Klein Tools CL360 Manuel utilisateur

INSTRUCTION MANUAL

ENGLISH

FRANÇAIS p. 25

ESPAÑOL pg. 13

200A AC Open Jaw

Fork Meter

True RMS

Measurement

Technology

• AUTO-RANGING

• DATA HOLD

• NON-CONTACT

VOLTAGE TESTER

• AUDIBLE

CONTINUITY

600V

60M

200A

1000V

mIP40

CAT III

600V

CAT II

1000V

CL360

GENERAL SPECIFICATIONS

Klein Tools CL360 is an automatically ranging true root mean square

(TRMS) digital open jaw fork meter that measures AC current via the

fork, AC/DC voltage, continuity, and resistance via test-leads, and can

detect the presence of voltage via the integrated non-contact voltage

(NCV) tester.

• Operating Altitude: <6562 ft. (2000m)

• Relative Humidity: <80% non-condensing

• Operating Temp: 32°to 122°F (0°to 50°C)

• Storage Temp: -4°to 140°F (-20°to 60°C)

• Dimensions: 8.39" x 2.12" x 1.38" (213 x 54 x 35 mm)

• Weight: 7.3 oz. (208 g) including batteries

• Calibration: Accurate for one year

• Standards: IEC EN 61010-1, 61010-2-032, 61010-2-033.

IEC EN 61326-1, 61326-2-2.

Conforms to: UL 61010-1, UL 61010-2-032,

UL 61010-2-033.

Certified to: CAN/CSA C22.2 NO. 61010-1,

61010-2-032, 61010-2-033.

• Accuracy: ± (% of reading + # of least significant digits)

Values stated at 65° to 83°F (18° to 28°C), Temp Coefficient:

0.1 x (Quoted Accuracy) per °C above 28°C or below 18°C,

corrections are required when ambient working temp is

outside of Accuracy Temp range

• Batteries: 2 x 1.5V AAA Alkaline (included)

• Drop Protection: 9.8 ft. (3m)

• Ingress Protection: IP40 dust resistant

• Pollution Degree: 2

• Safety Rating:

Jaw & Housing: CATIV 600V / CATIII 1000V

Electrical & Protection Circuit: CATIII 600V / CATII 1000V

Class 2, Double insulation

CAT II: Measurement Category II is applicable to test and measuring

circuits connected directly to utilization points (socket outlets and

similar points) of the low-voltage MAINS installation.

CAT III: Measurement category III is applicable to test and measuring

circuits connected to the distribution part of the building’s low-

voltage MAINS installation.

CAT IV: Measurement category IV is applicable to test and measuring

circuits connected at the source of the building’s low-voltage MAINS

installation.

• Electromagnetic Environment: IEC/EN 61326-1. This

equipment meets requirements for use in basic and controlled

electromagnetic environments like residential properties,

business premises, and light-industrial locations.

Specifications subject to change.

ENGLISH

ELECTRICAL SPECIFICATIONS

Function Range Resolution Accuracy

AC Voltage

(V AC) 600.0V 0.1V ±(1.2% + 3 digits)

Input Impedance: ≥10MΩ Frequency Range: 40 to 400Hz

Maximum Input: 600V AC RMS or 1000V DC

Accuracy specified from 5% to 100% of the measuring range

DC Voltage

(V DC)

6.000V 0.001V

±(0.8% + 3 digits)60.00V 0.01V

600.0V 0.1V

1000V 1V ±(1.0% + 5 digits)

Input Impedance:

≥

10MΩ Maximum Input: 600V AC RMS or 1000V DC

Accuracy specified from 5% to 100% of the measuring range

AC Current

(A AC)

0.2 – 2.0A 0.1A ±(1.8% + 2 digits)

2.1 – 5.0A 0.1A ±(1.8% + 3 digits)

5.1 – 200.0A 0.1A ±(1.8% + 5 digits)

Frequency Range: 50 to 60Hz

Accuracy specified from 5% to 100% of the measuring range

Resistance

600.0Ω 0.1Ω ±(1.2% + 2 digits)

6.000kΩ 1Ω

±(1.0% + 2 digits)60.00kΩ 10Ω

600.0kΩ 100Ω

6.000MΩ 1kΩ ±(1.2% + 2 digits)

60.00MΩ 10kΩ ±(1.5% + 5 digits)

Maximum Input: 600V AC RMS or 1000V DC

OTHER MEASUREMENT APPLICATIONS

• Continuity Check: Audible signal <10Ω, test current <1.5mA

• Non-Contact Voltage Testing (NCV): Audible & Visual indicators sound /

illuminate for >70V AC RMS at distances <10mm from the source

• Auto Power off: After 15 minutes of inactivity

• Backlight Auto off: After 3 minutes of inactivity

• Overload:

Buzzer sounds continuously for voltage >600VAC or >1000VDC,

"OL" indicated on display for voltage >610VAC or >1010VDC

• Sampling Frequency: 3 samples per second

• Polarity: "-" on display indicates negative polarity

• Display: 3-5/6 digit, 6000 Count LCD

ENGLISH

WARNINGS

To ensure safe operation and service of the meter, follow these

instructions. Failure to observe these warnings can result in

severe injury or death.

