Quantum DPM 5500 Manuel utilisateur

DPM5500

Quick Start Guide

TABLE OF CONTENTS

Choosing a Location ..........................1

Rack Space Requirements...............1

Environmental Conditions .............1

Preparing for the Installation ...........2

Providing Necessary Tools ..............2

Taking ESD Precautions ..................2

Unpacking the DPM5500 ...................2

Installing the DPM5500 System ........2

Locating the Mounting Position ....3

Installing the DPM5500 Chassis .....3

Cabling the DPM5500 ........................5

DPM5500 Default Configuration.......6

DPM5500 Initial Configuration .........6

Microsoft® System Center Data

Protection Manager 2006 ................10

This quick start guides provides basic installation and configuration instructions for

the DPM5500 system. For more information on Microsoft DPM, see http://

www.microsoft.com/windowsserversystem/dpm/default.mspx.

Choosing a Location 0

When choosing an installation site for the DPM5500 system, consider the

following requirements:

•Rack Space Requirements

•Environmental Conditions

Rack Space Requirements 0

Table 1 contains the rack requirements for the DPM5500.

Table 1 Rack Requirements

Environmental Conditions 0

The installation site must have the following environmental conditions:

• Humidity: 20%-80% non-condensing

• Temperature: 10°C-35°C (50°F-95°F)

• Altitude: 0 to 10,000 feet (0 to 3048 meters)

These environmental conditions apply when the DPM5500 system is in operation.

DPM5500

Depth 25.4 in (64.5 cm)

Width 19 in (48.3 cm)

Height 8.75 in (22.2 cm), 5U

Weight 122 lbs (55.33 kg)

Air Clearance Open 4.0 in (10.2 cm) behind unit for proper air

flow

DPM5500 Quick Start Guide

Preparing for the Installation 0

Before you begin the installation procedure in this section,

make the following preparations as described in this

section:

•Providing Necessary Tools

•Taking ESD Precautions

Providing Necessary Tools 0

Provide the following tools for unpacking and installing the

DPM5500 system:

• #1 PHILLIPS® screwdriver

• #2 PHILLIPS screwdriver

• #1 Flat head screwdriver

• Antistatic wrist strap included in accessory kit

Taking ESD Precautions 0

Some components within the DPM5500 system contain

static-sensitive parts. To avoid damaging these parts while

performing installation procedures, always observe the

following precautions:

• Keep the DPM5500 system turned off during all

installation procedures.

• Use an antistatic wrist strap (included in the accessory

kit).

• Keep static-sensitive parts in their original shipping

containers until ready for installation.

• Do not place static-sensitive parts on a metal surface.

Place them inside their protective shipping bag or on an

antistatic mat.

• Avoid touching connectors and other components.

Unpacking the DPM5500 0

This section explains how to unpack the DPM5500 system

components and move them to their final installation

location.

By following these instructions, you help ensure that the

system will continue to be safeguarded after it arrives at the

installation site.

NOTE:Dry climates and cold-weather heating

environments have lower relative humidity and

are more likely to produce static electricity.

Unpack and remove the following components from the

packing materials (see figure 1):

• DPM5500 chassis

• Hard drive sleds

• Accessory kit

Figure 1 Unpacking the

DPM5500

Installing the DPM5500 System 0

Installing the DPM5500 in a rack consists of the following

steps:

•Locating the Mounting Position

•Installing the DPM5500 Chassis

WARNING:The DPM5500 weights 85 lbs (38.55 kg)

without hard drives. Two people are required

to lift either unit.

Accessory kit

Foam

DPM5500

chassis

Foam

Harddrive

sleds

Anti static

bag

Lift point

DPM5500 Quick Start Guide

Locating the Mounting

Position 0

The DPM5500 system is designed to fit in a standard 19 inch

wide rack. It is important to the chassis installation to locate

the hole pattern in the rack rails (see figure 2).

Figure 2 Rail Hole Pattern

WARNING:If the rack is empty at the time of

installation, do NOT install the DPM5500

chassis too high in the rack. The weight of

the chassis may cause the rack to become

“top heavy” and unstable if installed in the

top of an empty rack.

5U of rack space

1 DPM5500 System (5U)

1U = 1.75 in

(44.45mm)

.625 in (15.9 mm)

.5 in (12.7 mm)

.625 in (15.9 mm)

Top of rack

.312 in (7.92 mm)

.5 in (12.7 mm)

Hole pattern

The marks above (X)

indicate the location of

mounting hardware on

the rack rails. Ensure that

any necessary mounting

hardware is installed on

the rack rails prior to

installing the chassis.

