E5061B/E5063A Security Feature

Rev. 6.0

March 2018

Page 2 of 16

Contacting Keysight Sales and Service Offices

Assistance with test and measurements needs and information on finding local Keysight

offices are available on the internet at, http://www.keysight.com/find/assist. If you do not

have access to the internet, please contact your field engineer.

Note: In any correspondence or telephone conversations, refer to the signal generator by

its model number and full serial number. With this information, the Keysight

representative can determine whether your unit is still within its warranty period.

Product Declassification and Security Product Name: Network Analyzer

Model Number(s): E5061B/E5063A

Page 3 of 16

Product Declassification and Security

Model Number(s): E5061B/E5063A

Product Name: Network Analyzer

Product Family Name: ENA

This document describes instrument security features and the steps to declassify an

instrument through memory sanitization or removal.

Table of Contents

Terms and Definitions. …………………………………………….......4

Instrument Memory……………………………………………….....….5

Memory Clearing, Sanitization and/or Removal………………6

User and Remote Interface Security ………...……………….….10

Product Declassification and Security Product Name: Network Analyzer

Model Number(s): E5061B/E5063A

Page 4 of 16

Terms and Definitions

Definitions:

Clearing –Clearing is the process of eradicating the data on media before reusing the media so that the

data can no longer be retrieved using the standard interfaces on the instrument. Clearing is typically used

when the instrument is to remain in an environment with an acceptable level of protection.

Sanitization –Sanitization is the process of removing or eradicating stored data so that the data cannot

be recovered using any known technology. Instrument sanitization is typically required when an instrument

is moved from a secure to a non-secure environment such as when it is returned to the factory for

calibration. Keysight memory sanitization procedures are designed for customers who need to meet the

requirements specified by the US Defense Security Service (DSS). These requirements are outlined in the

“Clearing and Sanitization Matrix” issued by the Cognizant Security Agency (CSA) and referenced in National

Industrial Security Program Operating Manual (NISPOM) DoD 5220.22M ISL 01L-1 section 8-301.

Security erase –Security erase is a term that is used to refer to either the clearing or sanitization

features of Keysight instruments.

Instrument declassification –A term that refers to procedures that must be undertaken before an

instrument can be removed from a secure environment such as is the case when the instrument is returned

for calibration. Declassification procedures will include memory sanitization and/or memory removal.

Keysight declassification procedures are designed to meet the requirements specified by the DSS NISPOM

security document (DoD 5220.22M chapter 8)

Product Declassification and Security Product Name: Network Analyzer

Model Number(s): E5061B/E5063A

Page 5 of 16

Instrument Memory

This section contains information on the types of memory available in your instrument. It explains the size of

memory, how it is used, its location, volatility, and the sanitization procedure.

Summary of instrument memory - base instrument

Memory Type and Size

Writable During

Normal Operation?

Data Retained When

Powered Off?

Purpose/Cont

ents

Data Input

Method

Location in

Instrument and

Remarks

Sanitization

Procedure

Main Memory (RAM)

E5061B

2GB[SN:MY491xxxxx]

2GB[SN:MY492xxxxx]

4GB[SN:MY493xxxxx]

4GB[SN:MY494xxxxx]

4GB[SN:MY495xxxxx]

4GB[SN:MY496xxxxx]

4GB[SN:MY497xxxxx]

4GB[SN:MY498xxxxx]

E5063A

4GB[SN:MY541xxxxx]

4GB[SN:MY542xxxxx]

4GB[SN:MY543xxxxx]

4GB[SN:MY544xxxxx]

4GB[SN:MY545xxxxx]

Yes

Windows

Operating

system

memory

Operating

system (not

user defined)

E5061B

A50/A60/A70/A80/

A53 CPU Module

E5063A

A80/ A53 CPU

Module

Cycle power

Media Storage

E5061B

(Hard Disk Drive)

160 GB –

[Revision Prefix:

ELxxx, KY203 -

KY221]

320 GB –

[Revision Prefix:

KY222]

(Solid State Drive)

80 GB –

[Revision Prefix:

KWxxx, YD472 -

YD486]

Yes

Windows

Operating

system boot

device,

factory

correction

data, and

users file

including

saved traces

data,

settings, or

images.

