Kramer VS-3232DN Manuel utilisateur

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

VS-3232DN

32x32 Digital Matrix Switcher

P/N: 2900-300164 Rev 3

VS-3232DN – Contents i

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

3Overview 3

3.1 Defining EDID 4

3.2 About the Power Connect™ Feature 4

4Defining the VS-3232DN 32x32 Digital Matrix Switcher 5

5Installing in a Rack 10

6Connecting the VS-3232DN 11

6.1 Port Numbering 12

6.2 Serial Data on DGKat Plus RS-232 Cards 14

6.3 Connecting to the VS-3232DN via RS-232 14

6.4 Connecting to the VS-3232DN via Ethernet 15

7Operating Your Video Matrix Switcher 18

7.1 Startup Display 18

7.2 Using the Selector Buttons 19

7.3 Confirming Actions 20

7.4 Switching Actions 21

7.5 Locking the Front Panel Buttons 24

7.6 Redundant Power Supplies 25

8Using the Configuration Menus 26

8.1 Using the Setup Menu 26

8.2 Using the Config Menu 31

9Configuring the Number of Installed Input and Output Ports 43

10 Installing and Using the Test Module to Troubleshoot Video Problems 44

10.1 Installing the Test Module 44

10.2 Setting the Resolution of the Generated Video 45

10.3 Setting the Pattern of the Generated Video 46

10.4 Using the Test Module to Troubleshoot Video Problems 46

11 Hardware Installation Instructions 49

11.1 I/O Card Installation 49

11.2 Power Supply Installation 51

12 Upgrading the VS-3232DN Firmware 53

13 Technical Specifications 54

14 Default Communication Parameters 55

15 Factory Default EDID 56

15.1 DVI Input Card 56

15.2 DVI (HDCP) Input Card 57

15.3 HDMI Input Card 58

15.4 DVI Dual Link Input Card 60

15.5 DGKat Input Card 62

15.6 Fiber Optic F670 Input Card 64

16 Communication Protocols 66

16.1 Protocol 3000 66

16.2 Protocol 2000 70

ii VS-3232DN - Introduction

Figures

Figure 1: VS-3232DN Front Panel Numeric Keypad 5

Figure 2: VS-3232DN 32x32 Digital Matrix Switcher Front Panel 6

Figure 3: VS-3232DN 32x32 Digital Matrix Switcher Rear Panel 8

Figure 4: Connecting the VS-3232DN 32x32 Digital Matrix Switcher 11

Figure 5: Sample Port Numbering 13

Figure 6: DGKat Card Serial Data Transmission 14

Figure 7: Local Area Connection Properties Window 16

Figure 8: Internet Protocol (TCP/IP) Properties Window 16

Figure 9: Default Startup Status Display Sequence 18

Figure 10: Resolution DIP-switch 45

Figure 11: Signal Paths for Isolating Problems 46

Figure 12: Inserting the Card into a Slot 49

Figure 13: Card Handles 50

Figure 14: Second Power Supply Installation 51

VS-3232DN - Introduction 1

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Video Products.

Congratulations on purchasing your Kramer VS-3232DN 32x32 Digital Matrix

Switcher which is ideal for the following typical applications:

•Professional display systems requiring video signal routing

•Broadcast, presentation and production facilities, as well as monitoring in

large duplication systems

•Rental/staging applications

Note: Throughout this user manual the chassis configuration is shown with 32 DVI

inputs and 32 DVI outputs as a representation only. The following cards are

available and may be mixed in the same chassis:

•DVI, DVI dual link

•DVI (HDCP), HDMI (HDCP)

•DVI (over 4LC fiber optic cable)

•DVI (over fiber optic cable) with 670 module (HDCP)

•HDMI over DGKat twisted pair cable with RS-232 (HDCP)

2 VS-3232DN - Getting Started

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high performance high resolution cables

•Use only the power cord that is supplied with this machine

Go to http://www.kramerelectronics.com to check for up-to-date

user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

•Use only good quality connection cables to avoid interference, deterioration

in signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

•Do not secure the cables in tight bundles or roll the slack into tight coils

•Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

•Position your Kramer VS-3232DN away from moisture, excessive sunlight

and dust

VS-3232DN - Overview 3

3 Overview

The Kramer VS-3232DN is a high performance matrix switcher chassis that

supports up to 32 x 32 ports. It features a very high bandwidth of up to 3.2Gbps

(for the chassis only, effective bandwidth of the system depends on the I/O cards)

that ensures transparent performance even in the most critical applications. The

cards re-clock and equalize the signals and the chassis can route any or all inputs

to any or all outputs simultaneously.

For maximum bandwidth supported by each type of card see the Technical

Specifications in Section 13

The VS-3232DN is highly configurable–you can add or remove inputs and outputs

independently in groups of four and mix different types of input/ouput cards in the

same chassis up to 32 x 32. For example, you can configure a device as a 4 x 24

or a 32 x 8 matrix switcher to exactly suit your needs.

The VS-3232DN features:

•Full 32 x 32 non-blocking matrix array to switch any of the 32 input digital

signals to any or all outputs (with limitations, see Section 6

•Kramer Core™—flexible infrastructure conversion. Copper, fiber or Twisted

Pair, all can be used at the same time according to input/output module

selection. The matrix receives signals from compatible Kramer transmitters,

automatically converts between available infrastructure options and sends

the signals to compatible Kramer receivers

)

•I-EDIDPro™ Kramer Intelligent EDID Processing™ – Intelligent EDID

handling and processing algorithm ensures plug and play operation for

DVI/HDMI systems

•A default EDID (Extended Display Identification Data) for each input

•Non-volatile EDID storage

•Equalization and re-clocking on all card types

•Support for dual, redundant power supplies

•Easy access to 59 preset memory locations for quick access to user-defined

setups

4 VS-3232DN - Overview

•The Kramer 2000 Protocol for serial control

•A lock function to prevent tampering with the front panel

•A 40 character by 2 line LCD that shows the operational status or the

configuration menu

You can operate the VS-3232DN via the front panel buttons or remotely via:

•RS-232 serial commands transmitted by a touch screen system, PC or other

serial controller

•Ethernet over a LAN

•The infrared remote control transmitter

The VS-3232DN is a sophisticated device but has been designed to be as simple

as possible to operate. Due to space limitations on the front panel a keypad

substitutes for 64 individual input/output selector buttons. For details of how to

route inputs to outputs, see Section 6

3.1 Defining EDID

. The VS-3232DN is housed in a 19" rack-

mountable enclosure.

The Extended Display Identification Data (EDID) is a data-structure provided by a

display, to describe its capabilities to a graphics card (that is connected to the display’s

source). The EDID enables the VS-3232DN to “know” what kind of monitor is

connected to the output. The EDID includes the manufacturer’s name, the product type,

the timing data supported by the display, the display size, luminance data and (for

digital displays only) the pixel mapping data. EDID is defined by a standard published

by the Video Electronics Standards Association (VESA).

3.2 About the Power Connect™ Feature

The Power Connect™ feature means that the VS-3232DN can supply power over the

TP cable to compatible DGKat devices (for example, the TP-573 or TP-574) when the

devices are within 90m (270ft) of each other. The Power Connect™ feature applies as

long as the cable can carry power and the distance does not exceed 90m on standard

TP cable. For longer distances, use heavier gauge cable (TP cable is still suitable for

the video/audio transmission, but not for feeding power at these distances).

VS-3232DN - Defining the VS-3232DN 32x32 Digital Matrix Switcher 5

4 Defining the VS-3232DN 32x32 Digital Matrix

Switcher

Figure 1, Figure 2and Figure 3define the VS-3232DN.

Figure 1: VS-3232DN Front Panel Numeric Keypad

Front Panel Numeric Keypad Labels

# Feature Function

1 ◄ (Backwards) Press to shift the sliding window to the right (The

LCD display is large enough to show only 13

cross-points out of a total of 32)

2 1, 2, 3, 4, 5, 6, 7, 8, 9, 0 Numeric keypad, 1 to 0

3 ► (Forward) Press to shift the sliding window to the left

6 VS-3232DN - Defining the VS-3232DN 32x32 Digital Matrix Switcher

Figure 2: VS-3232DN 32x32 Digital Matrix Switcher Front Panel

6VS-3232DN – Defining the VS-3232DN 32x32 Digital Matrix Switcher
