NESA NRC-80DLM Instructions d'installation et d'utilisation

NRC-80DLM

USER MANUAL & INSTALLATION GUIDE

Universal Reversing Camera

with Dynamic Guidelines

CONTENTS

1.0 INTRODUCTION.............................................................................2

1.1 Component List .....................................................................2

1.2 Technical Specications: .......................................................3

2.0 WIRING DIAGRAM .........................................................................3

3.0 DYNAMIC REVERSING GUIDELINES...........................................4

4.0 TESTING.........................................................................................4

4.1 How to test ............................................................................4

5.0 TROUBLESHOOTING ....................................................................4

6.0 CARE AND MAINTENANCE ..........................................................4

7.0 WARRANTY TERMS & CONDITIONS ...........................................5

8.0 NOTES .......................................................................................... 10

1.0 INTRODUCTION

Thank you for purchasing Nesa’s NRC-80DLM camera. We are

certain that our product will give you trouble-free operation while

providing you with safety features that enhance your driving

experience.

DISCLAIMER

Our products are to assist and aid the driver, not to replace the

manual function of the person operating the vehicle.

Although the NRC-80DLM is a visual aid and will allow you to view

what is behind the vehicle, it does not remove the responsibility

of driving the vehicle from the driver. Legal responsibility and

safe driving practise remains with the driver at all times.You have

purchased this product with the understanding that its use is as

an aid only. We highly recommend that you have this product

professionally installed to ensure that it will provide the functions it

is set out to perform.

CAUTION

• Ensure you are using your rear camera within your countries’

road laws. Please make sure you are familiar with your local

road legislation before use.

1.1 COMPONENT LIST

• Universal reverse camera

• 6m extention cable

• 3M double sided tape

• Installation guide and user manual

IMPORTANT NOTICE

• Please read this manual carefully before using the product.

• Wire connection points should always be insulated.

• Wiring should always be installed away from heat sources and

electrical components.

• Please perform tests after nishing installation to ensure

camera is working correctly.

• This camera is intended for use as an aid when reversing

your vehicle. Drivers must always use extreme caution when

operating a vehicle.

• Specications are subject to change without notice.

WARNING

• Do not disassemble the camera or cut the camera cable

as this voids the warranty. Disassembling the camera will

compromise the waterproof seal.

1.2 TECHNICAL SPECIFICATIONS:

Signal System: NTSC

Horizontal Resolution: 800 TVL

Minimum Illumination: 0.1 – 0.5Lux

Diagonal Angle: 170°

Waterproof Rating: IP69K

Nominal Voltage: 12V/24V

Working Temperature: -30°C to 85°C

2.0 WIRING DIAGRAM

Front view option: NRC-80DLM functions as a rear view camera

as standard. For front view application, please cut the thin WHITE

wire near the camera lead and restart power to see the image

reversed.

RED to Reversing Light +

BLACK to Ground

Switching Wire

Monitor Video Input video extension cable

3.0 DYNAMIC REVERSING GUIDELINES

Inbuilt G sensor moves the guidelines in accordance with the

vehicles' movement, this helps the driver to avoid obstacles while

reverse parking.

Guideline option: NRC-80DLM has parking guide-lines as a

default. To remove guide-lines, cut the thin GREEN wire near the

camera lead and the guide-lines will now be removed.

4.0 TESTING

4.1 HOW TO TEST

1. Apply the parking brakes. (Safety Precaution)

2. Turn ignition on. (DO NOT TURN ON VEHICLE)

3. Shift into reverse gear.

4. Image should appear on the monitor.

5.0 TROUBLESHOOTING

6.0 CARE AND MAINTENANCE

Always keep camera clear from dirt and mud. Clean camera with a

soft moist cloth.

PROBLEM SOLUTION

“No Signal” appears while

reversing

1. Check video input

connections

2. Check camera power

connections

Video image is not sharp Check camera lens for debris

7.0 WARRANTY TERMS & CONDITIONS

Our goods come with guarantees that cannot be excluded under

the Australian Consumer Law. You are entitled to a replacement

or refund for a major failure and for compensation for any other

reasonably foreseeable loss or damage. You are also entitled

to have the goods repaired or replaced if the goods fail to be of

acceptable quality and the failure does not amount to a major

failure.

This warranty is provided in addition to your rights under the

Australian Consumer Law.

Neltronics warrants that this product is free from defects in material

and workmanship for a period of 12 months from the date of

purchase or for the period stated on the packaging. This warranty is

only valid where you have used the product in accordance with any

recommendations or instructions provided by Neltronics.

