Life Span TR2000e Manuel utilisateur
Owner’s Manual
TR2000e \ TR3000e
Electric Folding Treadmill
Congratulations on Purchasing Your LifeSpan Treadmill!
At LifeSpan we take pride in the quality, safety, and reliability of our products
as well as the professionalism of our sales support and customer service
teams. Making it our number one priority that you have an exceptional
experience using our products.
In support of this quality focus we pre-assemble parts on the manufacturing
line whenever possible to reduce the number of steps and complexity of
customer assembly, independently certify our products to comply with the
latest industry Safety Standards, and use state of the art production processes
and quality components.
Then we back LifeSpan products with excellent warranties and a responsive
customer service department making it simple and easy to get assistance
should the need arise.
This attention to quality, our high standard for customer service and focus on
innovation has earned LifeSpan numerous awards and consistent praise from
independent review groups, industry authorities and you the consumer.
Thanks for choosing LifeSpan.
Please thoroughly read this manual before you assemble or operate your treadmill.
Neither LifeSpan nor its representatives can accept responsibility for any damages or injury
incurred as a result of information presented in this manual except under the terms of the
product warranty.
Welcome
Contents
About Your Treadmill.................................................................................................4
Specications
Unique Features
Warranty
Safety First.........................................................................................................................7
Children and Pets
Safety Tips
Safety Key
Proper Grounding
Assembling Your Treadmill................................................................................. 12
Exploded View & Hardware
Assembly Instructions
Console Basics.............................................................................................................. 20
Console Overview
Readout Display
Operating Keyboard
Operations...................................................................................................................... 25
Setting Date & Time, QuickStart
Personal Settings
Program Proles
Pre-Set Programs
Custom User Set-Up Programs
Heart Rate Control Programs
Maintenance and Tips............................................................................................ 40
Heart Rate Monitoring
Hand Pulse Sensors, Chest Strap
Cleaning, Lubrication
Folding & Unfolding
Moving
Belt Tensioning
Belt Alignment
Troubleshooting
4
About Your Treadmill
Specications
TR2000e
Drive Motor 2.5 HP Continuous Duty
Max User Weight 300 lb (136 kg)
Heart Rate Contact Sensors / Chest Strap Compatible
Speed Range 0.5 - 11 mph (0.8 - 18 kph)
Running Belt Size 20” x 56” (51 cm x 142 cm)
TR3000e
Cooling Fan 3 Speed
Drive Motor 2.75 HP Continuous Duty
Max User Weight 350 lb (136 kg)
Heart Rate Contact Sensors / Chest Strap Compatible
Speed Range 0.5 - 12 mph (0.8 - 20 kph)
Running Belt Size 20” x 56” (51 cm x 142 cm)
All Models
Display Readouts Program Prole, Time, Calories, Step Count,
Distance, Heart Rate, Speed, Incline
Programs Speed & Incline for Weight Mgmt, Healthy Living,
Sports Training, 2 Custom User & 2 Heart Rate
Control
Deck Suspension 8-Independent Shock Absorbers
Roller Size 2.5” (64 mm) front / 2” (51 mm) back
Incline Levels 0 - 15
5
Intelli-Guard™
Walk condently knowing your safety is assured with Intelli-Guard™.
Step away from your treadmill for more than twenty seconds and your
treadmill’s belt will automatically glide to a smooth stop.
Intelli-Key™
Console operation is simplied with sequential button illumination
prompting you through program selection and setup.
Intelli-Step™
Never miss a stride with Intelli-Step™. Your steps are automatically
calculated with meticulous precision, displaying immediate feedback.
eFold™
The TR2000e and TR3000e modelsa oers our simple, safe, and
convenient eFold feature for electric folding and unfolding at the touch
of a button.
USB Plus
Dual-purpose USB port charges most of your mobile devices* and saves
your exercise results.
* Does not charge iPad 1, iPad 2, and iPad 3.