User-Saved

Data

Operating

system (not

user defined)

HDD/SSD assembly

Remove

Product Declassification and Security Product Name: Network Analyzer

Model Number(s): E5061B/E5063A

Page 6 of 16

150 GB –

[Revision Prefix:

YD488 and above]

E5063A

(Solid State Drive)

80 GB –

[Revision Prefix: KA,

KD, KE]

150 GB –

[Revision Prefix: KE,

FK]

Memory for DSP

module (RAM)

Yes

Data

Processing

for

measurement

Measurement

(not user

defined)

A51/ A71 DSP

Module

Cycle power

Non-volatile

Memory (Flash)

Yes

Product serial

number,

Options

System

calibration

data

(E5061B)

(not user

defined

calibration

data)

Adjustment

Program

performed by

Keysight

factory

personnel or

by calibration

labs

A51/ A71 DSP

Module

N/A

(The data is

not stored

by user

under

normal

operation.)

Non-volatile

Memory

Yes

Module serial

number,

Revision

number

System

Calibration

Data

(E5063A)

Calibration at

factory

E5061B

A1 /A11 Source

Module

A2 Receiver Module

(Opt. 3L5)

A3 Receiver Module

(Opt. xx5, 50 ohm)

A4 Receiver Module

(Opt. xx7, 75 ohm)

A9 LF Source/Bias

Module (Opt. 3L5)

E5063A

For MY541/542,

A1 Analog Module

(All frequency

options)

For MY543/544/545

N/A

(The data is

not stored

by user

under

normal

operation.)

Product Declassification and Security Product Name: Network Analyzer

Model Number(s): E5061B/E5063A

Page 7 of 16

and above,

A1 Analog Module

(Opt 2D5/ 2H5)

A3 Analog Module

(Opt

205/215/235/245/2

65/285)

Product Declassification and Security Product Name: Network Analyzer

Model Number(s): E5061B/E5063A

Page 8 of 16

Memory Clearing, Sanitization and/or Removal Procedures

This section explains how to clear, sanitize, and remove memory from your instrument for all memory types.

Description and

purpose

Main Memory for Windows Operating system memory

Size

Windows XP: 2 GB, Windows 7: 4 GB, Windows 10: 4 GB

Memory clearing

Power rebooting. This is a volatile memory.

Memory sanitization

Power rebooting. This is a volatile memory.

Memory removal

This memory cannot be removed without damaging the instrument

Write protecting

N/A

Memory validation

N/A

Remarks

Description and

purpose

Media Storage (Hard Disk Drive/Solid State Drive)

Size

Windows XP/HDD:160 GB/ 320 GB, Windows 7/SSD: 80 GB/ 150 GB,

Windows 10/SSD: 150GB.

E5061B.

(Hard Disk Drive)

160 GB –[Revision Prefix: ELxxx, KY203 - KY221]

320 GB –[Revision Prefix: KY222]

(Solid State Drive)

80 GB –[Revision Prefix: KWxxx, YD472 - YD486]

150 GB –[Revision Prefix: YD488, YF]

E5063A

(Solid State Drive)

80 GB –[Revision Prefix: KA, KD, KE]

150 GB –[Revision Prefix: KE, FK]

Memory clearing

N/A

Memory sanitization

N/A

Memory removal

The storage drive needs to be removed and replaced with a new or unused

hard disk drive part as per the service manual.

Write protecting

N/A

Memory validation

N/A

Remarks

Description and

purpose

Memory for DSP (RAM) for A51 DSP Module

Size

1.8M bit

Memory clearing

Power rebooting. This is a volatile memory.

Memory sanitization

Power rebooting. This is a volatile memory.

Memory removal

This memory cannot be removed without damaging the instrument.

Write protecting

N/A

Memory validation

N/A

Remarks

Product Declassification and Security Product Name: Network Analyzer

Model Number(s): E5061B/E5063A

Page 9 of 16

Description and

purpose

Non-volatile memory (Flash) for A51 DSP Module. This memory is for

product serial number and option. The system calibration data are also

stored in the E5063A. (Any user data is not stored in these memory)

Size

64 MB

Memory clearing

N/A

Memory sanitization

N/A

Memory removal

The A51 DSM module needs to be removed and replaced with a new or

unused module as per the service manual. See E5061B/E5063A Service

Manual for more detail information on the procedure as well as the

replacement parts.

Write protecting

N/A

Memory validation

N/A

Remarks

Description and

purpose

E5061B Non-volatile memory (EEPROM) for A1, A2, A3, A4, A9 and A11

Modules. These memories are for board serial number, board revision

number. (Any user data is not stored in these memories)

Size

256 M Bit

Memory clearing

N/A

Memory sanitization

N/A

Memory removal

The E5061B A1, A2, A3, A4, A9 and A11 modules need to be removed and

replaced with a new or unused module as per the service manual. See the

E5061B Service Manual for more detail information on the procedure as

well as the replacement parts.

Write protecting

N/A

Memory validation

N/A

Remarks

Description and

purpose

E5063A Non-volatile memory (flash) for A1 Modules. These memories are

for board serial number, board revision number, and system calibration

data.

