OPERATING INSTRUCTIONS AND
SPECIFICATIONS
NI 9514
Servo Drive Interface Module withFeedback
ni.com/manuals
DeutschFrançais
2|ni.com |NI 9514Operating Instructions and Specifications
This document describes how to use the National Instruments 9514
module and includes specifications and pin assignments for the
NI 9514.
Note The safety guidelines and specifications in this
document are specific to the NI 9514. The other
components in the system may not meet the same safety
ratings and specifications. Refer to the documentation for
each component in the system to determine the safety
ratings and specifications for the entire system.
Related Information
Safety Guidelines
Operate the NI 9501 only as described in these operating
instructions.
NI 9514 Operating Instructions and Specifications |© National Instruments |3
Safety Guidelines for Hazardous Locations
The NI 9514 is suitable for use in Class I, Division 2, Groups A, B,
C, D, T4 hazardous locations; Class I, Zone 2, AEx nA IIC T4 and
Ex nA IIC T4 hazardous locations; and nonhazardous locations
only. Follow these guidelines if you are installing the NI 9514 in a
potentially explosive environment. Not following these guidelines
may result in serious injury or death.
Caution Do not disconnect I/O-side wires or connectors
unless power has been switched off or the area is known to
be nonhazardous.
Caution Do not remove modules unless power has been
switched off or the area is known to be nonhazardous.
Caution Substitution of components may impair
suitability for Class I, Division 2.
Caution For Division 2 and Zone 2 applications, install
the system in an enclosure rated to at least IP 54 as defined
by IEC/EN 60079-15.
4|ni.com |NI 9514Operating Instructions and Specifications
Caution For Division 2 and Zone 2 applications, install a
protection device between the input signal and the Vsup
pin. The device must prevent the Vsup-to-channel voltage
from exceeding 42 V if there is a transient overvoltage
condition.
Special Conditions for Hazardous Locations Use in
Europe and Internationally
This equipment has been evaluated as Ex nA IIC T4 Gc equipment
under DEMKO Certificate No. 07 ATEX 0626664X and is IECEx
UL 14.0089X certified. Each module is marked II 3G and is
suitable for use in Zone 2 hazardous locations, in ambient
temperatures of – 40 °C Ta 70 °C. If you are using the NI 9514
in Gas Group IIC hazardous locations, you must use the device in
an NI chassis that has been evaluated as Ex nC IIC T4, Ex IIC T4,
Ex nA IIC T4, or Ex nL IIC T4 equipment.
Caution You must make sure that transient disturbances
do not exceed 140% of the rated voltage.
Caution The system shall only be used in an area of not
more than Pollution Degree 2, as defined in IEC 60664-1.
NI 9514 Operating Instructions and Specifications |© National Instruments |5
Caution The system shall be mounted in an
ATEX/IECEx-certified enclosure with a minimum ingress
protection rating of at least IP54 as defined in
IEC/EN 60079-15.
Caution The enclosure must have a door or cover
accessible only by the use of a tool.
Electromagnetic Compatibility Guidelines
This product was tested and complies with the regulatory
requirements and limits for electromagnetic compatibility (EMC)
as stated in the product specifications. These requirements and
limits are designed to provide reasonable protection against
harmful interference when the product is operated in its intended
operational electromagnetic environment.
This product is intended for use in industrial locations. As such,
there is no guarantee that harmful interference will not occur in
a particular installation, when the product is connected to a test
object, or if the product is used in residential areas. To minimize
the potential for the product to cause interference to radio and
television reception or to experience unacceptable performance
6|ni.com |NI 9514Operating Instructions and Specifications
degradation, install and use this product in strict accordance with
the instructions in the product documentation.
Furthermore, any changes or modifications to the product not
expressly approved by National Instruments could void your
authority to operate it under your local regulatory rules.
Caution To ensure compliance with the applicable
regulatory requirements, product installation requires
either special considerations or user-installed, add-on
devices. See the product installation instructions for
further information.
Caution The inputs/outputs of this product can be
damaged if subjected to Electrostatic Discharge (ESD). To
prevent damage, industry-standard ESD prevention
measures must be employed during installation,
maintenance, and operation.
Special Guidelines for Marine Applications
Some products are Lloyd’s Register (LR) Type Approved for
marine (shipboard) applications. To verify Lloyd’s Register
certification for a product, visit ni.com/certification and
NI 9514 Operating Instructions and Specifications |© National Instruments |7
search for the LR certificate, or look for the Lloyd’s Register mark
on the product label.
Caution In order to meet the EMC requirements for
marine applications, install the product in a shielded
enclosure with shielded and/or filtered power and
input/output ports. In addition, take precautions when
designing, selecting, and installing measurement probes
and cables to ensure that the desired EMC performance is
attained.
Connecting the NI 9514
The NI 9514 servo drive interface module is part of a family of
C Series motion modules. The module provides servo drive
interface signals for a single axis, a full set of motion I/O including
inputs for a home switch and limit switches, incremental encoder
inputs for position feedback, and 0 to 30 V digital input lines. The
NI 9514 also includes a processor to run the spline interpolation
engine and PID control loop. Working together they produce
smoother motion resulting in precise servo motion control.
8|ni.com |NI 9514Operating Instructions and Specifications
System Connection
The NI 9514 has two connectors, a 15-pin DSUB drive interface
connector and a 20-pin MDR feedback connector. The 15-pin
DSUB includes command signals for interfacing with servo
amplifiers or drives, a 0 to 30 V general-purpose digital input line,
and a 19 to 30 V input for power connection. Refer to Table 1 for
the DSUB connector pin assignments.
Note The remainder of this document does not
distinguish between drives and amplifiers. All
references to drives also apply to amplifiers.
The 20-pin MDR connector includes incremental encoder
feedback inputs, a +5 V output for encoder power, home, limit,
and position compare inputs, an output for position compare, an
additional 19 to 30 V input for power connection, and an additional
0 to 30 V general-purpose digital input line. Refer to Figure 2 for
the MDR connector pin assignments.
Note The NI 9514 requires an external power supply.
You can connect the external power supply to the Vsup
input provided on the DSUB or MDR connector. Do not
connect more than one external power supply to the
module.
NI 9514 Operating Instructions and Specifications |© National Instruments |9
NI 9514 Connection Options
National Instruments offers several options for connecting the
NI 9514 to servo drives. You can use the NI 9514/16 to AKD cable
to connect the NI 9514 to the AKD analog servo drive and AKM
series servo motors from NI. To connect to third-party servo drives
use the NI 951x Cable and Terminal Block Bundle. Refer to
Figure 3 for the 37-pin terminal block pin assignments. Refer to the
NI 951x User Manual, which you can download from ni.com/
manuals, for information about additional connection accessories
and cabling recommendations.
Tip NI offers AKD analog servo drives and matched
servo motors. Refer to Getting Started with NI 9514/16
C Series Drive Interface Modules and AKD Analog Servo
Drives for installation and configuration information.
Refer to the Getting Started with NI 951x C Series Drive
Interface Modules and LabVIEW for information about
using the NI 9514 with other devices.
How to Connect the NI 9514 to Drives and I/O
Complete the following steps to connect the NI 9514 servo drive
interface module to drives and other I/O.
