GETTING STARTED GUIDE

NI 9262

1 MS/s/ch Simultaneous, ±10 V, 6-Channel

C Series Voltage Output Module

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

This document explains how to connect to the NI 9262.

Note Before you begin, complete the software and

hardware installation procedures in your chassis

documentation.

Note The guidelines in this document are specific to

the NI 9262. The other components in the system might

not meet the same safety ratings. Refer to the

documentation for each component in the system to

determine the safety and EMC ratings for the entire

system.

Safety Guidelines

Operate the NI 9262 only as described in this document.

Caution This icon denotes a caution, which advises

you to consult documentation where this symbol is

marked.

Caution Do not operate the NI 9262 in a manner not

specified in this document. Product misuse can result in

a hazard. You can compromise the safety protection

2| ni.com | NI 9262 Getting Started Guide

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

built into the product if the product is damaged in any

way. If the product is damaged, return it to NI for

repair.

Safety Guidelines for Hazardous Voltages

If hazardous voltages are connected to the device, take the

following precautions. A hazardous voltage is a voltage greater

than 42.4 Vpk voltage or 60 V DC to earth ground.

Caution Ensure that hazardous voltage wiring is

performed only by qualified personnel adhering to local

electrical standards.

Caution All wiring must be insulated for the highest

voltage used.

Caution Do not mix hazardous voltage circuits and

human-accessible circuits on the same module.

Caution Ensure that devices and circuits connected to

the module are properly insulated from human contact.

Caution When module terminals are hazardous

voltage LIVE (>42.4 Vpk/60 V DC), you must ensure

NI 9262 Getting Started Guide | © National Instruments | 3

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

that devices and circuits connected to the module are

properly insulated from human contact.

NI 9262 Safety Voltages

Connect only voltages that are within the following limits.

AO-to-COM ±30 V maximum

Isolation

Channel-to-channel None

Channel-to-earth ground

Continuous 60 V DC,

Measurement Category I

Withstand 1,000 V RMS, verified by a 5 s

dielectric withstand test

Measurement Category I is for measurements performed on

circuits not directly connected to the electrical distribution system

referred to as MAINS voltage. MAINS is a hazardous live

electrical supply system that powers equipment. This category is

for measurements of voltages from specially protected secondary

circuits. Such voltage measurements include signal levels, special

4| ni.com | NI 9262 Getting Started Guide

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

equipment, limited-energy parts of equipment, circuits powered

by regulated low-voltage sources, and electronics.

Caution Do not connect the NI 9262 to signals or use

for measurements within Measurement Categories II,

III, or IV.

Note Measurement Categories CAT I and CAT O are

equivalent. These test and measurement circuits are for

other circuits not intended for direct connection to the

MAINS building installations of Measurement

Categories CAT II, CAT III, or CAT IV.

Safety Guidelines for Hazardous Locations

The NI 9262 is suitable for use in Class I, Division 2, Groups A,

B, C, D, T4 hazardous locations; Class I, Zone 2, AEx nA IIC T4

Gc and Ex nA IIC T4 Gc hazardous locations; and nonhazardous

locations only. Follow these guidelines if you are installing the

NI 9262 in a potentially explosive environment. Not following

these guidelines may result in serious injury or death.

Caution Do not disconnect I/O-side wires or

connectors unless power has been switched off or the

area is known to be nonhazardous.

NI 9262 Getting Started Guide | © National Instruments | 5

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Caution Do not remove modules unless power has

been switched off or the area is known to be

nonhazardous.

Caution Substitution of components may impair

suitability for Class I, Division 2, or Zone 2.

Caution The system must be installed in an enclosure

certified for the intended hazardous (classified)

location, having a tool secured cover/door, where a

minimum protection of at least IP54 is provided.

Special Conditions for Hazardous Locations Use in

Europe and Internationally

The NI 9262 has been evaluated as Ex nA IIC T4 Gc equipment

under DEMKO 12 ATEX 1202658X and is IECEx UL 14.0089X

certified. Each NI 9262 is marked II 3G and is suitable for use

in Zone 2 hazardous locations, in ambient temperatures of -40 °C

≤ Ta ≤ 70 °C. If you are using the NI 9262 in Gas Group IIC

hazardous locations, you must use the device in an NI chassis that

has been evaluated as Ex nC IIC T4, Ex IIC T4, Ex nA IIC T4, or

Ex nL IIC T4 equipment.

