HP 64793 Series Manuel utilisateur

HP 64793

H8/338/329 Emulator

Softkey Interface

User’s Guide

HP Part No. 64793-97002

Printed in U.S.A.

October 1992

Edition 1

Notice Hewlett-Packard makes no warranty of any kind with regard to

this material, including, but not limited to, the implied warranties

of merchantability and fitness for a particular purpose.

Hewlett-Packard shall not be liable for errors contained herein or for

incidental or consequential damages in connection with the furnishing,

performance, or use of this material.

Hewlett-Packard assumes no responsibility for the use or reliability of

its software on equipment that is not furnished by Hewlett-Packard.

This document contains proprietary information, which is protected by

photocopied, reproduced or translated to another language without the

prior written consent of Hewlett-Packard Company. The information

contained in this document is subject to change without notice.

UNIX is a registered trademark of AT&T.

Torx is a registered trademark of Camcar Division of Textron, Inc.

Hewlett-Packard Company

Colorado Springs Division

8245 North Union Boulevard

Colorado Springs, CO 80920, U.S.A.

Printing History New editions are complete revisions of the manual. The date on the

title page changes only when a new edition is published.

A software code may be printed before the date; this indicates the

version level of the software product at the time the manual was issued.

Many product updates and fixes do not require manual changes, and

manual corrections may be done without accompanying product

changes. Therefore, do not expect a one-to-one correspondence

between product updates and manual revisions.

Edition 1 64793-97002, October 1992

Using This Manual

This manual introduces you to the following emulators as used with the

Softkey Interface.

HP 64793A H8/338 emulator

HP 64793B H8/329 emulator

Throughout this documentation, the following names are used to

denote the microprocessors listed in the following table of supported

microprocessors.

Model Supported Microprocesorts Reffered to as

HP 64793A (H8/338 emulator) HD6473388CP

HD6433388CP

HD6413388CP

HD6473378CP

HD6433378CP

HD6413378CP

HD6433368CP

H8/338

H8/337

H8/336

HP 64793B (H8/329 emulator) HD6473298P

HD6473298C

HD6433298P

HD6413298P

HD6433288P

HD6473278P

HD6473278C

HD6433278P

HD6413278P

HD6433268P

H8/329

H8/328

H8/327

H8/326

For the most part, the H8/329 and H8/338 emulators all operate the

same way. Differences between the emulators are described where they

exist. Both the H8/329 and H8/338 emulators will be referred to as the

"H8/338 emulator". In the specific instances where H8/329 emulator

differs from H8/338 emulator, it will be described as the "H8/329

emulator".

This manual:

Shows you how to use emulation commands by executing

them on a sample program and describing their results.

Shows you how to use the emulator in-circuit (connected to a

target system).

Shows you how to configure the emulator for your

development needs. Topics include: restricting the emulator

to real-time execution, selecting a target system clock source.

This manual does not:

Show you how to use every Softkey Interface command and

option; the Softkey Interface is described in the Softkey

Interface Reference.

Organization

Chapter 1 Introduction. This chapter lists the H8/338 emulator features and

describes how they can help you in developing new hardware and

software.

Chapter 2 Getting Started. This chapter shows you how to use emulation

commands by executing them on a sample program. This chapter

describes the sample program and how to: load programs into the

emulator, map memory, display and modify memory, display registers,

step through programs, run programs, set software breakpoints, search

memory for data, and use the analyzer.

Chapter 3 In-Circuit Emulation. This chapter shows you how to plug the

emulator into a target system, and how to use the "in-circuit" emulation

features.

Chapter 4 Configuring the Emulator. You can configure the emulator to adapt

it to your specific development needs. This chapter describes the

options available when configuring the emulator and how to save and

restore particular configurations.

Chapter 5 Using the Emulator. This chapter describes emulation topics which

are not covered in the "Getting Started" chapter.

Conventions Example commands throughout the manual use the following

conventions:

bold Commands, options, and parts of command syntax.

bold italic

Commands, options, and parts of command syntax

which may be entered by pressing softkeys.

normal User specified parts of a command.

$Represents the HP-UX prompt. Commands which

follow the "$" are entered at the HP-UX prompt.

<RETURN> The carriage return key.

