Pickering 40-880 Manuel utilisateur

pickeringtest.com

Issue 2.3 June 2021

40-880 User Manual

PXI 50Ω SPDT Terminated 6GHz RF Switch Module

Page (II) 50Ω SPDT TERMINATED 6GHz RF SWITCH 40-880

pickering

Page (II) REED RELAY MODULE 40-110/115/120/125

pickering

No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by

any means without the written permission of Pickering Interfaces.

Technical details contained within this publication are subject to change without notice.

ISO 9001

Reg No. FM38792

Page (III)

50Ω SPDT TERMINATED 6GHz RF SWITCH 40-880

pickering

Page (III)

REED RELAY MODULE 40-110/115/120/125

pickering

TECHNICAL SUPPORT

For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.

WARRANTY

All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of

three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be

defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.

Products serviced and repaired outside of the warranty period are warranted for ninety days.

Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.

ENVIRONMENTAL POLICY

Pickering Interfaces operates under an environmental management system similar to ISO 14001.

Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the

environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and

safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can

be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

Worldwide Technical Support and Product Information

pickeringtest.com

Germany

Tel: +49 89 125 953 160

E-mail: [email protected]

Sweden

Tel: +46 340-69 06 69

E-mail: [email protected]

USA

Tel: (West) +1 541 471 0700

Tel: (East) +1 781 897 1710

E-mail: [email protected]

Czech Republic

Tel: +420 558 987 613

E-mail: [email protected]

France

Tel +33 9 72 58 77 00

E-mail [email protected]

Pickering Interfaces Headquarters

Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom

Tel: +44 (0)1255-687900

E-Mail: [email protected]

China

Tel: +86 4008 799 765

E-mail: [email protected]

Page (IV) 50Ω SPDT TERMINATED 6GHz RF SWITCH 40-880

pickering

Page (IV) REED RELAY MODULE 40-110/115/120/125

pickering

MEANING / DESCRIPTION SYMBOL

PROTECTIVE EARTH (GROUND)

To identify any terminal which is intended for connection to an external conductor for

protection against electric shock in case of a fault, or the terminal of a protective earth

(ground) electrode.

DANGEROUS VOLTAGE

To indicate hazards arising from dangerous voltages.

WARNING / CAUTION

An appropriate safety instruction should be followed or caution to a potential hazard

exists.

Refer to the relevant instructions detailed within the product manual.

HEAVY

If this product is heavy reference should be made to the safety instructions for

provisions of lifting and moving.

STATIC SENSITIVE

To indicate that static sensitive devices are present and handling precautions should

be followed.

SAFETY SYMBOLS

PRODUCT SAFETY

The following safety symbols may be used on the product and throughout the product documentation.

Page (V)

50Ω SPDT TERMINATED 6GHz RF SWITCH 40-880

pickering

Technical Support and Warranty................................................III

Product Safety .............................................................................IV

Contents (this page)....................................................................V

Warnings and Cautions ..............................................................VII

Section 1

Technical Specication...............................................................1.1

Section 2

Technical Description .................................................................2.1

Functional Description..........................................................2.1

Section 3

Installation....................................................................................3.1

Pre Operation Checks...........................................................3.1

Hardware Installation ............................................................3.2

Software Installation .............................................................3.2

Testing Operation ..................................................................3.3

Section 4

Programming Guide....................................................................4.1

Programming Options For Pickering PXI Modules ............4.1

Switch Module Architecture .................................................4.3

Programming The Switch Module........................................4.4

Section 5

Connector Information................................................................5.1

Section 6

Trouble Shooting.........................................................................6.1

Section 7

Maintenance Information............................................................7.1

CONTENTS

Page (VI) 50Ω SPDT TERMINATED 6GHz RF SWITCH 40-880

pickering

THIS PAGE INTENTIONALLY BLANK

Page (VII)

50Ω SPDT TERMINATED 6GHz RF SWITCH 40-880

pickering

Page (VII)

REED RELAY MODULE 40-110/115/120/125

pickering

WARNINGS AND CAUTIONS

WARNING - HAZARDOUS ENVIRONMENTS SYMBOL

atmospheres. If the product is to be used in hazardous environments we recommend that the user

ensures suitable protective measures are taken.

WARNING - DANGER OF ELECTRIC SHOCK SYMBOL

This module may contain hazardous voltages. Before removing the module from the rack remove all

supplies and disconnect user I/O signals.

Unused slots in the host chassis are populated with blanking plates to prevent access to user

I/O signals that may be present. Blanking panels are available to order from Pickering in a variety

of slot widths. If the product is not used in this manner for example by using an extender card then

additional care must be taken to avoid contact with exposed signals.

CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL

Certain semiconductor devices used in this equipment are liable to damage due to static voltage.

Observe the following precautions when handling these devices in their unterminated state, or

sub-assemblies containing these devices:

1. Persons removing sub-assemblies from equipment using these devices must be earthed by a

wrist strap and a resistor at the point provided on the equipment.

2. Soldering irons used during the repair operations must be low voltage types with earthed tips and

isolated from the mains voltage by a double insulated transformer.

3. Outer clothing worn must be unable to generate static charges.

anti-static bags.

