Panasonic EYFLA4 Manuel utilisateur

Guides, Instruction, Tool Certification Guide & Worksheets

Table of Contents

Page

Number

Identifying Joint Type……………………………………………………… 3

Remote Control Setup…………………………………………………….. 4

Remote Programming Guides……………………………………………. 5-7

Setup Work Sheet…………………………………………………………. 8

Mechanical Pulse

- Verifying MPT tools on Applications………………………....... 10-11

- Reinstating MPT tools on Applications ……………………….. 12-13

- MPT Torque Graphs by Joint type…………………………….. 14-14

AccuPulse

-AccuPulse setup…………………………………………………. 17

-Verifying AccuPulse on Applications…………......................... 18-19

-Reinstating AccuPulse on Applications……………………….. 20-21

-AccuPulse Torque Graphs by Joint type…………………….... 22-23

Precision Clutch Tool

- Verifying Clutch Tools on Applications……….......................... 25-26

Low Torque Clutch Tools

- Programming Instruction EY7411…………………………........ 27

Warranty and Service

- Warranty and Service forms…………………………………….. 28-29

Panasonic Life Solutions Company of America Assembly Tools Division

2 Riverfront Plaza 5th Floor Newark, NJ 07102

www.panasonic.com/assemblytools

Identifying Joint Types

Panasonic Life Solutions Company of America Assembly Tools Division

2 Riverfront Plaza 5th Floor Newark, NJ 07102

www.panasonic.com/assemblytools

Programming the tool with the remote control

1. Cycle Power –Remove then re-install the battery on the tool.

2. Enter Program Mode –On the tool,

•press and hold down the “Light Button” while pulling and releasing the tool’s “Trigger/Switch”

you can then release both buttons.

•The display starts blinking, the tool is now in program mode.

•If the display is solid, return to step one.

3. Edit Programmable Features –While the display is flashing,use the remote control to change feature

settings according to the charts on the next pages.

Two-Way communication capable Tool Models:

EYFLA7AR, EYFLA8PR/CR/AR, EYFLA9PR/CR and EYFMA2PR/CR

(Please refer to the Owner's Manual for further instruction beyond Best Practices)

These models can operate in both One-Way mode or Two-Way mode.

•One-Way communication mode –The Remote control is used to change tool settings.

•Two-Way communication mode –The Qualifier will change tool features and will override any settings

made by the remote control.

Each press of the A,B,C or D buttons on the remote control will cycle through the sub-

menus.

The + and –buttons change the sub menu feature values

The blue button is the Save button. Press this button after features are selected to

save changes.

Remote Control Setup

On the back is a quick

reference for each of the

buttons.

Panasonic Life Solutions Company of America Assembly Tools Division

2 Riverfront Plaza 5th Floor Newark, NJ 07102

www.panasonic.com/assemblytools

EYFLA4 | EYFLA5 | EYFLA6 | EYFMA1

Quick Programming guide

Number

of Push

1~30: Shut-off

F: Non shut-off

L1: Stage 1 Select stage with ＋/－button. Initial setting is 「L1」

L2: Stage 2 L1: For applications with no pulses before the flush point (fragile material)

L2: For applications when the tool pulses before achieving flush point

0～30 = OFF

1～3.0 = .1 tp 3.0 sec

1 time Restore Factory Defaults F All settings return to initial setting. On "F" press "Save" (Blue Button)

C0: OFF Select stage with ＋/－button. Initial setting is 「C0」

C1: ON

In the event that wireless communicationcannot be completed between the tool and the

qualifier, the tool will be disabled and cannot be operated.

D1 time Tool Model Number Model Number Will display model number

Button

Setting Mode

Tool display

Description

Torque setting

Select stage with ＋/－button. Initial setting is 「F」

1 time

Flush Detection Mode

Setting

2 times

Out Of Range/Anti-Theft

Select stage with ＋/－button. Initial setting is 「0」

1 times

Rehit Prevention

EYFNA1 | EYFPA1

Quick Programming guide

Number

of Push

1~30: Shut-off

F: Non shut-off

L1: Stage 1 Select stage with ＋/－button. Initial setting is 「L1」

L2: Stage 2 L1: For applications with no pulses before the flush point (fragile material)

L2: For applications when the tool pulses before achieving flush point

b0: No buzzer

b1: Buzzer with OK

b2: Buzzer with NOK

d1: by LED button (for

d2: by trigger switch

0～30 = Off Select stage with ＋/－button. Initial setting is 「0」

1～3.0 = .1 to 3.0 sec If the clutch is activated before the programmable minimum runtime,

the tool alerts the operator to a NOK fastening. (0.1sec. per stage)

P0: Variable speed (ON) Select stage with ＋/－button. Initial setting is 「P0」

P1: Single speed (OFF) Speed can be controlled by use of the trigger.

