Interlogix UVD-XP4DNR Manuel utilisateur

UVD-XP4DNR(-P)

Camera Quick Start

Guide

P/N 1079205A • REV 1.0 • ISS 20DEC11

Trademarks and

patents

Interlogix, UltraView names and logos are trademarks of

UTC Fire & Security.

Other trade names used in this document may be trademarks

or registered trademarks of the manufacturers or vendors of the

respective products.

Manufacturer UTC Fire & Security Americas Corporation, Inc.

2955 Red Hill Avenue, Costa Mesa, CA 92626-5923, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

Certification

N4131

FCC compliance Class A: This equipment has been tested and found to comply

with the limits for a Class A digital device, pursuant to part 15 of

the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the

equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential

area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own

expense.

ACMA compliance Notice! This is a Class A product. In a domestic environment

this product may cause radio interference in which case the

user may be required to take adequate measures.

Canada This Class A digital apparatus complies with Canadian ICES-

003.

Cet appareil numérique de la classe A est conforme à la norme

NMB-0330 du Canada.

European Union

directives

12004/108/EC (EMC directive): Hereby, UTC Fire & Security

declares that this device is in compliance with the essential

requirements and other relevant provisions of Directive

2004/108/EC.

2002/96/EC (WEEE directive): Products marked with this

symbol cannot be disposed of as unsorted municipal waste in

the European Union. For proper recycling, return this product to

your local supplier upon the purchase of equivalent new

equipment, or dispose of it at designated collection points. For

more information see: www.recyclethis.info.

Contact

information

For contact information, see www.interlogix.com or

www.utcfssecurityproducts.eu.

Quick Start Guide 3 EN

Description

The UVD-XP4DNR(-P) camera consists of the following parts:

• The camera assembly

• Monitor output cable

• Mounting screws, wall anchors, and hex key

Figure 1: The camera assembly and monitor output cable

1. Lens body 5. Camera body

2. Bubble 6. Monitor output BNC

3. Video monitor output 7. Monitor output RCA

4. OSD control pad

Use the video output BNC and power jack for normal system

operation. Use the monitor output cable for installation and

maintenance.

OSD control pad

The onscreen display (OSD) control pad is a five-direction joystick that

provides the ability to manually control the camera functions.

EN 4 Quick Start Guide

OSD control pad

Table 1 lists the OSD control pad functions and describes their use.

Table 1: OSD control pad functions

Pad directions Description

Up Moves the cursor upward to select an item.

Left Moves the cursor left to select or adjust the parameters

of the selected item.

Right Moves the cursor to the right to select or adjust the

parameters of the selected item.

Down Moves the cursor downward to select an item.

Enter Press the center of the control pad to display the Setup

menu. If the selected item has its own menu, press the

control pad to enter a submenu. Press the control pad for

2 seconds to save all settings and exit the Setup menu.

Installation

Complete all the necessary programming before you install the

camera. This section provides information on how to install the camera

and adjust camera angle and focus.

WARNING: To reduce the risk of fire or electronic shock, do not

expose the camera to rain or moisture and do not remove the cover or

back.

Cable connection

To make cable connections, do the following:

1. Connect a coaxial cable from the camera’s BNC connector to a

CCTV monitor or video recording device.

2. Connect a 12 VDC or 24 VAC power supply to the power input.

The label on the camera gives the following information:

Red cable. Power in.

Black cable. Power in.

Quick Start Guide 5 EN

White cable. Video out.

Black cable. Video ground.

Note: For AC24V or DC12V, Black or Red may be used for ground.

Camera installation

To mount the camera, attach the camera to the mounting surface using

the appropriate fasteners.

Angle adjustment

To adjust the horizontal angle of the platform up to 180 degrees, turn

the platform (1).

To adjust the horizontal angle of the rotor up to 350 degrees, turn the

rotor on the platform (2).

To adjust the vertical angle of the platform up to 90 degrees, turn the

platform (3).

Focus adjustment

To adjust the camera zoom and focus:

EN 6 Quick Start Guide

1. Zoom ring thumbscrew for VA2 and focus ring for VA9 lens.

2. Focus ring thumbscrew for VA2 and zooming ring for VA9 lens.

1. Loosen the zoom ring thumbscrew.

2. Turn the zoom ring to set the desired zoom.

3. Tighten the zoom ring thumbscrew.

4. Loosen the focus ring thumbscrew.

5. Turn the focus ring to set the desired focus.

6. Tighten the focus ring thumbscrew.

Connect the monitor

Program the cameras by attaching a standard video monitor to the

system.

To connect the monitor, do the following:

1. Plug the monitor output cable to the video monitor output

connector.

2. Connect the BNC cable to the video monitor.

3. Press the OK button to display the Setup menu.

Programming

The camera is configured through the setup menus which appear on-

screen. See Figure 2.

Figure 2: Main menu

To access and navigate the menus, press and hold the center of the

OSD control pad. Press Up or Down on the control pad to move

between items, and press Enter (center of the control pad) to select the

Quick Start Guide 7 EN

item. Press Right or Left on the control pad to select the different

options available for the item.

You can return to the previous menu from any of the menus (except

the Main menu) by selecting the Previous page option.

The menu map is shown on the back page of this manual.

Refer to the User Manual for detailed programming instructions.

Table 2: Main menu options

Menu option Description

Preset Preset settings.

Setup Camera ID, Line Lock, motion detection, and WDR settings.

Viewing Flip and resolution settings

Exposure AGC, AE preferences, range control, shutter limit, frame

RPT, and B/W control settings.

White balance White balance settings.

Save/Restore Save and restore user and factory settings.

Specifications

Electrical

Power Input 12 VDC or 24 VAC

Power consumption 3W (DC); 2.4 W (AC)

Environmental and physical

Weight 33.8 oz. (958 g)

Dimensions 5.22 x 4.11 in. (133 x 105 mm)

Operating Temperature -58 to +122°F (-50 to +50°C)

Weather resistant IP66

EN 8 Quick Start Guide