Unique Features
As a leader in the tness industry, LifeSpan has developed a number of
unique features in our treadmills making them more engaging, safer and
easier to use. Learn more about how to use these features in the Personal
Settings sections of this Owner’s Manual.
About Your Treadmill
6
Warranty
Your LifeSpan treadmill/bike desk comes with the following limited warranty
valid in North America. If you are outside of this area contact your local
authorized LifeSpan dealer.
LifeSpan warrants that the equipment it manufactures is free from defects
in materials and workmanship under normal use and services. The periods
above are based on the date of purchase. During these periods, LifeSpan will
repair or replace any defective part. Free labor is included on all parts that are
not normally assembled or replaced by the customer within the labor period.
If within the time frames specied above, any part fails to operate properly,
login to our website at www.LifeSpanFitness.com, click on “Customer Service”
and complete the form to request assistance or call 877.654.3837 x4 for a
Customer Service Agent (please note that certain kinds of service should only
be performed by a qualied service technician).
LifeSpan reserves the right to make changes and improvements to our
products without incurring any obligations to similarly alter any product
purchased. In order to insure our product warranty and to ensure the safe
and ecient operation of your LifeSpan product, only authorized parts can be
used. The warranty is void if any parts other than those provided by LifeSpan
are used.
Exclusions and Limitations:
• This warranty does not apply to any defects caused by negligence,
misuse, improper assembly, or maintenance, accident, or “act of God.”
• This warranty does not apply to discoloration of paints or plastics.
• LifeSpan shall not be responsible for incidental or consequential
damages.
• This warranty is non-transferable form the original owner.
About Your Treadmill
Treadmill Frame Lifetime
Motor Lifetime
Parts 5 Years
Labor 1 Year
7
Safety First
When using exercise equipment, basic precautions should always be followed,
including:
• Never drop or insert any object into any opening. If an object falls into
an opening, turn the power o and unplug the power cord from the
outlet. Remove the object or call customer service at 877.654.3837 x4.
• Never operate this treadmill if it has been damaged or partially
submersed in water.
• To reduce the risk of electric shock, unplug the treadmill from the wall
outlet when not in use, before performing any maintenance, or before
moving the treadmill.
• Do not use outdoors or in areas of high humidity or extreme
temperature changes.
• Do not lean against or climb on the treadmill.
• Do not operate where aerosol spray products are being used or where
oxygen is being administered.
• Never place the power cord under carpeting or place any object on top
of the cord, this may pinch or damage the cord causing re damage or
personal injury.
• Use this exercise product for its intended use as described in this
Owner’s Manual. Do not use attachments that are not recommended by
LifeSpan.
• Do not leave your treadmill running while not in use.
Children and Pets
• Keep children from playing on your treadmill at all times.
• When in use children and pets should be kept at least 10 feet (3m) away.
• This treadmill can be used by children ages 12 years and above and
persons with reduced physical, sensory or lack of experience and
knowledge if they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the hazards involved.
• Cleaning and user maintenance shall not be made by children without
supervision.
8
Safety First
Safety Tips While in Use
• Always consult a physician before beginning an exercise program.
• If you experience chest pains, nausea, dizziness or shortness of
breath, stop exercising immediately and consult your physician before
continuing. Do not wear clothing or jewelry that might catch on any part
of the treadmill.
• Wear shoes with high traction rubber soles. Do not wear shoes with
heals, leather soles, cleats or spikes.
• In case of emergency, grab onto the side handrails and place your feet
on the side rails located on each side of the running belt.
• Do not walk or run backwards on the treadmill, always face forward.
• Allow the running belt to fully stop prior to getting o the treadmill.
• Keep the treadmill on a solid surface, with the side rails and front of
the treadmill a minimum of 2 feet (0.6m) from any walls or furniture.
Make sure that the area behind the treadmill remains completely clear
during use. A minimum of 7 feet (2m) of clearance is required for safety
reasons.
