Rexing DT2 Manuel utilisateur
User Manual
DT2
The information in this manual is subject to change without notice.
Rexing All Rights Reserved
www.rexingusa.com
& Choose Your
FREE Gift!
Scan The QR To Activate &
Select Your Free Gift
Activate within 30 days of purchase to
claim your free gift and extend your
limited 12-month warranty to 18 months.
Activate Your
18-Month
Warranty
https://www.rexingusa.com/productreg/
1
We hope you love your new products as much as we do. If you need
assistance, or have any suggestions to improve it, please contact us.
Our support team will respond to you as soon as possible.
Always a surprise with Rexing
• https://www.facebook.com/rexingusa/
• https://www.instagram.com/rexingdashcam/
• https://www.rexingusa.com/support/registration/
Overview
Thank you for choosing REXING!
Check us out here.
Facebook Instagram Site Product Support
(877) 740-8004
User Manual
DT2
Theinformation in this manual is subject to change without notice.
RexingAll Rights Reserved
www.rexingusa.com
Package Contents
1. Rexing DT2 Dash Cam
2. Rear camera with rear camera cable
3. Type-C Data Cable (for transferring files only)
4. 3M Adhesive
5. Cable Clips
6. Car Charger
7. Cable Management Tool
8. Users Manual
9. 32GB SD Card
10. Warning Sticker
11. Electrostatic Sticker
65
1 2 3
4 9 10
7 8 11
2
Double Coated Tissue
Double Coated Tissue
DoubleCoatedTissue
DoubleCoatedTissue
DoubleCoatedTissue
DoubleCoatedTissue
Paste the electrostatic film
on the front windshield
Paste the bracket into this
circular area
Camera Overview
3
M
OK
3“ LCD Screen
Front Camera
Reset
Button
Rear
Camera
Port
USB-C
Charging Port
OK/RECORD
/ POWER
Button
MENU/
MODE/LOCK
Button
DOWN/
MUTE
Button
UP/
TOGGLE
VIEW
Button
Micro SD
Card Slot
1. Recording Mode
2. Recording (On)
3. WDR Mode (On)
4. G-Sensor Sensitivity Level
5. Recording Time (Current Clip)
6. Video Resolution
7. Parking Mode (On)***
8. Memory Card（Inserted)
9. Battery Charging
10. Plate Number
11. Time
12. Current Date Time
13. MIC (ON)
14. Exposure Value
15. Loop Recording Time Interval
*** Please connect a Smart Hardwire Kit or an Intelligent Hardwire Kit to activate the
parking monitor feature.
4
AABCDEFG
01/31/2023 03:05:57
3
1080 FHD
00:00:06
1
15
14
6
7
8
9
2 3 4
13 12 11 10
5
Get Started
Step 1
Installing Adhesive Mount
Place the 3M adhesive on the mount plate and properly orient the mount
piece to the roof and hood line of the vehicle.
Step 2
Installing the Electrostatic Stickers
2.1 Prepare Your Windshield
Thoroughly cleanse your windshield with either water or alcohol. Follow
this by wiping it dry using a clean, dry cloth to ensure a spotless surface.
2.2 Position the Sticker
Next, carefully peel off the protective film from the electrostatic sticker.
Attach the sticker to the windshield, ideally behind the rear-view mirror.
This position is recommended to avoid obstructing your view while
you're on the road.
Elecrostatic
sticker
5
Be sure to handle each component with care and follow the
guidelines in their respective order. This is to ensure optimal
performance of the sticker, the mount, and the camera.
2.3 Secure the Mount and Camera
Now, remove the 3M tape from
the mount. Once done, you can
proceed to fix both the mount
and camera onto the previously
positioned electrostatic stickers.
Note:
Step 3
Mount the Rear Camera
Mount the rear camera as shown below. Use the included rear camera
cable to connect the rear camera to the front camera.
6
Rear
camera
wiring
instructions
Plug the rear
camera into
the rear
camera port
DoubleCoatedTissue
DoubleCoatedTissue
DoubleCoatedTissue
DoubleCoatedTissue
Step 4
Insert the Memory Card
The Rexing DT2 accepts Class 10/ UHS-1 or higher Micro SD memory cards
up to 128GB. You will need to insert a memory card before recording.
Before inserting or removing a memory card, ensure you've powered down
the device.
Gently push the memory card in until you hear a click, and allow the spring
release to push the card out.
7
Hold the OK
button for
about 3
seconds to
turn the
power off first
M
OK
8
Step 5
Power on the Camera and Format the Memory Card
Power the camera by connecting the charger to the car cigarette
lighter and the camera.
To ensure the DT2 records to your memory card properly and without error,
we strongly recommend you to format the card within the camera when
you're using the dash cam for the first time.
Note:
Always remember backup important data stored on the memory card
before formatting.
The camera will shut down after 3 seconds when it's disconnect from the
power source and it should begin recording automatically the next time it is
powered on.
Plug the
Type-C
Connector to
the dash cam
Route the
power
cable
Plug the
charger into
the power
outlet or a
cigarette
lighter
