Rexing S1 Manuel utilisateur
S1
Quick Start Guide
S1 クイックスタートガイド
Guide de démarrage rapide S1
Guida di avvio rapido S1
Guía de inicio rápido S1
S1 Schnellstartanleitung
FR
IT
DE
SP
JP
2
Table of Contents
English
Overview
What’s in the Box
Camera Overview
Installation
Basic Operation
日本語
概説
本製品の同梱物
カメラの概説
画面のアイコン
基本操作
Français
Aperçu
Que contient la Boîte
Aperçu de la Caméra
Installation
Opération de Base
Italiano
Panoramica
Cosa c’è nella Scatola
Panoramica della Telecamera
Installazione
Operazioni di Base
page
4
5
6
8
12
18
19
20
22
26
32
33
34
36
40
46
47
48
50
54
3
Español
Visión General
Qué hay en la Caja
Resumen de la Cámara
Instalación
Operación Básica
Deutsch
Übersicht
Schachtelinhalt
Kamera Übersicht
Installation
Grundlegender Betrieb
60
61
62
64
68
74
75
76
78
84
page
4
1. Overview
Thank you for choosing REXING! We hope you love your new
product as much as we do. If you need assistance, or have any
suggestions to improve it, please contact us. You can reach us
support team will respond you as soon as possible.
Always a surprise in Rexing. Check us out here.
https://www.facebook.com/rexingusa/
https://www.instagram.com/rexingdashcam/
https://www.rexingusa.com/support/registration/
https://www.rexingusa.com/support/product-support/
Facebook Instagram Site Product Support
5
2. What’s in the Box
1. S1 Quick Start Guide
2. Safety Guide
3. USB Cable
4. 3M Adhesive Mount
5. Cable Adhesive Spacer
6. Cable Management Tool
7. Rexing S1 Dashboard Camera
8. Car Power Connector (12ft)
9. Rear camera and Rear camera cable
8.
1.
3.
2.
4.
5.
6.
7 .
1. Overview
6
3. Camera Overview
1. Power Button
2. Menu Button / Mode Button
3. Left Navigation Button/ Record Button
4. OK (Confirm) Button / Emergency Lock Button
5. Right Navigation Button / Screen Toggle Button / Hold to take
6. Front Camera
7. 4 IR Lights / Cabin camera
8. Power / USB Charging Port
9. Micro SD Card Slot
10. Rear Camera Port
11. Reset Button
Front
Side
7
Screen Icons
Wi-Fi
Recording Time
Recording (ON)
Resolution
Mic (ON)
IR Lights (ON)
Battery
Gravity
Sensor
Date
(MM/DD/YYYY) Time (24h)
8
Step 1:
Install the Dash Cam
Place the 3M tape on the mount and properly orient the mount
square to the roof and hood line of the vehicle.
Firmly press the mount onto the windshield. Wait at least 20
minutes before mounting the camera.
Orient the mount as shown on the illustration above.
Step 2:
Insert the Memory Card
The Rexing S1 accepts [Class 10/UHS-1 or higher] Micro SD
memory cards up to 256GB. You will need to insert a memory
card before you can begin recording. Before inserting or
removing a memory card, rst ensure you’ve powered
down the device. Gently push the memory card in until you
hear a click, and allow the spring release to push the card out.
Orient the
mount as shown
4.Installation
9
Step 3: Power the Camera and Format the Memory
Card
Power the camera by connecting the charger to the car cigarette
lighter and camera. To ensure the S1 records to your memory
card properly and without error. Before you start using a new
memory card, you must format the card within the camera
using the format function. Always backup important data
stored on the memory card before formatting.
10
To format the memory card, make sure you have inserted your
memory card, then turn on the device by connecting to a
power source. Press Left Navigation Button to stop recording.
Then press the MENU button twice to enter the System Setup
Menu.
Use the RIGHT and LEFT navigation buttons and go to the
Format setting. Press the OK button to confirm the selection.
You may now disconnect from power. The camera will shut
down after 3 seconds. The camera should begin recording
automatically the next time it is powered on.
Press the YES
button to conrm
formatting the
card
Press the Menu
button twice
