Programmable Terminal NB-series

Practices Guide

New Functionalities for

NB-Designer V1.50

NB3Q-TW01B

NB5Q-TW01B

NB7W-TW01B

NB10W-TW01B

V462-E1-01

■ Introduction

This guide describes reference information to create NB screens. It does not provide safety

information.

Be sure to obtain the manuals for NB-series Programmable Terminals, read and understand the

safety points and other information required for use, and test sufficiently before actual use of the

equipment.

Terms and Conditions Agreements

Thank you for your usage of products of Omron Corporation (“Omron”). Without any special

agreements, these terms and conditions shall apply to all transactions regardless of who

sells.

Definitions of Terms

Omron product(s): Omron’s factory automation system devices, general control devices,

sensing devices, and electronic/mechanical components.

- Catalogs: Any and all catalogs (including “Best Components” and other catalogs),

specifications, instructions and manuals relating to Omron products, including

electronically provided data.

- Conditions: Use conditions, rating, performance, operating environment, handling

procedure, precautions and/or prohibited use of Omron products described in the

catalogs.

- User application(s): Application of Omron products by a customer, including but not

limited to embedding/using Omron products into customer’s components, electronic circuit

boards, devices, equipment or systems.

- Conformity: (a) conformity, (b)performance, (c) no infringement of intellectual property of

third party, (d) compliance with laws and regulations, and (e) conformity to various

standards of Omron products in user applications.

Note about Descriptions

- Rating and performance is tested separately. Combined conditions are not warranted.

- Reference data is intended to be used just for reference. Omron does NOT guarantee that

the Omron Product can work properly in the range of reference data.

- Examples are intended for reference. Omron does not warrant the conformity in usage of

the examples.

- Omron may discontinue Omron products or change specifications of them because of

improvements or other reasons.

Note about Use

Adopt and use Omron products considering the following cautions.

- Use the product in conformance to the conditions, including rating and performance.

- Check the conformity and decide whether or not Omron products are able to be adopted.

Omron makes no guarantees about the conformity.

- Make sure in advance that electricity is properly supplied to Omron products and they are

set up rightly in your system for intended use.

- When you use Omron products, ensure the followings: (i) allowance in aspect of rating

and performance, (ii) safety design which can minimize danger of the application when the

product does not work properly, (iii) systematic safety measures to notify danger to users,

and (ⅳ) periodical maintenance of Omron products and the user application.

- Omron assumes no responsibility for any direct or indirect loss, damage and expense

resulting from infection of our products, installed software, any computer devices,

computer programs, network, and databases with the followings: DDoS attack (distributed

DoS attack); computer virus and other technically harmful program; and unauthorized

access.

Please conduct the followings by yourself: (i) anti-virus software, (ii) data input/output, (iii)

lost data recovery, (ⅳ) protections against computer virus that contaminate Omron

products or the installed software, and (ⅴ) measures to protect Omron products from

unauthorized access.

- Omron products are designed and manufactured as commodity for general industrial

products. For this reason, the usages (a) to (d) are to be unintended. Omron makes no

guarantees on Omron products, if you use Omron products for those purposes. However,

special applications that Omron expects or usages with especial agreement are excluded.

(a) Applications requiring high-level safety (e.g. nuclear control facilities, combustion

facilities, aerospace and aviation facilities, railroad facilities, elevating facilities,

amusement facilities, medical facilities, safety devices or other applications which

has possibility to influence lives or bodies)

(b) Applications requiring high reliability (e.g. gas/water/electricity supply system, 24-

hour operating system, applications handling with rights/property, such as payment

system)

potential of chemical contamination or electromagnetic interference, facilities with

vibration or impact, facilities on continual operation for a long period).

(d) Applications under conditions or environment which are not described in the catalogs

- Omron products in the catalogs are not intended to be used in automotive applications

(including two-wheel vehicles). Please DO NOT use Omron products in automotive

applications. Contact our sales personnel for automotive products.

Warranty

Warranty of Omron products is subject to followings.

-Warranty Period: One year after your purchase.

However, except when there is a separate statement in the catalogs.

-Coverage: Omron will provide one of the services listed below, on the basis of Omron’s

decision.