This warranty excludes defects resulting from alterations of the

product, accident, misuse, abuse or neglect.

In order to claim the warranty, you must return the product to the

retailer from which it was purchased or if that retailer is part of a

National network, a store within that chain, along with satisfactory

proof of purchase. The retailer will then return the goods to

Neltronics. Neltronics will repair, replace or refurbish the product at

its discretion. The retailer will contact you when the product is ready

for collection. All costs involved in claiming this warranty, including

the cost of the retailer sending the product to Neltronics, will be

borne by you.

For full warranty terms and conditions, vist:

https://www.neltronics.com.au/warranty-terms-and-conditions/

Neltronics Address: 4/50 Jersey St, Jolimont, Western Australia

Ph: +61 08 9383 7833 Email: [email protected]

INDEMNITY

YOU AGREE TO DEFEND, INDEMNIFY AND HOLD HARMLESS

NESA AND ITS SUBSIDIARIES AND AFFILIATES FROM AND

AGAINST ANY AND ALL CLAIMS, PROCEEDINGS, INJURIES,

LIABILITIES, LOSSES, COSTS AND EXPENSES (INCLUDING

REASONABLE LEGAL FEES), INCLUDING BUT NOT LIMITED

TO, CLAIMS ALLEGING NEGLIGENCE, INVASION OF

PRIVACY, COPYRIGHT INFRINGEMENT AND/OR TRADEMARK

INFRINGEMENT AGAINST NESA AND ITS SUBSIDIARIES

AND AFFILIATES OR THE NESA SERVICES, RELATING TO

OR ARISING OUT OF YOUR BREACH OF ANY PROVISION

OF THESE TERMS, YOUR MISUSE OF THE NESA OR NESA

SERVICES, OR YOUR UNAUTHORIZED MODIFICATION OR

ALTERATION OF PRODUCTS OR SOFTWARE.

WARRANTY AND WARRANTY DISCLAIMER

NESA HAS A LIMITED WARRANTY ON WHEREBY NESA

WARRANTS TO AND ONLY TO YOU THAT THE ON NESA

VEHICLE DASH CAMERAS, MIRROR DASH CAMERAS, FRONT,

REAR AND REVERSING CAMERAS AND MIRROR MONITOR

DEVICES WILL BE FREE FROM DEFECTS IN MATERIALS AND

WORKMANSHIP FOR ONE (1) YEAR FROM THE DATE OF YOUR

PURCHASE OF THE ON NESA VEHICLE DASH CAMERAS,

MIRROR DASH CAMERAS, FRONT, REAR AND REVERSING

CAMERAS AND MIRROR MONITOR DEVICES (UNLESS A

LONGER WARRANTY PERIOD IS REQUIRED BY LAW).

THE SPECIFICS OF THIS NESA LIMITED WARRANTY ARE AT

HTTPS://WWW.NELTRONICS.COM.AU/WARRANTY-TERMS-

AND-CONDITIONS/

TO THE EXTENT POSSIBLE UNDER GOVERNING LAW,

OTHER THAN THE ABOVE PRODUCT WARRANTY FOR THE

NESA VEHICLE DASH CAMERAS, MIRROR DASH CAMERAS,

FRONT, REAR AND REVERSING CAMERAS AND MIRROR

MONITOR DEVICES, YOU UNDERSTAND AND AGREE THAT

THE NESA SERVICES ARE PROVIDED ON AN "AS IS" AND "AS

AVAILABLE" BASIS. NESA MAKES NO WARRANTY THAT THE

NESA SERVICES WILL MEET YOUR REQUIREMENTS OR THAT

USE OF THE NESA SERVICES WILL BE UNINTERRUPTED,

TIMELY, SECURE OR ERROR-FREE NOR DOES NESA MAKE

ANY WARRANTY AS TO THE ACCURACY OR RELIABILITY

OF ANY INFORMATION OBTAINED THROUGH THE NESA

SERVICES (INCLUDING THIRD PARTY CONTENT), THAT ANY

DEFECTS IN THE NESA SERVICES WILL BE CORRECTED OR

THAT THE NESA PRODUCTS OR NESA SERVICES WILL BE

COMPATIBLE WITH ANY OTHER SPECIFIC HARDWARE OR

SERVICE. FURTHER, NESA DOES NOT WARRANT THAT THE

NESA SERVICES OR THE NESA SERVERS THAT PROVIDE

YOU WITH DATA AND CONTENT ARE FREE OF VIRUSES OR

OTHER HARMFUL COMPONENTS. NESA ALSO ASSUMES NO

RESPONSIBILITY FOR AND SHALL NOT BE LIABLE FOR ANY

DAMAGES CAUSED BY VIRUSES THAT MAY INFECT YOUR

NESA VEHICLE DASH CAMERAS, MIRROR DASH CAMERAS,

FRONT, REAR AND REVERSING CAMERAS AND MIRROR

MONITOR DEVICES, COMPUTER SOFTWARE, OR OTHER

HARDWARE.

