Honeywell HM12CESWK Manuel utilisateur

Model: HM Series

www.HoneywellAirComfort.com

E-mail: [email protected]

Local Air Conditioner

User Manual

Read and save these instructions before use

•

DO NOT operate the unit with a damaged plug or loose wall

outlet. If the supply cord is damaged, it must be replaced

by the manufacturer, its service agent or similarly qualiﬁed

persons in order to avoid a hazard.

DO NOT cover the air intake and exhaust when in use.

DO NOT place objects on or sit on the unit.

Always turn off and unplug the unit when cleaning or

servicing.

DO NOT use the appliance if it is damaged.

If service is needed contact an authorized service agent.

Unplug the unit when stored or not in use.

DO NOT pull or carry the appliance by the power cord.

DO NOT pinch the power cord in the door and DO NOT pull

it along edges or sharp corners.

DO NOT run the power cord under carpeting and rugs.

Use caution to prevent tripping on cord.

DO NOT use the device in the following cases:

- Near a ﬁre source

- In areas where gasoline, paint or other ﬂammable

goods are stored

- In an area where the water can be projected

DO NOT touch the plug or the device with wet hands.

Basic safety precautions should always be followed when

using electrical appliances.

This appliance has been manufactured for use in domestic

environments and should not be used for other purposes.

SAFETY

READ AND SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS. READ CAREFULLY AND

KEEP FOR FUTURE REFERENCE. IN CASE THERE IS ANY

INCONSISTENCY OR CONFLICT BETWEEN THE ENGLISH

VERSION AND ANY OTHER LANGUAGE VERSION OF THE

CONTENT OF THIS MATERIAL, THE ENGLISH VERSION

SHALL PREVAIL.

WARNING:

SAFETY (CONTINUED)

Only use the installation kit provided to install this unit.

DO NOT attempt to extend the hose or install this unit

using other methods other than that shown in this

manual. Improper installation will void any existing

warranties.

DO NOT use an extension cord with this unit.

This appliance can be used by children aged from 8 years

and above, and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the

hazards involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by

children without supervision.

Never insert your ﬁngers or rods into the air outlet. Take

special care to warn children of these dangers.

The manufacturer is not liable for injury caused to

persons or property damage due to non-compliance

with maintenance instructions and improper use of the

appliance.

The appliance shall be installed in accordance with national

wiring regulations.

The appliance is not to be used by persons (including

children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction.

Children should be supervised to ensure that they do not

play with the appliance.

Electrical equipment and installations regulated by national

legislation must be followed.

The appliance should be transported upright or on its side.

DO NOT turn on the appliance for at least one hour before

starting it.

It is essential that the appliance is connected to an efﬁcient

earth system checked by a qualiﬁed electrician.

•

SAFETY (CONTINUED)

•

Stagnation of possible leaks of refrigerant gas in

unventilated rooms could lead to ﬁre or an explosion hazard

should the refrigerant come in contact with electric heaters,

stoves or other sources of ignition.

Use care when storing the appliance to prevent mechanical

faults.

Only persons authorized by an accredited agency certifying

their competence to handle refrigerants in compliance with

sector legislation should work on refrigerant circuits.

DO NOT use means to accelerate the defrosting process

or to clean, other than those recommended by the

manufacturer.

Flammable substances or pressurized containers (eg.

aerosol cans) should be kept a minimum of 50cms away

from heat or ﬁre.

Use only implements recommended by the manufacturer

for defrosting or cleaning.

DO NOT operate your air conditioner in a wet room such as

a bathroom or laundry room.

This appliance should be used in a room that allows for

good ventilation between the unit and any walls/furniture or

other objects. The room size should correspond to the room

area as speciﬁed for operation by the manufacturer and

the appliance should be well kept to prevent mechanical

damage.

A warning to keep ventilation openings clear of obstruction.

Do not pierce or burn the refrigerants.

Be aware that refrigerants may not contain an odor.

Do not modify this appliance in any way to avoid danger.

This marking indicates that this product should not be disposed with other household

wastes throughout the EU. To prevent possible harm to the environment or human

health from uncontrolled waste disposal, recycle it responsibly to promote the

sustainable reuse of material resources. To return your used device, please use the

return and collection systems or contact the retailer where the product was purchased.

