Intel GDT6113RS Manuel utilisateur

ICP Disk Array Controllers

Excellence in Controllers

32-Bit 33MHz PCI - Wide/Ultra160 SCSI

Hardware RAID Controller

●RAID 0, 1, 4, 5 and 10

●Hot Plug, Auto Hot Plug with SAF-TE/SES Support

●Private or Pool Hot Fix drives

●totally independent of host and operating system

Versatile Connectivity

●1 or 2 Wide/Ultra160 SCSI channels with active,

software-switchable multi-mode termination

●either SE (Single Ended) or LVDS (Low Voltage

Differential Signalling) operation

●maximum synchronous data transfer rate up to

160 MB/sec per channel (LVDS)

●up to 15 devices per channel

●cable length up to 12 meters (LVDS) per channel

●1 or 2 external VHD connectors

Multiprocessor RISC Architecture

●100 MHz Intel i960®RS RISC I/O processor

●completely offloads the host CPU

Memory Technology

●SDRAM cache memory, non-buffered PC133 DIMM,

from 32 MB, 64 MB to 128 MB, ECC support

●intelligent multi-level Cache Algorithm with adaptive

Delayed Write and Read Ahead cache functions

Compatibility and Performance

●Bus Master DMA transfer rates up to 132 MB/sec

●PCI 2.2 compatible

●Scatte/Gather, Command Queuing

●SCSI-2/-3 protocol support

●backwards compatible to Wide/Ultra SCSI devices

Driver Support

●MS-DOS*, Windows* 9x/NT/2000/XP, Novell* NetWare*,

SCO* Unix*, UnixWare*, Linux*, Solaris* and FreeBSD*

Configuration Flexibility

●simultaneous operation of several disk arrays

●variable capacity configuration

●Online Capacity Expansion

●Online RAID Level Migration

●complete Disk Array Migration

Delivery Contents

●ICP Disk Array Controller (without RAM)

●User’s Manual (Quick Installation Guide)

●ICP RAID Navigator and ICP RAID Console: installation

and configuration programs as well as monitoring utilities

●CD-ROM with tools and drivers

●software updates with Flash RAM technology,

easy download from www.icp-vortex.com

*Other names and brands may be claimend as the property of others. Technical changes reserved. Product pictures

may differ from actual products. 02/02

Excellence in Controllers

ICP vortex Computersysteme GmbH · Konrad-Zuse-Str. 9 · D-74172 Neckarsulm · Germany

Phone: +49-7132-9620-0 · Fax: +49-7132-9620-200 · E-mail: [email protected] · http://www.icp-vortex.com

USA · Sales: +1-480-552-1730 · Tech Support: +1-480-552-1422 · Fax: +1-480-552-0557

E-mail: [email protected] · http://www.icp-vortex.com

Number of Wide/Ultra160

SCSI Channels / Number

of Attached Devices

ICP Controller

Maximum Synchronous

Data Transfer rate per

Wide/Ultra160 channel

PCB Size

Cache RAM in MB,

SDRAM

number of External

VHDConnectors

RAID 0, 1, 4, 5 and 10

Hot Fix/Hot Plug and

SAF-TE/SES Support

RAID 0/1

Hot Fix/Hot Plug and

SAF-TE/SES Support

GDT6113RS 1/15 160MB/sec. yes upgradable 32 - 128 1 short

GDT6123RS 2/30 160MB/sec. yes upgradable 32 - 128 2 short

GDT6513RS 1/15 160MB/sec. yes yes 32 - 128 1 short

GDT6523RS 2/30 160MB/sec. yes yes 32 - 128 2 short
