NXP Semiconductors K32W Manuel utilisateur

SECURITY

STATUS

JN-RM-2080

K32W module development reference manual

Rev. 1.0 —27 Mar 2020

Reference manual

Document information

Info

Content

Keywords

K32W061/041, module

Abstract

Reference Manual for K32W061/041 modules and platform design.

SECURITY

STATUS

NXP Semiconductors

JN-RM-2080

K32W module development reference manual

JN-RM-2080

All information provided in this document is subject to legal disclaimers.

Reference manual

Rev. 1.0 —27 Mar 2020

2 of 30

Contact information

For more information, please visit: http://www.nxp.com

Revision history

Rev

Date

Description

1.0

20200327

Creation

SECURITY

STATUS

NXP Semiconductors

JN-RM-2080

K32W module development reference manual

JN-RM-2080

All information provided in this document is subject to legal disclaimers.

Reference manual

Rev. 1.0 —27 Mar 2020

3 of 30

Contact information

For more information, please visit: http://www.nxp.com

1. Introduction

This manual describes the hardware for the reference designs for modules based around

the NXP K32W061/041 wireless microcontrollers. The NXP K32W061 version is fitted to

the NXP modules. These are small, low-power and cost-effective evaluation and

development board or application prototyping and demonstration of the K32W061 device.

The K32W061/041 is an ultra-low-power, highly integrated single-chip device that

enables Standard IEEE 802.15.4 and BLE 5.0 RF connectivity for portable, extremely

low-power embedded systems.

The K32W061/041 SoC integrates a radio transceiver operating in the 2.4 GHz ISM band

supporting IEEE 802.15.4/BLE 5.0 Radio, an ARM Cortex-M4 processor, up to 640 kB

flash,152 kB SRAM (and 128 kB ROM), BLE Link layer processing hardware and

peripherals optimized to meet the requirements of the target applications.

The design considerations presented in this manual are equally valid for bespoke

solutions where the K32W061/041 device is placed directly onto the product PCB.

Three modules models are available:

•K32W061-001-M10

•K32W061-001-M13

•K32W061-001-M16

The models available are described in Table 1.

In order to complete a successful PCB design by your own the hardware guidelines

described in this reference manual must be followed as strictly as possible. Further

information on the K32W061/041 characteristics are available in the “K32W061/041

IEEE802.15.4 and BLE 5.0 Wireless Microcontroller” datasheet.

The K32W-001-M10 module has been fitted to a mezzanine board (OM15077) for use on

the IOTZTB evaluation kit. The module is known as K32W -001-T10.

The K32W-001-M16 module has been fitted to a mezzanine board (OM15077) for use on

the IOTZTB evaluation kit. The module is known as K32W -001-T16.

1.1 Audience

This guide is intended for systems designers

1.2 Regulatory approvals

The K32W061-001-M10 and M13 are compliant with:

•RED 2014/53/UE

•CFR 47 FCC part 15

•Industry Canada requirements

SECURITY

STATUS

NXP Semiconductors

JN-RM-2080

K32W module development reference manual

JN-RM-2080

All information provided in this document is subject to legal disclaimers.

Reference manual

Rev. 1.0 —27 Mar 2020

4 of 30

Contact information

For more information, please visit: http://www.nxp.com

The high power K32W061-001-M16 is not approved for use in Europe. It is compliant

with:

•CFR 47 FCC part 15

•Industry Canada requirements

2.Reference Design

The reference design package includes the following information for each module

variant:

•Reference manual: JN-RM-2080

•Schematics

•Layout

•Bill-of-Materials

Full design databases including schematics and layout source files are available on

request.

The following table provides a summary of the K32W061/041 Module Reference Design

that is available from the Wireless Connectivity area of the NXP web site.

Table 1. Modules references

Part number

Description

Content

Reference

Manual

JN-RD-6059

K32W061/041

Module

Reference

Design

Package

OM15069

Standard Power

PCB Antenna

K32W061-001-

M10

JN-RM-2080

OM15069

Standard Power

Fl connector

K32W061-001-

M13

OM15072

High Power

Antenna diversity (PCB

antenna and Fl

connector)

K32W061-001-

M16

Note: These reference designs are approved for the operating temperature range of

−40 ºC to +125 ºC.

SECURITY

STATUS

NXP Semiconductors

JN-RM-2080

K32W module development reference manual

JN-RM-2080

All information provided in this document is subject to legal disclaimers.

