Huawei E600 Manuel utilisateur

Contents

Getting E600 Ready...................................................................1

Installation Guide.......................................................................1

Introduction to the E600 Manager Interface..............................2

Internet Service..........................................................................2

Call Service................................................................................2

SMS Service...............................................................................4

Contacts Service.........................................................................4

Call Register Service..................................................................5

Welcome to use the HUAWEI E600 Data Card.

With the E600, you can easily access the:

yInternet service

yCall service

ySMS service

yContacts service

yCall Register service

Getting E600 Ready

Please insert the SIM card into the slot according to

the direction arrow on the back of the E600 with the

golden contact point downward and the blunt corner

inwards.

Installation Guide

The installation procedures of the E600 Manager may

be somewhat different under different operating

systems (Windows XP and Windows 2000). Please

refer to the actual installing tips if the installing

description is different from the following. Here, we

will take the Windows XP operating system as an

example.

1. Installing the E600 Manager

1) Put the disk that contains the E600 Manager into

the CD-ROM drive of your computer.

2) The installation procedures will start

automatically. If the auto-run program does not

start, go to the drive path, find the Setup.exe file

and double click on it, and then the program is

running.

3) When the Choose Language dialog box appears,

select the installation language correspondingly,

and click <OK>.

4) Do according to the instructions of the setup

program.

5) After successful installation, a shortcut for the

E600 will be seen on the desktop.

2. Installing the E600 Driver

1) Insert the E600 which contains the SIM

(Subscriber Identity Module) card into the

PCMCIA slot of the computer.

2) Now the system will automatically find the new

hardware and automatically initialize the new

hardware Installation Shield Wizard.

3) If a prompt such as "The software failed to pass

the Logo Test" appears, please click <Continue

Anyway> to continue the installation.

4) When the installation is over, click <Finish> to

complete the installation.

3. Removing the E600

Note: To remove the E600, please use the hardware

deleting function of the Windows system to stop

the operation of the E600 and then pull it out.

1) Double click on the lower right corner of the

computer screen; the "Safely Remove Hardware"

window will be displayed.

2) Stop the use of the E600 hardware "NEC PCI to

USB Open Host Controller".

3) When the system prompts you that it is safe to

remove the device, pull out the E600.

Introduction to the E600 Manager Interface

1. Entering the E600 Manager Interface

Double click on the desktop to start the E600

Manager. If the system prompts you to input a PIN

(Personal Identity Number), please input a correct one.

2. Shortcut Icons Description

/: Connecting from/Disconnecting to the

network.

: Opening the default Internet browser in the

operating system.

: Accessing the Call service.

: Accessing the SMS (Short Message Service)

service.

: Accessing the Contacts service.

: Accessing the Call Register service.

Internet Service

1. Network Connection Settings

Creating a New Profile:

1) Select Settings ––> Network Connection Settings

on the menu bar.

2) Click <New>.

3) Enter a new profile name and other parameters.

4) Click <Save> to save the new profile.

Note: Please contact your network operator to get the

parameters and the values.

2. Accessing the Internet

1) Click to connect the network.

2) When the connection is completed, corresponding

information about the connected network will be

displayed on the right side of the window, which

includes:

yHaving connected time of the current connection;

yThe data flow volume of the current connection;

yThe volume, rate and the top rate of the current

sending and received data.

3) Click to open the Browser.

4) Click to disconnect the network.

Call Service

Insert an earphone into the earphone jack of the E600

before a call service.

1. Making a Call by Directly Entering a

Telephone Number

1) Click to open the Call Service window.

2) You may enter a telephone number:

yWith the keyboard; or

yBy clicking telephone keypad on the Call Service

window.

3) Click to make a call.

4) Click to hang up.

Note: You may click to cancel the input

number digit by digit or to cancel the whole input

number by clicking and holding down it for a

moment. Alternatively, you may also do it by

pressing the Backspace key of the computer

keyboard.

2. Making a Call by Choosing a Telephone

Number from the Contacts List

1) Click to go to the Call Service window.

