Kramer VS-84H Manuel utilisateur

Kramer Electronics, Ltd.

Preliminary

USER MANUAL

Model:

VS-84H

8x4 HDMI Matrix Switcher

Contents

1Introduction 1

2Getting Started 1

2.1 Quick Start 2

3Overview 3

3.1 Defining the EDID 3

3.2 About HDMI 4

3.3 About HDCP 4

3.4 Recommendations for Best Performance 5

4Defining the VS-84H 8x4 HDMI Matrix Switcher 5

4.1 Using the IR Transmitter 8

5Installing the VS-84H in a Rack 9

6Connecting the VS-84H 8x4 HDMI Matrix Switcher 10

7Operating the VS-84H 8x4 HDMI Matrix Switcher 11

7.1 Switching an Input to an Output 11

7.2 Acquiring the EDID 11

7.2.1 Acquiring the EDID from One Output 11

7.2.2 Acquiring the EDID from Several Outputs 12

7.2.3 Acquiring the Default EDID 12

7.3 Storing and Recalling a Switching Setting from a Preset 13

7.4 Resetting the VS-84H 8x4 HDMI Matrix Switcher’s IP Parameters 13

7.5 Connecting to the VS-84H 8x4 HDMI Matrix Switcher via RS-232 13

7.6 Connecting to the VS-84H 8x4 HDMI Matrix Switcher via Ethernet 14

7.6.1 Connecting the Ethernet Port directly to a PC 14

7.6.2 Connecting the Ethernet Port via a Network Hub 15

8Upgrading the Firmware 15

9Technical Specifications 16

10 Default EDID 16

11 Default Communication Parameters 19

12 Kramer Protocol 2000 20

Figures

Figure 1: VS-84H 8x4 HDMI Matrix Switcher Front Panel 6

Figure 2: VS-84H 8x4 HDMI Matrix Switcher Rear Panel 7

Figure 3: Connecting the VS-84H 8x4 HDMI Matrix Switcher 10

Figure 4: Local Area Connection Properties Window 14

Figure 5: Internet Protocol (TCP/IP) Properties Window 15

Contents

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Tables

Table 1: VS-84H 8x4 HDMI Matrix Switcher Front Panel Features 6

Table 2: VS-84H 8x4 HDMI Matrix Switcher Rear Panel Features 7

Table 3: Technical Specifications of the VS-84H 8x4 HDMI Matrix Switcher 16

Table 4: Default Communication Parameters 19

Table 5: Protocol Definitions 20

Table 6: Instruction Codes for Protocol 2000 21

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront the video, audio, presentation and

broadcasting professional on a daily basis. In recent years we have

redesigned and upgraded most of our line, making the best even better! Our

1,000-plus different models now appear in 11 groups1

Congratulations on purchasing your Kramer VS-84H 8x4 HDMI Matrix

Switcher.

that are clearly

defined by function.

The VS-84H is ideal for conference room presentations and advertising

applications as well as for rental and staging.

Each package includes the following items:

•VS-84H 8x4 HDMI Matrix Switcher

•Power cord

•Windows®-based Kramer control software2

•Windows®-based Ethernet Configuration Manager and Virtual Serial

Port Manager

•Kramer RC-IR3Infrared Remote Control Transmitter (including the

required batteries and a separate user manual3)

•This user manual3

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high performance high resolution cables4

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;

GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;

GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products

2 Downloadable from http://www.kramerelectronics.com

3 Download up-to-date Kramer user manuals from http://www.kramerelectronics.com

4 The complete list of Kramer cables is available from http://www.kramerelectronics.com

Getting Started

KRAMER: SIMPLE CREATIVE TECHNOLOGY

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

Overview

3 Overview

The VS-84H is a high quality 8 x 4 matrix switcher for HDMI signals that

fits into one vertical space of a standard 19” professional rack enclosure.

In particular, the VS-84H features:

•Up to 2.25Gbps bandwidth per graphic channel1

•Support for HDCP (High Definition Digital Content Protection)

•HDMI Support – HDMI (V.1.4 with 3D, Deep Color, x.v.Color™,

Lip Sync)

•3D Pass-Through

•I-EDIDPro™ Kramer Intelligent EDID Processing™ – Intelligent

EDID handling & processing algorithm ensures Plug and Play

operation for HDMI systems

•Kramer reKlocking™ & Equalization Technology that rebuilds the

digital signal to travel longer distances

•A LOCK button to prevent unwanted tampering with the buttons on

the front panel

•Preset memory locations for quick access to common configurations

You can control the VS-84H using the front panel buttons, or remotely via:

•RS-232 serial commands transmitted by a PC, touch screen system or

other serial controller

•The Kramer infrared remote control transmitter

•A PC connected to the Ethernet port on the device via a LAN

3.1 Defining the EDID

The Extended Display Identification Data (EDID2

7.2

) is a data-structure

provided by a display to describe its capabilities to an HDMI source. The

EDID enables the VS-84H to “know” what kind of monitor is connected to

the output. The EDID includes the manufacturer’s name, the product type,

the timing data supported by the display, the display size, luminance data

and (for digital displays only) the pixel mapping data. See Section for

details of how to acquire the EDID.