Reference manual

Rev. 1.0 —27 Mar 2020

5 of 30

Contact information

For more information, please visit: http://www.nxp.com

K32W061

Matching

Printed

antenna

K32W061-001-M13

3. Block diagram

Fig 1. K32W061-001-M10 & M13 block diagrams

Fig 2. K32W061-001-M16 block diagram

4. Design considerations

To have successful wireless hardware development, the proper device footprint, RF

layout, circuit matching, antenna design, and RF measurement capability are essential.

RF circuit design, layout, and antenna design are specialties requiring investment in tools

and experience. With available hardware reference designs from NXP, RF design

considerations, and the guidelines contained in this application note, hardware engineers

can successfully design IEEE802.15.4 and BLE radio boards with good performance

levels. The following figures show the K32W061 M10 & M13 reference modules. They

contain the K32W061 device and all necessary I/O connections.

K32W061

Matching

µFl connector

K32W061-001-M10

K32W061

SKY66403

Matching

K32W061-001-M16

Printed

antenna

µFl connector

SECURITY

STATUS

NXP Semiconductors

JN-RM-2080

K32W module development reference manual

JN-RM-2080

All information provided in this document is subject to legal disclaimers.

Reference manual

Rev. 1.0 —27 Mar 2020

6 of 30

Contact information

For more information, please visit: http://www.nxp.com

Fig 3. K32W061-001-M10 & M13

DCDC external components 32 kHz XTAL

32 MHz XTAL RFIO &

MatchingNetwork

IF Printed antenna

µFl connector

FEM SKY66403

Fig 4. K32W061-001-M16

The device footprint and layout are critical as the RF performance is affected by the

design implementation. For these reasons, use of the NXP recommended RF hardware

reference designs are important for successful board performance. Additionally, the

reference platforms have been optimized for radio performance. Even small changes in

the location of components can mistune the circuit. If the recommended footprint and

SECURITY

STATUS

NXP Semiconductors

JN-RM-2080

K32W module development reference manual

JN-RM-2080

All information provided in this document is subject to legal disclaimers.

Reference manual

Rev. 1.0 —27 Mar 2020

7 of 30

Contact information

For more information, please visit: http://www.nxp.com

design are followed exactly in the RF region of the board, sensitivity, output power,

harmonic and spurious radiation, and range will have a high likelihood of first-time

success.

The following subsections describe important considerations when implementing a

wireless hardware design starting with the device footprint, PCB stack-up, RF circuit

implementation, and antenna selection. The following figure shows an example of a

typical layout with the critical RF section which must be copied exactly for optimal radio

performance. The less critical layout area can be modified without reducing radio

performance.

NOTE:

Exact dimensions are not given in this document, but can be found in the manufacturing

files for the K32W061/ modules

4.1 K32W061/041 device footprint

The performance of the wireless link is largely influenced by the device’s footprint. As a

result, a great deal of care has been put into creating a footprint so that receiver

sensitivity and output power are optimized to enable board matching and minimal

component count. NXP highly recommends copying the die flag exactly as it is shown in

the following figure; this includes via locations as well. Deviation from these parameters

can cause performance degradation.

RFIO

GND vias

Die flag

Fig 5. Critical Layout of die flag area

Figure 5 shows the critical areas of the device die flag. These are the following:

•Ground vias and locations

•RF output and ground traces

SECURITY

STATUS

NXP Semiconductors

JN-RM-2080

K32W module development reference manual

JN-RM-2080

All information provided in this document is subject to legal disclaimers.

Reference manual

Rev. 1.0 —27 Mar 2020

8 of 30

Contact information

For more information, please visit: http://www.nxp.com

•Die flag shape

4.2 PCB Stack-Up

Complexity is the main factor that will determine whether the design of an application

board can be two-layer, four-layer, or more. From an RF point of view a 4 layers PCB

is preferred to a two layers PCB. Nevertheless, in a very simple application it should

be possible to use a 2 layers PCB.

The recommended board stack-up for either a four-layer or two-layer board design is

as follows:

•4-layer stack-up:

—Top: RF routing of transmission lines

—L2: RF reference ground

—L3: DC power

—Bottom: signal routing

•Two-layer stack-up:

—Top: RF routing of transmission lines, signals, and ground

—Bottom: RF reference ground, signal routing, and general ground

The K32W061-001-M10 and K32W061-001-M13 (OM15069) and K32W061-001-M16

(OM15062) modules are built on a standard 4–layer printed circuit board (PCB) with the

individual layers organized as shown in Figure 6.

