Interlogix TruVision TVA-1101 Manuel utilisateur

TruVision Covert IP

Camera Installation

Manual

P/N 1072912-EN • REV B • ISS 22MAY15

Interlogix is part of UTC Building & Industrial Systems, a unit of United

Trademarks and

patents

rade names used in this document may be trademarks or registered trademarks

of the manufacturers or vendors of the respective products.

Manufacturer Interlogix

2955 Red Hill Avenue, Costa Mesa, CA 92626-5923, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

Certification

N4131

FCC compliance Class A: This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions:

(1) This device may not cause harmful interference

(2) This Device must accept any interference received, including interference

that may cause undesired operation.

Any changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

ACMA compliance Notice! This is a Class A product. In a domestic environment this product may

cause radio interference in which case the user may be required to take

adequate measures.

Canada This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme NMB-0330 du

Canada.

European Union

directives

12004/108/EC (EMC directive): Hereby, UTC Fire & Security declares that this

device is in compliance with the essential requirements and other relevant

provisions of Directive 2004/108/EC.

2012/19/EU (WEEE directive): Products marked with this symbol cannot be

disposed of as unsorted municipal waste in the European Union. For proper

recycling, return this product to your local supplier upon the purchase of

equivalent new equipment, or dispose of it at designated collection points. For

more information see: www.recyclethis.info.

2006/66/EC (Battery directive): This product contains a battery that cannot be

disposed of as unsorted municipal waste in the European Union. See the product

documentation for specific battery information. The battery is marked with this

symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or

mercury (Hg). For proper recycling, return the battery to your supplier or to a

designated collection point. For more information see: www.recyclethis.info.

Contact information

For contact information, see www.interlogix.com or

www.utcfssecurityproducts.eu.

Installation Manual 3

Content

Product overview 4

Installation 4

Installation environment 4

Package contents 5

Cable requirements 5

Camera description 6

Which adhesive tape to use 7

Set up the camera 7

Complete the installation 13

Configuration 13

Access the SD card 13

Use the camera with an Interlogix NVR or Hybrid DVR or another system 14

Use the camera with TruVision Navigator 14

Specifications 14

TruVision Covert IP cameras 14

Pin definitions 15

4 Installation Manual

Product overview

This is the installation manual for the following TruVision Covert IP camera

models:

TVA-1101 (1.3MPX IP ATM/covert camera, WDR, PAL)

TVA-3101 (1.3MPX IP ATM/covert camera, WDR, NTSC)

TVL-0101 (TruVision Covert Lens, 1.3MPx, Pinhole, 3.7mm@ F2.3, 2m

cable)

TVL-0102 (TruVision Covert Lens, 1.3MPx, L-shape, 3.7mm@ F2.3, 2m

cable)

TVL-0103 (TruVision Covert Lens, 1.3MPx, Cylinder, 4mm@ F2.0, 2m

cable)

TVL-0104 (TruVision Covert Lens, 1.3MPx, Pinhole, 3.7mm@ F2.3, 8m

cable)

TVL-0105 (TruVision Covert Lens, 1.3MPx, L-shape, 3.7mm@ F2.3, 8m

cable)

TVL-0106 (TruVision Covert Lens, 1.3MPx, Cylinder, 4mm@ F2.0, 8m

cable)

Installation

This chapter provides information on how to install the cameras.

Installation environment

When installing your product, consider these factors:

•Electrical: Install electrical wiring carefully. It should be done by qualified

service personnel. Always use a proper PoE switch or a 12 VDC UL listed

Class 2 or CE certified power supply to power the camera. Do not overload

the power cord or adapter.

•Ventilation: Ensure that the location planned for the installation of the

camera is well ventilated.

•Temperature: Do not operate the camera beyond the specified

temperature, humidity or power source ratings. The operating temperature of

the camera is between -30 to +60°C (-22 to 140°F). Humidity is below 90%.

•Moisture: Do not expose the camera to rain or moisture, or try to operate it

in wet areas. Turn the power off immediately if the camera is wet and ask a

qualified service person for servicing. Moisture can damage the camera and

also create the danger of electric shock.

