Norac UC4+ Raptor Pro 1200 Manuel utilisateur
Raptor Pro 1200 (2004)
Installation Manual
Spray Height Controller
Improving the competitiveness o Industry and
Agriculture through Precision Measurement
Printed in Canada
Copyright 2005-08 by NORAC Systems International Inc
Reorder P/N: UC4+BC+RP1-INST Rev E (Raptor Pro 1200)
NOTICE
NORAC Systems International Inc reserves the right to improve products and their specifications without notice and without the requirement to update
products sold previously Every effort has been made to ensure the accuracy of the information contained in this manual The technical information in
this manual was reviewed at the time of approval for publication
TABLE OF CONTENTS
1
INTRODUCTION..................................................................................................................................................1
2
GENERAL SYSTEM DESCRIPTION ..................................................................................................................2
3
PARTS LISTS ......................................................................................................................................................3
4
INSTALLATION PROCEDURE ...........................................................................................................................8
4.1
EXISTING SYSTEM CHECK ...............................................................................................................................8
4.2
BOOM SPEED TEST........................................................................................................................................8
4.3
WING SENSOR INSTALLATION.......................................................................................................................10
4.4
MAIN LIFT SENSOR INSTALLATION................................................................................................................13
4.5
ROLL SENSOR INSTALLATION.......................................................................................................................14
4.5.1
Boom Frame Roll Sensor Mounting 15
4.5.2
Chassis Roll Sensor Mounting 16
4.
HYDRAULIC INSTALLATION ...........................................................................................................................17
4.6.1
Valve Assembly 1
4.6.2
Valve Mounting 18
4.6.3
Hydraulic Plumbing 19
4.7
ELECTRICAL INSTALLATION ..........................................................................................................................20
4.8
COMPLETING THE INSTALLATION ..................................................................................................................24
5
ELECTRICAL REFERENCE – CABLE DRAWINGS........................................................................................25
5.1
ITEM C01: 44 2B-40 – SENSOR TRUNK CABLE .........................................................................................25
5.2
ITEM C02: 44 8 – SENSOR BRANCH CABLE...............................................................................................25
5.3
ITEM C02B: 44 4 – CABLE UC4 CAN NODE DUAL....................................................................................2
5.4
ITEM C03: 44 5 D – CABLE VALVE VARIABLE RATE DT..............................................................................2
5.5
ITEM C04: 44 51 – VALVE EXTENSION CABLE .............................................................................................27
5.
ITEM C10: 44 50-33 – POWER CABLE UC3 BOOM RP1 ..............................................................................27
5.7
ITEM C12: 44 58-11 – BC RP1 VALVE CABLE ............................................................................................28
1
1
INTRODUCTION
Congratulations on your purchase of the NORAC UC4+ Spray Height Controller This system is
manufactured with top quality components and is engineered using the latest technology to provide
operating features and reliability unmatched for years to come
When properly used the system can provide protection from sprayer boom damage, improve sprayer
efficiency, and ensure chemicals are applied correctly
Please take the time to read this manual completely before attempting to install the system A thorough
understanding of this manual will ensure that you receive the maximum benefit from the system
YOUR INPUT CAN HELP MAKE US BETTER! If you find issues or ha e suggestions regarding
the parts list or the installation procedure, please don’t hesitate to contact us ia the information
gi en below:
Phone: 1-800-667-3921 Canada (Toll Free)
1-866-306-6722 United States (Toll Free)
(+33) 06 03 87 80 78 Europe
1-306-664-6711 all other regions
E-mail: ser [email protected]
Website: www.norac.ca
2
2
GENERAL SYSTEM DESCRIPTION
Figure 1 depicts the general system layout of the UC4+ Spray Height Control system
Figure 1 – System Components and General Location
NOTICE:
Every effort has been made to ensure the
accuracy of the information contained in this
manual All parts supplied are selected specially
to fit the sprayer to facilitate a complete
installation However, NORAC cannot
guarantee all parts fit as intended due to the
variations of the sprayer by the manufacturer
Please read this manual in its entirety before
attempting installation.
