Kramer VP-729 Manuel utilisateur

Kramer Electronics, Ltd.

USER MANUAL





Model:

729

Presentation Switcher / Scaler

Contents

Introduction 1

Getting Started 1

2.1

Quick Start 1

Overview 3

3.1

About HDMI 5

3.2

Recommendations for Best Performance 6

Your Presentation Switcher / Scaler 6

Installing in a Rack 10

Connecting your Presentation Switcher / Scaler 11

6.1

Connecting a PC 13

6.2

Connecting the VP-729 via the ETHERNET port 13

Presentation Switcher / Scaler Buttons 14

7.1

Switching an Input 14

7.2

The PIP Button Feature 14

7.2.1

Activating the PIP Feature 15

7.2.2

Selecting the PIP Source 15

7.2.3

Quick Selection of the PIP Source 15

7.2.4

Toggling between the PIP and the Screen Source (Swap) 16

7.3

Locking and Unlocking the Front Panel 17

7.4

The Infra-Red Remote Control Transmitter 17

Configuring the VP-729 via the OSD MENU Screens 19

8.1

The Input Screen 20

8.2

The Picture Screen 21

8.3

The Output Screen 22

8.4

The PIP Screen 23

8.5

The Audio Screen 24

8.6

The Geometry Screen 25

8.7

The Setup Screen 26

8.7.1

The Advanced Setup Screen 27

8.8

Verifying Configuration Details via the Info Screen 30

Technical Specifications 31

VP-729 Communication Protocol 36

Figures

Figure 1: VP-729 Presentation Switcher / Scaler Front Panel 7

Figure 2: VP-729 Presentation Switcher / Scaler Rear Panel 7

Figure 3: Connecting the VP-729 Rear Panel 12

Figure 4: Connecting the PC 13

Figure 5: PIP Source Over Background 15

Figure 6: OSD SWAP Status 16

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Contents

Figure 7: Infra-Red Remote Control Transmitter 18

Figure 8: MENU Items 19

Figure 9: Input Screen 20

Figure 10: Picture Screen 21

Figure 11: Output Screen 22

Figure 12: PIP Screen 23

Figure 13: Audio Screen 24

Figure 14: Geometry Screen 25

Figure 15: Setup Screen 26

Figure 16: Advanced Setup Screen 27

Figure 17: Firmware Download Screen 28

Figure 18: Information Screen 30

Tables

Table 1: Front Panel Presentation Switcher / Scaler Features 8

Table 2: Rear Panel Presentation Switcher / Scaler Features 9

Table 3: PIP Source Appearance Availability 16

Table 4: Infra-Red Remote Control Transmitter Functions 18

Table 5: Input Screen Functions 20

Table 6: Picture Screen Functions 21

Table 7: Output Screen Functions 22

Table 8: PIP Screen Functions 23

Table 9: Audio Screen Functions 24

Table 10: Geometry Screen Functions 25

Table 11: Available Settings for Each Application 25

Table 12: Setup Screen Functions 26

Table 13: Mode Set Functions 27

Table 14: OSD Functions 27

Table 15: Misc Functions 28

Table 16: Input Functions 29

Table 17: Output Functions 29

Table 18: Technical Specifications of the VP-729 Presentation Switchers / Scaler 31

Table 19: Technical Specifications of the RGBHV / RGBS (PC) / RGsB (PC) Signal 32

Table 20: Technical Specifications of the Y/C, Video Signal 32

Table 21: Technical Specifications of the DVI Signal (for RGB Colorspace)32

Table 22: Technical Specifications of the HDMI Signal (for RGB or YUV Colorspace) 33

Table 23: Technical Specifications of the Component Input Signal 33

Table 24: Technical Specifications of the RGBHV/Comp/YPbPr Output Signal 34

Table 25: Technical Specifications of the HDMI/DVI/RGB Output Signal 35

Table 26: Technical Specifications of the 1920x1080 Output Signal 35

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better! Our 500-plus different models now

appear in eight groups

that are clearly defined by function.

Congratulations on purchasing your Kramer VP-729 Presentation Switcher /

Scaler, which is ideal for the following typical applications:

Projection systems in conference rooms, boardrooms, auditoriums, hotels and

churches

Production studios, rental and staging

Any application where high quality conversion and switching of multiple and

different video signals to graphical data signals is required for projection

purposes

The package includes the following items:

VP-729 Presentation Switcher / Scaler

Infra-red remote control transmitter

Power cord

and null-modem adapter

This user manual

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Use Kramer high performance high resolution cables

2.1 Quick Start

The quick start charts summarize the basic setup and operation steps of the

VP-729.

1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:

Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;

GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors

2 We recommend that you use only the power cord that is supplied with this machine

3 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com

4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

Overview

3 Overview

The Kramer VP-729 is a 9-input Proscale™ Presentation Switcher / Scaler

with unbalanced stereo and digital S/PDIF audio.