2) Click to open the Contacts list. Double

click a contact or select a contact and then click

<Call>:

yIf the contact you have selected has only one number,

this number will appear on the window and be dialed

out directly.

yIf the contact has two or more numbers, double click

the intended number from the pop-up Select Phone

Number window or click <OK> after selecting the

number; and the selected number will appear on the

window and be dialed out directly.

3) Click to hang up.

3. Making a Call by Selecting a Recently Dialed

Number

1) Click to go to the Call Service window.

2) Click to display a list of 10 recently dialed

numbers. Double click the intended telephone

number or click <Call> after selecting the number,

then the number will be dialed out directly.

3) Click to hang up.

4. Answering a call

The E600 may prompt you an incoming call by sound

or vision. You may select Settings––> Options to set

the prompt mode for incoming calls.

yThe E600 provides a sound prompt mode. You will

hear a sound on an incoming call.

1) Click to enter the Call Service window.

2) Click to answer a call.

3) Click to hang up.

yYou will see a pop-up window on an incoming call if

you have enabled "Display alerts when a call

coming".

Click <Answer> to answer a call.

Click <Reject> to reject a call.

5. Volume Control

Click to open the Call Service window. You may

adjust the voice volume by pressing or .

yPress to increase the volume;

yPress to decrease the volume.

SMS Service

1. Writing a New SMS Message

1) Click to open the SMS Service window.

2) Click <Write> to open a New SMS window.

3) Enter a telephone number and SMS contents.

4) Click <Send> to send the message.

Note: You may also click <Contacts> to search for a

telephone number in the Contacts book.

2. Viewing an SMS Message

An incoming SMS message can be prompted by sound

or vision as is preset on the menu bar Settings––>

Options.

yYou will hear sound prompt on a new incoming SMS

message if you have enabled "Play a sound when a

message is received".

1) Click to enter the SMS window.

2) Click <Inbox> to enter the inbox to view received

SMS messages.

yYou will see a pop-up window on a new incoming

SMS message if you have enabled "Display alerts

when a message is received".

Click <View> on the pop-up window to enter the

Inbox to read SMS messages, or click <Close> to

overlook SMS messages.

3. SMS settings

Select Settings ––> SMS Settings, the SMS settings

window will be displayed:

yRequest status report: With this function being

enabled, the network will send you a report once the

receiver has received an SMS message.

yUse same SMS centre for reply: Set the SMS center

number which receivers used to reply messages to the

same one as the sender.

ySMS Bear: The bearer field that is used to send SMS

messages: if Packet Switched (PS) is enabled,

messages are sent through the packet field; if Circuit

Switched (CS) is enabled, messages are sent through

the circuit field.

yValidity: Select the valid period during which SMS

messages can be stored in the SMS center.

yCurrent SMS centre: The E600 will read the number

of the current SMS centre. If no such information or

it has been accidentally deleted, please contact your

card provider to get this number.

Contacts Service

1. Creating a New Item in the Contacts

1) Click to enter the Contacts window.

2) Click <New>.

3) Enter such information as Name, telephone

numbers, e-Mail and other information.

4) Click <Save> to save the information.

2. Modifying Items in the Contacts

1) Click to enter the Contacts window.

2) Highlight the information to be modified and

double click it or click <Edit>.

3) Click <Save> to save the modified information.

3. Deleting Items from the Contacts

1) Click to open the Contacts window.

2) Select one or more items you want to remove

from the contacts, and then click <Delete>.

3) Click <OK> to confirm the deletion.

4. Sending a Message

1) Click to open the Contacts window.

2) Select one or more items from the Contacts, a

dialog box of "Please select number" will pop up.

3) Select one or more numbers you want to send, and

then click <OK>; the program will jump to the

window for creating a new message.

Note: If the item you have selected contains only one

telephone number, the window for creating a new

message will be displayed automatically.

4) The mobile numbers retrieved appear in the blank

column behind the "Contacts". Input the content

for the message and click <Send>.

