Rexing S3 Manuel utilisateur

User Manual

Dash Cam

The information in this manual is subject to change without notice.

www.rexingusa.com

We hope you love your new products as much as we do. If you need any

assistance, or have any suggestions to help us improve, please contact us.

Our support team will respond to you as soon as possible.

Always a surprise in Rexing.

•https://www.facebook.com/rexingusa/

•https://www.instagram.com/rexingdashcam/

•https://www.rexingusa.com/support/registration/

•https://www.rexingusa.com/support/product-support/

About Us

Thank you for choosing REXING!

Check us out here

Facebook Instagram Site Product Support

[email protected]

(877) 740-8004

What's in the box？

1. Rexing S3 3-Channel Dash Cam

2. Power Cable with GPS Logger (12ft)

3. Cable Management Kit

4. Adhesive Mount

5. User Manual

6. Safety Guide

1 2

MOK

User Manual

Dash Cam

Theinformation in this manual is subject to change without notice.

RexingAll Rights Reserved

www.rexingusa.com

Safety Guide

www.rexingusa.com

安全ガイド

Camera Overview

1. Power Port

2. Micro SD Card Slot

3. Reset Pin Hole

4. Menu Button, Mode

Switch Button

5. Record Button, Photo

Button, Up Button

6. Power Button, Screen

Button

45 6 78

7. Screen-view Switching, Audio

Button, Down Button

8. Confirm Button, Video Lock

Button, Wi-Fi Button

9. Rotating Front Camera (90°)

10. Rotating Rear/Cabin Cameras

(180° horizontal and 270° vertical)

11. Infrared Lights

M OK

POWER

Use a pin and press it for 5 seconds to reset the device

back to the manufactures' default settings

Button Function

•Press to turn on or turn off the screen

•Press and hold for 3 seconds to turn the device on or off

•Press to confirm a selection in settings

•Lock a Video: Press to manually lock / unlock

a video file while recording

•Press and hold for about 3 seconds to turn

on/off the Wi-Fi

•Press to navigate UP through the options in settings

•Press to start / stop video recording

•Press and hold for about 3 seconds to take a photo

•Press to navigate DOWN through the options in settings

•Press this button to switch among three camera's views

•Press and hold for 3 seconds to turn on/off the audio

Please press the Record Button to stop recording first.

•Press once/twice to switch between Video Settings and

General Settings; press and hold for 3 seconds to exit

settings

•Press and hold for 3 seconds to switch between video

recording and playback modes

•In the playback mode, press to switch among the three

cameras' footages

Screen Icons

00:25 1080P*3 11/10/2021 15:25:04

13 4 562 7 8 9 10 11

1. Recording Mode

2. Recording Indicator

3. Recording Time

4. Resolution

5. Date

6. Time

7. Wi-Fi Signal

8. GPS Signal

9. Microphone

10. SD Card

11. Power Indicator

Installation

Step 1

Installing Adhesive Mount

Place the 3M adhesive on the mount plate and properly orient the mount piece to

the roof and hood line of the vehicle.

Important! Ensure the T-interlock on the mount is oriented in the correct direction.

Firmly press the mount onto the windshield. Wait at least 20 minutes before

mounting the camera.

Orient the mount as shown

MOK

Step 2

Mount the Rear Camera

Mount the rear camera as shown below. Use the included rear camera cable to

connect the rear camera to the front camera.

Plug the rear

camera into the

rear camera port

Rear camera

wiring

instructions

MOK

Step 3

Insert the Memory Card

The Rexing S3 accepts Class 10/ UHS-1 or higher Micro SD memory cards up to

256GB. You will need to insert a memory card before recording. Before inserting or

removing a memory card, ensure you've powered down the device.

Gently push the memory card in until you hear a click, and allow the spring release

to push the card out.

Step 4

Power on the Camera and Format the Memory Card

Place the camera on the mount and carefully route the power cable around the

windshield and tuck it in under the trim.

Power the camera by connecting the charger to the car cigarette lighter and the

camera.

To ensure the S3 records to your memory card properly and without error, we

strongly recommend you to format the card within the camera when you're using

the dash cam for the first time.

Note:

Always remember backup important data stored on the memory card before

formatting.

The camera will shut down after 3 seconds when it's disconnect from the power

source and it should begin recording automatically the next time it is powered on.

M OK

Plug the mini

USB connector

to the dash cam

Route the

power cable

Plug the charger

into the power

outlet or a

cigarette lighter

MOK
