USER MANUAL

Model:

VS-162V

16x16 Video Matrix Switcher

Contents

1Introduction 1

2Getting Started 1

2.1 Quick Start 1

3Overview 3

4Your Video Matrix Switcher 4

4.1 Using the IR Transmitter 7

5Installing the VS-162V in a Rack 8

6Installing and Operating a Single VS-162V - Overview 9

7Configuring the VS-162V Video Matrix Switcher 10

7.1 Configuring the Standalone VS-162V 10

7.1.1 Configuring a 16x16 Composite Video Switcher 10

7.1.2 Configuring an 8x8 s-Video (Y/C) Switcher 11

7.1.3 Configuring a 5x5 YUV/RGB Switcher 12

7.1.4 Configuring a 4x4 RGBS Switcher 12

7.2 Configuring 16x16 Multi-Channel Video Switchers 13

7.2.1 Configuring a 2-Unit 16x16 Y/C Switcher 13

7.2.2 Configuring a 3-Unit 16x16 YUV/RGB Switcher 14

7.2.3 Configuring a 4-Unit 16x16 RGBS Switcher 15

7.3 Configuring a Multi-Unit Matrix Switcher 15

7.3.1 Configuring a 32x16 Switcher 16

7.3.2 Configuring a 32x32 Switcher 17

7.4 Configuring a System of Interconnected Switchers 18

8Understanding Addressing and System Modes 20

8.1 Setting the DIP-Switches 20

8.2 Setting the MACHINE # 21

8.3 Setting the MACHINE ADDRESS # 21

8.4 Understanding the SYSTEM Mode 21

8.5 Understanding the SLAVE Mode 22

9Connecting a Control Interface 22

9.1 Connecting the RS-232 Control Interface 23

9.1.1 Connecting Two Units with a Null-Modem Adapter 24

9.1.2 Connecting Two Units without a Null-Modem Adapter 24

9.1.3 Connecting to a 9-pin PC COM Port with a Null-Modem Adapter 24

9.1.4 Connecting to a 9-pin PC COM Port without a Null-Modem Adapter 25

9.1.5 Connecting to a 25-pin PC COM Port with a Null-Modem Adapter 25

9.1.6 Connecting to a 25-pin PC COM Port without a Null-Modem Adapter 25

9.2 Connecting the RS-485 Control Interface 26

9.3 Configuring the Sync 29

9.4 Connecting the KEYBOARD EXTENSION 29

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Contents

10 Operating Your Video Matrix Switcher 30

10.1 Startup Display 30

10.2 Using the Front Panel Buttons 31

10.3 Toggling Between the AT ONCE and CONFIRM Modes 32

10.4 Switching 32

10.4.1 Switching One Input to One Output 32

10.4.2 Switching Several Inputs to Several Outputs 33

10.4.3 Switching One Input to All Outputs 34

10.5 Clearing 35

10.5.1 Clearing an Output 35

10.5.2 Clearing Several Outputs 36

10.5.3 Clearing All Outputs 37

10.6 Storing and Recalling Setups 37

10.6.1 Storing Setups 37

10.6.2 Recalling Setups 38

11 MENU Commands 39

11.1 Locking and Unlocking the Front Panel 41

11.2 Choosing the Follow or Breakaway from System Mode 42

11.3 Choosing the Video Format Setting 43

11.4 Setting the MACHINE ADDRESS 44

11.4.1 Changing the Standalone MACHINE ADDRESS to a Large Matrix 45

11.4.2 Changing the Large Matrix MACHINE ADDRESS to Standalone 46

11.4.3 Changing to a Different Large Matrix MACHINE ADDRESS 47

11.5 Choosing the SWITCHING METHOD Setting 48

11.5.1 Understanding the SWITCHING METHOD Settings 48

11.5.2 Configuring a SWITCHING METHOD 50

11.6 Choosing the Extended Keyboard Setting 50

11.7 Setting the STORE/RECALL KEYBOARD Mode 51

11.8 Choosing the INDICATE Setting 51

11.9 Choosing the COMMUNICATION Setting 52

11.10 Setting the IR REMOTE Control 53

11.11 Choosing the AUTO STORE Current SETUP 54

11.12 Identifying the MACHINE 55

11.13 Choosing the Initial RESET 55

12 Upgrading the Flash Memory 56

12.1 Connecting the PC to the RS-232 Port 56

12.2 Upgrading the Firmware 57

13 Technical Specifications 59

14 Communication Protocol 59

Contents

iii

Figures

Figure 1: VS-162V 16x16 Video Matrix Switcher 5