1 Suitable for resolutions up to UXGA at 60Hz, and for all HD resolutions

2 Defined by a standard published by the Video Electronics Standards Association (VESA)

Overview

KRAMER: SIMPLE CREATIVE TECHNOLOGY

3.2 About HDMI

High-Definition Multimedia Interface (HDMI) is an uncompressed

all-digital1

In particular, HDMI:

audio/video interface, widely supported in the entertainment and

home cinema industry. It delivers the highest high-definition image and

sound quality. Note that Kramer Electronics Limited is an HDMI Adopter

and an HDCP Licensee.

•Provides a simple2interface between any audio/video source, such as

a set-top box, DVD player, or A/V receiver and video monitor, such

as a digital flat LCD / plasma television (DTV), over a single

lengthy3

•Supports standard, enhanced, high-definition video, and multi-

channel digital audio

cable

•Transmits all ATSC HDTV standards and supports 8-channel digital

audio, with bandwidth to spare to accommodate future enhancements

and requirements

on a single cable

•Benefits consumers by providing superior, uncompressed digital

video quality via a single cable5

•Is backward-compatible with DVI (Digital Visual Interface)

, and user-friendly connector

•Supports CEC, two-way communication between the video source

(such as a DVD player) and the digital television, enabling new

functionality such as automatic configuration and one-button play

HDMI has the capacity to support existing high-definition video formats

(720p, 1080i, and 1080p, 2K and 4K), standard definition formats such as

NTSC or PAL, as well as 480p and 576.

3.3 About HDCP

The High-Bandwidth Digital Content Protection (HDCP) standard6

1 Ensuring an all-digital rendering of video without the losses associated with analog interfaces and their unnecessary digital-

to-analog conversions

protects

digital video and audio signals transmitted over DVI or HDMI connections

between two HDCP-enabled devices to eliminate the reproduction of

2 With video and multi-channel audio combined into a single cable, the cost, complexity, and confusion of multiple cables

currently used in A/V systems is reduced

3 HDMI technology has been designed to use standard copper cable construction at up to 15m

4 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to

support Dolby 5.1 audio and high-resolution audio formats

5 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a

simple, cost-effective manner

6 Developed by Intel

Defining the VS-84H 8x4 HDMI Matrix Switcher

copyrighted material. To protect copyright holders (such as movie studios)

from having their programs copied and shared, the HDCP standard provides

for the secure and encrypted transmission of digital signals.

3.4 Recommendations for Best Performance

To achieve the best performance:

•Use only good quality connection cables1

•Avoid interference from neighboring electrical appliances that may

adversely influence signal quality and position your Kramer VS-84H

away from moisture, excessive sunlight and dust

to avoid interference,

deterioration in signal quality due to poor matching, and elevated

noise levels (often associated with low quality cables).

4 Defining the VS-84H 8x4 HDMI Matrix Switcher

Figure 1 and Table 1 define the VS-84H.

1 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com

Defining the VS-84H 8x4 HDMI Matrix Switcher

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Figure 1: VS-84H 8x4 HDMI Matrix Switcher Front Panel

Table 1: VS-84H 8x4 HDMI Matrix Switcher Front Panel Features

Feature

Function

1 IR LED Lights yellow when receiving signals from the infrared remote control transmitter

2 IR Receiver Signal receiver for the Infrared remote control transmitter

3 POWER LED Lights when the device is turned on

4 ALL Button Press followed by an input button to connect the selected input to all outputs

OFF Button Press after pressing an output button to disconnect the selected output from the inputs.