The VP-729 scales any composite, s-Video (Y/C), component video (YUV),

HDMI or computer graphics video signal, as well as jpeg files (via USB) up

or down to a selectable graphics or HDTV output resolution and provides

glitch-free switching between sources through FTB™ (fade-thru-black)

switching technology. The output signal is available simultaneously on a 15-

pin HD computer graphics video (UXGA) connector and on an HDMI

connector.

The VP-729 features include:

K-Storm™ Scaling Technology - Kramer’s extremely high performance

scaling technology. High quality 3:2 and 2:2 pull down

de-interlacing and full

up and down scaling of computer graphics video input signals

Fade-Thru-Black (FTB™) Switching - the video fades to black and then the

new input fades from black for glitch-free and smooth switching. The output

signal provides constant sync so the display never glitches

K-IIT™ Picture-in-Picture Image Insertion Technology - ultra stable picture-in-

picture image insertion capability. Any video source can be inserted into a

computer graphics video source or vice versa (or 2 images can be placed side-

by-side) with positioning and sizing controls

Four user definable (universal) video inputs (each can be set as composite

video, s-Video (Y/C) or component video), two computer graphics video

inputs, two HDMI inputs and 1 USB input (for reading JPEG picture files

)

HDTV compatible component input

HDTV output resolutions - 480p, 576p, 720p 1080i, and 1080p

Scaled video outputs - HDMI and computer graphics video

HDMI supports up to 2.25Gbps bandwidth per graphic channel

Multiple computer graphics output resolutions - including a user-defined output

resolution with selectable refresh rates

Multiple aspect ratio selections

Companion AFV (audio-follow-video) for every analog video input - supports

embedded audio on the two HDMI inputs and output

Built-in noise reduction and picture enhancement features

1 Accommodates the frame-rate of a converted movie (24 frames per second) to video frequencies (25 frames per second

(PAL); 30 frames per second (NTSC)

2 JPEG files in EXIF format are recognized, up to 1920x1200

3 Suitable for resolutions up to UXGA at 60Hz, and for all HD resolutions

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

Audio inputs - four (stereo audio or S/PDIF on 2 RCA connectors) for each of

the four universal video inputs; two stereo audio (on 3.5mm connectors) for the

two computer graphics video inputs; and embedded audio on the HDMI inputs

Audio outputs - S/PDIF and stereo audio (RCA connectors). Transcodes stereo

or S/PDIF audio to both stereo and S/PDIF audio and embeds audio onto the

HDMI output

Built-in Time Base Corrector - stabilizes video sources with unstable sync

Built-in video Proc-Amp - color, hue, sharpness, contrast, and brightness are set

individually for each input

A BLANK button, a FREEZE button, a RESET TO XGA/720P button (to

hardware-reset the output resolution); and a PANEL LOCK button

Built-in audio Proc-Amp - with bass, treble, balance and loudness control, as

well as audio delay

Supports firmware upgrade

via the USB port

An OSD (On-Screen Display) – for making adjustments – that can be located

anywhere on the screen, and can be doubled in size.

For example, the OSD can be used to deactivate the source prompt, choose the

color of the blank screen, and choose from three seamless switching image

transition speeds

In addition, the VP-729:

Includes non-volatile memory that retains the last settings, after switching the

power off and then on again

Digitally reprocesses the signal to correct mastering errors, and regenerates the

video at a higher line and pixel rate format, providing native-resolution video

for LCD, DLP and plasma displays

Is specifically designed to improve video quality by reducing chroma noise

Scales and zooms (to up to 400% of the original size)

Can provide non-linear scaling for 4:3, 16:9 transformation

Control your VP-729 directly via the front panel push buttons, or:

By RS-232 serial commands transmitted by a touch screen system, PC, or other

serial controller

Remotely, from the infra-red remote control transmitter (with on-screen menus)

Via the Ethernet

The VP-729

is housed in a 19” 1U rack mountable enclosure, with rack “ears”

included, and is fed from a 100-240 VAC universal switching power supply.

1 The front panel blank, freeze and lock buttons can be programmed via the OSD menu (see Table 15)

2 To check if firmware upgrades are available, go to our Web site at http://www.kramerelectronics.com

Overview

3.1 About HDMI

High-Definition Multimedia Interface (HDMI) is an uncompressed all-digital

audio/video interface, widely supported in the entertainment and home cinema

industry. It delivers the maximum high-definition image and sound quality in use

today. Note that Kramer Electronics Limited is an HDMI Adopter

and an HDCP

Licensee

In particular, HDMI

Provides a simple

interface between any audio/video source, such as a set-top

box, DVD player, or A/V receiver and video monitor, such as a digital flat LCD

/ plasma television (DTV), over a single lengthy

cable

Supports standard, enhanced, high-definition video, and multi-channel digital

audio

on a single cable

Transmits all ATSC HDTV standards and supports 8-channel digital audio,

with bandwidth to spare to accommodate future enhancements and

requirements

Benefits consumers by providing superior, uncompressed digital video quality

via a single cable8, and user-friendly connector

Is backward-compatible with DVI (Digital Visual Interface)

