart Windows to complete the

installation.

Autres manuels pour Serial ATA PCI

Table des matières

Autres manuels SIIG Matériel informatique

SIIG

SIIG ExpressCard/54 CF R/W Manuel utilisateur

SIIG

SIIG Silent Mini Notebook Cooler Manuel utilisateur

SIIG

SIIG AV-GM0AK3-S1 Manuel utilisateur

SIIG

SIIG DP PCI-to-PS/2 Manuel utilisateur

SIIG

SIIG SIIG 2-Port Serial 950-Value Manuel utilisateur

SIIG

SIIG JJ-E01111-S1 Manuel utilisateur

SIIG

SIIG USB 2.0 Bay Reader/Writer+Floppy Manuel utilisateur

SIIG

SIIG eSATA II ExpressCard Manuel utilisateur

SIIG

SIIG DP PCI-to-PS/2 Manuel utilisateur

SIIG

SIIG Single-Serial PC Card Manuel utilisateur

SIIG

SIIG CyberParallel Dual Manuel utilisateur

SIIG

SIIG FireWire Home DV Kit Manuel utilisateur

SIIG

SIIG CE-ED0011-S1 Manuel utilisateur

SIIG

SIIG FireWire 800 2-Port ExpressCard/34 Manuel utilisateur

SIIG

SIIG SC-SAE512-S1 Manuel utilisateur

SIIG

SIIG Hi-Speed ExpressCard CF R/W Manuel utilisateur

SIIG

SIIG Cyber PCI I/O Manuel utilisateur

SIIG

SIIG UltraATA 133 PCI Manuel utilisateur

SIIG

SIIG FireWire Dual-Port CardBus Manuel utilisateur

SIIG

SIIG NN-000032-S1 Manuel utilisateur

SIIG

SIIG I/O Expander 2S Manuel utilisateur

SIIG

SIIG JJ-EC2011-S1 Manuel utilisateur

SIIG

SIIG DP FireWire 800 3-Port PCIe Manuel utilisateur

SIIG

SIIG CyberSerial ExpressCard Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
