USER MANUAL

Model:

VS-4x4YCxl

4x4 s-Video Audio Matrix Switcher

Contents

Introduction 1

Getting Started 1

Overview 2

Your VS-4x4YCxl 4x4 s-Video Audio Matrix Switcher 2

Connecting the VS-4x4YCxl 6

5.1

Connecting the VS-4x4YCxl Rear Panel 7

5.2

Controlling via RS-232 (for example, using a PC) 8

5.3

Controlling via RS-485 9

5.4

Connecting the Balanced/Unbalanced Stereo Audio Input/Output 10

5.5

Setting the Dipswitches 11

5.5.1

Setting the MACHINE # 11

Controlling via RS-232 and RS-485 12

Operating the VS-4x4YCxl 14

7.1

Displaying Unit Characteristics 14

7.2

Choosing the Audio-Follow-Video or Breakaway Option 14

7.2.1

Setting the Audio-Follow-Video Option 15

7.2.2

Setting the Breakaway Option 15

7.3

Switching OUT-IN Combinations 15

7.4

Confirming Settings 15

7.4.1

Toggling between the AT ONCE and CONFIRM Modes 16

7.4.2

Confirming a Switching Action 16

7.5

Storing/Recalling Input/Output Configurations 17

7.5.1

Storing an Input/Output Configuration 17

7.5.2

Recalling an Input/Output Configuration 17

7.5.3

Deleting an Input/Output Configuration 18

7.6

Locking the Front Panel 18

7.7

Adjusting the Audio Gain Control 18

Flash Memory Upgrade 19

8.1

Downloading from the Internet 19

8.2

Connecting the PC to the RS-232 Port 19

8.3

Upgrading Firmware 20

Technical Specifications 24

Table of Hex Codes for Serial Communication 25

Tables of Hex Codes for Audio Input/Output Gain Control 25

11.1

Tables of Hex Codes for Audio Input Gain Control 25

11.2

Tables of Hex Codes for Audio Output Gain Control 27

Kramer Protocol 2000 29

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Contents

Figures

Figure 1: VS-4x4YCxl 4x4 s-Video Audio Matrix Switcher 3

Figure 2: VS-4x4YCxl Underside View 5

Figure 3: Connecting the VS-4x4YCxl 4x4 s-Video Audio Matrix Switcher 7

Figure 4: Connecting a PC without using a Null-modem Adapter 8

Figure 5: Controlling via RS-485 (for example, using an RC-3000) 9

Figure 6: Connecting the Balanced Stereo Audio Input/Output 10

Figure 7: Connecting the Unbalanced Stereo Audio Input 10

Figure 8: Connecting the Unbalanced Stereo Audio Output 10

Figure 9: Dipswitch Settings 11

Figure 10: Cascading Individual Units in a Control Configuration via RS-232 and RS-485 13

Figure 11: VS-4x4YCxl Unit Characteristics 14

Figure 12: Storing and Recalling using the Input / Output Buttons 17

Figure 13: Splash Screen 20

Figure 14: Atmel – Flip Window 20

Figure 15: Device Selection Window 21

Figure 16: Device Selection window 21

Figure 17: Loading the Hex 22

Figure 18: RS-232 Window 22

Figure 19: Atmel – Flip Window (Connected) 23

Figure 20: Atmel – Flip Window (Operation Completed) 23

Tables

Table 1: Front Panel VS-4x4YCxl 4x4 s-Video Audio Matrix Switcher Features 4

Table 2: Rear Panel VS-4x4YCxl 4x4 s-Video Audio Matrix Switcher Features 5

Table 3: Dipswitch Settings 11

Table 4: Machine # Dipswitch Settings 11

Table 5: VS-4x4YCxl Hex Codes for Switching via RS-232/RS-485 25

Table 6: VS-4x4YCxl Hex Codes for Audio Input Gain Control 26

Table 7: VS-4x4YCxl Hex Codes for Audio Output Gain Control 28

Table 8: Protocol Definitions 29

Table 9: Instruction Codes for Protocol 2000 30

Introduction

1 Introduction

Welcome to Kramer Electronics (since 1981): a world of unique, creative and

affordable solutions to the infinite range of problems that confront the video,

audio and presentation professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

350-plus different models now appear in 8 Groups

, which are clearly defined

by function.