Installing the DPM5500

Chassis 0

1Assemble the DPM5500 rack rails as shown in figure 3.

You must pull the slide out of the support brackets to

gain access to the mounting holes.

Figure 3 Assembling the Rack

Rails

2Install the left and right rack rails at the beginning of a

hole pattern (see Locating the Mounting Position) and

install two 10-32 x .50 PHILLIPS screws on each rail at

the front and back of the rack (see figure 4).

NOTE:Quantum ships sufficient clip nuts to support

mounting the DPM5500 rack rails and also to

secure the front of the chassis to the rails.

NOTE:The support brackets extend to accommodate

rack depths or 30 to 36 in. (76.2 to 91 cm).

NOTE:Ensure that clip nuts are installed on the rails (see

figure 2) prior to installing the DX5000 rails.

Clip nut

DPM5500: Adjustment

screws; adjusts to the

depth of your rack

DPM5500: Front mounting

bracket preset. Ensure the

screws are in the correct

position.

DPM5500 Quick Start Guide

Figure 4 Installing the Chassis

Support Brackets

3Once the rails are secured to the rack, tighten the rail

adjustment nuts on each rail.

4With the support brackets installed, prepare the chassis

mounting holes if necessary (see figure 5 for hole

location).

DX5000

support

brackets

10-32 x .50

PHILLIPS

screws Clip nuts

Figure 5 DPM5500 Chassis

Mounting Holes

5Carefully slide the storage array into the rack.

6Secure the DPM5500 chassis to the rack with two 10-32

x 1.25 in. (M5 x 32 metric also provided) black PHILLIPS

screws on each side of the front of the chassis. Tighten

to 5 in/oz. (see figure 6).

WARNING:The DPM5500 weights 85 lbs (38.55 kg).

Two people are required to lift the unit.

Chassis mounting

holes

Chassis mounting

holes

DPM5500 Quick Start Guide

Figure 6 Securing the DPM5500

Chassis to the Rack

7Install each of the hard drive sleds into the DPM5500

chassis. Ensure each drive is completely installed in the

chassis with the drive handle in the closed position (see

figure 7).

CAUTION:Use ESD procedures when handling the hard

drives sleds (see “Taking ESD Precautions” on

page 2). Place the ESD wrist strap on your

wrist and connect the other end of the strap

to the DPM5500 chassis.

NOTE:The hard drives must be installed in the

proper sequence since RAID sets have already

been established at the factory. Refer to the

label on the bottom of the drive sled for the

drive number. The hard drives must also be

installed in the array in which it was

configured.

DPM5500 chassis

DPM5500 Drive 0 Drive 1 Drive 2 Drive 3

Drive 4 Drive 5 Drive 6 Drive 7

Drive 8 Drive 9 Drive 10 Drive 11

Drive 0 Drive 1 Drive 2 Drive 3

Drive 4 Drive 5 Drive 6 Drive 7

Drive 8 Drive 9 Drive 10 Drive 11

Array

controller 2

Array

controller 1

Figure 7 Installing the Disk

Drives in the DPM5500 Chassis

The DPM5500 chassis is now installed in the rack.

Cabling the DPM5500 0

Connect the following cables to the back of the DPM5500

system (see figure 8):

• Connect a power cable to each power supply

• Connect an Ethernet cable to ports ETH1 to connect the

DPM5500 to the local area network (LAN).

Figure 8 DPM5500 System

Cabling

Drive11

Drive0

Drive11

Array

controller 2

Array

controller 1

Power supply cables

Ethernet cables (ports 1 and 2)

1 2

DPM5500 Quick Start Guide

DPM5500 Default Configuration 0

The DPM5500 is configured from Quantum with Microsoft

Windows Server 2003 and Data Protection Manager loaded

on the device. The DPM5500 contains a system

motherboard, processor, and a SCSI HBA. Refer to the

following username and password to access the system:

Username: administrator

Password: Quantum-DPM

The storage array portion of the DPM5500 system contains

12, 18, or 24 hard drives and is used as the primary storage

area of the DPM5500. The DPM application, SQL DPM

database, and the Windows 2003 operating system are

located on 2 internal mirrored hard drives. The DPM5500 is

formatted from Quantum with the following partition:

•37 GB Partitions

•Storage Area

37 GB Partitions

The operating system hard drives contain a single 37 GB

partition. This partition contains the Windows Server 2003

operating system which serves as the boot partition. This

partition also contains the DPM application software and

DPM application database.

