Juniper Networks CTP2000 Circuit to

Packet Platform

Upgrade to CTPOS 7.x

Modified: 2015-11-17

Juniper Networks, Inc.

1133 Innovation Way

Sunnyvale, California 94089

USA

408-745-2000

www.juniper.net

Juniper Networks, Junos, Steel-Belted Radius, NetScreen, and ScreenOS are registered trademarks of Juniper Networks, Inc. in the United

States and other countries. The Juniper Networks Logo, the Junos logo, and JunosE are trademarks of Juniper Networks, Inc. All other

trademarks, service marks, registered trademarks, or registered service marks are the property of their respective owners.

Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper Networks reserves the right to change, modify,

transfer, or otherwise revise this publication without notice.

Products made or sold by Juniper Networks or components thereof might be covered by one or more of the following patents that are

owned by or licensed to Juniper Networks: U.S. Patent Nos. 5,473,599, 5,905,725, 5,909,440, 6,192,051, 6,333,650, 6,359,479, 6,406,312,

6,429,706, 6,459,579, 6,493,347, 6,538,518, 6,538,899, 6,552,918, 6,567,902, 6,578,186, and 6,590,785.

Upgrade to CTPOS 7.x

Revision History

December 2015—Revision 1;

The information in this document is current as of the date on the title page.

END USER LICENSE AGREEMENT

The Juniper Networks product that is the subject of this technical documentation consists of (or is intended for use with) Juniper Networks

software. Use of such software is subject to the terms and conditions of the End User License Agreement (“EULA”) posted at

http://www.juniper.net/support/eula.html. By downloading, installing or using such software, you agree to the terms and conditions of

that EULA.

Table of Contents

Chapter 1 Introduction to CTPOS 7.0 Upgrade Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

CTPOS7.0R1andLaterUpgradeKits....................................7

PP310 Upgrade Kit - CTP2000-RAM-RTM-UPG . . . . . . . . . . . . . . . . . . . . . . . 8

PP332 Upgrade Kit - CTP2000-RAM-UPG . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

PP833 Upgrade Kit - CTP2000-RAM-RTM-UPG . . . . . . . . . . . . . . . . . . . . . . . 9

Chapter 2 Upgrading the CTP2000 Series Device to CTPOS 7.x . . . . . . . . . . . . . . . . . . . 11

UpgradingwiththePP310UpgradeKit..................................11

UpgradingwiththePP332UpgradeKit..................................13

UpgradingwiththePP833UpgradeKit..................................14

Using the Upgrade CompactFlash Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Migrating from a Previous Operating System . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Preparing a System for Firstboot Using CTPOS 7.0R1 and Later . . . . . . . . . . 20

RegisteringYourUpgrade.............................................22

Related Procedures .................................................22

ServicingtheCTP2000CPU......................................23

Installing or Replacing CTP2000 DRAM Memory Modules in the PP310 or

PP332CPU.................................................23

Restoring BIOS Defaults for the CTPOS 7.0R1 and Later Upgrade

(PP310) ...................................................24

Installing or Removing a CTP2000 Series CompactFlash Card . . . . . . . . . . . 26

Upgrading the CTP2000 Series Device to CTPOS 7.x

List of Figures

Chapter 1 Introduction to CTPOS 7.0 Upgrade Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Figure1:PP310CPU..................................................7

Figure2:PP332CPU..................................................7

Chapter 2 Upgrading the CTP2000 Series Device to CTPOS 7.x . . . . . . . . . . . . . . . . . . . 11

Figure 3: RTM Default Jumper Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Figure 4: CompactFlash Adapter with CompactFlash Card Inserted . . . . . . . . . . . 17

Figure 5: DRAM Memory Module Replacement — PP310 . . . . . . . . . . . . . . . . . . . . 24

Figure 6: Jumper Setting for Restoring BIOS Defaults . . . . . . . . . . . . . . . . . . . . . . 25

Figure7:CompactFlashontheRTM....................................26

Upgrading the CTP2000 Series Device to CTPOS 7.x

CHAPTER 1

Introduction to CTPOS 7.0 Upgrade Kits

•CTPOS 7.0R1 and Later Upgrade Kits on page 7

CTPOS 7.0R1 and Later Upgrade Kits

Because of the new features and hardware supported in CTPOS 7.0R1 and later, a direct

code upgrade by means of an upgrade archive from earlier versions of CTPOS is not

supported. This topic includes the procedures for performing an upgrade using an upgrade

kit and for registering the upgrade. There are three upgrade kits, the use of which depends

on whether you are using a PP310, PP332, or PP833 processor in your CTP2000 series

device. Figure 1 on page 7 shows the front of the CPU that contains the PP310 processor

and Figure 2 on page 7 shows the front of the CPU that contains the PP332 processor.