Contents

1 Introduction to the H8/338 Emulator

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Purpose of the H8/338 Emulator . . . . . . . . . . . . . . . . . . . 1-1

Features of the H8/338 Emulator . . . . . . . . . . . . . . . . . . . 1-3

Supported Microprocessors . . . . . . . . . . . . . . . . . . . . 1-3

Clock Speeds . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Emulation Memory . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Analysis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Single-Step . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Breakpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Reset Support . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Real-Time Execution . . . . . . . . . . . . . . . . . . . . . . . 1-5

Limitations, Restrictions . . . . . . . . . . . . . . . . . . . . . . . 1-6

Foreground Monitor . . . . . . . . . . . . . . . . . . . . . . . . 1-6

Monitor Break at Sleep/Standby Mode . . . . . . . . . . . . . . 1-6

Store Condition and Trace . . . . . . . . . . . . . . . . . . . . 1-6

Step Command and Interrupts . . . . . . . . . . . . . . . . . . 1-6

RAM Enable Bit . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

Software Performance Measurement . . . . . . . . . . . . . . . 1-6

2 Getting Started

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

A Look at the Sample Program . . . . . . . . . . . . . . . . . . 2-2

Sample Program Assembly . . . . . . . . . . . . . . . . . . . . 2-6

Linking the Sample Program . . . . . . . . . . . . . . . . . . . 2-6

Generate HP Absolute file . . . . . . . . . . . . . . . . . . . . 2-6

Entering the Softkey Interface . . . . . . . . . . . . . . . . . . . . 2-7

From the "pmon" User Interface . . . . . . . . . . . . . . . . . 2-7

From the HP-UX Shell . . . . . . . . . . . . . . . . . . . . . . 2-8

Using the Default Configuration . . . . . . . . . . . . . . . . . 2-9

On-Line Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9

Contens - 1

Softkey Driven Help . . . . . . . . . . . . . . . . . . . . . . . . 2-9

Pod Command Help . . . . . . . . . . . . . . . . . . . . . . . 2-10

Loading Absolute Files . . . . . . . . . . . . . . . . . . . . . . . 2-11

Displaying Symbols . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Global . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Local . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Displaying Memory in Mnemonic Format . . . . . . . . . . . . . 2-13

