Honeywell CO25MM Manuel utilisateur

Portable Evaporative Air Cooler

Enfriador de Aire Portátil por Evaporación

OWNER’S MANUAL

Read and save these instructions before use

MANUAL DEL USUARIO

Lea y guarde estas instrucciones antes de usar

Model: CO25MM

Modelo: CO25MM

Power rating: 1.58A/190W

Made in P.R.C.

Fabricado en China

Customer Support : 1-800-474-2147

Centro de servicios al cliente: 1-800-474-2147

Voltage rating: 120 Volt, 60Hz

Potencia: 1.58A/190W

Voltage: 120 Volt, 60Hz

For product inquiries or support, visit www.honeywellaircoolers.com

Para consultas sobre productos o soporte técnico visite: www.honeywellaircoolers.com

Fill with water and plug into a standard

power outlet.

Place near an open door or window.

Note : Evaporative air cooler requires cross ventilation.

Turn ON and enjoy the cooling breeze.

Note: Start with LOW speed and gradually increase

to higher speed for optimum cooling performance.

Note: Please make sure the household power voltage

matches the product specifications.

QUICK START GUIDE

2. USER TIPS .................................................................................................................

3. SAFETY ......................................................................................................................

4. PARTS DESCRIPTION .........................................................................................

Control buttons ....................................................................................................

Filling with water ...................................................................................................

8. TECHNICAL SPECIFICATIONS ...........................................................................

9. ELECTRICAL WIRING DIAGRAM ........................................................................

5. USE & OPERATION ............................................................................................. 9

Control panel ....................................................................................................... 9

6. CLEANING & MAINTENANCE ............................................................................. 12

7. TROUBLESHOOTING GUIDE .............................................................................. 14

10. SERVICE AND WARRANTY ................................................................................ 17

SECTION PAGE

1. THANK YOU ............................................................................................................... 2

INDEX

Read all instructions carefully before setting up and operating the cooler, and keep this

instruction manual for future reference. This manual is designed to provide you with impor-

tant information needed to setup, operate, maintain, and troubleshoot your cooler. Failure to

follow these instructions may damage and/or impair its operation and void the warranty.

THANK YOU

Congratulations on your purchase of this versatile Honeywell Evaporative Air Cooler. For

optimum cooling from your cooler, please fill the water tank to maximum level and load ice

inside the ice compartment before you turn on your air cooler.

Cooler Location – Indoors (Important - Please Read!)

The cooler in front of an open door or window. Ensure that there is adequate cross - ventilation

in the room by leaving a door or window open opposite the cooler.

Following these guidelines will ensure your cooler will work as effectively as possible.

Not an Air Conditioner (Important - Please Read!)

The evaporative air cooler is not an air conditioner as it does not use a compressor or

refrigerant gas. It should not be expected to cool as efficiently as a refrigerated air conditioner.

USER TIPS

Pump

Water

Honeycomb Cooling Media

Evaporative Air Cooling Mechanism

Warm and

dry air

Cool and

humid air

Energy Efficient, No Compressor

Honeywell Evaporative Air Coolers are built to maximize energy efficiency and keep costs low.

Warm air is drawn into the cooler through a dust and odor-reducing carbon filter and enters the

Honeycomb Cooling Media. Water pumped from the tank pours over the Honeycomb Cooling

Media. As the warm air passes through the Honeycomb Cooling Media, the water absorbs the

heat, naturally cooling and humidifying the air. A fan propels the cooled air out into the room. This

no-compressor system cools naturally, efficiently and inexpensively.

USER TIPS

NOTE (Important - Please Read!)

When the product is used for the first time the Honeycomb Cooling Media will have an odor

which will dissipate in a few hours or so of initial use.

The recommended maximum relative humidity level is 60% or

less, which allows a noticeable temperature decrease. The

temperature decrease will be greater in drier climates

because higher evaporation occurs when the humidity is low.