• Before each use verify meter operation by measuring a known

voltage or current.

• Never use the meter on a circuit with voltages that exceed the

category based rating of this meter.

• Do not use the meter during electrical storms or in wet weather.

• Do not use the meter or test leads if they appear to be damaged.

• Use only with CAT III or CAT IV rated test leads.

• Ensure meter leads are fully seated, and keep fingers away from the

metal probe contacts when making measurements.

• Use caution when working with voltages above 25V AC RMS or 60V

DC. Such voltages pose a shock hazard.

• To avoid false readings that can lead to electrical shock, replace

batteries when a low battery indicator appears.

• Do not attempt to measure resistance or continuity on a live circuit.

• Always adhere to local and national safety codes. Use personal

protective equipment to prevent shock and arc blast injury where

hazardous live conductors are exposed.

• To avoid risk of electric shock, disconnect leads from any voltage

source before removing battery door.

• To avoid risk of electric shock, do not operate meter while battery

door is removed.

SYMBOLS ON METER

Alternating Current (AC) Direct Current (DC)

Resistance (ohms) Audible Continuity

Warning or Caution

Risk of electrical shock

Double Insulated Class II

Ground

Voltage

Amperage

SYMBOLS ON LCD

Alternating Current (AC) Direct Current (DC)

Voltage (Volts) Amperage (Amperes)

Continuity Data Hold

Non-Contact Voltage Testing High Voltage

Resistance (Ohms) Low Battery

Auto-Ranging Auto-Power Off

kilo (value x 10

) Mega (value x 10

)

Negative Reading

FEATURE DETAILS - METER

NOTE: There are no user-serviceable parts inside meter.

1. 6000 count LCD display 7.

NCV (Non-Contact Voltage Testing)

Sensor

2. Function selector switch

3. Open jaw fork 8.

NCV (Non-Contact Voltage Testing)

visual indicator

4. "COM" jack

5. "VΩ" jack 9.

Data Hold / Backlight button

NCV (Non-Contact Voltage Testing)

Button

10. Arrow markings

11. Battery door (back)

FRONT BACK

FUNCTION BUTTONS

ON/OFF

To power ON the meter, rotate the Function Selector switch

from

the OFF setting to any measurement setting. To power OFF the meter,

rotate the Function Selector switch

to the OFF setting. By default,

the meter will automatically power OFF after 15 minutes of inactivity.

If the meter automatically powers OFF while in a measurement

setting, press any button to power ON the meter. To deactivate

the power OFF functionality press and hold the "NCV" button

before powering ON from the OFF setting. When auto power OFF

is deactivated, the Auto Power Off icon will not be visible in the

display.

DATA HOLD / BACKLIGHT

Press the Hold/Backlight button

to hold the current reading on the

LCD. Press again to return to live measuring. Press and hold to turn

ON or OFF the backlight. NOTE: The backlight will automatically turn

OFF after 3 minutes of inactivity.

NON-CONTACT VOLTAGE TESTING

Press and hold the NCV button

to test for AC voltage using the

integrated non-contact voltage tester. Approach the conductor under

test leading with the sensing antenna

. The meter delivers audible

and visual warning signals

when AC voltage is detected.

Non-contact voltage tester only detects AC voltages >70V AC RMS.

ENGLISH

OPERATING INSTRUCTIONS

CONNECTING TEST LEADS

Do not test if leads are improperly seated. Results could cause

intermittent display readings. To ensure proper connection, firmly

press leads into the input jack completely.

TESTING IN CAT III / CAT IV MEASUREMENT LOCATIONS

Ensure the test lead shield is pressed firmly in place. Failure to use

the CATIII / CATIV shield increases arc-flash risk.

TESTING IN CAT II MEASUREMENT LOCATIONS

CAT III / CAT IV shields may be removed for CAT II locations. This

will allow testing on recessed conductors such as standard wall

outlets. Take care not to lose the shields.