Displaying Memory with Symbols . . . . . . . . . . . . . . . . . 2-14

Running the Program . . . . . . . . . . . . . . . . . . . . . . . . 2-15

From Transfer Address . . . . . . . . . . . . . . . . . . . . . 2-15

From Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15

Displaying Memory Repetitively . . . . . . . . . . . . . . . . . . 2-16

Modifying Memory . . . . . . . . . . . . . . . . . . . . . . . . . 2-16

Breaking into the Monitor . . . . . . . . . . . . . . . . . . . . . 2-17

Using Software Breakpoints . . . . . . . . . . . . . . . . . . . . 2-17

Enabling/Disabling Software Breakpoints . . . . . . . . . . . 2-18

Setting a Software Breakpoint . . . . . . . . . . . . . . . . . 2-18

Clearing a Software Breakpoint . . . . . . . . . . . . . . . . . 2-20

Stepping Through the Program . . . . . . . . . . . . . . . . . . . 2-20

Displaying Registers . . . . . . . . . . . . . . . . . . . . . . . . 2-21

Using the Analyzer . . . . . . . . . . . . . . . . . . . . . . . . . 2-22

Specifying a Simple Trigger . . . . . . . . . . . . . . . . . . 2-22

Displaying the Trace . . . . . . . . . . . . . . . . . . . . . . 2-23

Displaying Trace with Time Count Absolute . . . . . . . . . . 2-24

Changing the Trace Depth . . . . . . . . . . . . . . . . . . . 2-25

H8/338 Analysis Status Qualifiers . . . . . . . . . . . . . . . 2-26

Trace Analysis Considerations . . . . . . . . . . . . . . . . . . . 2-27

How to Specify Trigger Condition . . . . . . . . . . . . . . . 2-27

Store Condition and Trace . . . . . . . . . . . . . . . . . . . 2-28

Triggering the Analyzer by Data . . . . . . . . . . . . . . . . 2-30

For a Complete Description . . . . . . . . . . . . . . . . . . . 2-31

Exiting the Softkey Interface . . . . . . . . . . . . . . . . . . . . 2-31

End Release System . . . . . . . . . . . . . . . . . . . . . . . 2-31

Ending to Continue Later . . . . . . . . . . . . . . . . . . . . 2-31

Ending Locked from All Windows . . . . . . . . . . . . . . . 2-31

Selecting the Measurement System Display or

Another Module . . . . . . . . . . . . . . . . . . . . . . . . . 2-32

3 Using the H8/338 Emulator In-Circuit

Installing the Target System Probe . . . . . . . . . . . . . . . . . . 3-2

Pin Guard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

2 - Contents

Pin Protector(H8/329 Only) . . . . . . . . . . . . . . . . . . . 3-3

Installing the Target System Probe . . . . . . . . . . . . . . . . 3-3

Pin State in Background . . . . . . . . . . . . . . . . . . . . . . . 3-5

Target System Interface (H8/338) . . . . . . . . . . . . . . . . . . 3-6

Target System Interface (H8/329) . . . . . . . . . . . . . . . . . . 3-8

In-Circuit Configuration Options . . . . . . . . . . . . . . . . . . 3-10

Running the Emulator from Target Reset . . . . . . . . . . . . . 3-10

4 Configuring the Emulator

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

General Emulator Configuration . . . . . . . . . . . . . . . . . . . 4-3

Micro-processor clock source? . . . . . . . . . . . . . . . . . . 4-3

Enter monitor after configuration? . . . . . . . . . . . . . . . . 4-3

Restrict to real-time runs? . . . . . . . . . . . . . . . . . . . . . 4-4

Memory Configuration . . . . . . . . . . . . . . . . . . . . . . . . 4-5

Mapping memory . . . . . . . . . . . . . . . . . . . . . . . . . 4-5

Emulator Pod Configuration . . . . . . . . . . . . . . . . . . . . . 4-7

Processor type? . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7

Processor operation mode? . . . . . . . . . . . . . . . . . . . . 4-8

Enable /NMI input from the target system? . . . . . . . . . . . . 4-9

Enable /RES input from the target system? . . . . . . . . . . . . 4-9

Reset value for stack pointer? . . . . . . . . . . . . . . . . . . . 4-9

Debug/Trace Configuration . . . . . . . . . . . . . . . . . . . . 4-10

Break processor on write to ROM? . . . . . . . . . . . . . . . 4-10

Trace background or foreground operation? . . . . . . . . . . 4-10

Simulated I/O Configuration . . . . . . . . . . . . . . . . . . . . 4-11

Interactive Measurement Configuration . . . . . . . . . . . . . . 4-11

External Analyzer Configuration . . . . . . . . . . . . . . . . . . 4-11

Saving a Configuration . . . . . . . . . . . . . . . . . . . . . . . 4-12

Loading a Configuration . . . . . . . . . . . . . . . . . . . . . . 4-12

5 Using the Emulator

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Features Available via Pod Commands . . . . . . . . . . . . . . . 5-2

Using a Command File . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Debugging C Programs . . . . . . . . . . . . . . . . . . . . . . . . 5-4

Displaying Memory with C Sources . . . . . . . . . . . . . . . 5-4

Displaying Trace with C Sources . . . . . . . . . . . . . . . . . 5-4

Stepping C Sources . . . . . . . . . . . . . . . . . . . . . . . . 5-5

Limitations, Restrictions . . . . . . . . . . . . . . . . . . . . . . . 5-5

Foreground Monitor . . . . . . . . . . . . . . . . . . . . . . . . 5-5

Contens - 3

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels HP Matériel informatique

HP Smart Array B140i Manuel utilisateur

HP 6600 FIP-20 Flex Instructions de montage

HP 64782 Manuel utilisateur

HP 64751 Manuel utilisateur

HP A1250 Series Instructions de montage

HP Nc6400 - Compaq Business Notebook Manuel utilisateur

HP Smart Array P400 Instructions d'utilisation

HP Xw6600 - Workstation - 2 GB RAM Manuel utilisateur

HP Kayak XW U3-W3 Manuel utilisateur

HP SC08Ge Manuel utilisateur

HP MPEGscope Portable Guide de l'utilisateur

HP GbE2c - Blc Layer 2/3 Fiber SFP Option Comment utiliser

HP NC550SFP Manuel utilisateur

HP HPE SimpliVity 325 Manuel utilisateur

HP Xw4600 - Workstation - 2 GB RAM Manuel utilisateur

HP Adaptive Rack Cooling System Guide de l'utilisateur

HP 273914-B21 - Smart Array 6404/256 RAID... Manuel utilisateur

HP AB479A Manuel utilisateur

HP Smart Array P400 Instructions d'utilisation

HP StorageWorks XP128 Manuel utilisateur

HP Nx9420 - Compaq Business Notebook Manuel

HP Wireless USB Network Adapter hn215w Manuel utilisateur

HP ML570 - ProLiant - G2 Manuel utilisateur

HP 8886 - Photosmart Camera Dock Digital Docking... Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
