NCR RealPOS 25 Mode d'emploi

SITE PREPARATION GUIDE

NCR RealPOS 25 (7610)POS

Release 2.0

B005-0000-2018

Issue C

The product described in this book is a licensed product of NCR Corporation.

NCR is a registered trademark of NCR Corporation. NCR RealPOS is a trademark of NCR Corporation in the United States

and/or other countries. Other product names mentioned in this publication may be trademarks or registered trademarks of their

respective companies and are hereby acknowledged.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks

of HDMI Licensing LLC in the United States and other countries.

Where creation of derivative works, modifications or copies of this NCR copyrighted documentation is permitted under the terms

and conditions of an agreement you have with NCR, NCR's copyright notice must be included.

It is the policy of NCR Corporation (NCR) to improve products as new technology, components, software, and firmware become

available. NCR, therefore, reserves the right to change specifications without prior notice.

All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances,

photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR

office for information that is applicable and current.

To maintain the quality of our publications, we need your comments on the accuracy, clarity, organization, and value of this book.

Please use the link below to send your comments.

Documentation Feedback

By NCR Corporation

Duluth, GA U.S.A.

iii

Preface

Audience

This book is written for hardware installer/service personnel, system integrators, and

field engineers.

Notice: This document is NCR proprietary information and is not to be disclosed or

reproduced without consent.

Safety Requirements

The NCR RealPOS 25 conforms to all applicable legal requirements. To view the

compliance statements see the NCR RealPOS Terminals Safety and Regulatory Statements

(B005-0000-1589).

Caution: The on/off switch is a logic switch only. The AC line voltage primaries are

live at all times when the power cord is connected. Therefore, disconnect the AC power

cord before opening the unit to install features or service this terminal.

Caution: This product does not contain user serviceable parts. Servicing should only

be performed by a qualified service technician.

Fuse Replacement

Warning: For continued protection against risk of fire, replace only with the same

type and ratings of fuse.

Attention: Pour prévenir et vous protéger contre un risque de feu, remplacer la fusible

avec une autre fusible de même type, seulement.

Lithium Battery Warning

Warning: Danger of explosion if battery is incorrectly replaced. Replace only with

the same or equivalent type as recommended by the manufacturer. Discard used

batteries according to the manufacturer's instructions.

Attention: Il y a danger d'explosion s'il y a remplacement incorrect de la batterie.

Remplacer uniquement avec une batterie du même type ou d'un type recommandé par

le constructeur. Mettre au rébut les batteries usagées conformément aux instructions du

fabricant.

Battery Disposal (Switzerland)

Refer to Annex 4.10 of SR814.013 for battery disposal.

IT Power System

This product is suitable for connection to an IT power system with a phase-to-phase

voltage not exceeding 240 V.

Peripheral Usage

This terminal should only be used with peripheral devices that are certified by the

appropriate safety agency for the country of installation (UL, CSA, TUV, VDE) or those

which are recommended by NCR Corporation.

Warning: DO NOT connect or disconnect the transaction printer while the terminal

is connected to AC power. This can result in system or printer damage.

Warning: DO NOT connect or disconnect any serial peripherals while the terminal

is connected to AC power. This can result in system or printer damage.

Grounding Instructions

In the event of a malfunction or breakdown, grounding provides a path of least

resistance for electric current to reduce the risk of electric shock. This product is

equipped with an electric cord having an equipment-grounding conductor and a

grounding plug. The plug must be plugged into a matching outlet that is properly

installed and grounded in accordance with all local codes and ordinances. Do not

modify the plug provided – if it will not fit the outlet, have the proper outlet installed by

a qualified electrician. Improper connection of the equipment-grounding conductor can

result in a risk of electric shock.

The conductor with insulation having an outer surface that is green with or without

yellow stripes is the equipment-grounding conductor.

If repair or replacement of the electric cord or plug is necessary, do not connect the

equipment-grounding conductor to a live terminal. Check with a qualified electrician or

service personnel if the grounding instructions are not completely understood, or if you

are in doubt as to whether the product is properly grounded.