Congratulations on purchasing your VS-4x4YCxl 4x4 s-Video Audio Matrix

Switcher, which is ideal for the following typical applications:

 Professional display systems requiring true 4x4 matrix operation

 Multimedia and presentation source and acceptor selection, and remote

monitoring of computer activity in schools and businesses

The package includes the following items:

 VS-4x4YCxl 4x4 s-Video Audio Matrix Switcher

 Power cord

 Null-modem adapter

 Windows®-based Kramer control software

 Infra-red remote control transmitter (including the required battery and a

separate user manual

)

 This user manual

2 Getting Started

We recommend that you:

 Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

 Review the contents of this user manual

 Use Kramer high performance high resolution cables

1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:

Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;

GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors

2 Downloadable from our Web site at http://www.kramerelectronics.com

3 Download up-to-date Kramer user manuals from our Web

site: http://www.kramerelectronics.com

4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

3 Overview

The VS-4x4YCxl is a true 4x4 matrix switcher for s-Video signals and

balanced stereo audio signals. The high quality VS-4x4YCxl lets you

simultaneously route any or all of the 4 inputs to any or all of the 4 outputs.

The VS-4x4YCxl 4x4 s-Video Audio Matrix Switcher includes:

 Video bandwidth of 75MHz that ensures transparent performance

 Easy-to-connect detachable terminal block connectors for the audio signals

 Glitch-free transitions, which are produced when sources share a common

reference sync

 DC coupled inputs and outputs

 Audio-follow-video and breakaway options

 Storing and recalling setups

 “Take” button for precise switch control

 “Lock” button to prevent tampering with the front panel

 The ability to control via the front panel buttons, via the Infra-red remote

control transmitter, and remotely by RS-485 or RS-232 serial commands

transmitted by a touch screen system, PC, or other serial controller

To achieve the best performance:

 Connect only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise

levels (often associated with low quality cables)

 Avoid interference from neighboring electrical appliances that may

adversely influence signal quality and position your Kramer VS-4x4YCxl

away from moisture, excessive sunlight and dust

4 Your VS-4x4YCxl 4x4 s-Video Audio Matrix Switcher

Figure 1, Table 1 and Table 2 define the VS-4x4YCxl 4x4 s-Video Audio

Matrix Switcher:

1 As it switches during the vertical interval

Your VS-4x4YCxl 4x4 s-Video Audio Matrix Switcher

   

1 12 23 34 4

POWER

OUTPUT

INPUTALL OFF

VIDEO AUDIO AFV

LOCK

STO

TAKE

RCLAUDIOVIDEO





AUDIO

VIDEO

OUT 4OUT 2SYNC IN 4IN 2

IN 3IN 1

+ +- -

G G

L L

2 2

R R

+ +- -+ +- -

G G

L L

3 3

R R

+ +- -+ +- -

G G

L L

4 4

+ +-

RS-232 RS-485

FLASH

PROG

G B A

OUTPUTS

INPUTS

100-240 VAC, 50/60 Hz

+ +- -

G G

L L

1 1

R R

+ +- -

IN 1

EXT

OUT 3OUT 1

MACH.

RS-485

TERM

Figure 1: VS-4x4YCxl 4x4 s-Video Audio Matrix Switcher

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VS-4x4YCxl 4x4 s-Video Audio Matrix Switcher

Table 1: Front Panel VS-4x4YCxl 4x4 s-Video Audio Matrix Switcher Features

# Feature Function

1 IR Receiver The red LED is illuminated when receiving signals from the Infra-red remote

control transmitter

2 Power Switch Illuminated switch for turning the unit ON or OFF

3 OUTPUTS Buttons Select the output to which the input is switched

4 INPUTS Buttons Select the input to switch to the output

5 ALL Button Pressing ALL followed by an INPUT button, connects that input to all outputs

6 OFF Button An OFF-OUT combination disconnects that output from the inputs; an

OFF-ALL combination disconnects all the outputs

7 VIDEO 7-segment

Display Displays the selected video input switched to the output (marked above

each input)