ATTENTION:
When installing the UC4+ Spray Height Control
system please be aware that at a point in the
installation your sprayer booms will be
inoperative until the installation is complete
Any installation procedure requiring boom
mo ement will need to be done first. Once the
hydraulics have been disconnected you must
complete the electrical installation before the
booms become operative
3
3
PARTS LISTS
The parts that come with your UC4+ Sprayer Boom System are listed in Table 1. The item number on
the left side of this table references each part
Please ensure that all parts in your kit are present before proceeding with your installation.
Table 1 – Raptor Pro 1200 Spray Height Control system Parts
Item Part Number Name Quantity
B05 44706-01 KIT CABLE TIE BLACK 10 PCS 21 IN 150 PCS 7 5 IN 1
B10 44700-06 BRACKET VALVE MOUNTING STD 1
B11 44743 MOUNTING BRACKET MAIN LIFT SENSOR UC4 PLUS 1
B13 44728 MOUNTING BRACKET COMPLETE UC4 BREAKAWAY EXTENDED 2
C01 44662B-40 CABLE UC3 SENSOR TRUNK AMPF TO AMPF BLACK STANDARD 40FEET 1
C02 44668 CABLE UC3 SENSOR BRANCH 1 AMP RECEPT 3 AMP PLUG BC 1
C02B 44664 CABLE UC4 CAN NODE DUAL 1
C03 44656D CABLE VALVE VARIABLE RATE DT 1
C04 44651 CABLE VALVE EXTENSION 1
C10 44650-33 CABLE POWER UC3 BOOM CONTROL RP1 1
C12 44658-11 CABLE UC4 VALVE BC RP1 1
E01 4461BC+ UC4 PLUS BOOM CONTROL PANEL 1
E02 44631 UC4 ULTRASOUND SENSOR 3
E03 44641 UC4 PLUS ROLL SENSOR W TEMPERATURE PROBE 1
E04 44642 UC4 PLUS ROLL SENSOR 1
H02 44862-08 HOSE ASSEMBLY 122R2-04 36 IN L 6FORX 6FORX 2
H20 44865-28 HYDRAULICS FITTING KIT - RP1 1
M01 446BC+MAN7 OPERATOR MANUAL UC4+ SPRAY HEIGHT CONTROL 1
M10 UC4+BC+RP1-INST MANUAL INSTALLATION UC4+ RAPTOR 1
V01 44963D VALVE BLOCK ASSEMBLY 2 STATION CC/LS PROP DT 4 BOLT 1
4
Substitution parts will in no way affect the operation of the system pro ided that they are installed
as directed.
Item V01 – 2 Station Val e Block (44963D) may be substituted with:
Item Part Number Name Quantity
V01 44933D VALVE BLOCK ASSEM UC4-BC 2-STATION CC/LS VARIABLE RATE 1
The 44933D is a direct replacement for the 44963D Both valve blocks function the same The blocks
are identifiable by the filter cap shape and by the part number stamped on the side
The A and B ports are opposite on each al e block so erify that the hoses are being connected to
the correct port. The raise lines always go to the “B” port and the lower lines go to the “A” port.
44933D Val e Block Shown Alongside 44963D Val e Block
Filter Cap Part Number
(44933D)
Filter Cap Part Number
(44963D)
5
Table 2 – 44865-28 - Hydraulics Fittings Kit
Item Part Number Name Quantity Picture
F02 104369 PLUG - 6MBP 4
F03 104586 TEE ADAPTER - 6FORXR 6MORT 2
F04 44917 MALE ADAPTER - 6MB-6MOR MACHINED ORB 4
F06 44928 ORIFICE INSERT 047 IN ONE WAY 2
6 M B - 6 M OR X 90
SIZE IN
1/16
TH'S
GENDER: MA E
OR FEMA E
90
°
ANG E
SWIVE
TYPE
GENDER
SIZE
TYPE:
B - ORB
J - JIC
OR - F AT
FACE
P - PIPE
Fitting Name
Example:
The use of dielectric grease is not recommended on any NORAC electrical connections.
To ensure all stainless steel hardware does not gall or seize apply a light coating of the supplied
Permatex Anti-seize grease to all threaded parts upon installation. Permatex Anti-seize lubricant is
preferred, but other similar anti-seize products may be used.
6
The parts that come with your UC4+ Spray Height Control system are shown below in their general
installation configuration.
Figure 2 – UC4+ Spray Height Control Components
7
Figure 3 – Hydraulic Components