Use only 3-wire extension cords that have 3-prong grounding plugs and 3-pole

receptacles that accept the product’s plug. Repair or replace damaged or worn cords

immediately.

References

•NCR RealPOS 25 User Guide (B005-0000-2017)

•NCR RealPOS 25 Hardware Service Manual (B005-0000-2019)

•NCR RealPOS 25 Parts Identification Manual (B005-0000-2020)

Table of Contents

NCR RealPOS 25 Terminal Site Preparation

Introduction 1

Product IDs 1

Customer Responsibilities 2

Third Party Peripheral Certification 3

LAN Communications 3

Environmental Requirements 4

Barometric Pressure 4

Temperature 4

Humidity 4

Dimensions 5

Terminal w/MSR 5

Terminal and Table Top Stand Dimensions 6

Terminal and Table Top Stand w/Power Supply Enclosure 6

Terminal w/Customer Display Dimensions 7

7409-K502 Flush Wall Mount Dimensions 7

VESA Mounting Hole Dimentions 8

NCR 5943 LCD / 5967 12-Inch Touch LCD Dimensions 9

5943 LCD / 5967 15-Inch Touch LCD Dimensions 9

NCR 5976 2x20 LCD Dimensions 10

Tall Pole Mount 11

Base Plate Mounting Hole Dimensions 12

NCR 5982 6.5-Inch LCD Dimensions 12

Power Supply Dimensions 13

Power Supply Bracket 13

NCR 5932-5xxx USB Big Ticket POS Keyboard Dimensions 14

5932-65xx PS/2 Compact Keyboard Dimensions 14

NCR 5932-66xx USB Compact Keyboard Dimensions 15

NCR 7167 Printer Dimensions 15

NCR 7168 Printer Dimensions 16

NCR 7197 Thermal Receipt Printer Dimensions 16

NCR 7198 Thermal Receipt Printer Dimensions 17

NCR 2181 Cash Drawer Dimensions 17

NCR 2183 Compact Cash Drawer Dimensions 18

NCR 2185 Flip Top Drawer Dimensions 18

NCR 2186 Compact Cash Drawer Dimensions 19

Component Weights 19

Shipping Weight Estimate 20

Service Clearance Requirements 20

Airflow Requirements 21

Electrical Requirements 22

7610 Terminal Power Requirements 22

Peripheral Power Requirements 22

AC Store Wiring Requirements 22

Cable Routing 23

Customer Display Configuration 25

Custom Enclosures 26

Appendix A: TransientProtection

AC Power Line Transient Protection 1

Data Line Transient Protection 2

Revision Record

Issue Date Remarks

A Oct 2010 First Issue

B Aug 2012 Release 1.1

C June 2013 Release 2.0

NCR RealPOS 25 Terminal Site Preparation

Introduction

This document provides the information necessary to prepare a site to NCR

specifications prior to installing an NCR RealPOS 25 terminal (also referred to as the

NCR 7610). Prepare the site properly before installing the terminal because site

preparation deficiencies may be difficult to detect and correct after installation.

Product IDs

Major Model CPU

7610-5020 Intel Atom D2550 Dual Core 1.86G Hz, 2 GB DDR3, Diskless

2 NCR RealPOS 25 Terminal Site Preparation

Customer Responsibilities

Before installing the system, the customer must perform or provide the following:

• When required by NCR, provide the NCR Customer Services representative with

appropriate drawings that indicate:

• Equipment location

• Site wiring (power and communications, paths and lengths)

• Location of other equipment that may generate electrical noise, electromagnetic

interference, or heat

• Make building alterations necessary to meet wiring and other site requirements

• Provide and install all communications cables, wall jacks, special connectors, and

associated hardware

• Provide and install necessary power distribution boxes, conduits, grounds, lightning

protection devices, and associated hardware

• Ensure all applicable codes, regulations, and laws (including, but not limited to,

electrical, building, safety, and health) are met

• Provide and install auxiliary power or other equipment as required

• Provide storage or service areas as required

• Meet all system/unit environmental requirements

• Provide and install floor coverings and environment systems that limit or control

static electricity build-up and discharge

In general, keep the NCR equipment area free from dust, smoke, lint, and other

particles. Restrict smoking, eating, and drinking around the equipment. Avoid locating

the equipment near other machines that generate ink, carbon, and paper dust particles.

