Before attempting to connect or operate this product,

please read these instructions carefully and save this manual for future use.

Network Interface Unit

Network Operating Instructions

Model No. WJ-NT304

LINK

RCV SND

OPERATE

Network Interface Unit WJ-NT304

CONTENTS

Preface ..................................................................................................................................... 3

About these operating instructions ....................................................................................... 3

Trademarks and registered trademarks ............................................................................... 3

Viewer Software ................................................................................................................... 3

Monitor Images on a PC ........................................................................................................... 4

Monitor images from a single camera .................................................................................. 4

Monitor images from multiple cameras ................................................................................ 8

Action at an Alarm Occurrence ................................................................................................. 9

Transmit Images onto an FTP Server ...................................................................................... 10

Transmit an alarm image at an alarm occurrence (Alarm image FTP transmission) ........... 10

Transmit images at a designated interval or period (FTP periodic transmission) ................ 10

Save images on the SD memory card when failed to transmit images by the

FTP periodic transmission function ...................................................................................... 11

About the Network Security of This Unit ................................................................................... 13

Equipped security functions ................................................................................................. 13

Display the Setup Menu and Configure the Settings of the Unit using a PC ............................ 14

How to display the setup menu ............................................................................................ 14

How to operate the setup menu ........................................................................................... 15

Configure the basic settings of the unit [Basic setup] ........................................................... 18

Configure the settings relating to images and audio [Camera setup] ................................... 24

Configures the multi-screen settings [Multi-screen setup] .................................................... 31

Configure the alarm settings [Alarm setup] .......................................................................... 32

Configure the settings relating to the authentication [Authentication setup] ......................... 37

Configure the settings of the servers [Server setup] ............................................................ 39

Configuring the network settings [Network setup] ................................................................ 41

Maintenance of the unit [Maintenance] ................................................................................ 48

About the Displayed System Log ............................................................................................. 51

Troubleshooting ........................................................................................................................ 53

Preface

About these operating instructions

There are 2 sets of operating instructions for the WJ-NT304 as follows.

• Installation Guide (book, these operating instructions)

• Network operating instructions (PDF)

These operating instructions contain descriptions of how to operate this product using a PC via a network and of

how to configure the settings.

Refer to the operating instructions for descriptions of how to install this product and of how to connect to a network.

Adobe®Reader is required to read these operating instructions (PDF). When the Adobe®Reader is not installed on

the PC, download the latest Adobe®Reader from the Adobe web site and install it.

Trademarks and registered trademarks

• Microsoft, Windows, Internet Explorer, ActiveX, and DirectX are either registered trademarks or trademarks of

Microsoft Corporation in the United States and/or other countries.

• Adobe and Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the United

States and/or other countries.

• SD logo is a trademark.

• Other names of companies and products contained in these operating instructions may be trademarks or regis-

tered trademarks of their respective owners.

Viewer Software

• Images will not be displayed when the viewer software "Network camera View3" is not installed on the PC. Install

the viewer software from the provided CD-ROM.

• The viewer software used on each PC should be licensed individually. Refer to your dealer for the software

licensing.

Monitor Images on a PC

The following are descriptions of how to monitor images from the unit on a PC.

Monitor images from a single camera

entries. The default user name and password are as

follows.

User name: admin

Password: 12345

When accessing the unit without changing the

default password, the pop-up window saying that it

is recommended to change the password will be dis-

played.

To enhance the security, change the password for

the user "admin". It is recommended to change this

password periodically. (☞page 37)

• When "Unicast port (AUTO)" or "Unicast port (MAN-

UAL)" is selected for "Transmission type" (☞page

25), up to 8 users per channel (up to 16 users for the

total of all the channels) can access the unit concur-

rently. Depending on the set values for "Total bit

rate" and "Max bit rate (per 1 client)", the maximum

concurrent access number may be limited. When 8

users have been concurrently accessing already, the

access limit message will be displayed for users who

accessed subsequently.

• When "ON" is selected for "MPEG-4 transmission"

(☞page 25), an MPEG-4 image will be displayed.

When "OFF" is selected, a JPEG image will be dis-

played. It is possible to display JPEG image even

when "ON" is selected for "MPEG-4 transmission".

In this case, the refresh interval will be lowered to

approx. half the set value.

When "ON" is selected for "MPEG-4 transmission"

JPEG (VGA): 15 fps

JPEG (QVGA): 60 fps

These are the total maximum values of all the chan-

nels.