The evaporative air cooler should not be used in enclosed

spaces. It must be kept level and there must be water in the

water tank. The room should have doors and windows

opened to allow free air flow. The evaporative air cooler works

best when placed near an open window, so that outside air is

drawn into the evaporative air cooler, the air circulates in the

room, then exits via the door. The maximum cooling effect is

felt when a person is in the flow of air coming out of the

evaporative air cooler.

The evaporative air cooler can also be used to humidify dry

air during cool weather. To be used for humidification the

windows and doors should be closed to allow the humidified

air to accumulate.

Indoor Use

Unit should be placed a minimum 10 inches away from any wall.

Outdoor Use

Room with open windows & door

(RECOMMENDED)

Room with closed windows & door

(NOT-RECOMMENDED)

Water Level Indicator

READ AND SAVE THESE INSTRUCTIONS:

SAFETY

120V ~ 60Hz

Shock Hazard

When using electrical appliances, basic safety precautions should always be followed:

•

Before operating the product remove it from its packaging

and check that it is in good condition.

DO NOT operate any product with a damaged cord or plug.

We recommend not using an extension cord with this appli-

ance.

DO NOT run power cord under carpeting, or cover it with rugs

or runners. Keep the cord away from areas where it may be

tripped over.

Always unplug the product before refilling the water tank.

Always unplug the appliance from the power source before

cleaning, servicing or relocating the unit.

Remove the power cord from the electrical receptacle by

grasping and pulling on the power cord plug-end only, never

pull the cord.

DO NOT use the product in areas where gasoline, paint or

other flammable goods and objects are stored.

Your cooler runs on 120 Volt, 60 Hz current. Check the

household voltage to ensure it matches the appliance's rate

specification.

When using the COOL setting, check the water tank to

ensure that it is full. Operation of this cooler on the COOL

setting with an empty tank may result in damage to the water

pump.

Floor Level

DO NOT attempt repair or adjust any electrical or mechanical

functions of the cooler, as this may void the warranty.

DO NOT cover the air inlet or outlet on the appliance as this

may cause motor damage.

DO NOT insert or allow objects to enter any ventilation or

exhaust opening as this may damage the product and could

cause an electrical shock or fire.

DO NOT operate with the Honeycomb media removed as this

will overload and damage the motor.

DO NOT let children play with this appliance, packaging or

plastic bags.

Place the unit on a level floor.

This product is not intended for use in wet or damp locations.

DO NOT use in bathrooms. Never locate the product where

it may fall into a bathtub or other water container.

Store in a dry area when not in use.

This appliance is not intended for use by persons (including

children or elderly) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless they

have been given supervision or instruction concerning use of

the appliance by a person responsiblefor their safety.

Always Always grip the side handles to move the cooler.

SAFETY

•

If the unit is damaged or it malfunctions, do not continue to

operate it. Refer to the troubleshooting section and seek

professional advice.

DO NOT leave the operating appliance unattended for any

extended period of time.

SAFETY

This appliance equipped with a GFCI plug, press the TEST button (then RESET button) every

month to assure proper operation.

Power cords have to be contained. If they must run along the ground, make sure every inch

of them is secured so they will not be tripped over.

The wiring and connections must be waterproof. Be sure the connections (to the air cooler)

never get wet. Your unit is waterproof, but everything attached to it must be waterproof, too.

Set up your unit so it cannot be tripped over or wobble loose. It must rest on a solid

support.

Warning:

To reduce the risk of fire or electric shock, do not use this appliance with any solidstate speed

control device.

Installation must be performed in accordance with the requirements of NEC and CEC by

authorized personnel only.

The source of electrical supply is to be disconnected prior to the beginning of any such servicing

or cleaning operations.

•

11 1

1 Tray for Tools

2 Side Panel

3 Control Panel

4 Horizontal Louvers

5 Water Tank

6 Water Inlet Valve

7 Casters

8 Water Level Indicator

9 Lever for Horizontal Louvers

10 Back Panel

11 Water Inlet Cover

12 Water Drain Plug

13 Rear Grill Removal Screws

PARTS DESCRIPTION