NCR RealPOS 25 Terminal Site Preparation 3

Third Party Peripheral Certification

Third party peripherals must be certified with the POS terminal or a potential ESD issue

can occur. Third party peripherals include any electrically powered devices connected

to the POS terminal that is not an NCR branded product or a certified solution

advocated by NCR. Examples of third party products include printers, external CD-

ROM drives, cash drawers, cigarette boxes, pin pad devices, etc.

Peripherals tend to be less sensitive to electrostatic damage when directly grounded

through their power cords. If the peripheral is powered by the terminal and has no

dedicated ground, then all of the ESD energy is coupled into the port connection. Some

devices may require the use of an in-line galvanic isolator/surge protector in order to

prevent problems.

The NCR TPP/SCER process is designed to evaluate third party peripherals and

determine whether additional protective devices are needed.

The NCR Workstation and Peripherals AC Wiring Guide (BST0-2115-53) contains additional

information on this subject.

LAN Communications

The NCR 7610 Terminal supports Ethernet 10/100/1000baseT Local Area Network (LAN)

communication protocol. For Ethernet communications wiring specifications, refer to

the NCR Ethernet Communication Wiring Guide (BST0-2118-82).

4 NCR RealPOS 25 Terminal Site Preparation

Environmental Requirements

Barometric Pressure

The terminal operates within the following barometric pressure conditions:

• Maximum operating altitude: 3,000 m (9,843 ft.)

• Operating range of pressure: 105 to 69 kPa (15.2 to 10.0 lb./in.)

Temperature

The terminal operates over the temperature ranges shown below. Avoid continuous

operation at, near the indicated temperature extremes, or in locations where the

temperature changes beyond the restrictions.

Temperature Parameter Restriction

Operating 5°C to 40°C (41°F to 104°F), dry bulb

Storage -10°C to 50°C (14°F to 122°F), three months

Shipping -40°C to 60°C (-40°F to 140°F), one week

Humidity

The terminal operates within the humidity ranges shown below. Avoid continuous

operation at, near the indicated humidity extremes, or in locations where the humidity

changes beyond the restrictions. Never expose the terminal to condensation.

Humidity Type Restriction

Relative 10% to 90%

Maximum change rate 10%/60 minutes

Storage 10% to 90% relative humidity, three months

Shipping 5% to 95% relative humidity, one week

Autres manuels pour RealPOS 25

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels NCR Terminal tactile

Manuels Terminal tactile populaires d'autres marques

Wincor Nixdorf

Wincor Nixdorf iPOS plus Advanced Manuel utilisateur

Ingenico

Ingenico AXIUM EX4000 Manuel utilisateur

Heisei Electronics

Heisei Electronics Q-POS 815 Manuel utilisateur

Amano

Amano MTX-15 Manuel utilisateur

FLOWBIRD

FLOWBIRD CWT Compact Touch Manuel utilisateur

Demco

Demco SP7 Manuel utilisateur

Lathem

Lathem PC600 Series Manuel utilisateur

Partner

Partner MF-2352 Manuel utilisateur

Simrad

Simrad MS50 Instructions de montage

Unitech

Unitech MR350 MKII Guide de démarrage rapide

Jungheinrich

Jungheinrich WMT 210 Manuel utilisateur

Motorola

Motorola MTP850 Manuel utilisateur

YASKAWA

YASKAWA 62H-MDC0 Manuel utilisateur

MVG industries

MVG industries NeptuLink Manuel utilisateur

Price Industries Limited

Price Industries Limited FDC Manuel d'instructions

Honeywell

Honeywell TemaKey Manuel utilisateur

EBN

EBN BPC65-B-A16G Manuel utilisateur

Prestel

Prestel VCS-G2PRO Manuel utilisateur
