Juniper MX104 Manuel utilisateur

MX104 Universal Routing Platforms

Quick Start

April 2016

Part Number: 530-062013

Revision 02

This document describes how to install the Juniper Networks®MX104 Universal Routing Platform.

Contents MX104 Quick Start Description | 3

Step 1: Prepare the Site for MX104 Router Installation | 5

Step 2: Install the Router | 7

Tools Required to Install the Router in a Rack | 7

Install the MX104 Router in the Rack | 7

Step 3: Ground the MX104 Router | 9

Tools Required to Ground the MX104 Router | 9

Connect the Grounding Cable | 9

Step 4: Connect External Devices and Cables | 12

Connect the Router to a Network for Out-of-Band Management | 12

Connect the Router to a Management Console Device | 12

Connect MIC Cables to the MX104 Router | 13

Step 5: Connect Power to the MX104 Router | 15

Connect AC Power to an AC-Powered MX104 Router | 15

Connect DC Power to a DC-Powered MX104 Router | 16

Step 6: Perform Initial Software Configuration | 21

Enter Configuration Mode | 21

Configure User Accounts and Passwords | 22

Configure System Attributes | 22

Commit the Configuration | 23

Safety Warnings | 25

Compliance Statements for NEBS | 26

Compliance Statements for EMC Requirements | 27

Canada | 27

European Community | 27

Israel | 27

Japan | 28

United States | 28

Junos OS Documentation and Release Notes | 29

Requesting Technical Support | 29

Self-Help Online Tools and Resources | 29

Creating a Service Request with JTAC | 30

Revision History | 30

MX104 Quick Start Description

This Quick Start contains information you need to install and configure the router quickly. For complete

installation instructions, see the MX104 Universal Routing Platform Hardware Guide at

https://www.juniper.net/documentation/.

WARNING: This Quick Start contains a summary of safety warnings in “Safety

Warnings” on page 25. For a complete list of warnings for this router, including

translations, see the MX104 Universal Routing Platform Hardware Guide at

https://www.juniper.net/documentation/.

The router is environmentally hardened and is 3.5 rack units (U; that is 6.125 in., or 15.55 cm) tall. Several

routers can be stacked in a single floor-to-ceiling rack, for increased port density per unit of floor space.

The chassis installs in standard 11.81 in. (30 cm)-deep (or larger) enclosed cabinets, 19-in. equipment racks,

or telco open-frame racks.

Figure 1: Front View of the MX104 Router

g007602

17 16 15 1314 12

31 54 10 1198762

10—1—Grounding terminalsAlarm input and output contacts

11—2—Fan trayAlarm LEDs

12—3—MIC slots 0/1 and 1/110-Gigabit Ethernet SFP+ ports

13—4—Routing EngineONLINE/OFFLINE button

14—5—Routing EngineSystem status LED

15—6—Power supplies (AC or DC)External reference clocking port

16—7—Power supplies (AC or DC)Time-of-day (TOD) port

17—8—MIC slots 0/0 and 1/01-PPS and 10-MHz GPS input and output ports

9—ESD point

Step 1: Prepare the Site for MX104 Router Installation

Prepare your site for MX104 installation by observing the following guidelines:

•You can install the router in a four-post rack or cabinet or an open-frame rack.

•The rack rails must be spaced widely enough to accommodate the chassis's external dimensions: 6.125

in. or (15.55 cm) high, 9.5 in. (24.13 cm) deep, and 17.5 in. (44.5 cm) wide. The outer edges of the

mounting brackets extend the width to 19.2 in. (48.7 cm).

•One person must be available to lift the router while another secures the router to the rack.

•The rack must be strong enough to support the weight of the fully configured router, up to 32 lb (14.5 kg).

•For the cooling system to function properly, the airflow around the chassis must be unrestricted. Allow

at least 6 in. (15.2 cm) of clearance between side-cooled devices. Allow 2.8 in. (7 cm) between the side

of the chassis and any non-heat-producing surface such as a wall.

•For service personnel to remove and install hardware components, there must be adequate space at the

front and back of the router. Allow at least 30 in. (76.2 cm) in front of the router and 24 in. (61 cm)

behind the router.

•The rack or cabinet must have an adequate supply of cooling air.

•Ensure that the cabinet allows the chassis hot exhaust air to exit from the cabinet without recirculating

into the router.

•You must install the router into a rack that is secured to the building structure.

•Mount the router at the bottom of the rack if it is the only unit in the rack.

•When mounting the router in a partially filled rack, load the rack from the bottom to the top with the

heaviest component at the bottom of the rack.

•Install the router only in restricted areas, such as dedicated equipment rooms and equipment closets, in

accordance with Articles 110-16, 110-17, and 110-18 of the National Electrical Code, ANSI/NFPA 70.

Figure 2: MX104 Rack Clearance and Chassis Dimensions

Step 2: Install the Router

IN THIS SECTION

Tools Required to Install the Router in a Rack | 7

Install the MX104 Router in the Rack | 7

Tools Required to Install the Router in a Rack

To install the router in a rack, you need the following tools:

•Phillips (+) screwdriver, number 2

•ESD grounding wrist strap

Install the MX104 Router in the Rack

The router can be installed horizontally in a rack or cabinet.

Two people are required to install the MX104 router. The chassis weighs approximately 32 lb (14.5 kg).

To install the chassis (see Figure 3 on page 8):

1. Ensure that the rack is in its permanent location and is secured to the building. Ensure that the installation

site allows adequate clearance for both airflow and maintenance.

2. Position the router in front of the rack or cabinet.

3. Have one person grasp both sides of the router, lift the router, and position it in the rack, aligning the

mounting bracket holes with the threaded holes in the rack rails. Make sure the chassis is level.

4. Have the second person install a mounting screw into each of the open mounting holes aligned with

the rack, starting from the bottom.

5. Visually inspect the alignment of the router. If the router is installed properly in the rack, all the mounting

screws on one side of the rack should be aligned with the mounting screws on the opposite side, and

the router should be level.

Figure 3: Installing the Front-Mounted Router in the Rack

3—1—Mounting screwsRack

2—MX104 router

Step 3: Ground the MX104 Router

IN THIS SECTION

Tools Required to Ground the MX104 Router | 9

Connect the Grounding Cable | 9

Tools Required to Ground the MX104 Router

To ground the router, you need the following tools:

•Phillips (+) screwdriver, number 2

•ESD grounding wrist strap

•Two SAE 10-32 screws and washers

•Grounding lug, Panduit LCD10-10-L

•Grounding cable, use 14-AWG (2.08 mm2) 90°C wire for AC (not provided)

•Grounding cable, use 6-AWG (13.3 mm2) 60°C wire for 24V DC (not provided)

Connect the Grounding Cable

You ground the router by connecting a grounding cable to earth ground and then attaching it to the chassis

grounding points on the front of the router. To ground the router:

1. Verify that a licensed electrician has attached the cable lug provided with the router to the grounding

cable.

2. Attach an ESD grounding strap to your bare wrist, and connect the other end of the strap to an approved

site ESD grounding point. See the instructions for your site.

3. Ensure that all grounding surfaces are clean and brought to a bright finish before grounding connections

are made.

4. Connect the grounding cable to a proper earth ground.

5. Detach the ESD grounding strap from the site ESD grounding point.

6. Attach an ESD grounding strap to your bare wrist, and connect the other end of the strap to an ESD

grounding point.

7. Place the grounding cable lug over the grounding points on the front of the chassis (see

Figure 4 on page 11).

8. Secure the grounding cable lug with the washers and screws. The holes are sized for SAE 10-32 screws.

Apply 4.34 lb-in. (0.49 Nm) of torque to each screw. Do not overtighten the screw. (Use a number 2

Phillips screwdriver.)

CAUTION: Ensure that each grounding cable lug seats flush against the surface of

the grounding points as you are tightening the screws. Ensure that each screw is

properly threaded into the grounding points. Applying installation torque to the

screw when improperly threaded may result in damage to the terminal.

CAUTION: The maximum torque rating of the grounding screws on the router is

4.34 lb-in. (0.49 Nm). The grounding screws may be damaged if excessive torque

is applied. Use only a torque-controlled driver to tighten screws. Use an

appropriately sized driver, with a maximum torque capacity of 5 lb-in. or less. Ensure

that the driver is undamaged and properly calibrated and that you have been trained

in its use. You may wish to use a driver that is designed to prevent overtorque when

the preset torque level is achieved.

9. Dress the grounding cable, and verify that it does not touch or block access to router components, and

that it does not drape where people could trip on it.
