Norac UC5 Topcon X30 Manuel utilisateur

Spray Height

ontroller

Miller Condor

Monobeam

Installation Manual

MC01

Printed in Canada

Reorder P/N UC5-BC-MC01-INST Rev A (Miller Condor Monobeam)

NOTICE: NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and without

the requirement to update products sold previously. Every effort has been made to ensure the accuracy of the information contained in this

manual. The technical information in this manual was reviewed at the time of approval for publication.

Contents

1 Introduction.............................................................................................................. 1

2 General UC5 System Layout .................................................................................. 2

3 it Parts.................................................................................................................... 3

4 Pre-Install Checklist ................................................................................................ 7

5 Ultrasonic Sensor Installation................................................................................. 8

6 Roll Sensor Installation ......................................................................................... 13

7 Module Installation................................................................................................ 16

8 Connecting the Sensors to the CANbus ............................................................... 20

9 Hydraulic Installation............................................................................................ 21

10 Software Setup ....................................................................................................... 24

11 Cable Drawings ...................................................................................................... 25

1 Introduction

Congratulations on your purchase of the NORAC UC5 Spray Height Controller. This system is

manufactured with top quality components and is engineered using the latest technology to

provide operating reliability unmatched for years to come.

When properly used the system can provide protection from sprayer boom damage, improve

sprayer efficiency, and ensure chemicals are applied correctly.

Please take the time to read this manual completely before attempting to install the system. A

thorough understanding of this manual will ensure that you receive the maximum benefit from

the system.

Your input can help make us better! If you find issues or have suggestions regarding the parts

list or the installation procedure, please don’t hesitate to contact us.

Phone 1 800 667 3921 Canada (Toll Free)

1 866 306 6722 United States (Toll Free)

(+33) 06 03 87 80 78 Europe

(+1) 306 664 6711 All other regions

E-mail [email protected]

Web www.norac.ca

Every effort has been made to ensure the accuracy of the information contained in this

manual. All parts supplied are selected to specially fit the sprayer to facilitate a complete

installation. However, NORAC cannot guarantee all parts fit as intended due to the

variations of the sprayer by the manufacturer.

Please read this manual in its entirety before attempting installation.

2 General UC5 System Layout

Figure 1 illustrates the general layout of the UC5 system components

Figure 1: General UC5 System Layout

The use of dielectric grease is not recommended on any NORAC electrical connections.

To ensure all stainless steel hardware does not gall or seize apply a light coating of the

supplied Permatex Anti-seize grease to all threaded parts upon installation. Permatex Anti-

seize lubricant is preferred, but other similar anti-seize products may be used.

3 Kit Parts

3.1 Kit Overview

Figure 2: MC01 System Parts

3.2 ydraulic Plumbing

Figure 3: MC01 Hydraulic Plumbing

3.3 List of Parts

Item Part Number Name Quantity

B05 44706-01 KIT CABLE TIE BLACK 10 PCS 21 IN 150 PCS 7 5 IN 1

B10 44729 MOUNTING BRACKET NITRO UNIVERSAL SPRING BREAKAWAY 2

B11 44743 MOUNTING BRACKET MAIN LIFT SENSOR UC4 PLUS 1

C01 43220-10 CABLE UC5 NETWORK 14 AWG 10M 1

C02 43220-01 CABLE UC5 NETWORK 14 AWG 1M 1

C03 43210-03 CABLE UC5 NETWORK 18 AWG 3M 1

C04 43210-01 CABLE UC5 NETWORK 18 AWG 1M 2

C05 43210-20 CABLE UC5 NETWORK 18 AWG 20M 2

C10 43230-04 CABLE UC5 VALVE 2PIN DT TO 2PIN DT 4

C20 43240-33 CABLE UC5 INTERFACE TILT GP (REVERSED POLARITY) 1

C21 43240-32 CABLE UC5 INTERFACE MAIN GP (REVERSED POLARITY) 1

C30 43250-06 CABLE UC5 BATTERY PIGTAIL FUSED 1

E01 43710 UC5 CONTROLLER MODULE 1

E02 43720 UC5 VALVE MODULE 1

E03 43732 UC5 INPUT MODULE PASS THRU 1

E04 43740 UC5 ROLL SENSOR 3

E05 43750 UC5 ULTRASONIC SENSOR 3

E11 43765 UC5 NETWORK COUPLER 8-WAY 1

E12 43764 UC5 NETWORK COUPLER 2-WAY 2

E20 43764T UC5 NETWORK COUPLER 2-WAY WITH TERMINATOR 2

H01 44863-51 HOSE ASSEMBLY 122R2-06 31IN L 6FORX 8FORX 2

H02 44862-52 HOSE ASSEMBLY 122R2-06 24IN L 6FORX 8FORX90 2

H10 44865-59 HYDRAULICS FITTING KIT - MC01 & MC02 1

M02 UC5-BC-MC01-INST MANUAL INSTALLATION UC5 MILLER CONDOR MONOBEAM 1

P01 106034 UC5 NETWORK 2 PIN PLUG 4

P02 106035 UC5 NETWORK 12 PIN PLUG (A-KEY) 1

P03 106162 UC5 NETWORK 6 PIN PLUG 1

V01 44963D VALVE BLOCK ASSEMBLY 2 STATION CC/LS PROP DT 4 BOLT 1

3.4 ydraulic Fitting Kit Details (P/N: 44865-59)

Item Part Number Name Quantity


F01 106314 MALE ADAPTER - 8MB 8MOR 2

F02 104590 90 DEGREE ADAPTER - 6MOR 6FORX90 4

F03 44917 MALE TO MALE ADAPTER - 6MB 6MOR 4

F04 104885 TEE ADAPTER - 8FORXR 8MORT 2

F05 104369 PLUG - 6MBP 2

F06 104884 MALE TO FEMALE ADAPTER - 6MOR 8FORX 2

F07 106156 MALE TO FEMALE ADAPTER - 8MOR 6FOR 2

F08 105184 018" INLINE ORIFICE - O-RING GROOVE ON FACE 2

F09 104592 O-RING HYD 3/8 IN FLAT FAC 2

F10 44928 ORIFIC INS RT .047 IN ON WAY 2

6 M B - 6 M OR X 90

SIZ IN

1/16

TH'S

G ND R: MAL

OR F MAL

90° ANGL

SWIV L

TYP

G ND R

SIZ

TYP :

B - ORB

J - JIC

OR - FLAT

FAC

P - PIP

Fitting Name

xample:

4 Pre-Install Checklist

The pre-install checklist is necessary to check the existing sprayer functionality before the

installation.

1. Unfold the sprayer over a flat, unobstructed area (i.e. no power lines…etc.).

2. Ensure all boom-fold operations are functional (place a check mark in boxes below).

3. Bring engine to field-operational RPM and record below.

4. Record the time (seconds) it takes for a full stroke for all boom functions. To ensure

repeatable measurements, take the average of 3 trials.

5. Not all sprayers will have the functions listed below in Figure 4.

Ensure the boom has sufficient travel so it does not contact the ground during these tests.

Figure 4: Pre-Install Boom Speeds