6| ni.com | NI 9262 Getting Started Guide

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Caution Transient protection shall be provided that is

set at a level not exceeding 140% of the peak rated

voltage value of 85 V at the supply terminals to the

equipment.

Caution The system shall only be used in an area of

not more than Pollution Degree 2, as defined in

IEC/EN 60664-1.

Caution The system shall be mounted in an

ATEX/IECEx-certified enclosure with a minimum

ingress protection rating of at least IP54 as defined in

IEC/EN 60079-15.

Caution The enclosure must have a door or cover

accessible only by the use of a tool.

Electromagnetic Compatibility Guidelines

This product was tested and complies with the regulatory

requirements and limits for electromagnetic compatibility (EMC)

stated in the product specifications. These requirements and

limits provide reasonable protection against harmful interference

when the product is operated in the intended operational

electromagnetic environment.

NI 9262 Getting Started Guide | © National Instruments | 7

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

This product is intended for use in industrial locations. However,

harmful interference may occur in some installations, when the

product is connected to a peripheral device or test object, or if the

product is used in residential or commercial areas. To minimize

interference with radio and television reception and prevent

unacceptable performance degradation, install and use this

product in strict accordance with the instructions in the product

documentation.

Furthermore, any changes or modifications to the product not

expressly approved by National Instruments could void your

authority to operate it under your local regulatory rules.

Caution To ensure the specified EMC performance,

operate this product only with a double-shielded cable.

Connect the inner shield to COM and the outer shield

to chassis.

Special Conditions for Marine Applications

Some products are Lloyd’s Register (LR) Type Approved for

marine (shipboard) applications. To verify Lloyd’s Register

certification for a product, visit ni.com/certification and search

for the LR certificate, or look for the Lloyd’s Register mark on

the product.

8| ni.com | NI 9262 Getting Started Guide

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Caution In order to meet the EMC requirements for

marine applications, install the product in a shielded

enclosure with shielded and/or filtered power and

input/output ports. In addition, take precautions when

designing, selecting, and installing measurement probes

and cables to ensure that the desired EMC performance

is attained.

Preparing the Environment

Ensure that the environment in which you are using the NI 9262

meets the following specifications.

Operating temperature

(IEC 60068-2-1, IEC 60068-2-2)

-40 °C to 70 °C

Operating humidity

(IEC 60068-2-78)

10% RH to 90% RH,

noncondensing

Pollution Degree 2

Maximum altitude 5,000 m

Indoor use only.

Note Refer to the device datasheet on ni.com/manuals

for complete specifications.

NI 9262 Getting Started Guide | © National Instruments | 9

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Table des matières

Autres manuels National Instruments Unité de contrôle

National Instruments

National Instruments R Series Manuel utilisateur

National Instruments

National Instruments NI PXIe-8374 Manuel utilisateur

National Instruments

National Instruments PXIe-6591R Manuel utilisateur

National Instruments

National Instruments FIELDPOINT FP-1600 Manuel utilisateur

National Instruments

National Instruments NI 9401 Manuel utilisateur

National Instruments

National Instruments NI 9871 Manuel utilisateur

National Instruments

National Instruments NI 6013 Guide de démarrage rapide

National Instruments

National Instruments NI PXI-4220 Manuel utilisateur

National Instruments

National Instruments FieldPoint FP-AO-210 Manuel utilisateur

National Instruments

National Instruments PXI Terminal Block NI TB-2708 Manuel utilisateur

National Instruments

National Instruments SCC-LP Series Manuel utilisateur

National Instruments

National Instruments SCC-A10 Manuel utilisateur

National Instruments

National Instruments FBUS-HSE/H1 LD Manuel utilisateur

National Instruments

National Instruments NI 9802 Manuel utilisateur

National Instruments

National Instruments FP-RLY-422 Manuel utilisateur

National Instruments

National Instruments GPIB-ENET Manuel utilisateur

National Instruments

National Instruments NI 9476E Manuel utilisateur

National Instruments

National Instruments 9775 Manuel

National Instruments

National Instruments NI 9218 Manuel utilisateur

National Instruments

National Instruments FieldPoint FP-1601 Manuel utilisateur

National Instruments

National Instruments NI-9208 Manuel utilisateur

National Instruments

National Instruments NI 9375 Manuel utilisateur

National Instruments

National Instruments 9759 Manuel utilisateur

National Instruments

National Instruments 9225 Manuel

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