Figure 2: DIP-Switch Setup on a Single Machine 9

Figure 3: Configuring the VS-162V for Composite Video (CV) 11

Figure 4: Configuring the VS-162V for s-Video (Y/C) 11

Figure 5: Configuring the VS-162V for YUV (RGB) 12

Figure 6: Configuring the VS-162V for RGBS 12

Figure 7: Configuring a 16x16 YUV (RGB) Switcher with 3 VS-162V Units 14

Figure 8: MACHINE ADDRESS # Designation 15

Figure 9: Configuring a 32x16 Switcher 16

Figure 10: Connecting the 32x32 Switcher 18

Figure 11: Assembling a System of Interconnected Switchers 19

Figure 12: Rear Panel DIP-switches 20

Figure 13: Connecting a PC to 4 VS-162V Units 23

Figure 14: Connecting to a 25-pin PC COM Port without a Null-Modem Adapter 25

Figure 15: RS-485 Connector PINOUT 26

Figure 16: Connecting the RS-485 Connectors between Two VS-162V Units 27

Figure 17: An RS-485 Control Interface Setup 28

Figure 18: Keyboard Extension (EXT. KEYS) Connector 30

Figure 19: Default Startup Status Display Sequence 31

Figure 20: Sequence of MENU Commands 40

Figure 21: Choosing the MTX (SYNC from Matrix) Setting 49

Figure 22: Choosing what to INDICATE 52

Figure 23: Machine Identification 55

Tables

Table 1: Front Panel VS-162V 16x16 Video Matrix Switcher Features 6

Table 2: Quick Reference Operating Guide for a Single Machine 9

Table 3: Standalone Switcher Configuration for CV, Y/C, YUV (RGB) and RGBS 10

Table 4: 16x16 Multi-Channel Configurations 13

Table 5: DIP-switch Definitions 20

Table 6: Machine # DIP-Switch Settings 21

Table 7: Summary of Basic RC-IR2 Setups 53

Table 8: Summary of Basic RC-IR2 Operations 54

Table 9: Technical Specifications of the VS-162V Video Matrix Switcher 59

Table 10: Hex Table for the VS-162V Video Matrix Switcher 60

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront the video, audio, presentation, and

broadcasting professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

1,000-plus different models now appear in 11 groups1

Congratulations on purchasing your Kramer VS-162V 16x16 Video Matrix

Switcher.

that are clearly

defined by function.

This product is ideal for:

•Professional display systems requiring video signal routing

•Broadcast, presentation and production facilities

•Rental/staging applications

•Monitoring in large duplication systems

The package includes the following items:

•VS-162V 16x16 Video Matrix Switcher

•Windows®-based Kramer control software2

•Power cord and null-modem adapter

•This user manual3

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

•Review the contents of this user manual

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:

Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories

and Rack Adapters; GROUP 11: Sierra Products

2 Download the latest software from our Web site at http://www.kramerelectronics.com

3 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

Overview

3 Overview

The Kramer VS-162V is a high-performance 16x16 vertical interval matrix

switcher for composite video signals on BNC connectors. In addition to its

typical 16x16 operation, the VS-162V can be configured as follows:

•8x8 for s-Video (Y/C)

•5x5 for YUV or RGB (with the sync on the green signal - RGSB)

•4x4 for RGBS signals

A main advantage of the VS-162V is that it forms part of the series of

16x16 matrix switchers that includes, but is not limited to, VS-1616A (a

16x16 analog balanced stereo audio matrix switcher), VS-1616SDI (a

16x16 digital video matrix switcher), VS-1616AD (a 16x16 digital audio

matrix switcher), and VS-1616RS (an RS-422 control signal matrix

switcher).