Storage Area

The storage area contains a 4.8 TB, 7.2 TB, or 9.6 TB

(approx.) partition for use as storage space for the DPM

software. This partition is only used by DPM and is not

accessible from the Windows Server 2003 operating system.

Microsoft® DPM 0

The Microsoft® DPM application software is installed on the

system, however, the software is not initially configured.

Refer to the Microsoft DPM documentation for information

on DPM configuration.

NOTE:The password is case sensitive.

NOTE:It is recommended to join a test domain within

Windows

DPM5500 Initial Configuration 0

To initially configure the DPM5500 and prepare for

operation:

1Turn on the DPM5500 system by pressing the power

button located on the front of the chassis.

2The DPM5500 uses DHCP (Dynamic Host Configuration

Protocol) to receive an IP address from a local DHCP

server. You will need this IP address to access the

DPM5500. Write the IP address in the space provided

below:

DPM5500 IP Address:___________________________

Example: https://<ip address>:8098

3Enter the IP address assigned to the DPM5500 into a

web browser to access the DPM5500 configuration

wizard.

The DPM5500 configuration wizard displays (see

figure 9).

NOTE:A domain server must be setup and on the same

network as the DPM5500 before continuing with

this procedure.

NOTE:It is highly recommended that the system

administrator with access to the DHCP server be

available during this initial configuration of the

DPM5500. The IP address assigned to the

DPM5500 must available to access the system.

NOTE:This IP address uses https, not the common

http and there is also a special port (8098)

that must be used. This address must be used

every time the web pages are accessed.

DPM5500 Quick Start Guide

Figure 9 Accessing the DPM5500

4Click the Start Wizard link to continue the configuration

wizard.

The Welcome screen displays (see figure 10).

Figure 10 Welcome Screen

5Click Next.

The License Agreement screen displays (see figure 11).

Start

wizard link

Figure 11 License Agreement

6You must select I agree with the Terms specified in

the EULA for all three license agreements to continue

with the DPM5500 configuration. Click Next to

continue.

The IP Address Configuration screen displays (see

figure 12).

Figure 12 IP Address

Configuration

NOTE:If you click Cancel, the system will shutdown

and you will have to turn the DPM5500 on by

pressing the power button on the front of

the chassis.

DPM5500 Quick Start Guide

7The DPM5500 system is configured by default to accept

IP addresses from a DHCP server. If you need to change

the IP Address, select Use the following IP settings

and enter the network information. One of the LAN

settings must be configured for the domain server.

When you have finished configuring the local area

connection settings, click Next to continue. The

DPM5500 reboots.

The system takes several minutes to reboot.

8Re-enter the DPM5500 IP address in the web browser

to access the configuration wizard.

9Click the Start Wizard link to continue the

configuration wizard.

The Date and Time Configuration screen displays (see

figure 13).

Figure 13 Date and Time

Configuration

10 Enter the date and time information and click Next to

continue.

The Server Identity screen displays (see figure 14).

NOTE:Local Area Connection and Local Area

Connection 2 correspond to Ethernet ports 1

and 2 located on the back of the DPM5500

chassis.

NOTE:If the network settings were unchanged, the

DPM5500 will not reboot. Continue with the

next step.

Figure 14 Server Identity

Configuration

11 Enter the following server identity information:

• Server name or accept the system generated server

name. This name must be unique from any other

DPM5500 systems on the same network.

• Domain name, user, and password information.

This allows the DPM5500 to access the domain

server.

12 Click Next to continue. The DPM5500 reboots. The

system takes several minutes to reboot.

13 Re-enter the DPM5500 IP address in the web browser

to access the configuration wizard.

The system prompts you to log in.

14 Enter Administrator for the user name and Quantum-

DPM for the password.

The Server Setup Wizard displays.

15 Click the Start Wizard link to continue the

configuration wizard.

The Administrator Account screen displays (see

figure 15).

NOTE:If you receive a security warning from

Windows, click Yes to continue.

NOTE:The password is case sensitive.

DPM5500 Quick Start Guide

Figure 15 Administrator Account

Configuration

16 Enter the administrator information and click Next to

continue. This information is used to log into the

DPM5500.

The DPM Remote Desktop displays (see figure 16).

Figure 16 DPM Remote Desktop

17 Enter your username and password to login.

18 Configure DPM per the Microsoft® documentation.

When completed, click Next to continue.

