The 40-785C (PXI) and 42-785C (PXIe) range of PXI microwave

multiplexer modules are suitable for switching 50 Ω signals

up to 67 GHz. They are available in single or dual SP4T or

SP6T conﬁgurations with relays mounted on the front panel.

Remote versions are also available which can support up to

three multiplexers in a single slot.

The remote multiplexer versions, as well as occupying less

PXI panel space, allow the microwave relays to be placed

closer to the UUT and RF test equipment. This can shorten

the length of cables and improve system performance.

Remote versions are supplied with a 1.5 m interface cable.

The panel mounted 50 Ω terminated version occupies 3 slots

for the single version or 6 slots for the dual version. A 75 Ω

version is available with a bandwidth of 2.5 GHz and uses

Siemens 1.6/5.6 style connectors.

yAvailable as PXI or PXIe Modules

ySingle or Dual SP4T or SP6T Panel Mounted Multiplexer

yUp To 3 Remote SP4T or SP6T Multiplexers From Single

Slot Version

y50 Ω Versions With 3-67 GHz Bandwidth

y50 Ω Terminated and Unterminated Versions

y75 Ω Version With 2.5 GHz Bandwidth

yRelay Cycle Counting Included

yLED Indication

yVISA, IVI & Kernel Drivers Supplied for Windows

yPXI Version Supported by PXI or LXI Chassis

y3 Year Warranty

Microwave Multiplexer (Part No. 4x-785C) in

Single Unterminated Format

off

Single Unterminated SP6TSingle Unterminated SP4T

Single slot version

controls 1, 2 or 3

remotely mounted

microwave

multiplexers via

interface cables

The 4x-785C range is suitable for constructing complex

microwave switching networks and includes conﬁgurations

to suit most applications. Connection is by high performance

SMA, SMA 2.9, SMA 2.4, SMA 1.85 or N-type for 50 Ω versions.

These modules give you the highest RF and microwave

performance available within a Pickering switching system.

Although designed for microwave applications, they have

many uses in the RF spectrum where extremely low insertion

loss and ultra high isolation are critical.

Product Compatibility

The 4x-785C range has been introduced as an update to the

existing 40-785B family. These remain orderable but the new

4x-785C is recommended as it provides additional options

such as the PXIe control interface. The RF performance of the

4x-785C is identical to the 40-785B.

pickeringtest.com

4x-785C

PXI/PXIe Microwave Multiplexer

Issue 3.0 October 2022

Page 1.2 pickeringtest.com

Section 1 - Technical Speciﬁcation

off

MUX Bank 1

MUX Bank 2

MUX Bank 1

off

MUX Bank 2

off

MUX Bank 1

MUX Bank 2

off

MUX Bank 3

MUX Bank 1

off

MUX Bank 2

off

MUX Bank 3

Dual Unterminated SP6TDual Unterminated SP4T Triple Unterminated SP6TTriple Unterminated SP4T

off

Single Terminated SP6T

off

Single Terminated SP4T

off

Dual Terminated SP6T

off

Dual Terminated SP4T

off

MUX Bank 1

MUX Bank 2

MUX Bank 1

MUX Bank 2

off

Triple Terminated SP6T

off

Triple Terminated SP4T

off

MUX Bank 1

MUX Bank 2

MUX Bank 1

MUX Bank 2

off

MUX Bank 3 MUX Bank 3

4x-785C Terminated Multiplexer Range (triple versions are only available in remote mount format)

Relay Cycle Counting

To aid with module “health”

monitoring all versions are

provided with a relay cycle counting

cycle feature. The number of

operations per contact are stored

on the module and can be used to

determine if a relay is approaching

EOL. This information could allow

system connections to be revised

so that signals applied to heavily

used contacts are swapped with

lightly used contacts to prolong the

working life of the relay(s).

4x-785C Unterminated Multiplexer Range (triple versions are only

available in remote mount format)

4x-785C

pickeringtest.com Page 2

PXI/PXIe Microwave Multiplexer

Page 1.3 pickeringtest.com

Section 1 - Technical Speciﬁcation

pickering

MUX BANK 1

Remotely Mounted Microwave Multiplexers

3 off Interface Cables 1.5m Length

4x-785C

Single Slot

Version

MUX BANK 2MUX BANK 3

6 45

123

6 4

123

6 4

123

Interconnection Between 4x-785C Single Slot Version

and Remotely Mounted Microwave Multiplexers

Remote Mount Microwave Multiplexer (18-67 GHz) Range:

• Upper left, unterminated (all frequencies) relay.

• Upper right, terminated 26.5 GHz, 40 GHz or 50 GHz relay.

• Lower left, unterminated (all frequencies) relay mounted to optional bracket.

• Lower right, terminated 26.5 GHz, 40 GHz or 50 GHz relay mounted to optional bracket.

Remotely Mounted Microwave Multiplexer Versions

4x-785C

pickeringtest.com Page 3

PXI/PXIe Microwave Multiplexer

Table des matières

Autres manuels Pickering Unité de contrôle

Pickering

Pickering PXI 40-510 Manuel utilisateur

Pickering

Pickering PXI BRIC 40-562A Manuel utilisateur

Pickering

Pickering PXI 40-785 Manuel utilisateur

Pickering

Pickering PXI 40-710 Manuel utilisateur

Pickering

Pickering 40-651 Manuel utilisateur

Pickering

Pickering 41-735 Manuel utilisateur

Pickering

Pickering PXI BRIC 40-569 Manuel utilisateur

Pickering

Pickering 40-545 Manuel utilisateur

Pickering

Pickering 40-292 Manuel utilisateur

Pickering

Pickering 40-575 Manuel utilisateur

Pickering

Pickering 40-785C Manuel utilisateur

Pickering

Pickering PXI 30 A Manuel utilisateur

Pickering

Pickering SYSTEM 10 Manuel utilisateur

Pickering

Pickering 41-765 Manuel utilisateur

Pickering

Pickering 40-262 Manuel utilisateur

Pickering

Pickering 40-191B Manuel utilisateur

Pickering

Pickering BRIC Series Manuel utilisateur

Pickering

Pickering Pxi 41-750 Manuel utilisateur

Pickering

Pickering 40-670 Manuel utilisateur

Pickering

Pickering 40-296 Manuel utilisateur

Pickering

Pickering PXI 40-145 Manuel utilisateur

Pickering

Pickering PXi 41-720 Manuel utilisateur

Pickering

Pickering SYSTEM 10 Manuel utilisateur

Pickering

Pickering 40-520 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