The refresh interval may be longer depending on a

network environment, PC spec, photographic sub-

ject, access traffic, etc.

Important:

When displaying multiple MPEG-4 images on a PC,

images may not be displayed depending on the per-

formance of the PC.

Refer to the next page for further information about the

"Live" page.

Step 1

Start up the web browser.

Step 2

Enter the IP address designated using the Panasonic IP

setup software in the address box of the browser.

(Example: http://192.168.0.10/)

Important:

• When the HTTP port number is changed from "80",

enter "http://IP address of the unit +: (colon) + port

number" in the address box of the browser, for

example, "http://192.168.0.11:8080".

• When the PC is in a local network, configure the

web browser to bypass the proxy server for the local

address.

Step 3

Press the [Enter] key on the keyboard.

→The "Live" page will be displayed.

Important:

Follow the instructions on page 58 when the mes-

sage is displayed on the information bar of the

browser.

Notes:

• When "ON" is selected for "User Authentication", the

authentication window will be displayed before dis-

playing live images for the user name and password

About the "Live" page

q[Setup] button (*1)

Click this button to display the setup menu. The but-

ton will turn green and the setup menu will be dis-

played.

w[Live] button

The button will turn green and the "Live" page will be

displayed.

e[1] to [4] buttons

Click this button to display the "Live" page. The but-

ton will turn green and the "Live" page will be dis-

played. It is possible to select a desired channel by

clicking the [1] to [4] buttons.

rMulti-screen buttons

Images from multiple cameras can be displayed on

a multi-screen by registering cameras on the setup

menu. (☞page 8)

tImage type buttons

:The letters "MPEG-4" on the button will

turn green and an MPEG-4 image will be

displayed. When "OFF" is selected for

"MPEG-4 transmission" on the setup

menu, the [MPEG-4] button will not be dis-

played. (☞page 25)

:The letters "JPEG" on the button will turn

green and JPEG image will be displayed.

yAUX buttons (*2)

Select 1 (AUX1) to (AUX3) from the pull-down menu

and click the [OPEN/CLOSE] button.

AUX1 and AUX2 are auxiliary outputs of camera.

AUX3 is the auxiliary output from the AUX 1 terminal

of this unit.

:The AUX connector will open.

:The AUX connector will close.

w[Live] button

e[1] to [4] buttons

q[Setup] button

yAUX buttons

rMulti-screen buttons

tImage type buttons

iZOOM buttons

oFOCUS buttons

!0 AUTO MODE !1 Control pad/buttons

!2 BRIGHTNESS buttons

!3 PRESET

!4 Unit title

!5 Alarm occurrence indication button !6 Mic input button

!8 One shot button

!7 Audio output button

@0 Main area

u[B/W] button

!9 Time and date

u[B/W] button (*2)

Click the desired button to switch color (colour) of

the displayed images between color (colour) and

B/W.

:Images will be displayed in B/W (black and

white).

:Images will be displayed in color (colour).

:Activates Auto 1 mode. (The camera

selects black and white mode if the picture

is dark, or color mode if the picture is

bright enough.) If the camera has only one

AUTO mode, click this button.

:Activates Auto 2 mode. (The camera

detects the light source type to prevent

malfunction. This setting is applicable

when using a near-infrared light source in

a dark place.)

iZOOM buttons (*2)

:Click this button to adjust the zoom ratio

to the WIDE side.

:Click this button to adjust the zoom ratio

to the TELE side.

oFOCUS buttons (*2)

:Click this button to adjust the focus auto-

matically.

:Click this button to adjust the focus to the

NEAR side.

:Click this button to adjust the focus to the

FAR side.

!0 AUTO MODE (*2)

Select an operation from the pull-down menu and

click the [START] button. The selected operation will

start.

Click the [STOP] button to stop the operation.

The selected operation will stop when the camera

(panning/tilting/zooming/focusing) is operated.

Auto pan: Automatically pans between the start

position and the end position set in advance.

Even when the camera is operated for zooming

or focusing, the camera continues panning.

Sort: Sequentially switches between preset posi-

tions counterclockwise, starting from the camera

home position.

Sequence: Automatically moves to the preset posi-

tions orderly (start from the lowest preset posi-

tion number).

Patrol: Operates the camera in accordance with

patrol function settings.

