Juniper JSA7500 Manuel utilisateur
Juniper Secure Analycs Hardware Guide
Published
2021-05-24
Juniper Networks, Inc.
1133 Innovaon Way
Sunnyvale, California 94089
USA
408-745-2000
www.juniper.net
Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc.
in the United States and other countries. All other trademarks, service marks, registered marks, or registered service
marks are the property of their respecve owners.
Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper Networks reserves the right
to change, modify, transfer, or otherwise revise this publicaon without noce.
Juniper Secure Analycs Hardware Guide
Copyright © 2021 Juniper Networks, Inc. All rights reserved.
The informaon in this document is current as of the date on the tle page.
YEAR 2000 NOTICE
Juniper Networks hardware and soware products are Year 2000 compliant. Junos OS has no known me-related
limitaons through the year 2038. However, the NTP applicaon is known to have some diculty in the year 2036.
END USER LICENSE AGREEMENT
The Juniper Networks product that is the subject of this technical documentaon consists of (or is intended for use
with) Juniper Networks soware. Use of such soware is subject to the terms and condions of the End User License
Agreement ("EULA") posted at hps://support.juniper.net/support/eula/. By downloading, installing or using such
soware, you agree to the terms and condions of that EULA.
ii
Table of Contents
About This Guide | vii
1
Overview
Introducon | 2
JSA Appliance Models | 2
JSA Appliance Hardware Features | 3
2
Components
Hardware Components and Specicaons | 6
Hardware Specicaons | 6
JSA Transceiver Interface | 8
JSA7500 | 10
JSA7500 Front Panel | 10
JSA7500 Back Panel | 12
3
Planning
Site Preparaon | 15
Addional Hardware Requirements | 15
General Site Installaon Guidelines for the JSA Appliance | 16
JSA Appliance Rack Requirements | 17
4
Safety
General Safety and Regulatory Informaon | 20
General Safety Guidelines and Warnings | 20
Denions of Safety Warning Levels | 21
Fire Safety Requirements | 23
Qualied Personnel Warning | 24
Warning Statement for Norway and Sweden | 25
iii
Agency Approvals for JSA | 26
Radiaon and Laser Warnings | 28
Laser and LED Safety Guidelines and Warnings for JSA | 28
Radiaon from Open Port Apertures Warning | 31
Installaon and Maintenance Safety Informaon | 33
Installaon Instrucons Warning | 33
Chassis Liing Guidelines for JSA | 34
Ramp Warning | 35
Rack-Mounng Warnings | 35
Grounded Equipment Warning | 40
Maintenance and Operaonal Safety Guidelines and Warnings | 41
Power and Electrical Safety Informaon | 47
General Electrical Safety Guidelines and Warnings | 47
Prevenon of Electrostac Discharge Damage | 49
AC Power Electrical Safety Guidelines | 51
AC Power Disconnecon Warning | 52
DC Power Electrical Safety Guidelines | 53
DC Power Disconnecon Warning | 54
DC Power Grounding Requirements and Warning | 56
DC Power Wiring Sequence Warning | 57
DC Power Wiring Terminaons Warning | 59
Mulple Power Supplies Disconnecon Warning | 60
TN Power Warning | 61
Acon to Take Aer an Electrical Accident | 61
Compliance Statements | 63
Compliance Statements for EMC Requirements for JSA | 63
iv
Compliance Statements for Acousc Noise for JSA | 66
Compliance Statements for NEBS Standards for JSA7500 | 66
5
Installaon
Hardware Installaon Overview | 69
Rack-Mount Installaon Overview | 69
Required Tools and Parts for Installing the JSA Appliance | 69
Soware Installaon Overview | 71
JSA Components | 71
Browser Support | 73
Preparing the Network Hierarchy | 73
Connecng the JSA Appliance | 77
Grounding the JSA7500 Appliance | 77
Connecng JSA7500 to a DC Power Source | 80
Connecng to a Management Device | 82
Installing the JSA Appliance | 83
Installing the JSA Hardware | 83
Front-and-Rear-Mounng the JSA Appliance Flush to a Rack | 86
Front-and-Rear-Mounng the JSA Appliance Recessed in a Rack | 87
Front-and-Rear-Mounng the JSA7500 in a 4-Post Sliding Rail Rack | 88
Mid-Mounng the JSA Appliance in a Two-Post Rack | 92
Installing the CNA Module on the JSA7500 Appliance | 94
Conguring Basic Sengs | 96
Idenfying Network Sengs | 96
Idenfying Security Monitoring Devices and Flow Data Sources | 97
Idenfying Network Assets | 97
Conguring Secure Web Access | 99
Conguring the Basic Sengs | 99
v
Accessing the JSA Interface | 102
6
Maintenance
Maintaining the Hardware | 105
Field-Replaceable Units on the JSA Appliance | 105
Replacing the Fan on the JSA Appliance | 106
Replacing the Air Filter on the JSA7500 Appliance | 109
Replacing an AC Power Supply on the JSA Appliance | 110
Replacing AC Power Supply Cables on the JSA Appliance | 111
Replacing a DC Power Supply on the JSA Appliance | 112
Replacing DC Power Supply Cables on the JSA Appliance | 113
7
Troubleshoong
Monitoring Hardware Components | 115
RAID Array | 115
Power Supply | 116
Cooling Fans | 117
Maintaining the JSA7500 Air Filter | 117
Juniper Networks Technical Assistance Center | 119
Contacng Juniper Networks Technical Assistance Center | 119
Knowledge Base | 120
vi
About This Guide
Use this guide to install hardware and perform inial soware conguraon, roune maintenance, and
troubleshoong for JSA7500.
Aer compleng the installaon and basic conguraon procedures covered in this guide, refer to the
JSA soware documentaon for informaon about further soware conguraon. See Juniper Secure
Analycs.
Juniper Secure Analycs (JSA) appliances are designed to respond to the right threats at the right me
through eecve analysis of networks, events, and audit log les. JSA has the ability to idenfy
environmental anomalies in the network, an aack path, and the source of a threat. JSA provides
network remediaon for threat responses across all security products.
RELATED DOCUMENTATION
Hardware Guide
Quick Start Guide
Release Notes
Introducing JSA5500
Introducing JSA7500
STRM Series to JSA Series Migraon Guide
Installing JSA Using a Bootable USB Flash-Drive Technical Note
vii
CHAPTER 1
Introducon
IN THIS CHAPTER
JSA Appliance Models | 2
JSA Appliance Hardware Features | 3
JSA Appliance Models
Juniper Secure Analycs (JSA) appliances are designed to respond to the right threats at the right me
through eecve analysis of networks, events, and audit log les. JSA has the ability to idenfy
environmental anomalies in the network, an aack path, and the source of a threat. JSA provides
network remediaon for threat responses across all security products.
The JSA appliances use two drivers, Security Informaon Management (SIM) and Security Event
Management (SEM), for security analysis of external and internal threats. SIM provides reporng and
analysis of data from host systems, applicaons, and security devices to support security policy
compliance management, internal threat management, and regulatory compliance iniaves. SEM
improves security incident response capabilies by processing data from security devices and network
devices. It helps network administrators to provide eecve responses to external and internal threats.
Table 1 on page 2 lists the Juniper Secure Analycs (JSA) appliance models.
Table 1: JSA Appliance Models
Model Device Type Memory Storage Conguraon
JSA3800 Low memory 64 GB Six 900 GB HDDs, RAID10
For more informaon on
JSA3800, see JSA3800
Hardware Guide
2
Table 1: JSA Appliance Models
(Connued)
Model Device Type Memory Storage Conguraon
JSA5800 High memory 128 GB Eight 900 GB HDDs, RAID10
For more informaon on
JSA5800, see JSA5800
Hardware Guide
JSA7500 High memory 128 GB 28 drives of 900 GB HDDs,
RAID10
JSA7800 High memory 128 GB Sixteen 2 TB HDDs, RAID6
For more informaon on
JSA7800, see JSA7800
Hardware Guide.
RELATED DOCUMENTATION
JSA Appliance Hardware Features | 3
Addional Hardware Requirements | 15
JSA Appliance Hardware Features
The Juniper Secure Analycs (JSA) appliance provides the following features:
• Monitor ulity for power supply unit (PSU) and fans
• Add setup logs automacally
• Support high availability (HA)
• Hot-swappable hard disk supporng RAID
•Automac RAID rebuild on HDD swap
3