YOU AGREE THAT NESA IS NOT AN INSURER AND THAT NESA

IS NOT PROVIDING ME WITH INSURANCE OF ANY TYPE. ANY

AMOUNTS THAT YOU PAY NESA FOR THE NESA SERVICE ARE

NOT INSURANCE PREMIUMS AND ARE NOT RELATED TO THE

VALUE OF YOUR VEHICLE OR PROPERTY, ANYONE ELSE’S

PROPERTY LOCATED IN YOUR VEHICLE OR PREMISES,

OR ANY RISK OF LOSS IN YOUR VEHICLE OR AT YOUR

PREMISES. IF YOU WANT INSURANCE TO PROTECT AGAINST

ANY RISK OF LOSS AT YOUR VEHICLE OR PREMISES, YOU

WILL PURCHASE IT. IN THE EVENT OF ANY LOSS, DAMAGE

OR INJURY, YOU WILL NOT LOOK TO NESA TO COMPENSATE

YOU OR ANYONE ELSE. YOU RELEASE AND WAIVE FOR

YOURSELF AND YOUR INSURER ALL SUBROGATION AND

OTHER RIGHTS TO RECOVER AGAINST NESA ARISING AS

A RESULT OF THE PAYMENT OF ANY CLAIM FOR LOSS,

DAMAGE OR INJURY.

NESA’S EQUIPMENT AND SERVICES DO NOT CAUSE AND

CANNOT ELIMINATE OCCURRENCES OF CERTAIN EVENTS,

INCLUDING, BUT NOT LIMITED TO, VEHICLE ACCIDENTS,

PROPERTY DAMAGE, LOST PROPERTY, THEFT OF VEHCLE

, THEFT OF PROPERTY. NESA MAKES NO GUARANTEE

OR WARRANTY, INCLUDING ANY IMPLIED WARRANTY

OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE, THAT THE NESA EQUIPMENT AND SERVICES

PROVIDED WILL DETECT OR AVERT SUCH INCIDENTS OR

THEIR CONSEQUENCES. NESA DOES NOT UNDERTAKE ANY

RISK THAT YOU OR YOUR VEHICLE OR PROPERTY, OR THE

PERSON OR PROPERTY OF OTHERS, MAY BE SUBJECT

TO INJURY OR LOSS IF SUCH AN EVENT OCCURS. THE

ALLOCATION OF SUCH RISK REMAINS WITH YOU, NOT NESA.