Figure 1: PP310 CPU

Figure 2: PP332 CPU

NOTE: You must register your upgrade and validate it with Juniper Networks.

If your upgrade kit includes a new RTM, you must also register the RTM. After

you register the upgrade and, if included, the RTM, allow up to 45 days for

restocking of the new hardware configuration to support any Next Day or

Same Day contracts. Juniper Networks will provide Best Effort support until

restocking of the converted product is complete. After the registration process

is completed and the new configuration is updated in the depot, you will have

access to the software and tools that support your device.

NOTE: The use of the upgrade kit is supported only on CTP2000 Series

products.

CAUTION: You cannot use CTPView to perform a system save of a node

running a version of CTPOS before 7.0R1 and restore the system to a node

running 7.0R1 and later. CTPView cannot be used to migrate from pre-7.0R1

to 7.0R1 and later. System save/restore between different CTPOS versions is

not supported.

PP310 Upgrade Kit - CTP2000-RAM-RTM-UPG

The PP310 upgrade kit contains:

•4-GB CTPOS 7.0R1 or later upgrade CompactFlash card

•USB to CompactFlash adapter

•1-GB non-ECC RAM module

•Rear transition module (RTM)

•Jumper (for BIOS reset)

PP332 Upgrade Kit - CTP2000-RAM-UPG

The PP332 upgrade kit contains:

•4-GB CTPOS 7.0R1 upgrade CompactFlash card

•USB to CompactFlash adapter

•1-GB ECC RAM module

Upgrading the CTP2000 Series Device to CTPOS 7.x

NOTE: The 4-GB upgrade CompactFlash card and USB to CompactFlash

adapters are the same in both kits. Whereas the PP310 and PP332 use the

same model RTM after you complete the upgrade, the RTMs are jumpered

differently for the two processors. Switching RTMs from a PP310 to a PP332

or vice versa without changing the jumper settings can damage the CPU.

PP833 Upgrade Kit - CTP2000-RAM-RTM-UPG

The PP833 upgrade kit contains:

•4-GB CTPOS 7.0R1 upgrade CompactFlash card

•USB to CompactFlash adapter

•1-GB ECC RAM module (two slots of 4096 MB)

•Rear transition module (RTM)

•Jumper (for BIOS reset)

RAM Details

Handle 0x001B, DMI type 17, 34 bytesMemory Device Array Handle: 0x001A

Error Information Handle: 0x001D Total Width: 128 bits Data

Width: 64 bits Size: 4096 MB Form Factor: DIMM Set: None

Locator: ChannelA-DIMM0 Bank Locator: BANK 0 Type: DDR3

Type Detail: Synchronous Speed: Unknown Manufacturer: CCT Memory

Serial Number: No serial number Asset Tag: 0123456789 Part

Number: No part number Rank: Unknown Configured Clock Speed: 1333

MHzHandle 0x001F, DMI type 17, 34 bytesMemory Device Array Handle: 0x001A

Error Information Handle: 0x0021 Total Width: 128 bits Data

Width: 64 bits Size: 4096 MB Form Factor: DIMM Set: None

Locator: ChannelB-DIMM0 Bank Locator: BANK 2 Type: DDR3

Type Detail: Synchronous Speed: Unknown Manufacturer: CCT Memory

Serial Number: No serial number Asset Tag: 0123456789 Part

Number: No part number Rank: Unknown Configured Clock Speed: 1333

MHz

Chapter 1: Introduction to CTPOS 7.0 Upgrade Kits

Upgrading the CTP2000 Series Device to CTPOS 7.x