In particular, the VS-162V:

•Produces glitch-free transitions, when sources share a common

reference sync1

•Offers excellent video performance, which ensures that it remains

transparent in almost any video application

In addition the VS-162V:

•May be used as a single unit, or expanded to up to 96 x 96

inputs/outputs

•Can be configured into a Kramer multi-signal switcher system

including digital and analog video, digital and analog audio, and

RS-422 control switchers

•When integrated in a system, all units switch in true audio-follow-

video mode

•Recalls up to 99 configuration setups via the non-volatile memory

and provides for an unlimited quantity of setups when using the

Kramer control software on your PC

•Includes a user-friendly LCD display (making operation even

easier)

•With its FLASH memory, lets you upgrade to the latest Kramer

firmware version via Internet download

•Comes with a choice of protocol format: hexadecimal or ASCII

1 As it switches during the vertical interval

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your Video Matrix Switcher

You can control the VS-162V:

•Using the front panel buttons

•Remotely, by RS-485 or RS-232 serial commands transmitted by

a touch screen system, PC, or other serial controller

•Remotely, from the Kramer RC-IR2Infrared Remote Control

Transmitter

•An external remote IR receiver (optional), see section 4.1

•Via external dry-contact push buttons

To achieve the best performance:

•Connect only good quality connection cables, thus avoiding

interference, deterioration in signal quality due to poor matching,

and elevated noise levels (often associated with low quality

cables)

•Avoid interference from neighboring electrical appliances that

may adversely influence signal quality and position your Kramer

VS-162V in a location free from moisture and away from

excessive sunlight and dust

4 Your Video Matrix Switcher

Figure 1and Table 1define the front and rear panels of the VS-162V.

Your Video Matrix Switcher

Figure 1: VS-162V 16x16 Video Matrix Switcher

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your Video Matrix Switcher

Table 1: Front Panel VS-162V 16x16 Video Matrix Switcher Features

Feature

Function

1 IR Receiver The red LED is illuminated when receiving signals from the Infrared

remote control transmitter

2 ALL Button Pressing ALL followed by an INPUT button, connects that input to

all outputs

3 OFF Button An OFF-OUT combination disconnects that output from the inputs; an

OFF-ALL combination disconnects all the outputs

4 STO Button Stores the current setting in the non-volatile memory

5 RCL Button Recalls a setup from the non-volatile memory

6 LCD MATRIX display

Displays the selected input(s) switched to the output(s) (above or

below the corresponding OUTPUT label) and user interface

messages

7 LCD STATUS Display

Displays the matrix status

8 OUT Buttons Select the output to which the input is switched (from 1 to 16)

9 IN Buttons Select the input to switch to the output (from 1 to 16)

10 MENU Button Selects the programming commands to setup the switcher

11 TAKE Button Used to confirm and complete setup and switching

12 SYNC IN BNC Connector Connects to the external video sync source

13 LOOP BNC

Connector Connects to the SYNC IN connector on the next unit

14 TERM SYNC Button Press to terminate at 75Ωor release for looping

EXT. (extension) KEYS

Terminal Block Connectors Connects to an external keyboard (remote unit)

16 RS-485 Detachable Terminal

Block Port Pins # 1 and # 2 are for vertical sync and Ground connection, and

Pins # 3 and # 4 are for RS 485

17 RS-232 IN 9-pin D-sub (F) Port Connects to the PC or the Remote Controller3

RS-232 OUT 9-pin D-sub (M)