Supports two-way communication between the video source (such as a DVD

player) and the digital television, enabling new functionality such as automatic

configuration and one-button play

Has the capacity to support existing high-definition video formats (720p, 1080i,

and 1080p/60), standard definition formats such as NTSC or PAL, as well as

480p and 576p

1 Ensuring an all-digital rendering of video without the losses associated with analog interfaces and their unnecessary digital-

to-analog conversions

2 See http://www.hdmi.org/about/adopters_founders.asp

3 See http://www.digital-cp.com/list/

4 HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI

licensing LLC

5 With video and multi-channel audio combined into a single cable, the cost, complexity, and confusion of multiple cables

currently used in A/V systems is reduced

6 HDMI technology has been designed to use standard copper cable construction at up to 15m

7 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to

support Dolby 5.1 audio and high-resolution audio formats

8 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a

simple, cost-effective manner

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your Presentation Switcher / Scaler

3.2 Recommendations for Best Performance

To achieve the best performance:

Connect only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise-levels

(often associated with low quality cables)

Avoid interference from neighboring electrical appliances and position your

Kramer VP-729 away from moisture, excessive sunlight and dust

4 Your Presentation Switcher / Scaler

Figure 1, and Table 1 define the front panel of the VP-729; Figure 2 and

Table 2 define the rear panel.

Your Presentation Switcher / Scaler

Figure 1: VP-729 Presentation Switcher / Scaler Front Panel

Figure 2: VP-729 Presentation Switcher / Scaler Rear Panel

Autres manuels pour VP-729

Table des matières

Autres manuels Kramer Commutateur matriciel

Kramer

Kramer VS-3232DVI Manuel utilisateur

Kramer

Kramer VS-88A Manuel utilisateur

Kramer

Kramer VS-88HCB Manuel utilisateur

Kramer

Kramer VS-66HN Manuel utilisateur

Kramer

Kramer VS-62DT Manuel utilisateur

Kramer

Kramer VS-84HN Manuel utilisateur

Kramer

Kramer VP-772T Manuel utilisateur

Kramer

Kramer VSM-4x4X Manuel utilisateur

Kramer

Kramer VS-44UHDA Manuel utilisateur

Kramer

Kramer VS-88DVI Manuel utilisateur

Kramer

Kramer 3232S Manuel utilisateur

Kramer

Kramer Sierra Video 1208V3 Manuel utilisateur

Kramer

Kramer XL 1204VS Manuel utilisateur

Kramer

Kramer VS-1616AD Manuel utilisateur

Kramer

Kramer VS-66HDCPxl Manuel utilisateur

Kramer

Kramer 3232HD Manuel utilisateur

Kramer

Kramer Sierra Video 3264V5Sxl Manuel utilisateur

Kramer

Kramer Sierra Video 1208V5S Manuel utilisateur

Kramer

Kramer Sierra Pro XL 1608V3 Manuel utilisateur

Kramer

Kramer Sierra Video 3216V5S Manuel utilisateur

Kramer

Kramer 1616DEE Manuel utilisateur

Kramer

Kramer VS-42HDCP Manuel utilisateur

Kramer

Kramer VS-88UHDA Manuel utilisateur

Kramer

Kramer 1616D Manuel utilisateur

Manuels Commutateur matriciel populaires d'autres marques

Broadcast Tools

Broadcast Tools SS 8.2 Manuel utilisateur

Altimium

Altimium MATF32 Manuel utilisateur

ALFAtron

ALFAtron ALF-MUK44N Manuel utilisateur

Monoprice

Monoprice Blackbird 15377 Manuel utilisateur

PTN

PTN FMX12 Manuel utilisateur

CYP

CYP nT15GX01 Manuel utilisateur

TESmart

TESmart HMA0402A40 Manuel utilisateur

Octava

Octava HD4XSTPMX Manuel utilisateur

Intelix

Intelix FLX-88 Mode d'emploi

Roland

Roland XS-1HD Manuel utilisateur

Atlona

Atlona AT-HDMI-22M Manuel utilisateur

Link

Link HD8X8 Manuel utilisateur

AMX

AMX AVS-OP-2020-117 Instructions et recettes

Lindy

Lindy 38042 Manuel utilisateur

Extron electronics

Extron electronics MTPX Plus Series Manuel utilisateur

Key Digital

Key Digital Champion KD-16x16CS Manuel utilisateur

Shinybow USA

Shinybow USA SB-8811 Manuel utilisateur

Optimus

Optimus Compact Manuel utilisateur