Note:

To activate auto pan, sort, sequence, or patrol, it is

required to perform the settings on the SETUP

MENU of camera in advance. (☞page 28)

!1 Control pad/buttons (*2)

: Left-click on the control pad or buttons

to adjust the horizontal/vertical position

of the camera (panning/tilting).

Panning/tilting speed will be faster if a

clicked point gets farther from the center

point of the control pad.

It is also possible to pan/tilt the camera by dragging

the mouse.

When the upper half area of the control pad is right-

clicked, the displayed image will be zoomed in.

When the lower half area is right-clicked, the dis-

played image will be zoomed out on. When the left

half area is right-clicked, the focus will be adjusted to

the FAR side. When the right half area is right-

clicked, the focus will be adjusted to the NEAR side.

!2 BRIGHTNESS buttons (*2)

:The displayed image will be darker.

:The adjusted brightness will return to the

default brightness.:

:The displayed image will be brighter.

Note:

When the BRIGHTNESS buttons are clicked while

the camera is at the preset position, the adjusted

brightness will automatically be registered for the

current preset position.

!3 PRESET (*2)

Select a preset position from the pull-down menu

and click the [GO] button. The camera will move to

the selected preset position. When "Home position"

is selected, the camera will move to the home posi-

tion.

To activate preset positions and home position, it is

required to configure the settings on the SETUP

MENU of camera in advance. (☞page 28)

!4 Unit title

The unit title entered for "Unit title" on the [Basic] tab

will be displayed. (☞page 18)

!5 Alarm occurrence indication

button (*2)

This button will be displayed at an alarm occurrence,

and the channel of alarm occurrence (one of [1] to

[4] buttons) will light. When the button is clicked, the

button will disappear and the alarm output connector

will be reset. (☞page 34)

!6 Mic input button (*3)

Turns on/off the audio reception (hear audio from

the unit on a PC). This button will be displayed only

when "Mic input" or "Interactive" is selected for

"Audio mode" on the setup menu. (☞page 29)

When this button is clicked, the button will turn into

the button and audio from the unit will not be

heard.

Note:

When this button is clicked, audio from the PC will

be turned off.

When closing the window, click the button again to

turn on the audio.

!7 Audio output button (*3)

Turns on/off the audio transmission (play audio from

the PC on the unit speaker). This button will be dis-

played only when "Audio output" or "Interactive" is

selected for "Audio mode" on the setup menu.

(☞page 31)

The button blinks while the audio transmission is

being carried out.

When this button is clicked, the button will turn into

the button and audio from the PC will not be

heard.

Notes:

• When a user is using the audio transmission func-

tion, the mic input button and the audio output button

will be inoperable for the other users.

• Possible duration of audio transmission is up to 5

minutes per transmission. When 5 minutes have

passed, the audio transmission function will be can-

celed and the audio reception function will automati-

cally be turned on. To turn the audio transmission

function on, click the audio output button again.

!8 One shot button

Click this button to take a picture (a still picture). The

picture will be displayed on a newly opened window.

The picture will be displayed on a newly opened win-

dow. When right-clicking on the displayed image, the

pop-up menu will be displayed. The displayed image

can be saved on the PC by selecting "Save" from

the pop-up menu.

!9 Time and date

Current time will be displayed in the set date/time

display format (☞page 18).

@0 Main area (*2)

Images from the camera will be displayed in this

area.

Click a desired point in the main area on the "Live"

page that is to be the centre of the angle of view.

The camera moves to adjust the position in order to

set the clicked point as the centre.

Note:

When using this function, set "PROPO.P/T" of cam-

era to ON. (☞page 28)

The following cameras are available for the function.

WV-CS950 series, WV-CW960 series, WV-CW970

series (as of January 2007)

*1 Operable by only users and hosts whose access

level is "1. Administrator"

*2 Only operable by users and hosts whose access

level is "1. Administrator" or "2. Camera control"

when "ON" is selected for "User authentication"

(☞page 37) and "Host authentication" (☞page 38).

*3 Operable by users and hosts who belong to the

access level selected for "Authentication" on the

[Audio] tab of the "Camera setup" page. (☞page 30)

Refer to page 37 for further information about the

access level.

Important:

It is impossible to display images and to receive/

transmit audio between the unit and the PC when

the viewer software "Network Camera View3" is not

installed on the PC. (Refer to the operating instruc-

tions for descriptions of how to install.)

