Norac Case AFS Pro 600 Manuel utilisateur
Spray Height Controlle
r
Case AFS Pro 600
Display Kit
In
sta
ll
at
i
o
n
M
a
n
ua
l
PRO600
Printed in Canada
Copyright 2010 by NORAC Systems International Inc.
Reorder P/N: 54VT-PRO600-INST Rev B (Case AFS PRO 600 Display Kit)
NOTICE: NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and
without the requirement to update products sold previously. Every effort has been made to ensure the accuracy of the information
contained in this manual. The technical information in this manual was reviewed at the time of approval for publication.
1
Contents
1INTRODUCTION .............................................................................................2
1.1 VT Software Version................................................................................................................................................. 2
1.2 List of Parts................................................................................................................................................................. 2
2INSTALLATION ...............................................................................................3
2.1 Self Propel ................................................................................................................................................................... 3
2.2 Switch Box Installation ............................................................................................................................................. 4
3CABLE DRAWINGS.........................................................................................5
3.1 ITEM C01: 43220-01 - CABLE UC5 NETWORK 14 AWG - 1M .................................................................. 5
3.2 ITEM C30: 43250-14 – CABLE UC5 BATTERY 2 PIN DT............................................................................. 5
3.3 ITEM C25: 44602-01 – SWITCH REMOTE HAND CONTROL.................................................................. 6
3.4 ITEM C26: 43240-26 – CABLE UC5 SWITCH BOX....................................................................................... 7
3.5 ITEM C40: 43260-07 – CABLE UC5 CAN BUS 3 PIN DT J1939 ................................................................. 8
APPENDIX A: ALTERNATE CONFIGURATION ............................................9
2
1Introduction
The Case AFS Pro 600 Display Kit Manual is intended to be used in conjunction with the UC5
Spray Height Control Installation Manual. This manual provides instructions to interface the
UC5 Control Module to the Case AFS Pro 600 Display. For installation of the rest of the UC5
Spray Height Control System please refer to the sprayer specific manual provided with the kit.
1.1 VT Software Version
Before you connect the UC5 to the Case AFS Pro 600, you must ensure that you have the
latest Pro 600 software installed. The Pro 600 software must be Version 25 or newer.
1.2 List of Parts
Item Part Number Name Quantity
C01 43220-01 CABLE UC5 NETWORK 14 AWG 1M 1
C25 44602-01 BOX SWITCH UC4 REMOTE HAND CONTROL VER.1 RMR 1
C26 43240-26 CABLE UC5 INTERFACE SWITCH BOX 1
C30 43250-14 CABLE UC5 BATTERY 2 PIN DT FUSED (ECU & SIG) 1
C40 43260-07 CABLE UC5 INTERFACE CAN BUS 3 PIN DT J1939 1
M01 UC5-BC-MANUAL-VT MANUAL UC5 OPERATORS - VIRTUAL TERMINAL 1
M04 54VT-PRO600-INST MANUAL UC5 DISPLAY KIT CASE AFS PRO 600 1
3
2Installation
The following instructions are for installation on a self propelled sprayer.
2.1 Self Propel
1. Securely mount the control module (E01) on the center boom at the rear of the sprayer.
2. Tee the CANbus interface cable (C40) in to the Case “Application” CANbus. The
“Application” CANbus is a 3 pin Deutsch connector located on the center section of the
boom at the rear of the sprayer.
3. Connect the Deutsch plug on cable C40 to the end of the control module with only one
Deutsch connector.
4. Connect the power cable (C30) to one of the two CANbus connectors on the control
module. Connect the 2 pin DT connector on C30 to a 15A, +12 VDC source.
5. Connect cable C01 to the other CANbus connector and route the cable to the Valve
Module.
Figure 1: Case AFS Pro 600 Display Kit – Self Propelled Sprayer
4
2.2 Switch Box Installation
1. Disconnect cable C20 (grey side connector) from the Input Module (E03). Remove the
wedge from the face of the 12 pin Deutsch plug.
2. Insert the Roll CW pin from C26 into position 3 of the 12 pin plug on C20. Insert the Roll
CCW pin from C26 into position 4 of the 12 pin plug on C20. Insert the wedge back into
the plug. Connect C20 to the grey side connector on the Input Module.
3. Connect the 12 pin Deutsch plug on C26 to the grey end connector on the input module.
Route the other end of the cable to the hitch of the sprayer (pull type) or to the cab (self
propelled).
4. Attach the switch box (C25) inside the cab and connect it to cable C26. An extra label is
provided with the switch box if you prefer to remove the switches from the housing and
mount them in the existing sprayer switch panel.
* Some sprayer types may not use all the switch functions.
* Refer to “Appendix A” for sprayers with European style slant control.
Figure 2: Switch Box Installation
5
3Cable Drawings
3.1 ITEM C01: 43220-01 - CABLE UC5 NETWORK 14 AWG - 1M
3.2 ITEM C30: 43250-14 – CABLE UC5 BATTERY 2 PIN DT
6
3.3 ITEM C25: 44602-01 – SWITCH REMOTE HAND CONTROL
7
3.4 ITEM C26: 43240-26 – CABLE UC5 SWITCH BOX
8
3.5 ITEM C40: 43260-07 – CABLE UC5 CAN BUS 3 PIN DT J1939