CAUTION - PRODUCT DOCUMENTATION SYMBOL

and understood before attempting to install or operate the product.

SAFETY INSTRUCTIONS

All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O

signals (refer to the Maintenance Section).

• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or

the combined weight of the modules & chassis.

• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the

chassis and the user I/O signals.

• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.

• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on

the front of the unit.

Page (VIII) 50Ω SPDT TERMINATED 6GHz RF SWITCH 40-880

pickering

THIS PAGE INTENTIONALLY BLANK

Page 1.1

50Ω SPDT TERMINATED 6GHz RF SWITCH 40-880

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

PXI 50 Ω SPDT Terminated 6 GHz RF Switch 40-880

ISSUE 3.2 JUN 2021

yWide Frequency Range 10 MHz to 6 GHz

yHigh Performance Solid State Switch

yDual, Quad, Hex and Octal Versions

yAutomatic Termination of Unused Channels

y+30 dBm Input Power Handling

yExcellent Crosstalk & Isolation

ySMA Coaxial Connectors

yVISA, IVI & Kernel Drivers Supplied for

Windows

ySupported in PXI or LXI Chassis

y3 Year Warranty

The 40-880 is a 50 Ω SPDT RF switch with automatic

termination of unused channels which can operate to

frequencies beyond 6 GHz. It is available in dual format in a 1

slot PXI module, quad format in a two slot PXI module or hex

and octal formats in a three slot PXI module.

The switch exhibits low insertion loss and VSWR through

the use of high performance solid state switches. Solid

state switches ensure a long service life with no wear

out mechanism, making the 40-880 ideal for ATE systems

requiring frequent and fast operating RF switching. The

40-880 can handle RF input powers of up to +30 dBm and is

able to sustain frequent hot switching without performance

degradation.

The module is ﬁtted with SMA connectors, ensuring module

compatibility with commonly used cables.

The 40-880 is supplied with drivers that allow users

to support the module in all popular PXI software

environments. In addition the 40-880 can be supported in

Pickering Interfaces 60-100 series LXI Modular Switching

chassis, permitting users to choose their switching platform.

1.1

1.2

2.1

2.2

50Ω

Switch 2

Switch 1

40-880-001 Dual SPDT Terminated

RF Switch Functional Diagram

40-880-002 Quad SPDT Terminated

RF Switch Functional Diagram

1.1

1.2

2.1

2.2

50Ω

Switch 2

Switch 1

3.1

3.2

4.1

4.2

50Ω

Switch 4

Switch 3

Page 1.2 50Ω SPDT TERMINATED 6GHz RF SWITCH 40-880

pickering

SECTION 1 - TECHNICAL SPECIFICATION

50 Ω SPDT Terminated 6 GHz Switch, 40-880

pickeringtest.com

Overview

1.1

1.2

2.1

2.2

50Ω

Switch 2

Switch 1

3.1

3.2

4.1

4.2

50Ω

Switch 4

Switch 3

5.1

5.2

6.1

6.2

50Ω

Switch 6

Switch 5

40-880-003 Hex SPDT Terminated

RF Switch Functional Diagram

1.1

1.2

2.1

2.2

50Ω

Switch 2

Switch 1

3.1

3.2

4.1

4.2

50Ω

Switch 4

Switch 3

5.1

5.2

6.1

6.2

50Ω

Switch 6

Switch 5

7.1

7.2

8.1

8.2

50Ω

Switch 8

Switch 7

40-880-004 Octal SPDT Terminated

RF Switch Functional Diagram

Table des matières

Autres manuels Pickering Unité de contrôle

Pickering

Pickering PXI 40-664A Manuel utilisateur

Pickering

Pickering PXI 30 A Manuel utilisateur

Pickering

Pickering Pxi 41-750 Manuel utilisateur

Pickering

Pickering PXI BRIC 40-569B Manuel utilisateur

Pickering

Pickering SYSTEM 10 Manuel utilisateur

Pickering

Pickering PXI BRIC 40-569 Manuel utilisateur

Pickering

Pickering 40-592A Manuel utilisateur

Pickering

Pickering 60-553 Manuel utilisateur

Pickering

Pickering 40-581 Manuel utilisateur

Pickering

Pickering 41-180 Manuel utilisateur

Pickering

Pickering 40-265 Manuel utilisateur

Pickering

Pickering 42-724 Manuel utilisateur

Pickering

Pickering PXi 41-720 Manuel utilisateur

Pickering

Pickering 40-500 Manuel utilisateur

Pickering

Pickering PXI 40-785 Manuel utilisateur

Pickering

Pickering 40-521 Manuel utilisateur

Pickering

Pickering 40-573 Manuel utilisateur

Pickering

Pickering 40-520 Manuel utilisateur

Pickering

Pickering 4 785C Series Manuel utilisateur

Pickering

Pickering SYSTEM 10 Manuel utilisateur

Pickering

Pickering 40-518A Manuel utilisateur

Pickering

Pickering 40-280 Manuel utilisateur

Pickering

Pickering Pxi 41-660 Manuel utilisateur

Pickering

Pickering 4 890 Series Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