1 time Restore Factory Default F All settings return to initial setting. On "F" press the "Save" (Blue Button)

0～99 = Off Select stage with ＋/－button. Initial setting is 「0」

1-99 = 10,000-990,000

When total fastening times are within 1 hour of preset maintenance interval, tool’s display blinks

notifying the operator.

Run Downs Once tool reaches the preset interval, the tool is looked out from further use.

C0: OFF Select stage with ＋/－button. Initial setting is 「C0」

C1: ON

In the event that wireless communication cannot be completed between the tool and the

qualifier, the tool will be disabled and cannot be operated.

R0: OFF Select stage with ＋/－button. Initial setting is「R0」

R1: 360°reverce (ON)

Tool first reverses 360 degree, aligning the threads, greatly reducing the possibility of cross

threads.

1 time

Cross thread reduction

2 times

Maintenance interval alarm

3 times

Out of range disable

function

1 Times

LED Light

Select stage with +/- button. Initial setting is 「d1」

Variable speed control

2 times

Rundown error detecting

3 times

Button

Setting Mode

Tool display

Description

Torque setting

Select stage with ＋/－button. Initial setting is 「F」

1 time

Flush (Snug torque)

detection mode setting

2 times

Buzzer setting

Select stage with ＋/－button. Initial setting is 「b0」

Mechanical Pulse

Panasonic Life Solutions Company of America Assembly Tools Division

2 Riverfront Plaza 5th Floor Newark, NJ 07102

www.panasonic.com/assemblytools

EYFLA7 | EYFLA8 | EYFLA9 | EYFMA2

Quick Programming guide

AccuPulse

Panasonic Life Solutions Company of America Assembly Tools Division

2 Riverfront Plaza 5th Floor Newark, NJ 07102

www.panasonic.com/assemblytools

EYFG1N | EYFG2N | EYFG3N

Quick Programming guide

Clutch Tools

Number

of Push

80 = Full speed Select stage with ＋/－button. Initial setting is 「80」

15~80: 10 rpm each Adjustable speed in 10 rpm increments

b0: No buzzer

b1: Buzzer with OK

b2: Buzzer with NOK

L1: by LED button (5min)

L2: by trigger switch

0～30 = Off Select stage with ＋/－button. Initial setting is 「0」

1～3.0sec = .1 to 3.0sec

P0: Variable speed (ON) Select stage with ＋/－button. Initial setting is 「P0」

P1: Single speed (OFF) Speed can be controlled by use of the trigger.

1 time Restore Factory Defaults F All settings return to initial setting. On "F" press "Save" (Blue Button)

0～99 = Off Select stage with ＋/－button. Initial setting is 「0」

1-99 = 10,000-990,000

When total fastening times are within 1 hour of preset maintenance interval, tool’s display blinks

notifying the operator.

Run Downs Once tool reaches the preset interval, the tool is locked out from further use.

C0: OFF Select stage with ＋/－button. Initial setting is 「C0」

C1: ON

In the event that wireless communication cannot be completed between the tool and the

qualifier, the tool will be disabled and cannot be operated.

R0: OFF Select stage with ＋/－button. Initial setting is「R0」

R1: 360°reverce (ON)

Tool first reverses 360 degree, aligning the threads, greatly reducing the possibility of cross

threads.

0～30 = Off Select stage with ＋/－button. Initial setting is 「U」

1～30 = .1 to 3.0sec High speed run down time starts on trigger pull then automatically downshifts to 300 rpm

Select stage with +/- button. Initial setting is 「L1」

1 time

Cross thread reduction

2 times

Auto Down Shift

2 times

Maintenance interval alarm

3 times

Out of range disable

function

Variable speed control

2 times

Rundown error detecting

3 times

1 Times

LED Light

Button

Setting Mode

Tool display

Description

Speed Setting

1 times

Buzzer setting

Select stage with ＋/－button. Initial setting is 「b0」

* A clutch adjustment tool is required for torque settings.

1. Rotate the clutch adjustmenttool CW to open the tamper resistant door.

2. Flip the clutch adjustment tool over to adjust the clutch to the desired torque.

3. Rotating the clutch adjustment tool clockwise will increase torque and counter clockwise to

decrease torque.

4. Once the desired torque is set, remember to close the tamper resistant door rotating the

clutch adjustment tool CCW.

Panasonic Life Solutions Company of America Assembly Tools Division

2 Riverfront Plaza 5th Floor Newark, NJ 07102

www.panasonic.com/assemblytools

Application

Tool Info

Accessories

Residual Audit

Setup Worksheet

Production Floor Information

Calibration Unit Settings

Single Tool Worksheet

Calibration Lab Information

Brand of Sockets /Extensions /Etc.

Apex

Sockets /Extensions /Etc.

Audit

13mm

Certification Results (Nm (+/- %or +/- Nm))

20 +/-20%

Flush Point (L1/L2)

Tool Program Setting (1~30)

Accessories

Target Torque

Torque High Limit

Torque Low Limit

Filter Frequency Setting (Hz)

500

Pulse Tool Compensation

1-800

Torque Units (Nm, Ft. Lbs., In. Lbs., Etc.)

