RIOTEC ICR6307ABM Manuel utilisateur

1

Programming Quick Guide

-iCR6307ABQ/iCR6307ABM

Connecting the Scanner

Be sure that PC is turned OFF, before Connect scanner cable to

the PC USB port on the PC as below described, Ensure that all

connections are ready, and turn on your PC.

1. Please switch ON and charge scanner for 4~5 hours at first time

before use. Scanner switch shown on Fig. 2.

2. After switch ON, the Orange LED will flash following with 3

beep-sounds. The RED LED will be OFF while it links to cradle

within 2.4GHz radio range.

3. If RED LED is continual ON, please re-plug USB cable, then, scan

the 3 barcodes on the bottom of cradle sequentially. (Shown on

Fig. 3 From 1 to 3).

4. Charging issue: Cradle works as charger when putting scanner on

it. Even if the scanner's battery is full, the cradle will continue to

supply power to the scanner. We suggest you to remove scanner

from cradle when scanner is charged fully

* Note: Please install PL-2303 driver for iCR6307ABM

LED Indicator Information

Oran

e LED ON Full char

Oran

e LED Flashin

Char

/ Low battery

Red LED ON Offline / out of service

Green LED ON Good read

Oran

e LED ON Good read (Batch mode)

Remark:

* When the battery power is too low, the Orange LED will flash and beep once.

Scanner should be charged immediately.

* If scanner shuts down it is recommended to charge it fully before turning it

back on.

* Under power-saving mode, there will not be LED indication when charging.

Reset Configuration to Defaults

(scan from A1 to A8 for iCR6307ABQ or B1 to B8 for iCR6307ABM)

iCR6307

A1 B1

A2 B2

A3 B3

A4 B4

A5 B5

A6 B6

A7 B7

A8 B8

* Note: Please install PL-2303 driver for iCR6307ABM

There are two operating modes on the scanner

1.Data Transmission mode

(

Default

)

It is a necessary to scan “clean memory data" when

switching between these two modes.

Within 2.4GHz radio rang

Beyond 2.4GHz radio range

Data

read

Transmit data to PC/terminal

directly

Save data into scanner’s memory,

scanner will transmit data to PC/

terminal automatically when back to

2.4GHz radio range.

Enter Data Storage mode

LED Green/ Orange LED flashes

followed by 3 beeps.

2.Data Storage mode (Batch Mode)

It is a necessary to scan

“

clean memory data" when switching

between these two modes.

Data

read

Save data directly to scanner’s memory, It will transmit the data to PC/

terminal after you scan the Transmit memory data code. To delete

data please scan the Clean memory data code.

Enter Data Transmission mod

LED

reen/Oran

e LED flashes followed b

3 bee

Always Clean memory data before switching to Data Transmission

Mode.

Otherwise Red/ Orange LED will flash with one long beep and will not

switch modes.

Under Data storage Mode

The data can be keep or delete by option after transmit

Keep the data

(Default)

Delete the data

Transmit memory data

Green/Orange LED Flashes followed by 3 beep

Clean memory data

Green/Oran

e LED flashes followed b

3 bee

The barcode data which is stored in the memory will be deleted.

2

Trigger Mode

Trigger always

(Trigger available at any time)

Trigger standard (Default)

(Trigger available, after data sent to the

device)

Transmission Speed

Transmission speed is dependent on your device. In order not to lose

data, please choose the correct speed. Middle-speed is the Default.

h-speed Ultra Slow-speed

Transmission

1 transmission

Middle-speed Ultra Slow-speed

Transmission

(Default)

ransmission

Slow-speed Ultra Slow-speed

Transmission 3 transmission

Wireless Auto-connection

Wireless Auto-connection ON:

When out of range, it will keep trying to

connect to device, scanner will not enter

power-saving mode.

Wireless Auto-connection OFF:

When you are out of BT signal range, scanner

will stop sending auto-connection signal to

device after 2 minutes. During this time, it will

not enter power-saving mode. Once you are

back within range, press trigger to connect to the

device. (Default)

Keyboard Country(For USB HID only)

Scan the appropriate country code as below to program the keyboard

layout for your country or language. As a general rule, the following

characters are supported, but need special care for countries other

than the United States: @ | $ # { } [ ] = / ‘ \ < > ~

USA

(Original setting)

Italian

Norway

France

Germany

ietnam

Sweden

Spain

Denmark

Portu

Switzerland Hun

ary

Power-saving Mode

Power-saving mode OFF

Power-savin

mode ON (Default):

Enter power-saving mode after 3-minute inactivity.