They can take this product for environmental safe recycling.

SAFETY (CONTINUED)

All working procedure that affects safety means shall only

be carried by competent persons.

This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not

play with the appliance.

Transport of equipment containing ﬂammable refrigerants.

Compliance with the transport regulations.

Marking of equipment using signs.

Compliance with local regulations.

Disposal of equipment using ﬂammable refrigerants.

Compliance with national regulations.

Storage of equipment/appliances.

The storage of equipment should be in accordance with the

manufacturer’s instructions.

Storage of packed (unsold) equipment.

Storage package protection should be constructed such

that mechanical damage to the equipment inside the

package will not cause a leak of the refrigerant charge.

The maximum number of pieces of equipment permitted to

be stored together will be determined by local regulations.

Transportation, marking and storage for units.

•

SYMBOL NOTE EXPLANATION

WARNING

This symbol shows that this

appliance uses a ﬂammable

refrigerant. If the refrigerant

is leaked and exposed to

an external ignition source,

there is a risk of ﬁre.

CAUTION

This symbol shows that the

operation manual should be

read carefully.

CAUTION

This symbol shows that a

service personnel should be

handling this equipment with

reference to the installation

manual.

CAUTION

This symbol shows that

information is available such

as the operating manual or

installation manual.

R32/R290 SAFETY

Read the instruction carefully before using the appliance.

R32/R290 refrigerant gas complies with European

environmental directives.

This appliance contains a certain number of grams (see rating

label at the back of the unit) of R32/R290 refrigerant gas. The

maximum refrigerant charge amount is R32 0.43 kg/

R290 0.226kg.

When defrosting or cleaning, do not use any method other

than those recommended by the manufacturer.

Do not place the appliance in a room with continuous

sources of ignition (e.g. open ﬂame, operating gas

appliance or working electrical heater).

Do not pierce and do not burn.

Do not perforate any part of the refrigerant circuit.

Refrigerant gas may be odorless.

The appliance must be installed, used and stored in an area

that is greater than R290 gas: 15 m²; R32 gas: 4 m².

Accumulation of possible refrigerant leaks in an

unventilated room could lead to ﬁre or explosion should the

refrigerant come in contact with electric heaters, stoves or

other sources of ignition.

The appliance must be stored in a way to prevent

mechanical damage.

Only individuals authorized by an accredited organization

certifying their competence to handle refrigerants in

compliance with industry legislation should work on the

refrigerant circuit.

Additional warnings for appliances with R32/R290

refrigerant gas.

•

Repair must be performed based on the recommendations from

the manufacturer. Maintenance and repair that requires the

assistance of other qualiﬁed personnel must be performed under

the supervision of specialists in the use of ﬂammable refrigerants.

THANK YOU

Congratulations on your purchase of this Honeywell Local Air Conditioner.

Regarding the information pertaining to the installation, handling, servicing, cleaning and disposal

of the appliance, please refer to the below paragraph of the manual.

USER TIPS

Local Air Conditioners are ideal for spot cooling. The compressor, condenser and evaporator are

housed in a compact unit. The air is dehumidified and cooled while a flexible hose sends heat

outside. The Local Air Conditioner includes a window venting kit.

No permanent installation is needed. The unit is easy to move from room to room and offers a truly

ﬂexible air conditioning solution.

Auto Evaporation System - The unit automatically evaporates the condensate through the hose.

There is no need to empty the drainage tank except in humid conditions. Read and follow the

instructions carefully.

To ensure optimal efﬁciency of the product, keep doors and windows closed when it is used as an air

conditioner or dehumidiﬁer. If the product is being used with the fan function only, an open window

could improve air circulation.

Important:

Before installing the unit, place it UPRIGHT for 1 hour before use to allow the refrigerant to stabilize.

Air outlet automatically opens when the unit is turned on, and automatically closes when the unit is

turned off. Manually adjust the air vent located at the top of the unit to adjust the direction of air ﬂow.

Follow installation instructions to set up the unit.

Plug the unit into a properly grounded circuit. DO NOT plug into an extension cord.

