TruVision High

Definition TVI

Bullet Camera Installation

Guide

TVB

-2402/TVB-4402

TVB-2404/TVB-4404

P/N 1072938-EN • REV A • ISS 10MAR15

Installation Guide 1

Contents

Product overview 2

Camera description 4

Installation 6

Programming 9

Setup menus 13

Specifications 15

Legal and regulatory information 16

2 Installation Guide

Product overview

This is the TruVision High Definition TVI Bullet

Camera Installation Guide for models TVB-

2402/TVB-4402 and TVB-2404/TVB-2404. This

guide describes a standard installation.

Package contents:

Camera with power

and video output

cables

4 screws and 4

anchors for wall or

ceiling installation

Back box

Screws M4.8 ×18,

4pcs to attach the

back box

Installation Guide 3

Template

Hex wrench

•WEEE and Battery

Disposal

CD

Ceiling Mounting

1:Screw Hole for

Bracket

2:Screw Hole for

Mounting Base

4 Installation Guide

Camera description

1. CVBS output cable

(black)

2. TVI output cable

(grey)

3. Power cable

4. Camera body

5. Sun shield

6. Lens cover

7. Mounting bracket

8. Back box

Note:

Please check the camera output settings before

setting up a system. The TVI video output can be

only connected to DVR with TVI signal input. The

Installation Guide 5

CVBS output supports the standard monitor, test

monitor, encoder and DVR.

For TVB-2402 / TVB-4402, the CVBS and TVI

output can not be performed at the same time, you

can use the built-in DIP switch to select the camera

video output.

For TVB-2404/TVB-4404, the built-in DIP switch is

used to enable/disable WDR feature, when WDR

feature is enabled, the CVBS output will be blocked

out.

DIP switch

Menu button

6 Installation Guide

Installation

To install the camera:

1. Using the template, place it level against the

mounting surface and mark the position of the

mounting holes.

2. Following all local codes, drill and prepare the

mounting holes.

3. (Optional) Install the back box on the wall.

Ceiling Mounting

1:Screw Hole for

Bracket

2:Screw Hole for

Mounting Base

Installation Guide 7

4. Route the cables to the cable hole and connect

the corresponding cables. Using a 75-ohm

coaxial video cable, connect the camera TVI

video output and a TVI DVR, and connect a

12 VDC or 24 VAC power supply to the power

cable.

5. Secure the camera to the ceiling or wall with

the screws.

8 Installation Guide

6. Loosen the three screws and adjust the camera

according to the figure below to get an optimum

angle. Tighten the screw after completing the

adjustment.