5. Making a Call

1) Click to open the Contacts window.

2) Select the item that contains the number you want

to dial from the Contacts, and then click <Call>.

yIf the item you have selected contains only one

telephone number, the Call Service window will be

displayed automatically.

yIf two or more telephone numbers are contained in

the item you have selected, the Select Phone Number

window will be displayed and you will be prompted

to select one number. After doing that, click <OK>

and the Call Service window will be displayed.

3) The phone number you have selected will be

displayed automatically in the Call Service

window; and the number will be dialed out

automatically.

6. Searching for Items in the Contacts

1) Click <Find>.

2) In the Search window:

ySelect a field item from the pull-down list in the

"Condition" area.

yEnter relevant searching terms in the "Value" text

box.

yChoose "Whole word only" and/or "Case sensitive"

for "Matching Type".

3) Click <Next> or <Prev> to begin searching.

Call Register Service

The call register service provides the information of

missed calls, received calls and dialled calls.

The executable operations and operating procedures

for these items of service are absolutely the same. Now

let's take the operations for the Missed Calls service as

an example for introduction.

1. Sending a Message

1) Click to open the Call Register window.

2) Click <Missed calls> to access the registered

missed calls.

3) Select one or more items, a dialog box of "Please

select number" will pop up.

4) Select one or more numbers you want to send, and

then click <OK>; the program will jump to the

window for creating a new message.

Note: If the item you have selected contains only one

telephone number, the window for creating a new

message will be displayed automatically.

5) The mobile numbers retrieved appear in the blank

column behind the "Contacts". Input the content

for the message and click <Send>.

2. Making a Call

1) Click to open the Call Register window.

2) Click <Missed calls> to access the registered

missed calls.

3) Select an item and click <Call>.

4) The selected phone number will be displayed

automatically on the window, and then the

number will be dialed out automatically.

3. Saving a Number

1) Click to open the Call Register window.

2) Click <Missed calls> to open the item of missed

calls.

3) Select an item and click <Get Number>, the

program will jump to the New Contacts window.

4) By default, the E600 will save the number of this

item to the Mobile column in the contacts.

5) Click <Save> to save the number.

4. Deleting Items

1) Click to open the Call Register window.

2) Click <Missed calls> to access the Missed calls

window.

3) Select one or more items.

4) Click <Delete>. If you are sure, click

<OK>.

Ver: V1.11 BOM: 31014924

Autres manuels pour E600

Table des matières

Autres manuels Huawei Modem

Huawei

Huawei R227h Manuel utilisateur

Huawei

Huawei E220 Manuel utilisateur

Huawei

Huawei EC306 Manuel utilisateur

Huawei

Huawei B681 Manuel utilisateur

Huawei

Huawei B315s Manuel utilisateur

Huawei

Huawei WebConnect Jet UMG1691 Manuel utilisateur

Huawei

Huawei E173 Caractéristiques techniques

Huawei

Huawei SmartAX MT882a Manuel utilisateur

Huawei

Huawei E5577 Manuel utilisateur

Huawei

Huawei LTE E8372 Manuel utilisateur

Huawei

Huawei EC152 Manuel utilisateur

Huawei

Huawei Mobile Broadband Manuel utilisateur

Huawei

Huawei Mobile WiFi Smart E355 Manuel utilisateur

Huawei

Huawei EC167 Manuel utilisateur

Huawei

Huawei Vodafone R207 Manuel utilisateur

Huawei

Huawei E5830 Manuel utilisateur

Huawei

Huawei E353S-6 Manuel utilisateur

Huawei

Huawei E3372 Manuel utilisateur

Huawei

Huawei GL08D Manuel utilisateur

Huawei

Huawei SmartAX MT882a Manuel utilisateur

Huawei

Huawei e3276 Manuel utilisateur

Huawei

Huawei Hilink E3276s Manuel utilisateur

Huawei

Huawei E270 Mode d’emploi

Huawei

Huawei 4G Dongle Manuel utilisateur

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur
