Publication date : May 2007 SJC00384AED 1

This product complies with the RoHS Directive (EU 2002/95/EC).

2SA2162G

Silicon PNP epitaxial planar type

For general ampliﬁcation

Complementary to 2SC6036G

Features

Low collector-emitter saturation voltage VCE(sat)

SSS-Mini type package, allowing downsizing of the equipment and automatic

insertion through the tape packing

Absolute Maximum Ratings Ta= 25°C

Parameter Symbol Rating Unit

Collector-base voltage (Emitter open) VCBO –15 V

Collector-emitter voltage (Base open) VCEO –12 V

Emitter-base voltage (Collector open) VEBO –5 V

Collector current IC–500 mA

Peak collector current ICP –1 A

Collector power dissipation PC100 mW

Junction temperature Tj125 °C

Storage temperature Tstg –55 to +125 °C

Electrical Characteristics Ta= 25°C±3°C

Parameter Symbol Conditions Min Typ Max Unit

Collector-base voltage (Emitter open) VCBO IC= –10 mA, IE= 0 –15 V

Collector-emitter voltage (Base open) VCEO IC= –1 mA, IB= 0 –12 V

Emitter-base voltage (Collector open) VEBO IE= –10 mA, IC= 0 –5 V

Collector-base cutoff current (Emitter open) ICBO VCB = –10 V, IE= 0 – 0.1 mA

Forward current transfer ratio hFE VCE = –2 V, IC= –10 mA 270 680 

Collector-emitter saturation voltage VCE(sat) IC= –200 mA, IB= –10 mA –250 mV

Transition frequency fTVCB = –2 V, IE= 10 mA, f = 200 MHz 200 MHz

Collector output capacitance

(Common base, input open circuited) Cob VCB = –10 V, f = 1 MHz 4.5 pF

Note) Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.

Package

Code

SSSMini3-F2

Marking Symbol: 2U

Pin Name

1. Base

2. Emitter

3. Collector

2SA2162G

2SJC00384AED

This product complies with the RoHS Directive (EU 2002/95/EC).

PCTaICVCE ICVBE

VCE(sat) IChFE ICCob VCB

020 40 60 80 100 120 140

100

120

2SA2162_ PC-Ta

Collector power dissipation PC(mW)

Ambient temperature Ta(°C)

0− 0.5 −1.0 −1.5 −2.0 −2.5 −3.0

−10

−20

−30

−40

−50

−60

−70

2SA2162_ IC-VCE

Collector current IC(mA)

Collector-emitter voltage VCE (V)

−140 µA

−120 µA

−100 µA

−80 µA

−60 µA

−40 µA

−20 µA

IB=−160 µA

Ta =25°C

0− 0.2 − 0.4 − 0.6 − 0.8 −1.0 −1.2 −1.4

−10

−20

−30

−40

−50

−60

−100

−70

−80

−90

2SA2162_ IC-VBE

Collector current IC(mA)

Base-emitter voltage VBE (V)

VCE =−2 V

Ta =85°C

25°C

−25°C

− 0.1 −1 −10 −100 −1

000

− 0.01

− 0.1

−1

2SA2162_ VCE(sat)-IC

Collector-emitter saturation voltage VCE(sat) (V)

Collector current IC(mA)

IC / IB =20

Ta =85°C

25°C

−25°C

−1 −10 −100 −1

000

100

200

300

400

500

600

2SA2162_ hFE-IC

Forward current transfer ratio hFE

Collector current IC(mA)

VCE =−2V

Ta =85°C

25°C

−25°C

0 5 10

100

2SA2162_ Cob-VCB

Collector output capacitance

(Common base, input open circuited) Cob (pF)

Collector-base voltage VCB (V)

f = 1 MHz

Ta= 25°C

This product complies with the RoHS Directive (EU 2002/95/EC).

SSSMini3-F2 Unit: mm

0.30 +0.05

−0.02

0.20 +0.05

−0.02 0.13 +0.05

−0.02

(0.4)

0.80 ±0.05

0.51 ±0.04

1.20 ±0.05

0.20 ±0.05

(0.27)

5°

0 to 0.05 (0.5)

5°
