Interlogix TruVision TVW-2401 Manuel utilisateur

TruVision

HD-TVI 1080P

Wedge Camera Installation

Guide

TVW

-2401/TVW-4401

P/N 1073183-EN • REV A • ISS 07JUL16

Installation Guide 3

Content

Product overview 4

Camera description 7

Installation 8

Operating temperature range 15

Program 15

Menu tree 18

Specifications 19

Legal and Regulatory information 20

4 Installation Guide

Product overview

This is the Installation Guide for the TruVision high

definition TVI wedge camera TVW-2401/TVW-4401.

This guide describes a standard installation.

Package contents

Camera assembly

(cable harness not

shown)

3 M4 x 25 mm

screws and 3

anchors for wall or

ceiling installation

Camera drill

template

2 screws M4 x 8

used for installing

the camera to the

adapter plate

Installation Guide 5

Torx wrench

Adapter plate

Adapter plate drill

template

Installation guide

CD

•Equipment disposal

instructions

6 Installation Guide

Lens adjustment

tool

HD-TVI video test

cable

12 VDC connector

(2 terminal

connectors with

positive and

negative indicators)

Installation Guide 7

Camera description

1. TVI video output

2. Power cable

3. Camera base

4. HD-TVI video test

cable

5. Menu button

Note: The HD-TVI wedge camera should only be

connected to a DVR that supports a TVI signal.

③

②

①

④⑤

8 Installation Guide

Installation

To install the camera on a surface:

1. Use the camera drill template to mark the

mounting holes.

2. Follow all local safety regulations. Drill through

the mounting surface. If you need to route the

cables from the bottom of the camera, drill a

larger hole in the mounting surface for the

cable harness.

3. Using the Torx wrench, loosen the four screws

to remove the housing cover from the device.

Installation Guide 9

4. Install the mounting base to the surface using

two of the M4 x 25 mm screws and anchors. If

routing the cable harness through the ceiling,

do so prior to mounting the camera.

5. Loosen the locking screw, located near the lens

assembly. Align the lens adjustment tool with

the two small holes located on the camera

assembly.

Rotate (pan) the camera assembly using the

lens adjustment tool until the lens is positioned

in the correct location. The tool is also used to

adjust the tilt angle.

10 Installation Guide

Note: Please do not remove the foam ring

attached to the lens. This foam ring is required

to reduce the glare of IR illuminators.

6. Tighten the locking screw and re-install the

housing cover to the camera assembly using

the Torx wrench.

Locking

Screw

Tilt

Pan

Rotation

Lens Adjustment

Tool
