Huawei E160G Manuel utilisateur

Copyright © 2008 Huawei Technologies Co., Ltd.

All Rights Reserved

No part of this document may be reproduced or transmitted in any form or by any

means without prior written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co.,

Ltd.

All other trademarks and trade names mentioned in this document are the

property of their respective holders.

Notice

The information in this document is subject to change without notice. Every effort

has been made in the preparation of this document to ensure accuracy of the

contents, but all statements, information, and recommendations in this document

do not constitute the warranty of any kind, express or implied.

i

Table of Contents

What Is in Your Package............................................. 1

Getting to Know Your E160G....................................... 3

Preparation .............................................................. 6

Installation/Removal Guide ......................................... 8

Safety Information ...................................................11

Acronyms and Abbreviations ......................................17

1

Thank you for choosing Huawei E160G HSDPA USB Stick

(hereinafter referred to as the E160G). With the E160G,

you can access the Internet through wireless network at

a high speed.

Note: This manual describes the appearance, installation and removal of

the E160G. For the operation of the management program, refer to the

User Manual.

What Is in Your Package

The package of your E160G contains the following items:

One E160G

2

One Quick Start

One USB cable

3

Getting to Know Your E160G

The following figure shows the appearance of the E160G. It is only for your

reference. The actual product may differ.

1

3

4

5

2

6

nUSB Interface

It connects the E160G to a computer.

4

oSIM/USIM Card Slot

It is where you insert the subscriber identity module/UMTS subscriber identity

module (SIM/USIM) card.

pMicro SD Card Slot

It is where you insert the Micro Secure Digital Memory (SD) card

qExternal Antenna Jack

It connects the E160G to an external antenna.

rStrap Hole

sIndicator

It indicates the status of the E160G.

Colour Status Meaning

Green Blinking (on for 100ms and

off for 100ms; then on for

100ms and off for

2700ms)

The E160G is powered on.

Green Blinking (on for 100ms and

off for 2900ms) The E160G is registered to a

GSM/GPRS/EDGE network.

Blue Blinking (on for 100ms and

off for 2900ms) The E160G is registered to a UMTS

network.

Green On The E160G is connected to a GPRS/EDGE

network.

Blue On The E160G is connected to a WCDMA

network.

Cyan On

T

he E160G is connected to a HSDPA

5

network.

- Off The E160G is removed.

6

Preparation

Requirements for the Computer

To use the E160G, the computer should meet the following requirements:

USB Type A Receptacle, Compatible with USB 2. 0 High Speed.

Windows 2000 SP4, Windows XP SP2, Windows Vista.

Your computer’s hardware system should meet or exceed the recommended

system requirements for the installed version of OS.

Resolution for the display: 800 × 600 or above.

Getting Your E160G Ready

Remove the USIM/SIM card slot from the E160G.

Insert the USIM/SIM card into the card slot.

Insert the card slot into the E160G.

7

Inserting the Micro SD Card (Optional)

Insert the micro SD card into the E160G, as shown in the following figure.

Note: Do not remove the micro SD card when it is being used. Removing

the card during an operation may damage the micro SD card as well as

the device, and data stored on the card may be corrupted.