Fig 6. PCB stack-up

Note: The NXP PCB layouts assume use of the layers defined above. If a different PCB

stack-up is used, then NXP does not guarantee performance.

NXP strongly recommends the use of the above stack-up.

As shown in Figure 6, regarding transmission lines, it is important to copy not just the

physical layout of the circuit, but also the PCB stack-up. Any small change in the

SECURITY

STATUS

NXP Semiconductors

JN-RM-2080

K32W module development reference manual

JN-RM-2080

All information provided in this document is subject to legal disclaimers.

Reference manual

Rev. 1.0 —27 Mar 2020

9 of 30

Contact information

For more information, please visit: http://www.nxp.com

thickness of the dielectric substrate under the transmission line will have a significant

change in impedance; all this information can be found on the fabrication notes for

each board design. As an illustration, consider a 50-ohm microstrip trace that is 18-mils

wide over 10 mils of FR4. If that thickness of FR4 is changed from 10 to 6 mils, the

impedance will only be about 36 ohms.

In any case the width of the RF lines must be re-calculated according to the PCB

characteristics in order to ensure a 50-ohm characteristic impedance.

When the top layer dielectric becomes too thin, the layers will not act as a true

transmission line, even though all the dimensions are correct. There is not universal

industry agreement on which thickness at which this occurs, but NXP prefers to use a

top layer dielectric thickness of no less than 8-10 mils.

There is also a limit to the ability of PCB fabricators to control the minimum width of a

PCB trace and

the minimum thickness of a dielectric layer. +/- 1 mil will have less

impact on an 18-mils wide

trace and a 10-mil thick dielectric layer, than it will on a much

narrower trace and thinner top layer.

This can be an especially insidious problem. The design will appear to be optimized

with the limited

quantityofprototypeandinitialproductionboards,inwhichthebare

PCB'swereallfabricated inthesame

lot.However,whenthe product goesintomass

productiontherecanbevariations in PCBfabricationfrom

lot-to-lot which can degrade

performance.

The use of a correct substrate like the FR4 with a dielectric constant of 4.4 will assist you

in achieving a good RF design.

While no special measures are required for the board design, it is recommended that

Class 1 tolerances be used.

4.3 RF circuit topology and matching

NXP always recommends that designers start by copying the existing NXP reference

design. This

applies to both the circuit portion (schematic) of the design, and the PCB

layout. For all RF designs, particularly for designs at frequencies as high as 2.4 GHz,

the PCB traces are a part of the design itself.

Even a very short trace has a small

amount of parasitic impedance (usually inductive), which has to be

compensated for in

the remainder of the circuit.

What may seem like a minor change to the layout, or what would certainly be a minor

change at a lower

frequency of operation, can actually be a significant change at 2.4

GHz. For example, we may consider that a metal trace on a PCB such as the K32W061-

001M1x modules is approximately 0.8 nH per mm. At lower frequencies, this would have

no impact, but at 2.4 GHz this would have a significant impact in any matching circuits.

The circuits used on the NXP reference designs are all tuned and optimized on the

actual layout of the

reference design, such that the final component values take into

account the effects of the circuit board

traces,andotherparasiticeffectsintroducedby

thePCB.Thisincludessuchissuesasparasiticcapacitance

between components,

traces, and/or board copper layers, inductance of traces and ground vias, the non-ideal

effects of components, and nearby physical objects.

SECURITY

STATUS

NXP Semiconductors

JN-RM-2080

K32W module development reference manual

JN-RM-2080

All information provided in this document is subject to legal disclaimers.

Reference manual

Rev. 1.0 —27 Mar 2020

10 of 30

Contact information

For more information, please visit: http://www.nxp.com

The layout of the RF portions of K32W061/041 based modules is critical. It is important

that the reference designs are strictly adhered to, otherwise the following may occur:

•Reduction in RF output

•Excessive spurious RF outputs leading to RF compliance issues

•Unacceptable power slope across the full channel range

•Poor range

•Reduced Rx sensitivity

4.4 Transmission lines

Transmission lines have several shapes such as microstrip, coplanar waveguide,

and strip-line. For BLE applications built on FR4 substrates, the types of

transmission lines typically take the form of microstrip or coplanar waveguide

(CPW). These two structures are defined by the dielectric constant of the board

material, trace width, and the board thickness between the trace and the ground.