Monitor images from multiple cameras

Images from multiple cameras can be displayed on a multi-screen. Images from 4 cameras can be displayed simul-

taneously. To display images on a multi-screen, it is necessary to register cameras in advance. 4 cameras can be

registered as a group and up to 4 groups (16 cameras) can be registered. (☞page 31)

Important:

• Select "OFF" for both the user authentication and the host authentication of the network device to be registered.

• Only JPEG images can be displayed on a multi-screen. Audio will not be heard.

• Multi-screen is the function that is available using this unit.

When the power is turned off or the LAN cable is disconnected while displaying images, displaying images on a

multi-screen will become unavailable.

Step 1

Click the [Multi-screen] button.

→Images from the registered cameras will be displayed

on a 4-split screen.

qTo display images on a single screen, click the the

[1] button or [Live] button.

wClick a camera title. Live images from the camera

corresponding to the clicked camera title will be dis-

played on the "Live" page of the newly opened win-

dow.

Action at an Alarm Occurrence

The alarm action will be performed when the following alarm occur.

Alarm type

Terminal alarm: When connecting an alarm device such as a sensor to the connector terminal (Alarm Input 1 to

4) on the rear of the unit, the alarm action (unit action at an alarm occurrence) will be performed when the

connected alarm device is activated. Alarm action to be performed differs depending on the settings config-

ured on the [Alarm] tab. (☞page 32)

Camera site alarm: When a camera connected to a VIDEO IN connector detects an alarm by alarm sensors or

cameras' motion detectors, etc., and the unit receives the alarm input signal from the camera, the alarm

action will be performed. (☞page 32)

Video Loss: When the loss of video input signals is detected due to coaxial cable disconnections or camera

troubles, the alarm action will be performed. (☞page 32)

Command alarm: When a Panasonic alarm protocol is received from the connected device via a network, the

alarm action will be performed. (☞page 32)

Action at an Alarm Occurrence

Display the [Alarm occurrence indication] button on the "Live" page (☞page 5).

The [Alarm occurrence indication] button will be displayed on the "Live" page at an alarm occurrence.

Note:

The [Alarm occurrence indication] button will be refreshed in 30 seconds intervals. For this reason, it may take a

maximum of 30 seconds until the [Alarm occurrence indication] button is displayed on the "Live" page at an alarm

occurrence.

Notify of alarm occurrences to the device connected to the alarm connector

It is possible to output signals from the alarm connector on the rear of the unit and sound the buzzer when an alarm

occurs. The settings for the alarm output can be configured on the [Alarm] tab of the "Alarm setup" page.

(☞page 32)

Transmit an image onto a server automatically

An alarm image can be transmitted at an alarm occurrence to the server designated in advance. The settings

required to transmit an alarm image to a server can be configured in the "Alarm image setup" section of the [Alarm]

tab of the "Alarm setup" page (☞page 33) and the [FTP] tab of the "Server setup" page (☞page 40).

Notify of alarm occurrences by e-mail

Alarm mail (alarm occurrence notification) can be sent at an alarm occurrence to the e-mail addresses registered in

advance. Up to 4 addresses can be registered as recipients of the alarm mail. The settings for alarm mail can be

configured in the "E-mail notification setup" section of the [Notification] tab of the "Alarm setup" page (☞page 35)

and the [Mail] tab of the "Server setup" page (☞page 40).

Notify of alarm occurrences to the designated IP addresses (Panasonic alarm protocol)

This function is available only when Panasonic device, such as the network disk recorder, is connected to the sys-

tem. When "ON" is selected for "Panasonic alarm protocol", the connected Panasonic device will be notified that the

unit is in the alarm state. The settings for Panasonic alarm protocol can be configured on the [Notification] tab of the

"Alarm setup" page. (☞page 36)

Transmit Images onto an FTP Server

Images can be transmitted to an FTP server. By configuring the following settings, transmission of images captured

at an alarm occurrence or captured at a designated interval to an FTP server will become available.

Important:

When using this function, set the user name and the password to access the FTP server to restrict users who

can log into the FTP server.

Transmit an alarm image at an alarm occurrence (Alarm image

FTP transmission)

An alarm image can be transmitted at an alarm occurrence to the FTP server. To transmit alarm images to an FTP

server, it is necessary to configure the settings in advance.

The settings for the FTP server can be configured on the [FTP] tab of the "Server setup" page. (☞page 40)

The alarm image FTP transmission function can be turned on/off on the [Alarm] tab of the "Alarm setup" page.