(a) Free repairing of the malfunctioning Omron products (except electronic/mechanical

components) at Omron maintenance service sites.

(b) Free replacement of the malfunctioning Omron products with the same number of

substitutes.

-Exceptions: This warranty does not cover malfunctions caused by any of the followings.

(a) Usage in the manner other than its original purpose

(b) Usage out of the conditions

(d) Remodeling/repairing by anyone except Omron

(e) Software program by anyone except Omron

(f) Causes which could not be foreseen by the level of science and technology at the

time of shipment of the products.

(g) Causes outside Omron or Omron products, including force majeure such as disasters

Limitation of Liability

The warranty described in this Terms and Conditions Agreements is a whole and sole

liability for Omron products. There are no other warranties, expressed or implied.

Omron and its distributors are not liable for any damages arisen from or relating to Omron

products.

Export Control

Customers of Omron products shall comply with all applicable laws and regulations of other

relevant countries regarding security export control, in exporting Omron products and/or

technical documents or in providing such products and/or documents to a non-resident.

Omron products and/or technical documents may not be provided to customers if they

violate the laws and regulations.

Table of Contents

Terms and Conditions Agreements...................................................................3

１Related Manuals..........................................................................................7

２Precautions .................................................................................................8

３New Functionalities for NB-Designer V1.50.............................................9

３-１Overview............................................................................................................... 9

４How to Use New Functionalities .............................................................10

４-１Connection Destination Setting Change ............................................................ 10

Related System Memory ............................................................... 10

Creating Sample Screen and Setting Objects............................... 11

４-２Project Import and Export from NB-Designer Menu........................................... 13

Example (Export)........................................................................... 13

Example (Import)........................................................................... 14

４-３Font Replacement.............................................................................................. 15

Sample Setting .............................................................................. 15

Revision History ................................................................................................16

１Related Manuals

No.

Model

Title

V106 NB□Q-TW01B

NB□W-TW01B

NB-series Programmable Terminals NB-Designer

OPERATION MANUAL

V107 NB□Q-TW01B

NB□W-TW01B

NB-series Programmable Terminals SETUP MANUAL

V108 NB□Q-TW01B

NB□W-TW01B

NB-series Programmable Terminals HOST

CONNECTION MANUAL

V109 NB□Q-TW01B

NB□W-TW01B

NB-series Programmable Terminals STARTUP GUIDE

２Precautions

(1) When building an actual system, check the specifications of the component devices of

the system, use within the ratings and specified performance, and implement safety

measures such as safety circuits to minimize the possibility of an accident.

(2) For safe use of the system, obtain the manuals of the component devices of the system

and check the information in each manual, including safety precautions, precautions for

safe use.

(3) It is customer’s responsibility to check all laws, regulations, and standards that the

system must comply with.

(4) No part of this publication may be reproduced, stored in a retrieval system, or

transmitted, in any form, or by any means, mechanical, electronic, photocopying,

recording, or otherwise, without the prior written permission of Omron.

(5) The information in this document is current as of March 2020.

The information contained in this document is subject to change without notice due to

improvements.

Special information in this document is classified as follows:

Precautions for Safe Use

Describes precautions on what to do and what not to do to ensure proper

operation and performance.

Precautions for Correct Use

Describes precautions on what to do and what not to do to ensure proper operation

and performance.

Additional Information

Additional information to read as required.

This information is provided to increase understanding or make operation easier.

Copyrights and trademarks

Sysmac is a trademark or registered trademark of Omron Corporation in Japan and other

countries for Omron factory automation products.

Microsoft, Windows, and Excel are the trademarks or registered trademarks of Microsoft

Corporation in the USA, Japan and other countries.

Other company names and product names in this document are the trademarks or registered

trademarks of their respective companies.

Screen shots are used with permission from Microsoft Corporation.

Some product photos and drawings in this guide are for illustrative purposes. Actual products

may vary.

３New Functionalities for NB-Designer

V1.50

３-１Overview

This guide provides information about the following features newly added in NB-Designer V1.50:

1. Connection destination setting change

2. Project import and export from/to NB-Designer

3. Font replacement

４How to Use New Functionalities

４-１Connection Destination Setting Change

Configuration to communicate with an Omron Ethernet host is possible in a specific system memory.