This function converses battery power. When you

press "SCAN/Power ON" button, it will wake up and

begin to scan.

Power-savin

mode ON:

Enter power-saving mode after 10-minute

inactivity. This function converses battery power.

When you press "SCAN/Power ON" button, it will

wake up and begin to scan.

* When charging, the scanner will not enter power-saving mode

automatically.

How to append a “prefix” or a “suffix” to the

barcode data

prefix suffix

1. Scan above configuration code for Prefix or Suffix

2. Enter the required values (right, numeric barcode) for Prefix or

Suffix using the hex values for the desired HEX values from “Prefix

& Suffix TABLE (blew page)”

3. Then, end by scanning Code X (below, right)

* The max. of special characters is 5.

* When you append 1~4 required values for Prefix or Suffix, it must

end with Code X.

* It doesn’t need Code X, if you append 5 values to barcode data.

How to delete Prefix or Suffix

1. Scan above configuration code for Prefix or Suffix

2. Enter the “0” “0” (above, right)

3. Then end by scanning Code X (below, right)

Numeric barcode for settings

3

Prefix & Suffix TABLE

HEX HID

(SPP) HEX HID

(SPP) HEX HEX HEX HEX

01 CTRL A

(SOH) 19 CTRL Y

(EM) 20 SPACE 38 8 50 P 68 h

02 CTRL B

(STX) 1A CTRL

Z(SUB) 21 ! 39 9 51 Q 69 i

03 CTRL C

(ETX) 1B ESC

(ESC) 22 " 3A : 52 R 6A j

04 CTRL D

(EOT) 1C CTRL \

(FS) 23 # 3B ; 53 S 6B k

05 CTRL E

(ENQ) 1D CTRL ]

(GS) 24 $ 3C < 54 T 6C l

06 CTRL F

(ACK) 1E CTRL ^

(RS) 25 % 3D = 55 U 6D m

07 CTRL G

(BEL) 1F CTRL _

(US) 26 & 3E > 56 V 6E n

08 Backspace

(BS) 27 ' 3F ? 57 W 6F o

09 Tab

(HT) 28 ( 40 @ 58 X 70 p

0A CTRL J

(LF) 29 ) 41 A 59 Y 71 q

0B CTRL K

(VT) 2A * 42 B 5A Z 72 r

0C CTRL L

(FF) 2B + 43 C 5B [ 73 s

0D Enter

(CR) 2C , 44 D 5C \ 74 t

0E CTRL N

(SO) 2D - 45 E 5D ] 75 u

0F CTRL O

(SI) 2E . 46 F 5E ^ 76 v

10 CTRL P

(DLE) 2F / 47 G 5F _ 77 w

11 CTRL Q

(DC1) 30 0 48 H 60 ` 78 x

12 CTRL R

(DC2) 31 1 49 I 61 a 79 y

13 CTRL S

(DC3) 32 2 4A J 62 b 7A z

14 CTRL T

(DC4) 33 3 4B K 63 c 7B {

15 CTRL U

(NAK) 34 4 4C L 64 d 7C |

16 CTRL

(SYN) 35 5 4D M 65 e 7D }

17 CTRL W

(ETB) 36 6 4E N 66 f 7E ~

18 CTRL X

(CAN) 37 7 4F O 67 g

Barcode Configuration Method:

(Flow chart for setup procedure :)

Start

Configuration

End

Configuration

1D Symbologies – 1

ENABLE

CODE 39 DISABLE

ENABLE

GS1-128

UCC/EAN-128

DISABLE

ENABLE

EAN-8 DISABLE

ENABLE

EAN-13 DISABLE

ENABLE

CODE 128 DISABLE

1D Symbologies – 2

ENABLE

CODE 93 DISABLE

ENABLE

CODE 11 DISABLE

ENABLE

ISSN DISABLE

ENABLE

ISBN DISABLE

ENABLE

UPC-E DISABLE

ENABLE

UPC-A

DISABLE

ENABLE

Interleaved

DISABLE

ENABLE

Matrix 25 DISABLE

ENABLE

Industrial 25 DISABLE

4

Barcode Configuration Method:

(Flow chart for setup procedure :)

Start

Configuration

End

Configuration

1D Symbologies – 3

ENABLE

GS1-Databar

(RSS) DISABLE

ENABLE

GS1-Databar

(RSS-Limited) DISABLE

ENABLE

GS1-Databar

(RSS-Expand) DISABLE

ENABLE MSI DISABLE

ENABLE CODABAR DISABLE

Quick guide is subject to change without notice. R_151116_01