8 AUDIO 7-segment

Display Displays the selected audio input switched to the output (marked above

each input)

9 VIDEO Button When pressed

actions relate to video

AFV Button When pressed

actions relate to video and audio channels. Audio channels

follow the video channels

AUDIO Button When pressed

actions relate to audio

STO (STORE) Button

Pressing STO followed by an output button stores the current setting

RCL (RECALL)

Button

Pressing the RCL button and the corresponding OUTPUT key recalls a

setup from the non-volatile memory. The stored status blinks. Pressing a

different OUTPUT button lets you view

another setup. After making your

choice, pressing the RCL button again implements the new status

TAKE Button Pressing TAKE toggles the mode between the CONFIRM mode

and the

AT ONCE mode (user confirmation per action is unnecessary)

LOCK Button Disengages the front panel switches

1 For example, press ALL and then Input button # 2 to connect input # 2 to all the outputs

2 Also displays the number of IN and OUT ports. Refer to section 7.1

3 Also displays the firmware version number and the MACHINE #. Refer to section 7.1

4 The VIDEO button is illuminated when the video breakaway mode is selected

5 The AFV button is illuminated when the AFV mode is selected

6 The AUDIO button is illuminated when the audio breakaway mode is selected

7 For example, press STO and then the Output button # 3 to store in Setup # 3

8 Only view, nothing is implemented at this stage

9 When in Confirm mode, the TAKE button illuminates

Your VS-4x4YCxl 4x4 s-Video Audio Matrix Switcher

Table 2: Rear Panel VS-4x4YCxl 4x4 s-Video Audio Matrix Switcher Features

# Feature Function

1 SYNC BNC Connector Connects to the external SYNC source

2 SYNC Source Selector

Button

Pushing in selects the (EXT) external sync

source; releasing

selects the (IN 1) internal sync

3 s-Video 4p INPUTS Connects to the s-Video sources (from 1 to 4)

VIDEO

s-Video 4p OUTPUTS Connects to the s-Video acceptors (from 1 to 4)

5 INPUTS Terminal Block

Connectors Connect to the balanced stereo audio sources (from 1 to 4)

AUDIO

OUTPUTS Terminal

Block Connectors Connect to the balanced stereo audio acceptors (from 1 to 4)

7 Dipswitches Dipswitches for setup of the unit (1, 2, 3 and 4 are for setting the

Machine #; 8 is for RS 485 Termination)

8 RS-232 DB 9F Port Connects to the PC or the Remote Controller

9 FLASH PROG Button Push in

for “Program” to upgrade to the latest Kramer firmware

(see section 8), or release for Normal (the factory default)

RS-485 Terminal Block Port Pin G is for Ground connection; Pins B (-) and A (+) are for RS 485

Power Connector with Fuse AC connector enabling power supply to the unit

The VS-4x4YCxl underside is illustrated in Figure 2, showing the Flash

Program Reset button (see section 8.2).

ENLARGED VIEW

Figure 2: VS-4x4YCxl Underside View

1 On the SYNC connector

2 On the VIDEO IN 1 connector

3 Using a screwdriver if required

4 Note that the FLASH PROG “Reset” button is located on the underside of the unit (Figure 2). Push in for “Reset”, or release

for Normal (see section 8)

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Connecting the VS-4x4YCxl

5 Connecting the VS-4x4YCxl

This section describes how to connect the VS-4x4YCxl. In particular, how to:

 Connect the VS-4x4YCxl rear panel (see section 5.1)

 Control via RS-232, for example, using a PC (see section 5.2)

 Control via RS-485 (see section 5.3)

 Connect the audio inputs/outputs (see section 5.4)

 Set the dipswitches (see section 5.5)

Connecting the VS-4x4YCxl

5.1 Connecting the VS-4x4YCxl Rear Panel

To connect the VS-4x4YCxl, do the following

1. Connect up to 4 s-Video sources

to the 4 Y/C 4p input connectors, and

connect

up to 4 balanced stereo audio sources

to the “ AUDIO

INPUTS” terminal block connectors.