The Finished Setup screen displays.

The DPM5500 is initially configured and ready for

operation. Refer to the Microsoft® documentation for

information on configuring the Microsoft® System

Center Data Protection Manager.

DPM5500 Quick Start Guide

United States of America

Quantum Corporation

141 Innovation Drive

Irvine, CA 92612

U.S.A.

phone 949.856.7800

fax 949.856.7799

European Headquarters

Quantum Corporaton

3 Bracknell Beeches

Old Bracknell Lane West

Bracknell

Berkshire RG12 7BW

United Kingdom

phone +44 1344 353500

fax +44 1344 353510

Asia Pacific

Quantum Corporaton

9 Temasek Boulevard, #08-03

Suntec Tower Two

Singapore 038989

Tel: +65 6334 0660

Fax: +65 6432 2830

Email: singapore.sales@quantum.com

Quantum Corporation. Other trademarks may be mentioned herein which belong to other companies.

81-81514-02 A01 February 2006

Microsoft® System Center Data

Protection Manager 2006 0

Microsoft® System Center Data Protection Manager 2006

(DPM) is a server software application that enables disk-

based data protection and recovery for file servers in an

Active Directory® domain. DPM performs replication,

synchronization, and shadow copy creation to provide

reliable protection and rapid recovery of data for both

system administrators and end-users.

For more information on Microsoft DPM, see http://

www.microsoft.com/windowsserversystem/dpm/

default.mspx.

Autres manuels pour DPM 5500

Table des matières

Autres manuels Quantum Stockage

Quantum

Quantum DLTtape SDLT 220 Manuel

Quantum

Quantum Scalar i2000 Mode d’emploi

Quantum

Quantum Scalar i40 Instructions d'utilisation et de sécurité

Quantum

Quantum Scalar 10K Manuel utilisateur

Quantum

Quantum LTO 4 Manuel utilisateur

Quantum

Quantum DPM 5500 Manuel utilisateur

Quantum

Quantum StorNext QD6000 Manuel utilisateur

Quantum

Quantum DLT-V4 Manuel utilisateur

Quantum

Quantum Superloader 3 Manuel utilisateur

Quantum

Quantum Scalar i6000 Manuel utilisateur

Quantum

Quantum A-Series FTP Manuel utilisateur

Quantum

Quantum Scalar LTFS Manuel d'utilisation et d'entretien

Quantum

Quantum Scalar i40 Instructions d'utilisation et de sécurité

Quantum

Quantum DXi4700 Manuel d'installation et d'exploitation

Quantum

Quantum ValueLoader DLT VS160 Manuel utilisateur

Quantum

Quantum DLT 2500 Manuel utilisateur

Quantum

Quantum DLT-S4 Manuel utilisateur

Quantum

Quantum ATL PowerStor L200 Series Manuel utilisateur

Quantum

Quantum DLTtape DLT 7000 Manuel utilisateur

Quantum

Quantum ATL M1500 Manuel utilisateur

Quantum

Quantum STD2401LW Manuel utilisateur

Quantum

Quantum DLTtape SDLT 220 Manuel utilisateur

Quantum

Quantum DLTtape DLT 2000 Manuel utilisateur

Quantum

Quantum DLT-V4 Manuel utilisateur

Manuels Stockage populaires d'autres marques

QNAP

QNAP TS 32PXU Series Manuel utilisateur

LaCie

LaCie RUGGED RAID Manuel utilisateur

Freecom

Freecom CLS DOCK Manuel utilisateur

PNY

PNY Attache P-FD64MBATT3 Manuel utilisateur

HP StorageWorks MSL2024 Manuel utilisateur

OLT

OLT 6x6 Maximizer Manuel utilisateur

Transcend

Transcend JetFlash 160 Manuel utilisateur

LaCie

LaCie RUGGED MINI Manuel utilisateur

Thunderbolt

Thunderbolt 600 Manuel utilisateur

Panasonic

Panasonic LB-DH8 series Manuel

Intel

Intel RAID High Availability Manuel utilisateur

LaCie

LaCie 12big Thunderbolt 3 Manuel utilisateur

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuel utilisateur

Panasonic

Panasonic LKM-F931-1 Manuel utilisateur

Tabernus

Tabernus Enterprise Erase E2400 Manuel utilisateur

Rocstor

Rocstor COMMANDER 3F series Manuel utilisateur

HP P9000 Manuel utilisateur

Western Digital

Western Digital Ultrastar Data60 Manuel utilisateur