OTHER THAN THE ABOVE PRODUCT WARRANTY FOR THE

NESA VEHICLE DASH CAMERAS, MIRROR DASH CAMERAS,

FRONT, REAR AND REVERSING CAMERAS AND MIRROR

MONITOR DEVICES, NESA AND ITS SUPPLIERS DISCLAIM ALL

WARRANTIES OF ANY KIND, WHETHER EXPRESS, IMPLIED,

OR STATUTORY, REGARDING THE NESA EQUIPMENT AND

ANY ASSOCIATED APP/SERVICE. INCLUDING ANY IMPLIED

WARRANTY OF TITLE, MERCHANTABILITY, FITNESS FOR

A PARTICULAR PURPOSE, OR NONINFRINGEMENT OF

THIRD PARTY RIGHTS. BECAUSE SOME JURISDICTIONS DO

NOT PERMIT THE EXCLUSION OF IMPLIED WARRANTIES,

THE LAST SENTENCE OF THIS SECTION MAY NOT APPLY

TO YOU. NESA HEREBY FURTHER EXPRESSLY DISCLAIMS

ALL LIABILITY FOR ANY CLAIMS FOR SERVICE FAILURES

THAT ARE DUE TO NORMAL PRODUCT WEAR, PRODUCT

MISUSE, ABUSE, PRODUCT MODIFICATION, IMPROPER

PRODUCT SELECTION OR YOUR NON-COMPLIANCE WITH

ANY AND ALL APPLICABLE FEDERAL, STATE OR LOCAL

LAWS. THIS WARRANTY AND WARRANTY DISCLAIMER

GIVE YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY HAVE

OTHER RIGHTS THAT VARY BY STATE, PROVINCE, OR

COUNTRY. OTHER THAN AS PERMITTED BY LAW, NESA

DOES NOT EXCLUDE, LIMIT OR SUSPEND OTHER RIGHTS

YOU HAVE, INCLUDING THOSE THAT MAY ARISE FROM THE

NONCONFORMITY OF A SALES CONTRACT. FOR A FULL

UNDERSTANDING OF YOUR RIGHTS YOU SHOULD CONSULT

THE LAWS OF YOUR STATE, PROVINCE, OR COUNTRY. FOR

OUR AUSTRALIAN CUTOMERS: PLEASE NOTE THAT THIS

WARRANTY IS IN ADDITION TO ANY STATUTORY RIGHTS

IN AUSTRALIA IN RELATION TO YOUR GOODS WHICH,

PURSUANT TO THE AUSTRALIAN CONSUMER LAW, CANNOT

BE EXCLUDED.

LIMITATIONS OF NESA LIABILITY

UNDER NO CIRCUMSTANCES WILL NESA BE LIABLE IN ANY

WAY FOR ANY CONTENT, INCLUDING, BUT NOT LIMITED TO,

THE LOSS OF CONTENT, ANY ERRORS OR OMISSIONS IN

ANY CONTENT, OR ANY LOSS OR DAMAGE OF ANY KIND

INCURRED IN CONNECTION WITH USE OF OR EXPOSURE

TO ANY CONTENT POSTED, EMAILED, ACCESSED,

TRANSMITTED, OR OTHERWISE MADE AVAILABLE.

NESA LIABILITY FOR DAMAGES, ESPECIALLY FOR BREACH

OF DUTY OR OBLIGATION, DELAY IN PERFORMANCE,

NON-PERFORMANCE, OR MALPERFORMANCE SHALL BE

PRECLUDED, EXCEPT WHEN THESE ARE DUE TO NEGLIGENT

BREACHES OF ANY SIGNIFICANT CONTRACTUAL DUTY OR

OBLIGATION ON THE PART OF NESA. ANY LIABILITY FOR

NEGLIGENCE IS LIMITED TO DIRECT LOSSES USUALLY

AND TYPICALLY FORESEEABLE IN SUCH CASE. SHOULD

THE CLAIM FOR DAMAGES BE BASED ON WILFUL OR

GROSSLY NEGLIGENT BREACH OF CONTRACTUAL DUTY OR

OBLIGATION ON THE PART OF NESA, THE PRECLUSION AND

LIMITATION OF LIABILITY MENTIONED IN THE PRECEDING

SENTENCES WILL NOT APPLY. THE PRECEDING PRECLUSION

AND LIMITATION OF LIABILITY WILL ALSO NOT APPLY TO

CLAIMS FOR DAMAGES ARISING OUT OF LOSS OF LIFE,

BODILY INJURY OR HEALTH IMPACTS FOR WHICH NESA MAY

BE LIABLE, OR FOR NON-CONTRACTUAL LIABILITY.

SOME STATES AND COUNTRIES DO NOT ALLOW

THE EXCLUSION OR LIMITATION OF INCIDENTAL OR

CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR

EXCLUSION MAY NOT APPLY TO YOU. ADDITIONALLY, THIS

PROVISION IS NOT INTENDED TO LIMIT NESA'S LIABILITY

IN THE EVENT OF NESA'S WILLFUL OR INTENTIONAL

MISCONDUCT.

1110

8.0 NOTES

V1.0

Table des matières

Autres manuels NESA Caméra embarquée

NESA

NESA NRC-80H Manuel utilisateur

Manuels Caméra embarquée populaires d'autres marques

Cansonic

Cansonic UltraDuo Z2 Manuel utilisateur

Gazer

Gazer F720 Manuel utilisateur

HP f500g Manuel utilisateur

Xblitz

Xblitz TANGO 4K Manuel utilisateur

Rexing

Rexing M1 Manuel utilisateur

Maka Technologies

Maka Technologies Marbella MXPro Manuel utilisateur

Kaiser Baas

Kaiser Baas R20 Manuel utilisateur

Boyo

Boyo VTM43TC Manuel utilisateur

Minolta

Minolta MNCD37 Manuel utilisateur

Thinkware

Thinkware FA10 Manuel utilisateur

Momento

Momento MD-5200 Manuel utilisateur

BlackVue

BlackVue DR590X-1CH Manuel utilisateur

HP F300 Manuel utilisateur

CammSys

CammSys BlackSys BH-300 Manuel utilisateur

Snooper

Snooper DVR-2HD Manuel utilisateur

Lukas

Lukas Q900 Manuel utilisateur

RVS

RVS 450C Manuel utilisateur

BlackVue

BlackVue 750G PRO Guide de référence
