NXP Semiconductors MPC-LS-VNP-RDB Manuel utilisateur

Quick Start Guide

MPC-LS Vehicle Network Processing

Reference Design Board

An advanced automotive gateway solution using

NXP’s MPC5748G gateway microcontroller and

LS1043A communications processor

MPC-LS-VNP-RDB

GET TO KNOW THE MPC-LS-VNP-RDB

Quick Start Guide

Figure 1: Front side of MPC-LS-VNP-RDB

12 V power

connector (J7)

30-pin LIN and

CAN connector

(J36)

MPC5748G

console port

(J13)

TJA1102

Ethernet ports

(J27, J28)

RJ45

connector

(J2)

RJ45

connector

(P4)

USB 3.0

Type A

connector

(J15)

LS1043A console

port (J39)

LS1043A JTAG

header (J9)

DIP switch (SW3)

FlexRay channel

B connector (J5)

Reset switch

(SW2)

M.2 slot (J1)

MPC5748G

JTAG header

(J8)

RJ45 connector

(J37)

GET TO KNOW THE MPC-LS-VNP-RDB

www.nxp.com

MPC-LS-VNP-RDB

The NXP MPC-LS VNP RDB brings

an advanced automotive gateway

solution using NXP’s MPC5748G

gateway microcontroller and

LS1043A communications processor.

The combination of a real-time

microcontroller with microprocessor

application processing enables

new gateway use cases and service-

oriented gateways.

Quick Start Guide

MPC-LS-VNP-RDB FEATURES

Hardware

MPC5748G Automotive Microcontroller

• AEC-Q100, Grade 2

• ISO 26262 ASIL B Functional Safety

• Processors

– (2x) Power Architecture®e200z4 @ 160

MHz

– (1x) Power Architecture e200z2 @ 80

MHz

• 8x CAN FD + 4 (Non FD) w/SPI expansion

• 2x AVB Ethernet (w/switch)

• 2x FlexRay, 4x LIN

• Embedded Hardware Security Module

(HSM)

– Supports SHE and EVITA standards

PMIC

• PF8200 PMIC

• Configurable and programmable outputs

to power the core processor, memory and

a wide range of peripherals

SJA1105S Automotive Ethernet Switches

• AEC-Q100, Grade 2

• 1024-entry MAC address learning table

• Hardware support for IEEE 802.1AS and

IEEE 802.1Qav for AVB networks

• SJA1105S: 4x MII/RMII RGMII, 1x SGMII

• SJA1105Q: 5x MII/RMII/RGMII

LS1043A Layerscape Microprocessor

• (4x) Arm

Cortex-A53 64-bit processors

– Up to 1.4 GHz

• Gigabit Ethernet Data Path Acceleration

• 10 Gbps Crypto Acceleration

• 2 GB DDR3L @ up to 1.6 GT/s

• 1 GB NAND flash

• 64 MB Serial NOR flash

• Micro SD card slot

• 10/100/1000 Mbit/s Ethernet

• 2x USB 3.0

www.nxp.com

MPC-LS-VNP-RDB FEATURES CONT.

Software

• MPC5748G: MCAL, Bare-metal

• LS1043A: Linux, fast path packet

forwarding

• Inter-Platform Communications

Framework (IPCF)

STEP-BY-STEP INSTRUCTIONS

1Installing

Software

1. Download and Install the Tera Term

terminal emulator, if not installed

already

Go to http://download.cnet.com/Tera-

Term/3001-2094_4-75766675.html and

download the executable file. Execute

the file and proceed with the default

configurations that the installation

wizard recommends. At the end of the

installation process you should have

Tera Term on your Windows PC.

2. Download and Install the MCP2221A

USB-to-UART driver, if not installed

already

Go to https://www.microchip.com/

wwwproducts/en/MCP2221A. Scroll

down and click Documents. In the

Software section, click “MCP2200/

MCP2221 Windows Driver & Installer”.

Install the driver.

2Booting the

LS1043A

1. Connect the power supply

Connect power supply to the power

jack of the MPC-LS-VNP-RDB board

and micro-B USB cable to the LS1043A

USB3 console port. Make sure the

power status LED is glowing green on

the board.

2. Setup Tera Term Console

Open Tera Term on Windows PC.

Select the COM port to which the

USB3 console port is connected and

click OK. Go to Setup>Serial Port and

select 115200 as the baud rate.

If no COM port is detected

automatically, make sure the

MCP2221A driver is downloaded and

installed correctly.

3. Reset the Board

Press the reset button on the chassis

back panel to reboot the board.

The boot log appears in the console

window.

Quick Start Guide

www.nxp.com

STEP-BY-STEP INSTRUCTIONS—CONT.

4. Application Startup

After the boot completes you will be

prompted for a TinyDistro Login.

Type “root” and then press enter.

The getting started IPCF (Inter-

Platform Communications Framework)

application is automatically executed

on login.

3Booting the

MPC5748G

1. Connect the power supply

Connect power supply to the power

jack of the MPC-LS-VNP-RDB board

and micro-B USB cable to the

MPC5748G USB4 Console port. Make

sure the power status LED is glowing

green on the board.

2. Setup Tera Term Console

Open Tera Term on Windows PC.

Select the COM port to which the

USB4 console port is connected and

click OK. Go to Setup>Serial Port and

select 115200 as the baud rate.

If no COM port is detected

automatically, make sure the

MCP2221A driver is downloaded and

installed correctly.

3. Reset the Board

Press the reset button on the chassis

back panel to reboot the board.

The boot log appears in the console

window.

4. Application Startup

The getting started IPCF (Inter-

Platform Communications Framework)

application is auto executed on login.

WARNING

The RDB enclosure provides thermal

management. Do not run the RDB

with the enclosure open without

proper cooling. Refer to the user

manual for cooling recommendations.

SUPPORT

Visit www.nxp.com/support for a list

of phone numbers within your region.

WARRANTY

Visit www.nxp.com/warranty for

complete warranty information.

www.nxp.com/MPC-LS-VNP-RDB
