Huawei Atool Manuel utilisateur

HUAWEI Module

Atool User Guide

Issue

Date

2015-01-31

No part of this manual may be reproduced or transmitted in any form or by any means without prior written

consent of Huawei Technologies Co., Ltd. and its affiliates ("Huawei").

The product described in this manual may include copyrighted software of Huawei and possible licensors.

Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract,

reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by

applicable laws or such actions are approved by respective copyright holders.

Trademarks and Permissions

, , and are trademarks or registered trademarks of Huawei Technologies Co., Ltd.

LTE is a trade mark of ETSI.

Other trademarks, product, service and company names mentioned may be the property of their respective

owners.

Notice

Some features of the product and its accessories described herein rely on the software installed, capacities

and settings of local network, and therefore may not be activated or may be limited by local network

operators or network service providers.

Thus, the descriptions herein may not exactly match the product or its accessories which you purchase.

Huawei reserves the right to change or modify any information or specifications contained in this manual

without prior notice and without any liability.

DISCLAIMER

ALL CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE

LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT

LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS

MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL HUAWEI BE

LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOSS OF

PROFITS, BUSINESS, REVENUE, DATA, GOODWILL SAVINGS OR ANTICIPATED SAVINGS

REGARDLESS OF WHETHER SUCH LOSSES ARE FORSEEABLE OR NOT.

THE MAXIMUM LIABILITY (THIS LIMITATION SHALL NOT APPLY TO LIABILITY FOR PERSONAL

INJURY TO THE EXTENT APPLICABLE LAW PROHIBITS SUCH A LIMITATION) OF HUAWEI ARISING

FROM THE USE OF THE PRODUCT DESCRIBED IN THIS MANUAL SHALL BE LIMITED TO THE

AMOUNT PAID BY CUSTOMERS FOR THE PURCHASE OF THIS PRODUCT.

Import and Export Regulations

Customers shall comply with all applicable export or import laws and regulations and be responsible to

obtain all necessary governmental permits and licenses in order to export, re-export or import the product

mentioned in this manual including the software and technical data therein.

To better understand how we protect your personal information, please see the privacy policy at

http://consumer.huawei.com/privacy-policy.

HUAWEI Module Atool User Guide

About This Document

Issue 02 (2015-01-31)

Huawei Proprietary and Confidential

About This Document

Revision History

Document

Version

Date

Chapter

Descriptions

2012-02-29

Creation

2015-01-31

Updated operations to perform on the Atool

Updated limitations to use the Atool

Updated console commands and

parameters

Updated Error Messages

Updated saving of test results

Added FAQ

HUAWEI Module Atool User Guide

Contents

Issue 02 (2015-01-31)

Huawei Proprietary and Confidential

Contents

1 Purpose ...................................................................................................................................... 5

2 Overview ................................................................................................................................... 6

3 Limitations ................................................................................................................................ 7

4 Connection Diagram................................................................................................................ 8

5 Console Commands and Parameters ..................................................................................... 9

5.1 conf............................................................................................................................................. 9

5.2 imsi............................................................................................................................................10

5.3 imei............................................................................................................................................10

5.4 meid...........................................................................................................................................11

5.5 esn.............................................................................................................................................11

5.6 rssi.............................................................................................................................................12

5.7 sim.............................................................................................................................................15

5.8 uim.............................................................................................................................................16

5.9 simlock.......................................................................................................................................16

5.10 bodysar....................................................................................................................................17

5.11 gps...........................................................................................................................................17

5.12 iccid.........................................................................................................................................18

6 Error Messages........................................................................................................................ 19

7 Saving Test Results................................................................................................................ 20

7.1 Setting the Log Save Path..........................................................................................................20

7.2 Setting the Log Save Mode........................................................................................................20

8 FAQ .......................................................................................................................................... 21

8.1 Why Is theAtool Not Running?...................................................................................................21

8.2 Why Do Module's Ports Fail to Be Initialized or Read/Write Operations May Fail When theAtool Is

Running?.........................................................................................................................................21

9 Acronyms and Abbreviations............................................................................................... 22

HUAWEI Module Atool User Guide

Purpose

Issue 02 (2015-01-31)

Huawei Proprietary and Confidential

1 Purpose

This document describes how to use Huawei module Atool, including the purpose of

this guide, overview of Atool, commands and parameters of Atool, examples, and

precautions.

This document enables relevant technical engineers to understand the commands of

theAtool and use the Atool to test Huawei modules.

HUAWEI Module Atool User Guide

Overview

Issue 02 (2015-01-31)

Huawei Proprietary and Confidential

2 Overview

The Atool is used to test Huawei modules. The Atool can test the product's basic

information (including the product name, IMEI, IMSI, hardware version, and software

version), and antenna connectivity. The Atool can also save test results.

You can perform operations on the Atool using console commands only.

Atool is the tool set of Atool_x86 and Atool_arm. The Atool_x86 and Atool_arm apply

to the systems using x86 and arm architectures, respectively.

HUAWEI Module Atool User Guide

Limitations

Issue 02 (2015-01-31)

Huawei Proprietary and Confidential

3 Limitations

Applicable

products:

See Release Notes of the Atool.

Operating

systems:

See Release Notes of the Atool.

Driver

version:

See Release Notes of the Atool.

Other

requirement:

Set the Atool according to its instructions to ensure proper

running of the Atool.

The driver must be the standard driver provided by Huawei.

The Atool needs to create result files when it is running. To log in

to the Atool, you must get the root right.

When the Atool is running, do not power off or hibernate the

operating system or perform operations that interfere with the

Atool.

In command lines, do not place parameters in quotation marks (')

or double quotation marks (").

The paths where the Atool is running and the log is saved must

contain English characters only.

HUAWEI Module Atool User Guide

Connection Diagram

Issue 02 (2015-01-31)

Huawei Proprietary and Confidential

4 Connection Diagram

The instrument shown in the figure is the CMU200, which can be replaced with any other

instruments that can test modules' Radio Frequency (RF).

It is recommended that the laptop be placed in a shield box during the test to avoid external

signal interference.

The test scheme applies to near-field coupling tests on module's antenna connectivity.

HUAWEI Module Atool User Guide

Console Commands and Parameters

Issue 02 (2015-01-31)

Huawei Proprietary and Confidential

5 Console Commands and Parameters

Optional parameters are presented in [] and mandatory parameters are presented in <>.

Parameters are separated by only one space character.

Parameters are case-insensitive.

5.1 conf

Command

syntax:

atool conf [-fw firmware] [-hw hardware]

Command

function:

Tests and displays product's basic information, including the

product name, software version, hardware version, IMEI/MEID

and IMSI.

Parameter

description:

-fw: Configure this parameter to check the software version of

the tested product (default value: null).

-hw: Configure this parameter to check the hardware version

of the tested product (default value: null).

Example:

Other

examples:

atool conf –fw 11.350.99.04.00

atool conf –hw ML1ME936M

HUAWEI Module Atool User Guide

Console Commands and Parameters

Issue 02 (2015-01-31)

Huawei Proprietary and Confidential

atool conf –fw 11.350.99.04.00 –hw ML1ME936M

5.2 imsi

Command

syntax:

atool imsi

Command

function:

Tests and displays the SIM card's IMSI number.

Parameter

description:

No parameter.

Example:

5.3 imei

Command

syntax:

atool imei

Command

function:

Tests and displays the product's IMEI number.

Parameter

description:

No parameter.

Example:
