Interlogix TruVision Line Manuel utilisateur

P/N 1072666A-EN • REV 1.0 • ISS 24SEP13

TruVision IP PTZ

Camera Installation

Guide

Interlogix is part of UTC Climate Controls & Security, a unit of United Technologies Corporation.

Trademarks and

patents

The Product Name and logo are trademarks of United Technologies.

Other trade names used in this document may be trademarks or registered trademarks of the

manufacturers or vendors of the respective products.

Manufacturer UTC Fire & Security Americas Corporation, Inc.

2955 Red Hill Avenue, Costa Mesa, CA 92626-5923, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

Certification

N4131

FCC compliance Class A: This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may cause

harmful interference to radio communications. Operation of this equipment in a residential area

is likely to cause harmful interference in which case the user will be required to correct the

interference at his own expense

ACMA compliance Notice! This is a Class A product. In a domestic environment this product may cause radio

interference in which case the user may be required to take adequate measures.

Canada This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme NMB-0330 du Canada.

European Union

directives

12004/108/EC (EMC directive): Hereby, UTC Fire & Security declares that this device is in

compliance with the essential requirements and other relevant provisions of Directive

2004/108/EC.

2002/96/EC (WEEE directive): Products marked with this symbol cannot be disposed of as

unsorted municipal waste in the European Union. For proper recycling, return this product to

your local supplier upon the purchase of equivalent new equipment, or dispose of it at

designated collection points. For more information see: www.recyclethis.info.

Contact information For contact information, see www.interlogix.com or www.utcfssecurityproducts.eu.

Installation Guide 3

Content

Introduction 3

Product overview 3

Before you begin 4

Installation environment 4

Camera description 5

Installing a camera 6

Pendant-mount camera 6

Flush-mount camera 8

Surface-mount camera 10

Using the camera with an Interlogix NVR or Hybrid DVR or

another system 14

Using the camera with TruVision Navigator 14

Accessing the camera over the internet 14

Specifications 16

Pin definitions 17

Introduction

This installation guide provides basic information on setting

up and using the TruVision IP PTZ Camera. Detailed

information on the cameras can be found in the

configuration manual.

Product overview

This is the installation guide for following TruVision IP PTZ

camera models:

4 Installation Guide

TVP-1101 (1.3MPX pendant, PAL)

TVP-3101 (1.3MPX pendant, NTSC)

TVP-1102 (1.3MPX surface, PAL)

TVP-3102 (1.3MPX surface, NTSC)

TVP-1103 (1.3MPX flush, PAL)

TVP-3103 (1.3MPX flush, NTSC)

TVP-1104 (2MPX pendant, PAL)

TVP-3104 (2MPX pendant, NTSC)

TVP-1105 (2MPX surface, PAL)

TVP-3105 (2MPX surface, NTSC)

TVP-1106 (2MPX flush, PAL)

TVP-3106 (2MPX flush, NTSC)

Before you begin

Unpack everything. Check the items for damage, and verify

that all items are included. The camera is shipped with the

following items:

Dome camera

Installation Guide

CD with the Configuration Manual

Installation environment

When installing your camera, consider these factors:

• Place the camera in a secure location.

• Ensure that the camera is in a well-ventilated area.

• Do not expose the camera to rain or moisture.

Installation Guide 5

Camera description

Figure 1: Overview of the dome camera (pendant-mount

shown)

1. Power supply cord

Connect 24 VAC power supply

2. Video output

Connect the BNC connector to a CCTV monitor

3. Ethernet RJ45 connector. Connect to the network

devices

Connect to the PoE+ switch

4. Alarm input/outputs and audio in/out port

5. Housing

6. Bubble

6 Installation Guide

Installing a camera

Pendant-mount camera

1. Prepare the mounting surface and install the camera

bracket.

2. Unscrew the bubble from the camera and remove the

protective tape from the PTZ module.

3. Press the two tabs on either side of the PTZ module

and remove the module from the camera housing.

4. Route the cables from the pendant bracket as shown

below.

5. Attach the safety cable to the bracket and connect the

cables to the PCB of the module through the cable entry

hole on top of the housing.

RED AC24V

YELLOW/GREEN

BLACK AC24V

Installation Guide 7

Safety cable

Note: If alarm and audio input/output relays are to be

used, also connect them to the PCB of the module.

Caution: The safety cable is made of metal. Please

ensure that it does not touch the PCB of the module.

6. Attach the camera housing to the bracket using the

screws enclosed with the bracket.

7. Insert the PTZ module into the housing:

Position the tabs on the PTZ module by aligning the

arrow label on the module with those on the housing

(see below). The module should firmly snap into

position. If using a SD card, insert it into the module

before inserting the module into the housing.

8. Re-attach the bubble by screwing it to the housing.

8 Installation Guide

9. See “Accessing the camera over the internet” on page

14 to configure the camera over the internet. Refer to

the Configuration Manual for detailed information.

Flush-mount camera

1. Drill a hole on the ceiling using the drill template.

2. Tie three safety cables (not supplied) to the safety

hooks on the camera and hang the camera from a

secure point.

3. Unscrew the bubble from the camera and remove the

protective tape from the PTZ module.

4. Press the two tabs on either side of the PTZ module

and remove it from the camera housing.

5. Route the cables from the bracket and connect them to

the PCB of the module through the cable entry hole on

the top of the housing.

Note: If alarm and audio input/output relays are to be

used, also connect them to the PCB of the module.

Installation Guide 9

6. Adjust the height of the two housing tabs by turning the

screw on which they are attached. The distance (h) of

the tabs from the housing ring must be greater than the

thickness of the ceiling.

Housing tab

Screw

7. Make sure the housing tab is closed and then PUSH the

housing into the pass-through hole. Hold the housing

and fix it by screwing the housing tabs down to the

mounting surface

8. Insert the PTZ module into the housing:

9. Re-attach the bubble by screwing it to the housing.

10 Installation Guide

10. Install the trim ring. Align the trim ring to the housing,

and insert the fix-pins to the holes. Then rotate the ring

clockwise to secure.

11. See “Accessing the camera over the internet” on page

14 to configure the camera over the internet. Refer to

the Configuration Manual for detailed information.

Surface-mount camera

The cables of PTZ camera can be routed either from the top

or the side of the housing. For the cables routed from the

top of the housing, you must drill a cable hole in the ceiling.