Size

2 MB

Memory clearing

N/A

Memory sanitization

N/A

Memory removal

The E5063A A1 modules need to be removed and replaced with a new or

unused module as per the service manual. See the E5063A Service Manual

for more detail information on the procedure as well as the replacement

parts.

Write protecting

N/A

Memory validation

N/A

Remarks

Storage removal (E5063A/E5061B-020 only for E5061B )

Because it is virtually impossible to completely and selectively erase all user data on a

hard drive without also destroying the operating system, the best method for maintaining

security when the E5061B/E5063A must be removed from a secure area is to replace the

storage with a "non-secure" hard drive, i.e. a drive that has never had any sensitive data

Product Declassification and Security Product Name: Network Analyzer

Model Number(s): E5061B/E5063A

Page 10 of 16

placed on it. This allows the E5061B/E5063A to still function properly in non-secured

areas or for use when servicing.

The E5061B-020 and all E5063A have a removable storage on the rear panel. Keysight

has available a pre-configured storage for the E5061B/E5063A that must be purchased in

order for this security method to work. A spare disk is available as below.

Product Number

Windows License (See the Windows label on the

rear panel)

Keysight Part

Number

E5061B

Windows Vista Business

Not Assigned

Windows XP Pro for Embedded Systems

E5061-65003

Windows Embedded Standard 7 (For MY494/

SG494, MY495/ SG495)

E5061-65004

Windows Embedded Standard 7 (For MY496/

SG496, MY497/ SG497)

E5061-65054

Windows 10 IoT

E5061-65055

E5063A

Windows Embedded Standard 7 (For MY541/

SG541)

E5063-65001

Windows Embedded Standard 7 (For MY542/

SG542)

E5063-65051

Windows Embedded Standard 7 (For MY543/

SG543)

E5063-65052

Windows 10 IoT

E5063-65056

Note: The limited number of times for removing/connecting is 50 times.

Hard disk removal procedure:

Two main variants of removable storage with distinct differences according to the listed

serial prefix.

The serial prefix identification is no longer applicable to the instrument(s) with digital

hardware/ OS upgrades applied. Refer to the physical appearance in identifying the

storage removal procedure.

These steps should be followed to maintain security:

Storage Removal Procedure A –Applicable to the following serial numbers

E5061B –Serial Prefix MY497 or SG497 and below

E5063A –Serial Prefix MY542 or SG542 and below

Storage Removal Procedure B –Applicable to the following serial numbers

E5061B –Serial Prefix MY498 or SG498 and above

E5063A –Serial Prefix MY543/MY544/MY545 or SG543/SG544/SG545 and above

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Keysight Technologies Instrument de mesure

Keysight Technologies

Keysight Technologies EXA Manuel d'installation et d'exploitation

Keysight Technologies

Keysight Technologies 86120B Manuel utilisateur

Keysight Technologies

Keysight Technologies N5241BU-677 Manuel utilisateur

Keysight Technologies

Keysight Technologies B2900B Series Manuel utilisateur

Keysight Technologies

Keysight Technologies M9216A Guide de l'utilisateur

Keysight Technologies

Keysight Technologies M9393A Manuel utilisateur

Keysight Technologies

Keysight Technologies 8163A/B Mode d'emploi

Keysight Technologies

Keysight Technologies M9393A Guide de démarrage rapide

Keysight Technologies

Keysight Technologies N5245-60106 Manuel d'installation et d'exploitation

Keysight Technologies

Keysight Technologies N5221/2A Series Manuel utilisateur

Keysight Technologies

Keysight Technologies X-Series Manuel utilisateur

Keysight Technologies

Keysight Technologies UXA N9040B Manuel d'installation et d'exploitation

Keysight Technologies

Keysight Technologies B2901A Manuel utilisateur

Keysight Technologies

Keysight Technologies 85059B Manuel de service

Keysight Technologies

Keysight Technologies U2000 Series Manuel utilisateur

Keysight Technologies

Keysight Technologies EXA N9010B Guide de démarrage rapide

Keysight Technologies

Keysight Technologies M9391A PXIe Manuel utilisateur

Keysight Technologies

Keysight Technologies B2981A Guide d'installation

Keysight Technologies

Keysight Technologies N9322C Manuel utilisateur

Keysight Technologies

Keysight Technologies PXA N9030A Manuel utilisateur

Keysight Technologies

Keysight Technologies N9000A Manuel utilisateur

Keysight Technologies

Keysight Technologies N9029AV01-V19 Manuel utilisateur

Keysight Technologies

Keysight Technologies B2900A Series Manuel utilisateur

Keysight Technologies

Keysight Technologies X Series Manuel d'installation et d'exploitation

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