Joint Simulator Model #

EYFJS22NM

Joint Type /Setting

Medium Hard

Mode

Pulse

Serial #

123456

Transducer Model #

EYFST22NM

Transducer Serial #

123456

Residual Audit Torque (Nm)

Calibration Date

2014-01-01

Model #

EYFST22NM

Sockets /Extensions /Etc.

13mm w/ 10" Ext

Audit Wrench Make

Brand

Audit Wrench Model/Serial #

ABC/123

Audit Wrench Mode

Peak

Audit Wrench Settings

Torque/Angle/Threshold

Tool Model Number

EYFLA5A

Tool Serial Number

YLA5AR1212074

Flush Point (L1/L2)

Tool Program Setting (1~30)

Brand of Sockets /Extensions /Etc.

Apex

Target Torque

Torque Tolerance (+/- %)

15%

Torque Tolerance (+/-)

Date of Install

2014-01-01

Application

Hood Install

Location

H26

Torque Units (Nm, Ft. Lbs., In. Lbs., Etc.)

EYFLA4 | EYFLA5 | EYFLA6

EYFMA1 | EYFNA1 | EYFPA1

Mechanical Pulse Tools

3. SetUp

Toolon

Application

4.Verify

ToolOn

Application

5. RecordTo

Worksheet

6.Verify

ToolIn

Calibration

Lab

7. RecordTo

Worksheet

1. Obtain

Application

Specifications

2. Determine

ToolFor

Application

Verify Mechanical Pulse Tools On Applications

Following these guidelines, including the “Set Up Worksheet”, will streamline

the set up and verification process.

Set Up

Worksheet

Static/Residual

TorqueAudit

w/ AuditWrench

TorqueCurves

Method For New

Installations

*In most cases, Residual (Audit Wrench) & Dynamic (Transducer)

torques will be differentdue to differencesin the joint!

Set Up

Worksheet

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Panasonic Outils électriques

Panasonic

Panasonic AccuPulse QP Low Noise Series Manuel utilisateur

Panasonic

Panasonic EYFLC1A Manuel utilisateur

Panasonic

Panasonic EYFPA1C Manuel utilisateur

Panasonic

Panasonic EY4550 Manuel utilisateur

Panasonic

Panasonic EY46A5 Manuel utilisateur

Panasonic

Panasonic EYFEA1N Mode d'emploi

Panasonic

Panasonic EY4541 Manuel utilisateur

Panasonic

Panasonic EY75A8 Manuel utilisateur

Panasonic

Panasonic EY3640 Manuel utilisateur

Panasonic

Panasonic EY4541X57 Manuel utilisateur

Panasonic

Panasonic 4541OLOA Manuel utilisateur

Panasonic

Panasonic EY3610 Manuel utilisateur

Panasonic

Panasonic EY4542 - CIRCULAR SAW 14.4V Manuel utilisateur

Panasonic

Panasonic EY75A8 Manuel utilisateur

Panasonic

Panasonic EY4550 Manuel utilisateur

Panasonic

Panasonic EYFLA4A Manuel utilisateur

Panasonic

Panasonic EYFPA1J Manuel utilisateur

Panasonic

Panasonic EY7552X57 Manuel utilisateur

Panasonic

Panasonic EY46A5 Manuel utilisateur

Panasonic

Panasonic EYFMA1B Manuel utilisateur

Panasonic

Panasonic EY4541 Manuel utilisateur

Panasonic

Panasonic EY7541 - CORDLESS IMPACT WRENCH Manuel utilisateur

Panasonic

Panasonic EY3640 Manuel utilisateur

Panasonic

Panasonic EY75A8 Manuel utilisateur

Manuels Outils électriques populaires d'autres marques

AEG

AEG OMNI-JS Manuel utilisateur

SIP

SIP 01533 Manuel utilisateur

Ribimex

Ribimex PRS499 Manuel utilisateur

3M Fiber Optic Connector Crimp Tool Manuel utilisateur

Ryobi

Ryobi P524 Manuel utilisateur

ROJEK

ROJEK FSN 300A Manuel utilisateur

Kemper

Kemper 1740PRO Manuel utilisateur

WABCO

WABCO OptiTire Manuel utilisateur

EINHELL

EINHELL TE-MS 18/210 Li Manuel utilisateur

Orgapack

Orgapack OR-T 85 Guide rapide

TOUGHCUT

TOUGHCUT Diamond 400 Manuel utilisateur

Yaros

Yaros PB-3603 Manuel utilisateur

Fein

Fein BSS 2.0 E Guide de configuration

Baileigh Industrial

Baileigh Industrial SS-2725 Manuel utilisateur

Milwaukee

Milwaukee 2674-20 Manuel utilisateur

Fein

Fein BLs 1.6 Manuel utilisateur

Princess

Princess Electric Multi Sharpener Manuel utilisateur

FOREDOM

FOREDOM K.1050 Manuel