5/32"

(4 mm)

.7" (18 mm)

INCORRECT

CORRECT

WIRE

ENGLISH

OPERATING INSTRUCTIONS

AC CURRENT (LESS THAN 200A)

AC Current is measured by positioning the open jaw fork

around

a current-carrying wire. When measuring, care should be taken to

ensure that the wire passes perpendicularly through the center of the

open jaw fork in line with the arrow markings

To measure current:

1. Rotate the Function Selector switch

to the AC current A

setting.

2. Place open jaw fork

around wire. The current measurement will be

shown in the display.

Disconnect test leads when measuring with the open-jaw fork.

DC VOLTAGE (LESS THAN 1000V)

1. Insert RED test lead into VΩ jack

, and BLACK test lead into

COM jack

, and rotate function selector switch

to the

DC voltage V setting. Note "DC" on the display.

2. Apply test leads to the circuit to be tested to measure voltage.

The meter will auto-range to display the measurement in the

most appropriate range.

NOTE: If "–" appears on the LCD, the test leads are being applied to

the circuit in reverse. Swap the position of the leads to correct this.

NOTE: When in a voltage setting and the test leads are open,

readings of order mV may appear on the display. This is noise and

is normal. By touching the test leads together to close the circuit

the meter will measure zero volts.

OPERATING INSTRUCTIONS

AC VOLTAGE (LESS THAN 600V)

1. Insert RED test lead into VΩ jack

, and BLACK test lead into

COM jack

, and rotate function selector switch

to the

AC voltage V setting. Note "AC" on the display.

2. Apply test leads to the circuit to be tested to measure AC

voltage, the measurement will be presented in the display.

NOTE: When in a voltage setting and the test leads are open,

readings of order mV may appear on the display. This is noise and

is normal. By touching the test leads together to close the circuit

the meter will measure zero volts.

Black lead Red lead

ENGLISH

RESISTANCE MEASUREMENTS

1. Insert RED test lead into VΩ jack

, and BLACK test lead into

COM jack

, and rotate function selector switch

to the

Resistance

setting. The Resistance icon will appear on the

display.

2. Remove power from circuit.

3. Measure resistance by connecting test leads to circuit. The

meter will auto-range to display the measurement in the most

appropriate range.

NOTE: When in a Resistance setting and the test leads are open

(not connected across a resistor), or when a failed resistor is under

test, the display will indicate O.L. This is normal.

DO NOT attempt to measure resistance on a live circuit.

CONTINUITY

1. Insert RED test lead into VΩ jack

, and BLACK test lead into

COM jack

, and rotate function selector switch

to the

Continuity setting. The Continuity icon will appear on the

display.

2. Remove power from circuit.

3. Test for continuity by connecting conductor or circuit with test

leads. If resistance is measured less than 10Ω, an audible signal

will sound and display will show a resistance value indicating

continuity. If circuit is open display will show "OL".

DO NOT attempt to measure continuity on a live circuit.

OPERATING INSTRUCTIONS

Black lead Red lead

Autres manuels pour CL360

Table des matières

Langues :

Autres manuels Klein Tools Instrument de mesure

Klein Tools

Klein Tools CL445 Manuel utilisateur

Klein Tools

Klein Tools 935DAF Manuel utilisateur

Klein Tools

Klein Tools CL310 Manuel utilisateur

Klein Tools

Klein Tools CL360 Manuel utilisateur

Klein Tools

Klein Tools CL800 Manuel utilisateur

Klein Tools

Klein Tools Ranger TDR VDV501-090 Manuel utilisateur

Klein Tools

Klein Tools CL312 Manuel utilisateur

Klein Tools

Klein Tools 501-915 Manuel utilisateur

Klein Tools

Klein Tools CL390 Manuel utilisateur

Klein Tools

Klein Tools VDV500-705 Manuel utilisateur

Klein Tools

Klein Tools CL1200 Manuel utilisateur

Klein Tools

Klein Tools CL3200 Manuel utilisateur

Klein Tools

Klein Tools Probe-Pro Manuel utilisateur

Klein Tools

Klein Tools ET450 Manuel utilisateur

Klein Tools

Klein Tools VDV500-051 Manuel utilisateur

Klein Tools

Klein Tools 93MCLG Manuel utilisateur

Klein Tools

Klein Tools VDV500-123 Probe-Pro Manuel utilisateur

Klein Tools

Klein Tools CL2000 Manuel utilisateur

Klein Tools

Klein Tools 935DAA Manuel utilisateur

Klein Tools

Klein Tools LAN Scout Jr. 2 Manuel utilisateur

Klein Tools

Klein Tools CL1100 Manuel utilisateur

Klein Tools

Klein Tools 93LDM100C Manuel utilisateur

Klein Tools

Klein Tools CL700 Manuel utilisateur

Klein Tools

Klein Tools ET100 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