Additionally, for CPW, the transmission line is defined by the gap between the trace

and the top edge ground plane. These parameters are used to define the

characteristic impedance of the transmission line (trace) that is used to convey the

RF energy between the radio and the antenna.

K32W061/041 has a single ended RF output with a 3-component matching

network composed of a shunt capacitor, a series inductor then another shunt

capacitor. In addition, a 0-ohm resistor has been placed between the RFIO port of

the chip and the first shunt capacitor. These elements transform the device

impedance to 50 ohms. The value of these components may varydepending on

your specific board layout. The recommended RF matching network is shown in

Figure 7.

Avoid routing traces near or parallel to RF transmission lines or crystal signals.

Maintaining a continuous ground under an RF trace is critical to maintaining the

characteristic impedance of that trace. Avoid any routing on the ground layer that

will result in disrupting the ground under the RF traces.

Keep the RF trace as short as possible.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels NXP Semiconductors Microcontrôleur

NXP Semiconductors

NXP Semiconductors MC68HC16Z1 Manuel utilisateur

NXP Semiconductors

NXP Semiconductors MPC5777M Manuel utilisateur

NXP Semiconductors

NXP Semiconductors UM10883 Manuel utilisateur

NXP Semiconductors

NXP Semiconductors OM-SE051ARD Manuel utilisateur

NXP Semiconductors

NXP Semiconductors SLN-VIZNAS-IOT Manuel utilisateur

NXP Semiconductors

NXP Semiconductors UM10741 Manuel utilisateur

NXP Semiconductors

NXP Semiconductors MPC574xR Series Instructions d'installation et d'utilisation

NXP Semiconductors

NXP Semiconductors LPC29 Series Manuel utilisateur

NXP Semiconductors

NXP Semiconductors MC9S08SU16 Manuel utilisateur

NXP Semiconductors

NXP Semiconductors S32R27 Mode d’emploi

NXP Semiconductors

NXP Semiconductors PN7462AU Manuel utilisateur

NXP Semiconductors

NXP Semiconductors S12VR32EVB Manuel utilisateur

NXP Semiconductors

NXP Semiconductors LEC-IMX8MM Manuel utilisateur

NXP Semiconductors

NXP Semiconductors FRDM665SPIEVB Manuel utilisateur

NXP Semiconductors

NXP Semiconductors Kinetis KE1xZ256 Manuel utilisateur

NXP Semiconductors

NXP Semiconductors Freescale TWR-POS-K81 Manuel utilisateur

NXP Semiconductors

NXP Semiconductors TWR-KL25Z Manuel utilisateur

NXP Semiconductors

NXP Semiconductors MC9S12ZVMB-Family Manuel utilisateur

NXP Semiconductors

NXP Semiconductors MPC5746R Manuel utilisateur

NXP Semiconductors

NXP Semiconductors i.MX31 Manuel utilisateur

NXP Semiconductors

NXP Semiconductors ADC1610S Series Manuel utilisateur

NXP Semiconductors

NXP Semiconductors MC9S08PA4 Manuel utilisateur

NXP Semiconductors

NXP Semiconductors EdgeLock A5000 Instructions d'installation et d'utilisation

NXP Semiconductors

NXP Semiconductors TWR-K70F120M Instructions d'utilisation et d'entretien

Manuels Microcontrôleur populaires d'autres marques

AMS

AMS AS7261 Demo Kit Manuel utilisateur

Novatek

Novatek NT6861 Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266 SDK Guide de configuration

Nuvoton

Nuvoton ISD61S00 ChipCorder Mode d’emploi

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manuel utilisateur

Texas Instruments

Texas Instruments Chipcon CC2420DK Manuel utilisateur

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manuel utilisateur

NEC

NEC 78GK0S/K 1+ Series Instructions d'installation et d'utilisation

Mikroe

Mikroe SEMITECH N-PLC Click Instructions d'installation et d'utilisation

Intel

Intel Agilex Manuel utilisateur

Cypress

Cypress CY4607 HX2VL Manuel utilisateur

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manuel utilisateur

Texas Instruments

Texas Instruments TMS320F2837 D Series Manuel utilisateur

CYPRES

CYPRES CY14NVSRAMKIT-001 Manuel utilisateur

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266EX Mode d'emploi

Abov

Abov AC33M8128L Manuel utilisateur

Laird

Laird BL654PA Manuel utilisateur
