Kramer VS-84HN Manuel utilisateur

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

VS-84HN

8x4 HDMI Matrix Switcher

P/N: 2900-300157 Rev 5

VS-84HN - Contents i

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 3

2.3 Recycling Kramer Products 3

3Overview 4

3.1 Defining the VS-84HN 8x4 HDMI Matrix Switcher 4

3.2 Using the IR Transmitter 7

4Installing in a Rack 8

5Connecting the VS-84HN 8x4 HDMI Matrix Switcher 9

6Operating the VS-84HN 8x4 HDMI Matrix Switcher 11

6.1 Switching an Input to an Output 11

6.2 Acquiring the EDID 11

6.3 Storing and Recalling a Preset 13

6.4 Resetting the IP Parameters 14

6.5 Switching Between Protocol 2000 and Protocol 3000 15

6.6 Connecting via RS-232 15

6.7 Connecting via Ethernet 15

6.8 Upgrading the Firmware 17

7Technical Specifications 18

8Default Communication Parameters 19

9Default EDID 20

10 Kramer Protocol 2000 23

11 Protocol 3000 26

11.1 Kramer Protocol 3000 Syntax 26

11.2 Kramer Protocol 3000 Commands 29

Figures

Figure 1: VS-84HN 8x4 HDMI Matrix Switcher Front Panel 5

Figure 2: VS-84HN 8x4 HDMI Matrix Switcher Rear Panel 6

Figure 3: Connecting the VS-84HN 8x4 HDMI Matrix Switcher 10

Figure 4: Store-Recall Button Configuration 13

Figure 5: Local Area Connection Properties Window 16

Figure 6: Internet Protocol (TCP/IP) Properties Window 17

VS-84HN - Introduction 1

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Video Products.

Congratulations on purchasing your Kramer VS-84HN 8x4 HDMI Matrix Switcher,

which is ideal for the following typical applications:

•Conference room presentations

•Advertising applications

•Rental and staging

2 VS-84HN - Getting Started

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

•Use only the power cord that is supplied with this machine

Go to http://www.kramerelectronics.com to check for up-to-date

user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

•Use only good quality connection cables (we recommend Kramer high-

performance high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

•Do not secure the cables in tight bundles or roll the slack into tight coils

•Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

•Position your Kramer product away from moisture, excessive sunlight and

dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

VS-84HN - Getting Started 3

2.2 Safety Instructions

Caution: There are no operator serviceable parts inside the unit

Warning: Use only the power cord that is supplied with the unit

Warning: Do not open the unit. High voltages can cause

electrical shock! Servicing by qualified personnel only

Warning: Disconnect the power and unplug the unit from the wall

before installing

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country

go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

4 VS-84HN - Overview

3 Overview

The VS-84HN is a high quality 8x4 matrix switcher for HDMI signals. It reclocks

and equalizes the signal and can route any input to any or all outputs

simultaneously.

In particular, the VS-84HN features:

•Up to 6.75Gbps data rate (2.25Gbps per graphics channel)

Suitable for resolutions up to UXGA at 60Hz and for all HD resolutions.

•Support for HDCP (High Definition Digital Content Protection)

•HDMI support for 3D, Deep Color, x.v.Color™, Lip Sync

•3D pass-through

•Support for up to 7.1 multichannel audio

•I-EDIDPro™ Kramer Intelligent EDID Processing™ – Intelligent EDID

handling & processing algorithm ensures Plug and Play operation for HDMI

systems

•Kramer reKlocking™ & Equalization Technology that rebuilds the digital

signal to travel longer distances

•A lock button to prevent unwanted tampering with the buttons on the front

panel

•12 Preset memory locations for quick access to common configurations

You can control the VS-84HN using the front panel buttons, or remotely via:

•RS-232 serial commands transmitted by a PC, touch screen system or other

serial controller

•The Kramer infrared remote control transmitter

•A PC connected to the Ethernet port on the device via a LAN

•An external remote IR receiver (optional), see

3.1 Defining the VS-84HN 8x4 HDMI Matrix Switcher

Section 3.2

This section defines the VS-84HN.

VS-84HN - Overview 5

VS-84HN – Overview 5

Figure 1: VS-84HN 8x4 HDMI Matrix Switcher Front Panel

Feature

Function

1 IR Indication LED Lights yellow when receiving signals from the infrared remote control transmitter

2 IR Receiver Signal receiver for the infrared remote control transmitter

3 POWER LED Lights when the device is turned on

4 ALL Button Press followed by an input button to connect the selected input to all outputs

For example, press ALL and then Input button # 2 to connect input # 2 to all the outputs

5 OFF Button Press after pressing an output button to disconnect the selected output from the inputs. To

disconnect all the outputs, press ALL followed by OFF

SELECT Buttons

OUT (1 to 4) Press to select an output to switch followed by an input (also used for storing machine

setups (see Section 6.3

)

IN (1 to 8) Press to select the input to switch after selecting an output (also used for storing machine

setups (see Section 6.3

)

STO Button Press to store the current switching setting to a preset (see Section 6.3

)

RCL Button Press to recall the current switching setting from a preset (see Section 6.3

)

LOCK Button Press and hold to toggle the locking/release of the front panel buttons.

When storing or recalling presets, press to store or recall the preset (see Section 6.3

)

EDID Button Press to capture the EDID (see Section 6.2

)

OUTPUT/INPUT 7-segment LED

Display

Displays the input currently switched to the output which is marked above each input

6 VS-84HN - Overview

Figure 2: VS-84HN 8x4 HDMI Matrix Switcher Rear Panel

Feature

Function

13 OUT HDMI Connectors(1 to 4) Connect to up to 4 HDMI acceptors

14 IN HDMI Connectors (1 to 8) Connect to up to 8 HDMI sources

15 RS-232 9-pin D-sub Connector Connect to a PC/serial controller

16 ETHERNET RJ-45 Connector Connect to a PC via a LAN

17 ETH RESET Button Press to reset to the factory default IP parameters:

IP number −192.168.1.39

Mask – 255.255.255.0

Gateway – 192.168.1.1

Depress the button while powering on the device. The device powers up with the factory default IP parameters

18 REMOTE IR Opening

Connect to an external IR receiver for controlling the device via and IR remote controller (see Section 3.2

Covered by a cap. The 3.5mm jack at the end of the internal IR connection cable fits into this opening

)

19 Mains Power Connector Connect to the mains power

20 Mains Power Fuse Fuse for protecting the device

21 Mains Power Switch Switch for turning the device on or off

6VS-84HN – Overview

VS-84HN - Overview 7

3.2 Using the IR Transmitter

You can use the RC-IR3 IR transmitter to control the machine via the built-in IR

receiver on the front panel or, instead, via an optional external IR receiver (Model:

C-A35M/IRR-50). The external IR receiver can be located up to 15 meters away

from the machine. This distance can be extended to up to 60 meters when used

with three extension cables (Model: C-A35M/A35F-50).

Before using the external IR receiver, be sure to arrange for your Kramer dealer to

insert the internal IR connection cable (P/N: 505-70434010-S) with the 3.5mm

connector that fits into the REMOTE IR opening on the rear panel. Connect the

external IR receiver to the REMOTE IR 3.5mm connector.