Port Connects to the RS-232 IN 9-pin D-sub port of the next unit in the

daisy-chain connection

19 SETUP DIP-Switches DIP-switches for setup of the unit

20 REMOTE IR 3.5mm Mini Jack Connect to an external IR receiver unit for controlling the machine

via an IR remote controller (instead of using the front panel IR

receiver)4

Power Switch Illuminated switch for turning the unit ON or OFF

22 OUT BNC Connectors Connect to the video acceptors (from 1 to 16)

23 IN BNC Connectors Connect to the video sources (from 1 to 16)

24 TERM IN Buttons Press to terminate at 75Ωor release for looping5

Power Connector with Fuse AC connector enabling power supply to the unit

1 In sections 11.1 and 12.2 the word “Displays” refers to the LCD MATRIX and STATUS Displays

2 Push in to terminate the sync line. Push out when the sync line extends to another unit

3 If the unit is not the first unit in the line, connects to the RS-232 OUT 9-pin D-sub port of the previous unit in the line

4 Can be used instead of the front panel (built-in) IR receiver to remotely control the machine, see section 4.1

5 Push in to terminate the input. Push out when the input extends to another unit (the last unit in the chain must be terminated

when looping)

Table des matières

Autres manuels Kramer Commutateur matriciel

Kramer

Kramer VS-3232DN Manuel utilisateur

Kramer

Kramer 88HDS Manuel utilisateur

Kramer

Kramer VS-44UHD Manuel utilisateur

Kramer

Kramer VP-23RC Manuel utilisateur

Kramer

Kramer VP-2x2 Manuel utilisateur

Kramer

Kramer VP-436N Manuel utilisateur

Kramer

Kramer 1616D Manuel utilisateur

Kramer

Kramer VS-44HN Manuel utilisateur

Kramer

Kramer VP-772 Manuel utilisateur

Kramer

Kramer VS-1602xl Manuel utilisateur

Kramer

Kramer XL 1616S Manuel utilisateur

Kramer

Kramer VS-66UHD Manuel utilisateur

Kramer

Kramer VS-48HDCPxl Manuel utilisateur

Kramer

Kramer Sierra Pro XL 1616V3 Manuel utilisateur

Kramer

Kramer Sierra Video 3232SXL Manuel utilisateur

Kramer

Kramer Sierra Video 3232V3S Manuel utilisateur

Kramer

Kramer Sierra Video 3264V5xl Manuel utilisateur

Kramer

Kramer Sierra Pro XL 1208V5S Manuel utilisateur

Kramer

Kramer Sierra Video 1204V3S Manuel utilisateur

Kramer

Kramer VS-88H Manuel utilisateur

Kramer

Kramer 88V3 Manuel utilisateur

Kramer

Kramer Sierra Video 6432V5Sxl Manuel utilisateur

Kramer

Kramer VS-1616D Manuel utilisateur

Kramer

Kramer VS-8 Series Manuel utilisateur

Manuels Commutateur matriciel populaires d'autres marques

Broadcast Tools

Broadcast Tools SS 8.2 Manuel utilisateur

Altimium

Altimium MATF32 Manuel utilisateur

ALFAtron

ALFAtron ALF-MUK44N Manuel utilisateur

Monoprice

Monoprice Blackbird 15377 Manuel utilisateur

PTN

PTN FMX12 Manuel utilisateur

CYP

CYP nT15GX01 Manuel utilisateur

TESmart

TESmart HMA0402A40 Manuel utilisateur

Octava

Octava HD4XSTPMX Manuel utilisateur

Intelix

Intelix FLX-88 Mode d'emploi

Roland

Roland XS-1HD Manuel utilisateur

Atlona

Atlona AT-HDMI-22M Manuel utilisateur

Link

Link HD8X8 Manuel utilisateur

AMX

AMX AVS-OP-2020-117 Instructions et recettes

Lindy

Lindy 38042 Manuel utilisateur

Extron electronics

Extron electronics MTPX Plus Series Manuel utilisateur

Key Digital

Key Digital Champion KD-16x16CS Manuel utilisateur

Shinybow USA

Shinybow USA SB-8811 Manuel utilisateur

Optimus

Optimus Compact Manuel utilisateur
