Interlogix TVD-5110-3 Manuel utilisateur

P/N 1072503B • ISS 18DEC12

TVD-5110-3 Dome Camera

Pocket Guide

Overview

This is the Pocket Guide for TVD-5110-3-P/ TVD-

5110-3-N Dome Camera. This guide describes a

standard installation.

The camera consists of the following:

• Camera with power and video output cable

Refer to the figures when performing the camera

setup procedures.

Figure 1: Parts of the camera

A. Video cable

B. Power cable

C. D/N sensor (Do not cover with the

shroud)

Figure 2: mounting sticker template (mm)

Installation

To install the camera:

1. Fasten the camera to a wall or ceiling (or another

solid surface). The camera must be stable when

connected.

2. Connect the 75 Ωcoaxial cable to the video

output.

3. Connect the power cable to the camera.

4. Adjust the camera position and angle as

required.

Specifications

Power supply 12 VDC ± 10% / 500mA

Current 50 mA

Power consumption 0.6 W max.

Operating temperature -10 to +50 °C (14 to 122°F)

Storage temperature -20 to70 °C (-4 to +158°F)

Weight 320 g (0.7 lb.)

Dimensions (H ×Ø) 60 x 100 mm (2.36 x 3.94 in.)

Contact information

For contact information, see www.interlogix.com or

www.utcfssecurityproducts.eu.

Regulatory information

Interlogix is part of UTC Climate Controls & Security, a unit of

Trademarks and patents

The IFS name and logo are trademarks of United Technologies.

Other trade names used in this document may be trademarks or

registered trademarks of the manufacturers or vendors of the

respective products.

Manufacturer

UTC Fire & Security Americas Corporation, Inc.

2955 Red Hill Avenue, Costa Mesa, CA 92626 5923, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

FCC compliance

Class B: This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications.

Changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to

operate the equipment.

ACMA compliance

Notice! This is a Class A product. In a domestic environment this

product may cause radio interference in which case the user may

be required to take adequate measures.

Canada

This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme

NMB-0330 du Canada.

Certification

N4131

European Union directives

12004/108/EC (EMC directive): Hereby, UTC Fire & Security

declares that this device is in compliance with the essential

requirements and other relevant provisions of Directive

2004/108/EC.

2002/96/EC (WEEE directive): Products marked

with this symbol cannot be disposed of as

unsorted municipal waste in the European

Union. For proper recycling, return this product

to your local supplier upon the purchase of

equivalent new equipment, or dispose of it at

designated collection points. For more

information see: www.recyclethis.info.
