Honeywell MN10CES Manuel utilisateur

For product inquiries or support / Para consultas del producto o soporte /

Pour les questions sur les produits ou pour du soutien:

www.honeywellportableac.com

Customer Support / Atención al cliente / Soutien au client:

1-800-474-2147

Portable Air Conditioner

Acondicionador de aire portátil

Système de climatisation portatif

OWNER’S MANUAL

Read and save these instructions before use

MANUAL DEL PROPIETARIO

Lea y guarde estas instrucciones antes de usar la unidad

MANUEL DU PROPRIÉTAIRE

Lire et conserver ces instructions avant utilisation

Model / Modelo / Modèle:

MN10CES / MN10CESWW / MN10CESBB

Made in China

Hecho en China

Fabriqué en Chine

Voltage rating / Tensión / Tension nominale: 115V~60Hz

Power rating / Potencia / Puissance nominale: 1050W

THANK YOU.....................................................................................................

INDEX .............................................................................................................. 1

USER TIPS........................................................................................................

SAFETY ............................................................................................................

PARTS DESCRIPTION.....................................................................................

INSTALLATION.................................................................................................

USE & OPERATION..........................................................................................

CLEANING & MAINTENANCE..........................................................................

TROUBLESHOOTING GUIDE...........................................................................

WATER CONDENSATION DRAINAGE............................................................

TECHNICAL SPECIFICATIONS.........................................................................

SERVICE AND WARRANTY .............................................................................

10.

11.

12.

SECTION PAGE

INDEX

Read all instructions carefully before setting up and operating the unit. Keep this

instruction manual for future reference. This manual is designed to provide important

information needed to setup, operate, maintain and troubleshoot your portable air

conditioner. Failure to follow these instructions may void the warranty.

Congratulations on your purchase of this versatile Honeywell Portable Air Conditioner.

Honeywell Portable Air Conditioners are ideal for spot cooling. The compressor, condenser

and evaporator are housed in a compact unit. The air is filtered, dehumidified and cooled while

a flexible air outlet hose sends heat outside. The air conditioner includes a window venting kit.

No permanent installation is needed. The unit is easy to move from room to room and offers a

truly flexible air conditioning solution.

Auto Evaporation System - The unit automatically evaporates the condensate through the air

outlet hose. There is no need to empty the drainage tank except in very high humidity conditions.

Read and follow the instructions carefully.

THANK YOU

USER TIPS

To ensure optimal efficiency of the product, keep doors and windows closed when it

is used as an air conditioner or dehumidifier.

If the product is being used with the fan function only, an open window could improve

air circulation.

Important : Before installing the unit, place it UPRIGHT for 20 minutes

before use to allow the refrigerant to stabilize.

• Follow installation instructions to set up the unit.

• Plug the unit into a properly grounded circuit.

Cooling and Dehumidifying Operation Fan Operation

SAFETY

WARNING

READ AND SAVE THESE INSTRUCTIONS

Improper handling can cause serious damage to the appliance.

DO NOT operate the unit with a damaged plug or loose wall outlet. If the power

cord is damaged, it must be replaced by the manufacturer or an authorized service agent.

DO NOT cover the air intake and exhaust when in use.

This appliance is not intended for use by children. Children should be supervised

and should not play on or around the appliance.

DO NOT place objects on or sit on the unit.

Always turn off and unplug the unit when cleaning or servicing.

If service is needed contact an authorized service agent.

Unplug the unit when stored or not in use.

DO NOT run the power cord under carpeting and rugs.

Use caution to prevent tripping on cord.

DO NOT use in areas where gasoline, paint or other flammable goods are stored.

Basic safety precautions should always be followed when using electrical appliances.

10.

11.

SAFETY

PARTS DESCRIPTION

1. Control Panel (Incl. Signal Receptor)

2. Air Outlet

3. Handle

4. Casters

5. Drain Plug (De-humidifier mode)

6. Air Filter

7. Back Grill

8. Drain Plug (Air Conditioning Mode)

9. Power Supply Cord

10. Exhaust Hose Connector

11. Remote Control

x 1

x 2 x 1

Installation Kit :

1. Window Bracket Kit.............................

2. Window Bracket Panel Adapter..........

3. Plastic Pin...........................................

4. Hose Connector..................................

5. Plastic Hose........................................

1 Set

1 Piece

2 Pieces

1 Piece

INSTALLATION

Install the plastic hose with window bracket adapter and hose connector on both sides.

Ensure proper fit on both ends.

Adjust the window bracket as per width or height of your window and insert the plastic

pins to fix at the desired position.

Note : Do not install the window

bracket to your window. This step is

required only to adjust it to the

size of your window. The bracket

should be removed from the window

after the size is adjusted.

Connect the plastic hose to the hose connector on the back of the unit. Push-in then rotate

clockwise.

Plastic Pin

Connect the window bracket to the opposite end of the plastic hose. Ensure that

all connections are tight and installed properly.

INSTALLATION

5Connect the window bracket to the window.

6The Portable Air Conditioner is now ready to use.

The supplied exhaust hose can be extended from 12 inches (1 foot) to 47 inches

(3.9 feet).

Do not bend (to the extent shown below) the exhaust hose.

A bent hose will block exhaust air and cause the unit to malfunction or shut-off.

The length of the exhaust hose is determined by the product specifications. Do not

replace or lengthen it as this could cause the unit to malfunction.

Make sure the back of the unit is at least 20 inches away from a wall.

Do not place the unit in front of curtains or drapes as this could obstruct the

airflow.

INSTALLATION

Note:

RECOMMENDEDNOT RECOMMENDED

Warning:

•

MIN. 14”

20”

MAX. 40”