(☞page 34)

Note:

Depending on the network traffic, number of the transmitted images may not reach the set number of images to

be transmitted.

Transmit images at a designated interval or period (FTP periodic

transmission)

Images can be transmitted at a designated interval or period. To transmit images at a designate interval or period, it

is necessary to configure the settings in advance.

The settings for the FTP server to which images are to be transmitted can be configured on the [FTP] tab of the

"Server setup" page. (☞page 40)

On the [FTP] tab of the "Network setup" page, the FTP periodic transmission function can be turned on/off, and the

settings relating to schedules (periods) can be configured. (☞page 46)

Notes:

• Depending on the network line speed or the network traffic, images may not be transmitted at the exact designat-

ed interval or period.

• When "ON" is selected for both of the alarm image FTP transmission function and the FTP periodic transmission

function, the alarm image FTP transmission function will be given priority over the FTP periodic transmission

function. For this reason, images may not be transmitted at the exact designated interval or period if alarms

occur frequently.

Autres manuels pour i-pro WJ-NT304

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Panasonic Matériel réseau

Panasonic

Panasonic LJ-SK56A Manuel utilisateur

Panasonic

Panasonic Switching Diodes MA2S101 Manuel utilisateur

Panasonic

Panasonic Schottky Barrier Diodes MA3X716 (MA716) Manuel utilisateur

Panasonic

Panasonic Schottky Barrier Diodes MA2SD250G Manuel utilisateur

Panasonic

Panasonic Schottky Barrier Diodes MA3XD21 Manuel utilisateur

Panasonic

Panasonic Schottky Barrier Diodes MA2SD32 Manuel utilisateur

Panasonic

Panasonic Schottky Barrier Diodes MA24D70 Manuel utilisateur

Panasonic

Panasonic Schottky Barrier Diodes MA2SE01 Manuel utilisateur

Panasonic

Panasonic Switching Diodes MA3J142AG Manuel utilisateur

Panasonic

Panasonic WJ-NXF02 Manuel utilisateur

Panasonic

Panasonic K-NL404K/G Manuel utilisateur

Panasonic

Panasonic Chip RC Networks EZACT Guide de l'utilisateur

Panasonic

Panasonic WJ-NT104 Manuel utilisateur

Panasonic

Panasonic WJ-PB65E01 Manuel utilisateur

Panasonic

Panasonic Transistors 2SC3931G Manuel utilisateur

Panasonic

Panasonic Transistors 2SB1030A Manuel utilisateur

Panasonic

Panasonic Transistors 2SC4562G Manuel utilisateur

Panasonic

Panasonic PN59021 Manuel utilisateur

Panasonic

Panasonic BB-HNP17A Manuel utilisateur

Panasonic

Panasonic Transistors 2SA2162G Manuel utilisateur

Panasonic

Panasonic Zener Diodes MAZSxxxG Series Manuel utilisateur

Panasonic

Panasonic Transistors 2SC5632G Manuel utilisateur

Panasonic

Panasonic PIN Photodiodes PNZ334 (PN334) Manuel utilisateur

Panasonic

Panasonic Transistors 2SB1218G Manuel utilisateur

Manuels Matériel réseau populaires d'autres marques

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuel utilisateur

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuel utilisateur

Yudor

Yudor YDS-16 Manuel utilisateur

D-Link

D-Link ShareCenter DNS-320L Manuel utilisateur

Samsung

Samsung ES1642dc Instructions d'utilisation

Honeywell Home

Honeywell Home LTEM-PV Instructions de montage

evertz

evertz 7700 Series Manuel utilisateur

D-Link

D-Link ShareCenter DNS-343 Manuel utilisateur

Asante

Asante AsanteBridge 1012 Manuel utilisateur

FireBrick

FireBrick FB2700 Manuel utilisateur

Audiovox Electronics

Audiovox Electronics ARWH2T Manuel utilisateur

ADC

ADC DSX-1 Manuel

NetComm

NetComm NF2 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 5620 Manuel utilisateur

Dell EMC

Dell EMC XC6420 Series Manuel utilisateur

Lanner

Lanner NCA-1020A Manuel utilisateur

Allied Telesis

Allied Telesis AT-TN121-A Manuel utilisateur

Arista

Arista CCA-ETM-Q12 Manuel utilisateur

Panasonic i-pro WJ-NT304 Manuel utilisateur

Manuels Matériel réseau populaires d'autres marques