•

Cooling and Dehumidifying

Operation Fan Operation

PARTS DESCRIPTION

1) Louver 8) Upper Rubber Drain Plug

(Dehumidifying Mode)

2) Control panel 9) Drain Tube

(For Continuous Drain)

3) Handle 10) Power Cord Winder

4) Casters 11) Lower Dust Filter

5) Remote Control 12) Lower Rubber Drain Plug

(Air Conditioning Mode)

6) Hose Connector 13) Storage Plug for Power Cord

7) Upper Dust Filter 14) Power Supply Cord

1 2

3EN

INSTALLATION

It is important that the installation instructions below are followed for successful installation of this

Local Air Conditioner. Please call Customer Support if you have any difﬁculties or queries

regarding these installation procedures.

Installation Kit:

Installation Steps:

Exhaust Hose Connector, Exhaust Hose and window bracket panel adapter are pre-assembled

inside the package.

1 2 3

Hose:

Length: 9.8'' to 59'' (25cm to 150cm)

x2 x1

4 6

x1 x1

1. Window Bracket Kit (1 Set) 4. Exhaust Hose (1 Piece)

2. Butterﬂy Screws (2 Piece) 5. Window Bracket Panel Adapter (1 Piece)

3. Drain Tube (Dehumidiﬁer Mode) (1 Piece) 6. Exhaust Hose Connector (1 Piece)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Honeywell Climatiseur

Honeywell

Honeywell CL25AE Manuel utilisateur

Honeywell

Honeywell HJ0CESWK7 Manuel utilisateur

Honeywell

Honeywell TC10PM Series Manuel utilisateur

Honeywell

Honeywell MN09 Series Manuel utilisateur

Honeywell

Honeywell MM14CCSBB Manuel utilisateur

Honeywell

Honeywell HF08CESWK Manuel utilisateur

Honeywell

Honeywell USHA CL50PM Manuel utilisateur

Honeywell

Honeywell CO60PM Series Manuel utilisateur

Honeywell

Honeywell HM Series Manuel utilisateur

Honeywell

Honeywell CL25AE Manuel utilisateur

Honeywell

Honeywell TC09PEU Manuel utilisateur

Honeywell

Honeywell R-MM14CCS Manuel utilisateur

Honeywell

Honeywell CL70PE Manuel utilisateur

Honeywell

Honeywell HW2CESVWW9 Manuel utilisateur

Honeywell

Honeywell CHS122AE Manuel utilisateur

Honeywell

Honeywell CL30XC Manuel utilisateur

Honeywell

Honeywell CO301PC Manuel utilisateur

Honeywell

Honeywell MP08 Series Manuel utilisateur

Honeywell

Honeywell CO25AE Manuel utilisateur

Honeywell

Honeywell CS074AEKK Manuel utilisateur

Honeywell

Honeywell CL30XC Manuel utilisateur

Honeywell

Honeywell CL60PM Series Manuel utilisateur

Honeywell

Honeywell CO60PM Series Manuel utilisateur

Honeywell

Honeywell CS10PE Manuel utilisateur

Manuels Climatiseur populaires d'autres marques

Spheros

Spheros CC 355 Manuel utilisateur

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manuel utilisateur

Panasonic

Panasonic CS-E12HKEW Manuel utilisateur

nedis

nedis ACMB1WT7 Manuel utilisateur

Samsung

Samsung AR KV Series Mode d’emploi

Daikin

Daikin FCFV50A Manuel utilisateur

Fujitsu

Fujitsu Inverter ASBA30JFC Manuel utilisateur

Toshiba

Toshiba RAS-M10SMUV-E Manuel utilisateur

Daikin

Daikin FXLQ20MAVE Manuel utilisateur

Hitachi

Hitachi RAS-E24CAK Manuel utilisateur

CIAT

CIAT Magister 2 Series Mode d’emploi

Bestron

Bestron AAC6000 Manuel utilisateur

Hisense

Hisense 7K Manuel technique

Frigidaire

Frigidaire FFRE0533S1E0 Manuel utilisateur

Samsung

Samsung AS09HM3N Manuel utilisateur

Frigidaire

Frigidaire CRA073PU11 Manuel du propriétaire

Soleus Air

Soleus Air GB-PAC-08E4 Manuel utilisateur

McQuay

McQuay MCK020A Manuel utilisateur
