HOLDEN WM II 2010 Series Guide de l'utilisateur

holden.com.au

WM Caprice Owner’s Handbook

WM Series II

CAPRICE

WM Series II CAPRICE

WM DOM_Sedan_MY11_cover 100K.pdfPage 1 7/16/2010 11:44:08 AM

GM Holden Ltd, ABN 84 006 893 232 (hereinafter Holden)

Change of name, address or ownership

In the event of a Safety Recall, or for various reasons,

Holden may need to contact you as the owner of this vehicle.

If you have recently changed your address, or name, or purchased this

vehicle second-hand, please help us to help you by taking a few minutes

to ﬁll in and mail the forms at the beginning of the Service/warranty booklet.

For information about GM Holden’s privacy policy or to update owner

details online, please visit Holden’s website at www.holden.com.au

Note Please refer to the inside front cover of the Service/

warranty booklet for the Vehicle Identiﬁcation Certiﬁcate.

Printed in Australia

Part No. 92239597

December 2010 (MY11 WM Caprice. Print 2)

Reproduction in whole or part is prohibited

without written approval from GM Holden Ltd,

ABN 84 006 893 232

MY11_WM_DOM_IFC.indd 1MY11_WM_DOM_IFC.indd 1 13/12/2010 11:05:16 AM13/12/2010 11:05:16 AM

Contents 1

Introduction .................................... 2

In brief ............................................4

Keys, doors, and windows ........... 15

Seats, restraints ........................... 32

Storage ........................................52

Instruments and controls ............. 58

Lighting ........................................ 98

Infotainment system ................... 105

Climate control ........................... 192

Driving and operating ................ 202

Vehicle care ............................... 235

Service and maintenance .......... 298

Technical data ............................ 300

Customer information ................ 307

Index .......................................... 309

WM_DOM BOOK.indb 1WM_DOM BOOK.indb 1 17/12/2010 9:40:22 AM17/12/2010 9:40:22 AM

2 Introduction

Introduction

We thank you for choosing Holden and want to

assure you of our continuing interest in your

driving pleasure and satisfaction.

This handbook applies to the current WM series II model.

Therefore, due to different models and options, you may

ﬁnd reference in this Handbook to some equipment

not ﬁtted to your own vehicle.

Please note that all information, illustrations and

speciﬁcations in this Handbook are based on the latest

production information available at the time of printing.

Holden reserves the right to make changes at any time

without notice and without incurring any obligation.

WM_DOM BOOK.indb 2WM_DOM BOOK.indb 2 17/12/2010 9:41:26 AM17/12/2010 9:41:26 AM

Introduction 3

Introduction

Your vehicle is a designed

combination of advanced technology,

safety, environmental friendliness and

economy.

This Owner’s Handbook provides

you with all the necessary

information to enable you to drive

your vehicle safely and efﬁciently.

Make sure your passengers are

aware of the possible risk of accident

and injury which may result from

improper use of the vehicle.

Using this manual

• The In brief section will give you

an initial overview.

• The table of contents at the

beginning of this manual and

within each chapter shows where

the information is located.

• The index will enable you to

search for speciﬁc information.

• Directional data, e.g. left or right,

or front or back, always relate to

the direction of travel.

• Depending on the model variant,

integrated special equipment

and accessories, the scope of

equipment of your vehicle can

differ from the descriptions in this

Owner’s Handbook.

• The Bluetooth®word mark and

logo are registered trademarks

and are owned by the Bluetooth

SIG, Inc.

• ESP®is a registered trademark

of Daimler Chrysler AG.

• iPod®is a registered trademark

of Apple Inc.

Danger, warnings

and cautions

Danger

Text marked Danger provides

information on risk of fatal injury.

Disregarding this information may

endanger life.

Warning

Text marked Warning

provides information on risk of

accident or injury. Disregarding

this information may lead to injury.

Caution

Text marked Caution provides

information on possible damage

to the vehicle. Disregarding this

information may lead to vehicle

damage.

WM_DOM BOOK.indb 3WM_DOM BOOK.indb 3 17/12/2010 9:41:26 AM17/12/2010 9:41:26 AM

4 In brief

In brief

Initial drive

information

Unlocking the vehicle

Remote keyless entry

e: Lock and arm the alarm

c: Unlock and disarm the alarm

s: Boot unlock

Keys and locks, see page 15.

Doors, see page 19.

Manual door locks

To lock, insert the key into the driver’s

door lock and turn towards the rear

of the vehicle, then turn it back to the

vertical position and remove.

This will lock all doors.

To unlock, turn the key once towards

the front of the vehicle to unlock the

driver’s door. Turn it twice towards

the front of the vehicle to unlock

all doors.

Keys and locks, see page 15.

Doors, see page 19.

WM_DOM BOOK.indb 4WM_DOM BOOK.indb 4 17/12/2010 9:41:26 AM17/12/2010 9:41:26 AM

In brief 5

Seat adjustment

The vehicle may have the following

levers and switches for seat

adjustment.

A. Lift for forwards/backwards

B. Up/down

C. Tilt

D. Recline

E. Lumbar

F. Forwards/backwards

WM_DOM BOOK.indb 5WM_DOM BOOK.indb 5 17/12/2010 9:41:26 AM17/12/2010 9:41:26 AM

6 In brief

Head restraints

Warning

The head restraint is a safety

feature. Do not use the head

restraint to rest the head upon.

The centre of the head restraint

should be at eye level, never at

neck level.

Lift the head restraint up to raise it.

Push the locking button and push

the head restraint down to lower it.

Front head restraints cannot be

removed.

Front seats, see page 33.

WM_DOM BOOK.indb 6WM_DOM BOOK.indb 6 17/12/2010 9:41:26 AM17/12/2010 9:41:26 AM

In brief 7

The vehicle may have adjustable

rear head restraints, these can be

removed.

Head restraints, see page 32.

Child restraints, see page 47.

Seat belt

Pull the metal tongue across

your body into the buckle, until it

clicks into place.

The belt should not be twisted. It

should lie ﬂat and ﬁt ﬁrmly across

your hips.

To remove, press the release button

on the buckle to allow the belt to

retract.

Three point belt, see page 39.

Mirror adjustment

Rear view mirror

The vehicle may have a manual rear

view mirror.

Push the lever (A) on the lower edge

of the mirror towards the front of the

vehicle, then adjust the position of

the mirror.

To reduce headlamp glare from

following vehicles, pull the lever (A)

towards the rear of the vehicle.

Interior mirrors, see page 26.

WM_DOM BOOK.indb 7WM_DOM BOOK.indb 7 17/12/2010 9:41:26 AM17/12/2010 9:41:26 AM

8 In brief

Automatic dimming

rear view mirror

The vehicle may have an automatic

dimming rear view mirror.

Press the switch to turn on. The

mirror will automatically switch in

and out of night view.

Interior mirrors, see page 26.

Exterior mirrors

Power mirrors

To adjust the external rear view

mirrors, turn the ignition on and use

switches (A) and (B) in the centre

console.

Exterior mirrors, see page 24.

Steering wheel

adjustment

Warning

Do not attempt to adjust the

steering wheel while driving.

1. Move the lever down to unlock.

2. Move the steering wheel up,

down, closer or away.

3. Move the lever up to lock.

4. Ensure the steering wheel is

locked in position before driving.

Controls, see page 59.

WM_DOM BOOK.indb 8WM_DOM BOOK.indb 8 17/12/2010 9:41:27 AM17/12/2010 9:41:27 AM