To disconnect all the outputs, press ALL followed by OFF

6 SELECT Buttons2OUT (1 to 4)

Press to select an output to switch followed by an input

7 IN (1 to 8) Press to select the input to switch after selecting an output

8 STO Button Press to store the current switching setting to a preset (see Section 7.3)

9 RCL Button Press to recall the current switching setting from a preset (see Section 7.3)

8 LOCK Button Press and hold to toggle the locking/release of the front panel buttons.

When storing or recalling presets, press to store or recall the preset (see Section 7.3)

9 EDID Button Press to capture the EDID (see Section 7.2)

12 INPUT 7-segment LED Display Displays the input currently switched to the output which is marked above each input

1 For example, press ALL and then Input button # 2 to connect input # 2 to all the outputs

2 These are also used for storing and recalling device setups (see Section 7.3)

Defining the VS-84H 8x4 HDMI Matrix Switcher

Figure 2: VS-84H 8x4 HDMI Matrix Switcher Rear Panel

Table 2: VS-84H 8x4 HDMI Matrix Switcher Rear Panel Features

Feature

Function

13 OUT HDMI Connectors(1 to 4) Connect to up to 4 HDMI acceptors

14 IN HDMI Connectors (1 to 8) Connect to up to 8 HDMI sources

15 RS-232 9-pin D-sub Serial Port

Connector

Connect to a PC/serial controller

16 ETHERNET RJ-45 Connector Connect to a PC via a LAN

17 ETH RESET Button Press to reset to the factory default IP parameters

REMOTE IR Opening

Connect to an external IR receiver for controlling the device via an IR remote controller (see

Section

4.1)

19 Mains Power Connector Connect to the mains power

20 Mains Power Fuse Fuse for protecting the device

21 Mains Power Switch Switch for turning the device on or off

1 First turn the VS-84H off and then turn it on again while pressing the ETH RESET button. The device will power up and load its memory with the factory default IP parameters

2 Covered by a cap. The 3.5mm jack at the end of the internal IR connection cable fits into this opening

Table des matières

Autres manuels Kramer Commutateur matriciel

Kramer

Kramer VS-622DT Manuel utilisateur

Kramer

Kramer XL 1204V Manuel utilisateur

Kramer

Kramer XL 1608VS Manuel utilisateur

Kramer

Kramer VS-88UT Manuel utilisateur

Kramer

Kramer VS-66HDCPxl Manuel utilisateur

Kramer

Kramer LASSEN XL 3232S Manuel utilisateur

Kramer

Kramer Sierra Video 3248V5xl Manuel utilisateur

Kramer

Kramer VS-48HN Manuel utilisateur

Kramer

Kramer VS-88H Manuel utilisateur

Kramer

Kramer VS-88HD Manuel utilisateur

Kramer

Kramer VSM-4x4X Manuel utilisateur

Kramer

Kramer VS-42HDCP Manuel utilisateur

Kramer

Kramer VP-772 Manuel utilisateur

Kramer

Kramer VS-42HN Manuel utilisateur

Kramer

Kramer Sierra Video 1204V3 Manuel utilisateur

Kramer

Kramer Sierra Pro XL 1616V5S Manuel utilisateur

Kramer

Kramer Sierra Video 3216V5 Manuel utilisateur

Kramer

Kramer VS-6464DN-EM Manuel utilisateur

Kramer

Kramer Sierra Video 1204V3S Manuel utilisateur

Kramer

Kramer AFM-20DSP-AEC Manuel utilisateur

Kramer

Kramer 88HDS Manuel utilisateur

Kramer

Kramer XL 1204V4 Manuel utilisateur

Kramer

Kramer VP-88K Manuel utilisateur

Kramer

Kramer XL 1616S Manuel utilisateur

Manuels Commutateur matriciel populaires d'autres marques

Broadcast Tools

Broadcast Tools SS 8.2 Manuel utilisateur

Altimium

Altimium MATF32 Manuel utilisateur

ALFAtron

ALFAtron ALF-MUK44N Manuel utilisateur

Monoprice

Monoprice Blackbird 15377 Manuel utilisateur

PTN

PTN FMX12 Manuel utilisateur

CYP

CYP nT15GX01 Manuel utilisateur

TESmart

TESmart HMA0402A40 Manuel utilisateur

Octava

Octava HD4XSTPMX Manuel utilisateur

Intelix

Intelix FLX-88 Mode d'emploi

Roland

Roland XS-1HD Manuel utilisateur

Atlona

Atlona AT-HDMI-22M Manuel utilisateur

Link

Link HD8X8 Manuel utilisateur

AMX

AMX AVS-OP-2020-117 Instructions et recettes

Lindy

Lindy 38042 Manuel utilisateur

Extron electronics

Extron electronics MTPX Plus Series Manuel utilisateur

Key Digital

Key Digital Champion KD-16x16CS Manuel utilisateur

Shinybow USA

Shinybow USA SB-8811 Manuel utilisateur

Optimus

Optimus Compact Manuel utilisateur