2 Feet (.6 m)
7 Feet (2.0 m) 2 Feet (.6 m)
2 Feet (.6 m)
Safety Clearance
9
Safety First
!!
!!
Insert safety key
Securely attach
safety key clip in
case of a fall
WARNING
: Heart rate monitoring systems may be inaccurate.
Over exercising may result in serious injury or death. If you feel faint
stop exercising immediately.
CAUTION:
For your safety always attach safety key clip to an article
of clothing prior to use. The safety key clip needs to be securely
attached to clothing parallel to or above the height of the safety key.
Note: Read all instructions and save for future reference.
Safety Key
The safety key is required to operate this treadmill. With the safety key
installed the treadmill is operational. With the safety key pulled, power is
turned o to the motor making the treadmill inoperable.
Do not use extension cords between the treadmill and power outlet.
Do not plug into a GFI outlet or circuit as it may trip the breaker.
10
Safety First
Proper Grounding
LifeSpan equipment must be grounded. Improper connection of the
equipment’s grounding conductor can result in the risk of electric shock.
Check with a qualied electrician or service person if you are in doubt as to
whether the outlet is properly grounded. Do not modify the plug provided
with the product or use a ground plug adapter to adapt to a non-grounded
outlet. If the plug will not t in the outlet, have the proper outlet installed by a
qualied electrician.
Power Cord Options
This treadmill should only be used with the proper power cord and power
outlet. Several power cord options (shown below) are available from LifeSpan.
We do our best do include the correct power cord with the treadmill for your
area. In the event that the correct power cord is not included in the packaging
please contact your local distributor.
Power Cord Options
115V
NEMA 5-15
115V
NEMA 5-20
Euro Plug
CEE 7/7
208/220V
NEMA 6-15
230V
UK
C
I
R
C
U
I
T
B
R
E
A
K
E
R
P
R
E
S
S
T
O
R
E
S
E
T
Treadmill Outlet
SWITCH
AC POWER
OVERLOAD
SWITCH
POWER
SOCKET
!!
!!
Autres manuels pour TR2000e
1
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Life Span tapis roulant
Life Span
Life Span Power Manuel utilisateur
Life Span
Life Span TORQUE III Manuel utilisateur
Life Span
Life Span Treadmill Manuel utilisateur
Life Span
Life Span TR1200i Manuel utilisateur
Life Span
Life Span TR800 Manuel utilisateur
Life Span
Life Span supreme Manuel utilisateur
Life Span
Life Span RHYTHM Manuel utilisateur
Life Span
Life Span Access Manuel utilisateur
Life Span
Life Span TR5500iC Manuel utilisateur
Life Span
Life Span TR2500-HRC Manuel utilisateur
Life Span
Life Span TR3000i Manuel d'utilisation et d'entretien
Life Span
Life Span VULCAN Manuel utilisateur
Life Span
Life Span PRO Series Manuel utilisateur
Life Span
Life Span SPRINTER XL Manuel utilisateur
Life Span
Life Span LFT 05 WalkingPad M2 Manuel utilisateur
Life Span
Life Span CORSAIR FREERUN 200 Manuel utilisateur
Life Span
Life Span ZONE Manuel utilisateur
Life Span
Life Span TR2250-HRC Manuel utilisateur
Life Span
Life Span Torque Manuel utilisateur
Life Span
Life Span LS Series Manuel utilisateur
Manuels tapis roulant populaires d'autres marques
Smooth Fitness
Smooth Fitness EVO 3i Manuel utilisateur
NordicTrack
NordicTrack NETL81810.0 Manuel utilisateur
Schwinn
Schwinn 830/Journey 8.0 Manuel utilisateur
Keys Fitness
Keys Fitness HealthTrainer HT-740T Manuel utilisateur
Spirit
Spirit XT8 Manuel utilisateur
NordicTrack
NordicTrack T 14.0 Treadmill Manuel utilisateur