A screen for entering values into the system memory enables to change the setting without using

NB-Designer.

You only can change the communication setting in the NB unit, not the setting of the connection

destination unit itself.

Related System Memory

Address

Description

LW9685 Enter the number of PLC to connect. The number must start with 3 and

ascending number, not a PLC number as it is.

For example, If 3 is assigned to this address, the Ethernet host that has

the lowest PLC number is selected. If 4 is assigned, the host whose PLC

number is the second lowest is selected.

After the PLC number is set to this address, the information about the

target host, such as current IP address, is automatically set to LW9686

and higher address.

LW 9686 to

9689

Enter the IP address of connection destination.

LW9686 is the most significant byte of the IP address. Ascending

addresses represents the lower bytes in sequence.

For example, IP address 192.168.250.0 is set as: 192 is LW9686, 168

is LW9687, 250 is LW9688, and 1 is LW9689.

LW9690

Enter the port number of connection destination.

LW9691 Set the node ID of connection destination. Enter the least significant byte

of the IP address, i.e. the same value as LW9689.

LB9272

Change set values in the addresses above. To enable the settings,

change this address to ON and then, reboot the NB unit.

PLC number ( LW9685)

LW 9686 to 9689

LW9690

LW9691

Autres manuels pour NB-series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Omron Terminal tactile

Omron

Omron NA-series Instructions d'utilisation

Omron

Omron NT600M Series Manuel utilisateur

Omron

Omron NS - HOST Manuel d'instructions

Omron

Omron NT11 - 01-2004 Manuel utilisateur

Omron

Omron DRT2 SERIES DEVICENET SLAVES - OPERATION ... Manuel utilisateur

Omron

Omron DeviceNet DRT2-AD04 Manuel utilisateur

Omron

Omron NXR Series Manuel utilisateur

Omron

Omron NSJ5 Manuel utilisateur

Omron

Omron NXR-ILM08C-EIT Manuel utilisateur

Omron

Omron NA-series Instructions d'utilisation

Omron

Omron ns series Guide de l'utilisateur

Omron

Omron NA5-15*101 series Guide de l'utilisateur

Omron

Omron NS12-TS00 Series Guide de l'utilisateur

Omron

Omron PC CONNECTION - 04-1997 Manuel utilisateur

Omron

Omron NV3W Series Manuel d'instructions

Omron

Omron NB3Q-TW**B series Manuel d'installation et d'exploitation

Omron

Omron NT2S-SF121B-E - Manuel d'instructions

Omron

Omron Programmable Terminals NT31 NT31C Guide de l'utilisateur

Omron

Omron NB-series Manuel utilisateur

Omron

Omron NT2S-SF122B-E START V1.03 Manuel d'instructions

Omron

Omron NV Series Manuel du propriétaire

Omron

Omron NT20S Manuel utilisateur

Omron

Omron NSH5 Series Manuel utilisateur

Omron

Omron NTXS Manuel utilisateur

Manuels Terminal tactile populaires d'autres marques

Wincor Nixdorf

Wincor Nixdorf iPOS plus Advanced Manuel utilisateur

Ingenico

Ingenico AXIUM EX4000 Manuel utilisateur

Heisei Electronics

Heisei Electronics Q-POS 815 Manuel utilisateur

Amano

Amano MTX-15 Manuel utilisateur

FLOWBIRD

FLOWBIRD CWT Compact Touch Manuel utilisateur

Demco

Demco SP7 Manuel utilisateur

Lathem

Lathem PC600 Series Manuel utilisateur

Partner

Partner MF-2352 Manuel utilisateur

NCR

NCR RealPOS 7460-2 Manuel

Simrad

Simrad MS50 Instructions de montage

Unitech

Unitech MR350 MKII Guide de démarrage rapide

Jungheinrich

Jungheinrich WMT 210 Manuel utilisateur

Motorola

Motorola MTP850 Manuel utilisateur

YASKAWA

YASKAWA 62H-MDC0 Manuel utilisateur

MVG industries

MVG industries NeptuLink Manuel utilisateur

Price Industries Limited

Price Industries Limited FDC Manuel d'instructions

Honeywell

Honeywell TemaKey Manuel utilisateur

EBN

EBN BPC65-B-A16G Manuel utilisateur