Installation Manual 5

•Servicing: Do not attempt to service this camera yourself. Any attempt to

dismantle or remove the covers from this product will invalidate the warranty

and may also result in serious injury. Refer all servicing to qualified service

personnel.

•Cleaning: Do not touch the sensor modules with fingers. If cleaning is

necessary, use a clean cloth with some ethanol and wipe the camera gently.

If the camera will not be used for an extended period of time, put on the lens

cap to protect the sensors from dirt.

Package contents

Check the package and contents for visible damage. If any components are

damaged or missing, do not attempt to use the unit; contact the supplier

immediately. If the unit is returned, it must be shipped back in its original

packaging.

Package contents:

•Camera or lens

•Mounting accessories

•Installation manual

•CD with Configuration Manual and TruVision Device Manager

Note:

The ATM/covert camera has no lens in the product package. The lens needs to

be purchased separately according to the application needs. Please notice there

are different cable length and form factors options.

CAUTION: Use direct plug-in UL listed power supplies marked Class 2/CE

certified or LPS (limited power source) of the required output rating as listed on

the unit.

CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose

of used batteries according to the instructions.

Cable requirements

For proper operation, adhere to the following cable and power requirements for

the cameras. Category 5 cabling or better is recommended. All network cabling

must be installed according to applicable codes and regulations.

Recommended power cable requirements to connect the camera:

12 VDC power jack or PoE (802.3af)

6Installation Manual

Camera description

Figure 1: Covert IP camera description

Covert camera unit:

1. Main unit

2. Mounting rack

9. Power indicator

10. Status indicator

11. Link indicator

12. Audio In/Out

13. RJ-12 port

14. Micro SD card slot

15. Reset button

16. Power port

17. PoE and network port

18. RS-232 and alarm port

Lens: (purchased separately)

3. L-shape lens

4. L-shape lens cover

5. L-shape lens mounting bracket

6. Pinhole lens

7. Lens cable with RJ-12 connector

8. Pinhole lens mounting bracket

19. Cylinder lens

20. Cylinder lens mounting bracket

Table 1: LED Indicators

LED Color and Status Indication

POWER Solid red Normal operation

Unlit Power Off

STATUS Solid green Camera works properly

Unlit Camera does not work properly.

Installation Manual 7

LINK Flashing amber Network connection is functioning

properly

Unlit No network connection

Which adhesive tape to use

There are two types of adhesive tape (1 mm and 4 mm) included in the package

that are used to attach the lens to the surface.

1 mm adhesive tape 4 mm adhesive tape

When the surface is around 4 mm

thick, use the 1mm adhesive tape.

The drilling hole should be around

10.5 mm wide.

When the surface is around 1 mm

thick, use the 4mm adhesive tape.

The drilling hole should be around

4.5 mm wide.

Set up the camera

Note: If the light source where the camera is installed experiences rapid, wide-

variations in lighting, the camera may not operate as intended.

To install the main unit:

1. Prepare the mounting surface. The surface should be smooth and clean.

2. Fix the mounting rack on the mounting surface.

8Installation Manual

3. Fix the mounting bracket on the rear panel of the main unit with four screws.

4. Hook the top catch of the main unit on the rack. Gently press the lower part

of the camera against the rack so that it snaps into position on the rack.

Note:If there is already a standard rail installed, you can directly snap the main

unit onto the installed rail.

Installation Manual 9

To install the pinhole lens:

Note: Before installing the device, ensure that the mounting surface is suitable

for adhesive mounting.

1. Drill a hole in the mounting surface.

Note: Please ensure that the hole size is appropriate for the camera lens.

2. Remove the protective film from the adhesive tape on the pinhole lens

mounting bracket. Align the bracket with the drilled hole and stick the

bracket on the mounting surface.

3. Install the pinehole lens into the mounting hole of the mounted bracket.

4. Twist the locking sleeve to lock the lens in place.

10 Installation Manual

To install the L-shape lens

1. Drill a hole in the mounting surface.

2. Remove the protective film from the adhesive tape on the L-shaped

mounting bracket. Align the bracket with the drilled hole and stick the

bracket on the mounting surface.

Note: Please ensure that the hole size is appropriate for the camera lens.

3. Install the L-shape lens into the mounting hole in the bracket then fix the

lens with screws.