2. Connect

the 4 Y/C 4p output connectors to up to 4 s-Video acceptors

and connect the corresponding “ AUDIO OUTPUTS” terminal block

connectors to the balanced stereo audio acceptors

3. Set the dipswitches (see section 5.5).

4. Connect a PC (if required) to the RS-232 port (see section 5.2).

5. Connect

the power cord

Figure 3: Connecting the VS-4x4YCxl 4x4 s-Video Audio Matrix Switcher

1 Switch OFF the power on each device before connecting it to your VS-4x4YCxl. After connecting your VS-4x4YCxl,

switch on its power and then switch on the power on each device. DO NOT push in the rear panel Flash Program “ Program”

button (item 9 in Table 2) and DO NOT push in the underside Flash Program “Reset” button. These are only used for upgrade

to the latest Kramer firmware (see section 8)

2 For example, VCR machines

3 See section 5.4 for a description of how to connect a balanced/unbalanced stereo audio input/output

4 Not illustrated in Figure 3

5 When less than four outputs are required, connect only those outputs of the VS-4x4YCxl that are required, and leave the

other outputs unconnected

6 We recommend that you use only the power cord that is supplied with this machine

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Kramer Commutateur matriciel

Kramer

Kramer VS-44DT Manuel utilisateur

Kramer

Kramer MTX3-88-SE Manuel utilisateur

Kramer

Kramer VS-44HDMI Manuel utilisateur

Kramer

Kramer Sierra Video 1608V5 Manuel utilisateur

Kramer

Kramer MV-4X Manuel utilisateur

Kramer

Kramer VP-27 Manuel utilisateur

Kramer

Kramer 20-04400030 Manuel utilisateur

Kramer

Kramer VS-44UHD Manuel utilisateur

Kramer

Kramer Sierra Video 1208V5S Manuel utilisateur

Kramer

Kramer VS-88HDCPxl Manuel utilisateur

Kramer

Kramer VS-3232V Manuel utilisateur

Kramer

Kramer MTX3-88-SE Manuel utilisateur

Kramer

Kramer 88D Manuel utilisateur

Kramer

Kramer VS-44FO Manuel utilisateur

Kramer

Kramer VP-729 Manuel utilisateur

Kramer

Kramer VS-88H Manuel utilisateur

Kramer

Kramer VS-88H Manuel utilisateur

Kramer

Kramer VS-3232DN Manuel utilisateur

Kramer

Kramer VS-6464DN-EM Manuel utilisateur

Kramer

Kramer Sierra Video 1204V5 Manuel utilisateur

Kramer

Kramer VS-88UT Manuel utilisateur

Kramer

Kramer Sierra Video 4832V5xl Manuel utilisateur

Kramer

Kramer 88DS Manuel utilisateur

Kramer

Kramer MTX3-16-M Manuel utilisateur

Manuels Commutateur matriciel populaires d'autres marques

Broadcast Tools

Broadcast Tools SS 8.2 Manuel utilisateur

Altimium

Altimium MATF32 Manuel utilisateur

ALFAtron

ALFAtron ALF-MUK44N Manuel utilisateur

Monoprice

Monoprice Blackbird 15377 Manuel utilisateur

PTN

PTN FMX12 Manuel utilisateur

CYP

CYP nT15GX01 Manuel utilisateur

TESmart

TESmart HMA0402A40 Manuel utilisateur

Octava

Octava HD4XSTPMX Manuel utilisateur

Intelix

Intelix FLX-88 Mode d'emploi

Roland

Roland XS-1HD Manuel utilisateur

Atlona

Atlona AT-HDMI-22M Manuel utilisateur

Link

Link HD8X8 Manuel utilisateur

AMX

AMX AVS-OP-2020-117 Instructions et recettes

Lindy

Lindy 38042 Manuel utilisateur

Extron electronics

Extron electronics MTPX Plus Series Manuel utilisateur

Key Digital

Key Digital Champion KD-16x16CS Manuel utilisateur

Shinybow USA

Shinybow USA SB-8811 Manuel utilisateur

Optimus

Optimus Compact Manuel utilisateur
